Digital BBQ Grill Thermometer
with Infrared and Probe Sensors
SET UP GUIDE
MODEL: M71800

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M71800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Backyard Creations M71800

  • Page 1 Digital BBQ Grill Thermometer with Infrared and Probe Sensors SET UP GUIDE MODEL: M71800...
  • Page 2 LCD Display Buttons Grill Thermometer Hanging Hole Magnets on the side Infrared Sensor and Laser Belt Probe Battery Clip Sensor Cover Buttons Hold to Turn Hold to freeze the Hold to scan and allow Thermometer Probe Temperature the Infrared Temperature ON or OFF Reading on the display Reading to change...

  • Page 3: Temperature Probe

    Power Up 1. Remove the Battery Cover screw using a screwdriver. Pull up firmly to open. 2. Insert 1-AAA alkaline battery (not included) according to polarity markings. 3. Use the °F/°C Switch to select your desired Temperature Display. 4. Replace the Battery Cover using the screw to secure it in place. Note: The Grill Thermometer is water-resistant and has a gasket around the battery cover that may make it difficult to remove easily.
  • Page 4 Point the IR Laser at your target and press and release the Button to freeze the temperature reading. The Icon will show. Note: The thermometer will shut off automatically when the temperature is reading less than 122°F (50°C) and no buttons have been pressed for 2 minutes.

  • Page 5: Specifications & Dimensions

    Specifications / Dimensions Power: 1-AAA, Alkaline battery, (Not Included) Display: LCD with Backlight Water-Resistance: IPX5 Dimensions: 6.36 in L x 1.23 in W x 1.57 in H (16.15 cm L x 3.12 cm W x 4.00 cm H) Probe Sensor: 3.71 in L (9.42 cm L) Range: -58ºF to 572ºF (-50ºC to 300ºC) Fast Read: 3 seconds Infrared Sensor Range: 32ºF to 932ºF (0ºC to + 500ºC)

  • Page 6: We're Here To Help

    We’re Here to Help SCAN HERE If you require additional assistance, get in touch with our friendly customer support team based in La Crosse, WI. Self Help: bit.ly/m71800_support Online: bit.ly/contact_techsupport Phone: 1.608.782.1610 Our knowledgable customer support team is available: Mon-Fri 8am-6pm CST Stay in Touch! Ask questions, watch set up videos, and provide feedback on our social media outlets.

  • Page 7: Care And Maintenance

    Care & Maintenance When batteries of different brand or type are used together, or new and old batteries are used together, some batteries may be over-discharged due to a difference of voltage or capacity. This can result in venting, leakage, and rupture and may cause personal injury.

  • Page 8: Fcc Statement

    FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
