ENFORCER SS-075Q Owner's Manual

Emergency/Push-to-Exit
Buttons
SS-075Q / SS-075CQ / SS-075C-PEQ
Manual
Specifications
Model SS-075Q
Operating
voltage
N.O.
Contact
(Push-to-close)
Switch rating
0.5A@12VDC
Connections
Operating
humidity
Operating
-40°~167° F (-40°~75° C)
temperature
Dimensions 3"x
Overview
SS-075Q
COM
California Proposition 65 Warning: These products may contain chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
WARRANTY: This SECO LARM product is warranted against defects in material and workmanship while used in normal service for one (1) year from the date of sale to the original
-
customer.
NOTICE: The SECO-LARM policy is one of continual development and improvement. For that reason, SECO-LARM reserves the right to change specifications without notice.
SECO-LARM is also not responsible for misprints. All trademarks are the property of SECO-LARM U.S.A., Inc. or their respective owners. Copyright © 2024 SECO-LARM U.S.A., Inc.
All rights reserved.
SECO-LARM
16842 Millikan Avenue, Irvine, CA 92606
Phone: (949) 261-2999 | (800) 662-0800
SS-075CQ SS-075C-PEQ
12~24 VDC
N.O. or N.C. (Selectable)
momentary contact
1A@12VDC
Screw terminals
0~95%, non-condensing
/ "x / " (76x23x15mm)
15 5
16 8
N.O.
U.S.A., Inc.
®
 Large button has "Emergency" printed on face*
 NO or NC (selectable) momentary contact
 Contact rated 0.5A@12VDC (1.0A@12VDC for
SS-075C-PEQ)
 Screw terminals
 Off-white
Parts List
1x Button*
*SS-075C-PEQ includes 3 labels "Emergency", "Push to Exit", and
"Presione Para Salir,"
†
SS-075Q is N.O. (push-to-close) momentary contact only
Installation
Please read this manual carefully before you begin
the installation.
1. Find the appropriate location to mount the
button.
2. Run 2 wires to the mounting location from the
device you want to control.
3. Connect the 2 wires to the back of the button.
a. To either the NO/COM or NC/COM for the
SS-075CQ or SS-075C-PEQ
b. To the NO/COM for the SS-075Q
4. Mount the button.
SS-075CQ
SS-075C-PEQ
N.O.
Website: www.seco-larm.com
Email: sales@seco-larm.com
†
1x Manual
COM
N.C.
®
PITSW1
Order Part# 763-045-1%
