January 2025
DIY Slimline Tank Stand
Instructions for use
WHAT'S IN THE BOX?
Components:
10x Support beams
A
A
2x Carrier beams
B
B
6x Base plates
C
C
6x Base plate bolts (12mm x 120mm)
D
D
complete with nuts
E
4x Carrier beam bolts (10mm x 25mm)
complete with nuts
Required for assembly:
1. 2x 17mm spanners
2. 19mm spanner
3. Ratchet and 19mm socket
4. Spirit level
B
A
Assembled example:
C
D
E
Advertisement
Summary of Contents for Jojo DIY Slimline Tank Stand
- Page 1 January 2025 DIY Slimline Tank Stand Instructions for use WHAT’S IN THE BOX? Components: Assembled example: 10x Support beams 2x Carrier beams 6x Base plates 6x Base plate bolts (12mm x 120mm) complete with nuts 4x Carrier beam bolts (10mm x 25mm)
- Page 2 ASSEMBLY INSTRUCTIONS STEP 1 STEP 4 Position one of the carrier beams (B) with the slots Place the second carrier beam (B) underneath one of the facing upward and insert two support beams (A) into support beams (A) on the other end. the designated slots on both ends.
- Page 3 ASSEMBLY INSTRUCTIONS (continued) STEP 5 STEP 7 Move your stand to where you would like it installed. Once all the support beams are on top of the second carrier From the top screw the six base plate bolts and nuts beam (B), push the carrier beam towards the support (D) through the threaded holes on the carrier beams.
- Page 4 Surfaces such as soil and grass are not suitable. Thank you for choosing JoJo. If there is anything that you are unsure about or need assistance with, please do not hesitate to contact us.
