Operating Instructions

Before the first commissioning read this manual thoroughly and completely and keep it in a safe

Observe and follow the safety instructions and only use the machine if you are sure that you have

Pneumatic Blind Stapler

Type/description:

Page 1 of 14

18.11.24

P:\Technik\TOP_MG_JK\Bedienungsanleitung\englisch\Operation Instructions TOP EH EN 11_2024.docx

USER GUIDE

Pneumatic Blind Stapler

TOP SP EH

Pneumatic Blind Stapler

Type TOP SP EH

IMPORTANT

completely understood all the instructions.

Failure to comply can lead to injuries!

If you have any questions, contact the manufacturer

MEZGER Heftsysteme GmbH

Saganer Straße 24

90475 Nürnberg

See label on tool

place.

Germany

Page:

Version: 11/2024

572

Table of Contents

Need help?

Do you have a question about the MG TOP SP EH Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Signode MG TOP SP EH Series

Page 1 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Operating Instructions Pneumatic Blind Stapler Type TOP SP EH IMPORTANT Before the first commissioning read this manual thoroughly and completely and keep it in a safe place. Observe and follow the safety instructions and only use the machine if you are sure that you have completely understood all the instructions.
Page 2: Table Of Contents
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Preface It is necessary to acquire the knowledge conveyed by this ORIGINAL-OPERATING INSTRUCTION for a safe operation. The information is presented in brief and clear form. The chapters are sorted by numbers.
Page 3 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Symbol Signal word Meaning Warning notice Risk of fingers being crushed! Prohibition Protect from moisture! warning notice Risk of fingers being crushed! warning notice Warning of cut and puncture hazard! Read and understand the device labels and manual.
Page 4: Warranty And Liability
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH 2 Warranty and liability Our “General Terms of Sale and Delivery” shall generally apply” These terms were made available to the operator by the time of contract award at the latest. Any warranty and liability claims in the case of personal and material damage shall be excluded, if such damage occurred as a result of: Improper use of the tool (not in compliance with intended use).
Page 5: Ambient Conditions
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH 4 Ambient conditions The machine should be operated at room temperature, protected against environmental influences. Use within an explosive atmosphere is permitted only with prior consent and written permission of the manufacturer.
Page 6: Scope/Intended Use
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Keep your work area tidy. Clutter in the work area can lead to accidents. • Only use ORIGINAL staples that have been specially manufactured for this quality device. Third- party clips can lead to malfunctions and considerable damage.
Page 7: General/Function
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Appropriate care helps to keep the stapler in a functional condition over the long term. The stapler should be thoroughly cleaned at least once a week. • No aggressive cleaning agents or solvents (damage seals) or even emery paper can be used for cleaning.
Page 8: Loading Of Staples
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Trigger Position of staple magazine for staples Staple Pusher The penetration depth of the staples is determined by the type of staple. There is no adjustment for setting the stapler. 12 Loading of Staples The staple pusher (1) is pulled back to the stop and hooked in.
Page 9: Error Detection
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Error detection Remove all staples from the stapler and clean the stapler. • Use a suitable tool to remove visible staples from the staple exit opening. Do not overload or damage the device! In difficult cases, open the magazine and pull out the staples upwards.
Page 10 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH 13.2 Removing jammed staples • Remove any staples still present in the staple repository. • •Loosen (do not remove completely) the four screws (3). • Remove all the staples from the staple magazine (4), staple ejection (5) and clean the tool from dirt and debris.
Page 11: Technical Data
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH 13.3 Driver change / Conversion to staple TOP SP 11 TOP SP 18  (s. according spare parts list) Open the 4x screws (3) and carefully pull the angle holding piece (8 with the staple magazine (21) off the front plate (22).
Page 12: Note On Residual Risks
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH For single corrugated cardboard the staple TOP SP 11 can be used with the stapler TOP SP P 11. For pneumatic staplers, we supply accessories such as balancers, spiral hoses, maintenance units, swivel arms, compressors, etc.
Page 13 USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Use caution when handling with stapling devices, especially when • loading and unloading, as items for debt collection have sharp points that could cause injury. Don't lean too far. Use only in a safe workplace. Always make sure you •...
Page 14: Technical Documentation/Service
USER GUIDE Page: Version: 11/2024 Pneumatic Blind Stapler TOP SP EH Technical Documentation/Service Repairs performed by: MEZGER Heftsysteme GmbH authorized professional companies Damages that are due in particular to natural wear and tear, overloading, improper handling or damage caused by the user or other use contrary to the operating instructions are excluded from the warranty.
