Thank you for choosing the CDRA series soft starter manufactured by Delixi (Hangzhou) Inverter
Co., Ltd.
As a standard appendix, the Manual should be read carefully and followed strictly before and
during use of CDRA series soft starter, in order to avoid operation errors, faults, shortened service
life or even personal injuries. Please keep the Manual properly for further inspection &
maintenance of soft starter.
The Manual contains operation steps and wiring diagrams for your reference. For any query or
special requirements of soft starter, please kindly contact our local offices or dealers, or directly
call our customer service center in the Headquarters for receiving wholehearted services.
The Manual is subject to a change without a prior notice.
Do unpacking inspection carefully as follows:
1. Check if there's product damage, part damage and falling and collision of main body during
transport.
2. Check if rated values in nameplate are consistent with your order requirements; the packaging
box contains the quality certificate, user manual and warranty card you need.
The soft starter is manufactured and packaged by the Company in strict accordance with the
quality guarantee system. For any omission of inspection, please contact us or supplier for
solution.
Preface
Preface
Warning
Do not print, spread or use the
Manual
unless
otherwise
permitted in writing. Violators
will be investigated for the legal
liabilities.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDRA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Delixi CDRA Series

  • Page 1 As a standard appendix, the Manual should be read carefully and followed strictly before and during use of CDRA series soft starter, in order to avoid operation errors, faults, shortened service life or even personal injuries. Please keep the Manual properly for further inspection &...
  • Page 2: Table Of Contents

    Contents Contents Contents………………………………………………………………………...………………….1 Chapter 1 Safe Running and Notice……………………...……………………………...……….1 1.1 Acceptance…………………………………………………………...……...………………….1 1.2 Safety Information…………………………………...……...………………………………….2 Chapter 2 Product Information…………………………………………...…….………………..3 2.1 Data and Coding Rules of Nameplate………………….………………………………………3 2.2 Technical Specification………………………….…………………………………………..….4 2.3 Model………………………………………………………………….………………………..5 2.4 Shape and Mounting Dimensions……………………………………………...……………….6 2.5 Daily Maintenance………………………………………………………..…………………….8 Chapter 3 Installation and Wiring of Soft Starter……………………………………………..10 3.1 Selection of Installation Location and Space………………………………………………….10 3.2 Wiring………………………………………………………………………………………….11 3.2.1 How it Works and Schematic Diagram for Basic Wiring……………………………...…..11...
  • Page 3: Contents

    As a new and highly advanced starting device developed based on power electronic technique, microprocessor technique and modern control theory technique, the CDRA series soft starter (hereinafter referred to as "the Product") can restrict the startup current of asynchronous motor effectively, be widely applied in heave-load equipment such as fans, water pumps, conveyors and compressors, making it the ideal alternative product for reduced-voltage starting Product, such as star/triangle conversion and self-coupling voltage reduction.
  • Page 4: Safety Information

    Chapter 1 Safe Running and Notice 1.2 Safety Information 1. Please install the Product on noncombustibles such as metal to avoid fire; Keep the Product far away from combustibles to avoid fire; Do not install the Product in places with explosive gas to avoid explosion. 2.
  • Page 5: Chapter 2 Product Information

    Data in nameplate: Take Type CDRA200T4 soft starter as example: Soft Starter Model: CDRA200T4 Rated power: 200kW Rated Frequency: 50Hz Rated Voltage: AC 380V Protection Grade: IP00 Data and model introduction of nameplate: Delixi soft starter Product design S/N Adapter motor power: Rated voltage): 380V Page 3...
  • Page 6: Technical Specification

    Chapter 2 Product Information 2.2 Technical Specification Operation control mode Keyboard/external terminal/RS485 communication Start mode Current limiting/voltage/heavy load Start/stop period Digital setting supported Start delay Digital setting supported Emergency stop Interrupt output of soft starter Starting current is lower than this value under current limiting and Limiting current heavy-load mode Operation...
  • Page 7: Model

    Chapter 2 Product Information 2.3 Model of CDRA Series Soft Starter Model of Soft Rated Rated Model of Circuit Model of Bypass Specification of Starter Power (kW) Current (A) Breaker (QF) Contactor (KM) Primary Wire CDRA011T4 CDM1-63L/32 CJ20-25 cable CDRA015T4...
  • Page 8: Shape And Mounting Dimensions

    Chapter 2 Product Information 2.4 Shape and Mounting Dimensions Shape and Mounting Dimensions of CDRA Series Soft Starter (Unit: mm) ¢d Model CDRA011T4 CDRA015T4 CDRA018T4 CDRA022T4 CDRA030T4 CDRA037T4 CDRA045T4 CDRA055T4 CDRA075T4 CDRA093T4 CDRA110T4 CDRA132T4 CDRA160T4 CDRA200T4 CDRA250T4 CDRA320T4 CDRA400T4 CDRA450T4...
  • Page 9 Chapter 2 Product Information Shape and Mounting Dimensions of CDRA-K3 Series Soft Starter (Unit: mm) ¢d Model 011-045T4 055-075T4 137.5 137.5 093-160T4 200-320T4 400-600T4 Page 7...
  • Page 10: Daily Maintenance

    Chapter 2 Product Information 2.5 Daily Maintenance (1) Daily Maintenance The Product should be given daily and regular maintenance against the adverse influences from ambient temperature, humidity, dust and vibration, to avoid reduced insulation grade and creepage distance, arc discharge or short circuit, control circuit failure, accidents, working failure or reduced service life.
  • Page 11 Chapter 2 Product Information The Product is damaged due to earthquake, fire, wind and fire disaster, abnormal voltage, other natural hazards or disaster-related factors. The Product is damaged in transport process (Note: The transport mode is designated by customer; the Company assists in handling the procedure of cargo transfer).
  • Page 12: Chapter 3 Installation And Wiring Of Soft Starter

    Installation direction: The Product must be installed vertically to ensure good cooling. Selection of installation space: The CDRA series soft starter should be reserved with sufficient cooling space when installed vertically to guarantee effective cooling; see diagram below: Do not drop any foreign matter into the Product during installation, to avoid reduced insulation grade or even short circuit.
  • Page 13: Wiring

    Chapter 3 Installation and Wiring of Soft Starter 3.2 Wiring 3.2.1 How it Works and Schematic Diagram for Basic Wiring The main circuit of CDRA soft starter is given inverse parallel connection via 6 thyristors before being given tandem connection to the stator loop on the AC motor. The soft start of motor is controlled by using the electronic switching of thyristor, changing the conduction angle of thyristor by controlling the variation of trigger angle through microprocessor, in order to change the input voltage of motor.
  • Page 14 Chapter 3 Installation and Wiring of Soft Starter Basic Wiring Diagram of CDRA Power 3-phase 380V-50Hz Equipped with circuit breaker (MCCB or ELCB) Soft starter Equipped with bypass electromagnetic contactor 3-phase asynchronous motor Page 12...
  • Page 15 Chapter 3 Installation and Wiring of Soft Starter Schematic Diagram for Basic Wiring of CDRA-K3 Soft starter Reset Output terminal of multifunction relay Emergency stop Stop Fault output terminal Running RS485 Communication terminal Keyboard Page 13 Chapter 3 Installation and Wiring of Soft Starter Basic Wiring Diagram of CDRA-K3...
  • Page 16 Power 3-phase 380V-50Hz Equipped with circuit breaker (MCCB or ELCB) Soft starter 3-phase asynchronous motor Page 14...
  • Page 17: Introduction To Cdra External Terminals

    Chapter 3 Installation and Wiring of Soft Starter Precautions of Wiring: 1. Make sure to power off before wiring. 2. Check if the Product's rated voltage is consistent with voltage grade of AC power supply. 3. Do connect the Product's input/output end reversely to avoid unexpected action, or damage of the Product and its motor.
  • Page 18: Connection And Use Of Cdra Control Terminal

    Chapter 3 Installation and Wiring of Soft Starter 3.2.3 Connection and Use of CDRA Control Terminal 1. Precautions of terminal wiring Please connect the control terminal using multi-core shielded cable or stranded wire. If shielded cable is used, the near end (the end closer to the Product) should be connected to the Product's ground terminal PE. In process of wiring, the control cable should be over 20 cm away from the main circuit and high-voltage line (including power wire, motor wire, relay wire and contactor wire), avoid parallel arrangement and be provided with vertical wiring as recommended, in order to avoid malfunction of the Product due to interference.
  • Page 19 Chapter 3 Installation and Wiring of Soft Starter Common 3-wire wiring method of external buttons is as follows: 2-wire wiring method as shown in diagram below: (7) Ground terminal 12 Please connect effective ground wire to this terminal and use multi-core cable. (8) Control power terminal 13, 14 Connect to external control power supply, AC 200v for supplying power to the control board.
  • Page 20: Chapter 4 Keyboard Operation And Running

    Chapter 4 Keyboard Operation and Running 4.1 Keyboard Operation 4.1.1 Keyboard Display, Button and Function Introduction Running status indicator Display function set value or output monitoring value 1. Move data modification position at parameter selection Read and store set data at and setting mode parameter setting mode Switch display of mean...
  • Page 21: Display Method And Operation Method

    Chapter 4 Keyboard Operation and Running 4.1.2 Display Method and Operation Method 1. Display contents The Product's keyboard display has two modes: Monitoring mode and function code mode. a) Display contents at monitoring mode: “READY”: Ready for start; “DELAY”: Delayed start; “START”: In start process;...
  • Page 22 Chapter 4 Keyboard Operation and Running Monitoring mode For example: Modify stop time parameter P002 from 2s to 5s Press MODE key once to switch to function code mode and keyboard will show the Display ready status, press MODE key to enter function code number READY function code mode...
  • Page 23: Running

    Chapter 4 Keyboard Operation and Running 4.2 Running 4.2.1 Trial Run Do trial run to see if revolving direction and transmission of motor are normal (1) Make sure all wires are connected reliably and phase of main electric wiring is correct; (2) Power on and keyboard displays "READY";...
  • Page 24: Chapter 5 Function Code Parameter

    Chapter 5 Function Code Parameter Chapter 5 Function Code Parameter 5.1 List of Function Codes Function Min. Default Name Range Introduction Code Unit Setting Initial Voltage mode P000 30%~70% voltage effective Starting modes P001 2~100S time effective P002 Parking time 0~50S 0 means free stop 0: Voltage...
  • Page 25 Chapter 5 Function Code Parameter Function Min. Default Name Range Introduction Code Unit Setting Fault relay P012 0: Normally open 1: Normally closed Set contact status control Closing 0: Running signal is effective moment P013 1: Start process multi-function 2: Bypass running relay 3: Stop process Opening...
  • Page 26: Introduction To Function Code

    Chapter 5 Function Code Parameter Function Min. Default Name Range Introduction Code Unit Setting Parameter 0: No protection Protect parameters P029 writing 1: Protection provided against modification protection Parameter 0: No action Recover default P030 initialization 1: Recovery default setting parameters latest fault...
  • Page 27 Chapter 5 Function Code Parameter Current-limiting start mode: Please refer to the introduction to current-limiting parameters of 5.2.13. Current-limiting mode applies to the scenarios with limitation on starting current. Jump and current limiting (heavy load) mode: Applies to scenarios with heavy load. Torque slope mode: Current is not limited when started at torque mode.
  • Page 28 Chapter 5 Function Code Parameter 5.2.12 P013: Closing moment of multi-function relay P014: Disconnection moment of multi-function relay P015: Closing delay of multi-function relay P016: Disconnection delay of multi-function relay Disconnection/closing moment and action delay of multi-function relay can be set flexibly by user as required. 5.2.13 P017: Current Limiting Current Set the current limit under current-limiting start mode;...
  • Page 29 Chapter 5 Function Code Parameter 5.2.16 P020: Full-scale Value of Analog Output P021: Select analog output Port FM-GND means output of analog quantity with output range of P021=0: 4~20mA, P021=1: 0~20mA. The analog output current is in linear relationship with the actual output current of the Product. The Product's output current corresponding to analog output 20mA is determined by P020.
  • Page 30: Chapter 6 Troubleshooting

    Chapter 6 Troubleshooting Chapter 6 Troubleshooting With complete protection functions, the Product will shut down and display the fault codes if meeting any fault, and it will not be restarted (auto start is supported if restart function is enabled) unless the fault status is relieved via STOP key or external control RET.
  • Page 31 Chapter 6 Troubleshooting Secondary Connection Diagram for CDRA Series Soft Starter Page 29...
  • Page 32 Chapter 6 Troubleshooting Secondary Wiring Diagram for CDRA-K3 Series Soft Starter Page 30...
  • Page 33: Attached Table 1

    Attached Table 1 Attached Table 1 Application scenarios Start Mode Value Setting Machine Type Load Type Start Time Heavy Voltage Current Voltage Current Load Standard Centrifugal pump load Heavy load Compressor Standard (pistol) load Compressor Standard (centrifugal) load Standard Conveyor load Standard Mixer...
  • Page 34: Appendix 1: Modbus Communication Protocol

    Appendix 1 Appendix 1: MODBUS Communication Protocol The CDRA series soft starter is equipped with RS-485 communication interfaces 1. Definition of MODBUS communication code: ASCII mode: 8-Bit data consist of two ASCII character sets; for example, one 1-Bit data 64H (hexadecimal) are expressed by ASCII“64”, including 6 (36H) and 4 “34H”.
  • Page 35 Appendix 1 6) END: END character is “CR”0DH, “LF”0AH Format of standard MODBUS RTU communication: …DATA DATA ( ) 1) STX: Start unit, the static period over 10MS. 2) A: Address of slave (soft starter). 3) K: Function of data packet. 03H: Read the contents from one or more registers.
  • Page 36 Appendix 1 LRC calibration of this case: Secondary supplementation of 01H+06H+00H+12H+00H+6EH=82H is 79H RTU mode: CRC calculation method 1. Preset one 16-bit register as hexadecimal FFFF (all of them is 1); this register is called CRC register; 2. Apply exclusive OR to the lower 8 bits of one 8-bit binary data (the first byte of communication frame) and 16-bit CRC register and put the result into CRC register;...
  • Page 37 Appendix 1 Introduction to parameter function: CMD: Function command 03H: Read the contents of one register For example: Read current-limiting current P017 Command information: RTU mode: Address of Soft Starter Data Address Data Number CRC Calibration Response: Address of Soft Starter Data Number Data Contents CRC Calibration...
  • Page 38 Appendix 1 ASCII mode: Start Bit Address of Soft Starter Data Address Data Number LRC Calibration Ending Character Response: Start Bit Address of Soft Starter Data Number Data Contents LRC Calibration Ending Character 06H: Write one character For example: Write motor overload protection parameter P018 Page 36...
  • Page 39 Appendix 1 Command information: RTU mode: Address of Soft Starter Data Address Data Contents CRC Calibration Response: Address of Soft Starter Data Address Data Contents CRC Calibration ASCII mode: Start Bit Address of Soft Starter Data Address Data Contents LRC Calibration Ending Character Page 37...
  • Page 40 Appendix 1 Response: Start Bit Address of Soft Starter Data Address Data Contents LRC Calibration Ending Character Page 38...
