Safelock Systems LA GARD 702 Quick Reference

Quick Reference Commands
Keypad firmware 1.4.0.0, Lock firmware 1.4.0.2 (v1)
Default codes: Master 00-87654321 | Manager 01-123456.
IDs 02-29 for the 702 model.
Available User IDs:
Users are deleted and can be added by the Master or Manager.
The Master can manage the Manager and User(s). The Manager can manage User(s).
Hierarchy:
The Master has full administrative control, but cannot open directly.
Enter a valid ID and code. If time delay is in operation, wait for the time delay to elapse and enter
Open lock:
the code again during the open window. If dual mode is in operation, enter a second ID and code.
Function
Change code (#52)
Permission: All
Dual mode (#12)
Permission: Master
Force change (#17)
Permission: Master
Code length (#11)
Permission: Master
Add Users (#50)
Permission: Master | Manager
Reset User code (#57)
Permission: Master | Manager
Delete Users (#56)
Permission: Master | Manager
Disable/enable Users (#54)
Permission: Master | Manager
Change User privilege (#55)
Permission: Master | Manager
Delete the Master
Permission: Master
Manager Management
Permission: Master
Activate PC Link (#30)
Permission: Authorised Users
LA GARD 702
Commands
Command Auth.
Command Auth.
Command Auth.
Command Auth.
Command Auth.
Command Auth.
Command Auth.
Command Auth.
Command Auth.
To delete the Master, the process is the same as for Users but only the Master code is valid to perform the
command.
Certain functions on the lock can only be carried out using the Master code. Ensure that all relevant
settings have been edited as required before deleting the Master code.
In 702 locks supplied by Safelock Systems Ltd, a Manager is installed with ID 01. To manage the Manager,
the process is the same as for Users but only the Master code is valid to perform the command.
Command Auth.
Default codes must be changed immediately.
Setting 1 Setting 2 Enter
Opening codes should be changed and
tested with the safe or vault door open
where possible.
Setting:
Setting Enter
1 - Manager Override
2 - Dual
(Users and Manager with Users)
3 - Dual + Manager
0 - Disable dual mode
Setting Enter
Setting:
1 - Enable
0 – Disable
Setting Enter
Setting: Code length 6-9 digits
Any existing installed managers and users will need
their code to be reset.
New Setting Setting
Code 1 2
Setting 1 Setting 2 Enter
Setting 1 + 2: The current ID and new
code
Setting Enter
Setting: The ID to be deleted
Setting 1 Setting 2 Enter
Setting 1: The ID to be changed
Setting 2: 1 - Enable | 0 - Disable
Setting 1 Setting 2 Enter
Setting 1: The ID to be changed
Setting 2: Use Setting 2 of Add Users
Enter
The Master and Manager can both activate PC Link. If a User
has been assigned audit privilege, that User can also activate
PC Link.
(Users with Users)
(Users with Manager, Manager with Users)
(Default)
(6 is Default)
Setting 1:
2 - User
Enter
4 - Manager
Setting 2:
1 - Open only
2 - Audit only
3 - Open and audit
5 - Open, override time delay
7 - Open, audit, override time delay
