- Page 1 MB32 ENERGIZER MANUAL ELECTRIC FENCE ENERGIZER WIFI REMOTE APP ENABLED POWERFUL YET SAFE* PLUG N PLAY - EASY SETUP...
-
Page 2: Table Of Contents
MB32 Features . . . . . . . . . . . . . . . . . . . - Page 3 MB32 ENERGIZER MANUAL 6 .4 Battery Alarm Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 6 .5...
-
Page 4: Introduction
INTRODUCTION Congratulations on your choice of an MB32 energizer . In choosing to purchase a Strainrite product you have opted for the highest quality in electric fencing . Please read this manual entirely before installing or operating your new energizer . - Page 5 . It is also remote ready and can be controlled using a remote control . The MB32 is designed to meet or exceed the requirements of IEC60335 .2 . 7 6 . Note: Your MB32 energizer may have a wire link connecting the ground and ground-reference terminals together.
-
Page 6: Important Notes
(eg . 1 .8m Galvanized earth rods) driven into the earth to a depth of at least 1 .2m . Three earthing rods are recommended for customers purchasing the MB32 . Additional earth connections may be required at the energizer or along the fence in poor soil conditions . -
Page 7: Power Supply Options
MB32 ENERGIZER MANUAL 2 .3 POWER SUPPLY OPTIONS The MB32 electric fence energizer can be powered from a number of power sources . a . 12V external battery (not supplied) b . 12V external battery with solar panel (not supplied) c . -
Page 8: Mb32 Features
MB32 FEATURES 3 .1 FEATURES Virtual Keypad via your Wi-Fi enabled device (smart phone, laptop etc . ) Distant Fault Detection (DFD™) technology High powered (up to 46 Joules stored) Mains or 12V Battery powered (mains via optional 24V plug pack) ... - Page 9 . The MB32 energizer seals the electronics inside a durable UV Stable • case to protect from ants, moisture and dust to maximise reliability .
-
Page 10: Specifications
3 .2 SPECIFICATIONS Specifications Output Stored Minimum Solar Panel Solar Peak Power 12V drain Voltage Energy Size Battery Output 24Vdc (Powerpack) 1 . 9 A @ 24Vdc 9 .5kV 350W (6hrs Sun) 450Ah 12Vdc 3 .5A @ 12Vdc (battery) No load, actual voltage on a short fence can be as high as 10kV . The energizer can also be powered with 110v/240Vac by using the external power pack supplied with the energizer . -
Page 11: Virtual Keypad
3 .3 VIRTUAL KEYPAD To connect to the VKP, scan for Wi-Fi networks within 15 meters of the MB32 energizer . Connect to the “IPE_xxxxxx” where “xxxxxx” is the serial number (found on the back of the device) . For example “IPE_500123” . - Page 12 Virtual Keypad (VKP) - Home Screen MB32 Displays the fence Feed 10.5 kV Turn on the energizer voltage in kV Displays the stored Energy energy in joules Disarm Turn off the energizer Displays triggered Alarm alarms Clear Clear alarms/warnings Warnings...
- Page 13 MB32 ENERGIZER MANUAL Virtual Keypad (VKP) - Device Settings Device Settings Fence Voltage Target voltage for energizer output Max Joules Joules Limit the energizer’s maximum stored Joules Pulse Time Time between fence pulses The Alarm settings are for the Energizer and Cloud Router .
- Page 14 Virtual Keypad (VKP) - Wi-Fi Settings 2.4GHz NETWORK ONLY . This Wi-Fi module is only compatible with 2 .4GHz networks . Hint: If you have a dual band Wi-Fi network, please disable 5GHz or create a 2 .4GHz only Wi-Fi Settings separate network .
-
Page 15: Fence Line Communications
MB32 ENERGIZER MANUAL 3 .4 FENCE LINE COMMUNICATIONS (FLC) 3 .4 .1 What is FLC? FLC is a proprietary protocol designed and developed by Pakton Technologies . This protocol allows communication between enabled devices on the same electric fence system . - Page 16 Strainrite has everything you need to get your fence operational . from lead out and underground cable, insulators, insulated wire strainers and earth stakes . Visit www .strainrite .co .nz to see the full range or contact us page . Page 16...
- Page 17 MB32 ENERGIZER MANUAL NOTES Page 17...
-
Page 18: Installation
2 . Design and build the fence . (Beyond the scope of this guide) 3 . Decide where the MB32 energizer is to be mounted . If on an external wall it should be housed within an equipment box and not in direct sunlight . -
Page 19: High Voltage Fence Terminals
MB32 ENERGIZER MANUAL 4 .2 HIGH VOLTAGE FENCE TERMINALS Model Ground Return 1 Return 2 MB32 Fence Ground Fence N/C Return (optional) (optional) Page 19... -
Page 20: Operation
• Removing power If the MB32 is configured with two different ways to control it, then the most recent method used will have control . For example, if the MB32 is armed via the Virtual Keypad and then disarmed at the side switch it will disarm . -
Page 21: Benefits Of Electric Fences
MB32 ENERGIZER MANUAL On touching the earth terminal on the energizer or the earth spikes in the ground, no shock should be felt . If a shock is felt on either of the above, it is an indication that the earthing is insufficient . To overcome this problem, extra earth spikes need to be added to the system . -
Page 22: Ground Return Setup
5 .4 EARTH RETURN SETUP The Earth Return (also called Ground Return) configuration is the most common method for electric fences, particularly smaller fence applications like “strip grazing”, due to its lower cost and ease of setting up . The fence live wire(s) are electrified and rely on the dirt to complete the circuit back to the energizer Earth terminal when an animal touches the fence . -
Page 23: Fence Return Setup
MB32 ENERGIZER MANUAL 5 .5 FENCE RETURN SETUP The Fence Return configuration for electric fences is used where the soil could be too dry to complete the circuit, or the animals are likely to try to force their way through between the fence wires . In this system earth wire(s) are also run along the fence with the live wire(s) to provide a low resistance path for the current to return to the energizer . -
Page 24: Earthing Your Energizer
5 .6 EARTHING YOUR ENERGIZER The best way to earth your energizer is using a 1 meter galvanized earth stakes . If the earth stake is too rusty it may not work properly . The best place to locate the earth stake is somewhere close to where the fence starts and that is kept damp like a garden bed, a water course, or the overflow from a rain water tank . -
Page 25: Low Voltage Terminals
MB32 ENERGIZER MANUAL 1 . Check the fence voltage using an electric fence volt meter . The fault finder will also detect faults and direct you towards them . 2 . Keep vegetation away from the fence . If it touches the fence it will reduce its performance . - Page 26 MAINS AND RECHARGEABLE BATTERY: SOLAR POWERED: Page 26...
-
Page 27: Surge Protection
MB32 ENERGIZER MANUAL SURGE PROTECTION: Note: Do not connect LV GND to the fence earth rod . It may be connected to a cabinet earth 5 .11 ARMING SWITCH When arming or disarming the energizer you can use the switch on the side of the enclosure . -
Page 28: Configuration Options In Detail
CONFIGURATION OPTIONS IN DETAIL 6 .1 GROUP ID A keypad bus group must have only 1 master . The other Energizers/ Monitors in the group are slaves . If the group contains Z series energizers and monitors, then an energizer should be the master . -
Page 29: Battery Alarm Voltage
MB32 ENERGIZER MANUAL 6 .4 BATTERY ALARM VOLTAGE This option sets the battery voltage threshold below which the general alarm will activate . This alarm can be set to activate one of the relays and is part of the General alarm . -
Page 30: Current Alarm Level
Range 0kV to 7.0kV. Default 4.0kV Virtual Keypad: Enter the Configuration page and alter the Voltage Alarm 1 value . Click Save Settings. 6 .7 CURRENT ALARM LEVEL Sets the alarm threshold for a Fence Short alarm . If the feed current on Zone 1 rises above this level for more than the Fence Alarm Delay (Pulse count) a fence alarm will occur . -
Page 31: Fence Alarm Delay (Pulse Count)
. Click Save Settings. 6 .10 DFD™ DFD™ enables the MB32 to detect a fault at the end of very long fences . Instead of only measuring the peak current the MB32 with DFD™ calculates the “real” current and rejects the “reactive” current . -
Page 32: Siren On Time
6 .11 SIREN ON TIME This option sets the duration of time that the siren will remain on after a fence alarm occurs . After this time the siren will turn off for the Siren Off Time indicated in the table . The siren will sound again if the alarm is still present after this off time has passed . -
Page 33: Siren Cycles
MB32 ENERGIZER MANUAL 6 .13 SIREN CYCLES This option sets the maximum number of times the siren will sound for the “on time” if the alarm continues . This may be limited by local regulations to stop an alarm causing undue disturbance to neighbours etc . -
Page 34: Device Troubleshooting
DEVICE TROUBLESHOOTING 7 .1 STATUS AND ERROR LEDS The status LEDs on the PCB allow the user to quickly check the status of the unit and if any action needs to be taken . Name Description Flashes Wi-Fi status: Once for station mode, twice for Wi-Fi Wi-Fi connected Fire 1... -
Page 35: Arming Switch
MB32 ENERGIZER MANUAL Status LED Meaning Corrective Action Flashes Replace the LID, or Fit J12 inhibit Tamper Alarm tamper Restore power, check the main power 24Vdc power fail fuse Low battery, bad Charge or replace battery, check the battery battery fuse... -
Page 36: Moisture And Ants
(See Errors and Error Codes) on the LED and LCD displays . 7 .2 MOISTURE AND ANTS Moisture and Ants should not be a significant problem for the MB32 as it comes in a weatherproof case . Still, where possible, keep the energizer protected from the weather . -
Page 37: Common Fence Problems
MB32 ENERGIZER MANUAL COMMON FENCE PROBLEMS The most common problem with electric fences is low voltage on the live wires caused by • Insufficient ‘earth’ • Shorts on the fence For tips on fence construction please see an Electric Fencing Manual . -
Page 38: Australian Standards Requirements - As60335.2.76
AUSTRALIAN STANDARDS REQUIREMENTS - AS60335.2.76 Instructions for installation and connection of electric fences in Australia, as required under AS60335 .2 . 7 6 This material is copyright of the International Electrical Commission (IEC) . 9 .1 DEFINITIONS Connecting lead an electric conductor, used to connect the energizer to the electric fence or the earth electrode Electric animal an electric fence used to contain animals within or ex-... - Page 39 MB32 ENERGIZER MANUAL 5 . 1 The size of the warning sign shall be at least 100 mm x 200 mm . 5 .2 The background colour of both sides of the warning sign shall be yellow . The inscription on the sign shall be black and shall be either: a .
- Page 40 10 . Connecting leads and electric animal fence wires shall not cross above overhead power or communication lines . 11 . Crossings with overhead power lines shall be avoided wherever possible . If such a crossing cannot be avoided, it shall be made underneath the power line and as nearly as possible at right angles to it .
-
Page 41: Particular Requirements For Electric Animal Fences In Australia
MB32 ENERGIZER MANUAL 9 .3 PARTICULAR REQUIREMENTS FOR ELECTRIC ANIMAL FENCES IN AUSTRALIA 1 . A distance of at least 10 m shall be maintained between the energizer earth electrode and any other earthing system connected parts such as the power supply system protective earth or the telecommunication system earth . -
Page 42: Warranty
.strainrite . c o .nz for more information Email visit www .strainrite . c o .nz and fill in the contact form . For more information on our complete range of electric fencing products please see the website: www .strainrite . c o .nz... - Page 43 MB32 ENERGIZER MANUAL 11 NOTES Page 43...
- Page 44 ELECTRIC FENCE ENERGIZER WIFI REMOTE APP ENABLED POWERFUL YET SAFE* PLUG N PLAY - EASY SETUP SPK00288...
