Welding Parasol- SKU 22RP02 (Blue), 22RP03 (Red)
G –Base Ring Knob
1.
Open fill cap (H) on base top, and fill sand into base then close the fill cap.
2.
Insert the lower pole (F) to base ring knob (G) (packed with base separately), then tighten the knob.
3.
Open the parasol (A), push tilt button (C) to get upper pole tilt when necessary.
4.
Insert the upper pole (D) to lower pole (F), adjust proper height and tighten with pole knob (E)..
5.
Before push the release button (B) to close the parasol, the tilt button (C) must be pushed again to recover the upper pole (D)
to upright position.
WARNINGS
TO AVOID SERIOUS INJURY AND ELECTRICAL SHOCK HAZARD. PLEASE
READ BELOW INFORMATION:
- FILL IN SAND IN THE BASE TO KEEP BALANCE.
- WELDING IN WET AREA CAN CAUSE ELECTRICALSHOCK.
- DO NOT USE IT AS PROTECTION FROM RAIN.
- DO NOT USE THIS PRODUCT IN STRONG WIND . TIP OVER HAZARD.
- WATCH YOUR HANDS WHEN OPEN AND CLOSE THE PARASOL.
- KEEP BYSTANDER AWAY WHEN OPERATE THE PARASOL.
Operation Instruction
A –Parasol
B –Release Button
C–Tilt Button
D –Upper Pole
E–Pole Knob
F –Lower Pole
G –Base Ring Knob
H –Fill Cap
I –Base Handle
Advertisement
Summary of Contents for Westward 22RP02
- Page 1 Operation Instruction Welding Parasol- SKU 22RP02 (Blue), 22RP03 (Red) A –Parasol B –Release Button C–Tilt Button D –Upper Pole E–Pole Knob F –Lower Pole G –Base Ring Knob G –Base Ring Knob H –Fill Cap I –Base Handle Open fill cap (H) on base top, and fill sand into base then close the fill cap.
- Page 2 Instrucción de la operación Soldadura Parasol-SKU 22RP02 (azul), 22RP03 (rojo) A –Parasol B –Botón de liberación C–Botón de inclinación D –Polo superior E–Perilla de polo F –polo inferior G –Perilla de la base del anillo G –Perilla de la base del anillo H –Tapa de llenado...
- Page 3 Instruction d'opération Soudure Parasol-SKU 22RP02 (bleu), 22RP03 (rouge) A –Parasol B –Bouton de dégagement C–Tilt Button D –pôle supérieur E–Bouton de pole F –Basse pole G –Base du Knob G –Base du Knob de Anneau de Anneau H –Remplissez Cap I –Handle de la Base...
