Summary of Contents for Mobibooth Cruise M Series
- Page 1 Quick Start Guide Mobibooth Cruise M Version Date Author Comments 9-19-24 Initial release...
-
Page 2: Table Of Contents
Table of Contents Supported Devices ..................4 Introduction ..................... 5 What’s in the Box ..................... 5 Unpack and inspect the Cruise M roamer ..........6 Operator Controls ..................7 Getting Started ....................9 Install camera Zoomer ................. 9 Installation of iPad ..................10 1. - Page 3 2. Log into your account ................20 3. Select your event ..................21 4. Select accessories ................. 21 5. Select your Mobibooth controller ............21 6. Device type selection (not required) ............. 22 7. Editing animations ................. 22 Connecting the Camera to Snappic ............. 23 1.
-
Page 4: Supported Devices
Supported Devices iPad Models iPad Air 11 2024 iPad Pro 11 2024 DSLR Camera Models Canon M50 Canon M50 Mark II Canon R50 Canon R100 Version 1 Last modified September 18, 2024 Page... -
Page 5: Introduction
They’ve been purposefully built with ease of use and ergonomic comfort in mind. The Mobibooth Cruise M can operate in two unique modes that include a decoupled manual mode, where the operator triggers the white light during photo taking, and fully automatic mode where the app can change the lights throughout the photo session automatically. -
Page 6: Unpack And Inspect The Cruise M Roamer
If you discover shipping damage upon inspection: Immediately notify the shipping company and file a damage report. Mobibooth, LLC is not responsible for any damage to the roamer incurred during shipment, and will not cover the repair of this damage under its warranty policy. -
Page 7: Operator Controls
Operator Controls Manual White Light Button - used to manually switch all LEDs to white. Handle - used for holding the roamer. Version 1 Last modified September 18, 2024 Page... - Page 8 5VDC Input Plug - supplies power to the LEDs. Manual Pattern Select Button - selects between 13 preprogrammed pattern/color combinations. Apple AV Hub- used to connect iPad power cable directly to the iPad charge port. Camera Communication Cable- used to connect camera directly to the iPad charge port.
-
Page 9: Getting Started
Getting Started This section outlines the steps required to set up the Cruise M roamer for the first-time use. Install camera Zoomer Install camera Zoomer by pushing down over lens housing. *Canon M50 requires removal of lens housing first and slides over from the rear. -
Page 10: Installation Of Ipad
Installation of iPad In this section we will discuss preparing the iPad for installation and installing it with charging. 1. Locate metal plates Locate the two metal plates shipped with your Cruise M roamer. Version 1 Last modified September 18, 2024 Page... -
Page 11: Metal Plate Installation
2. Metal plate installation Peel the paper back off one metal plate and attach it to the center of the iPad. The Apple logo is a great reference. Version 1 Last modified September 18, 2024 Page... -
Page 12: Remove Faceplate
Peel the paper back off the second metal plate and attach it to the previously placed metal plate making a stack of two. 4. Remove faceplate Remove the Cruise M roamer faceplate. It is recommended that you firmly grip the faceplate through the iPad opening and the outside and lift... -
Page 13: Install Ipad
Plug the iPad charge cable into the iPad. 6. Install iPad Place the iPad into the Cruise M roamer. There are magnets that will secure the iPad using the newly attached metal plates. Version 1 Last modified September 18, 2024 Page... -
Page 14: Install The Faceplate
Firmly seat iPad into iPad housing. 7. Install the faceplate Version 1 Last modified September 18, 2024 Page... - Page 15 Place the faceplate back on the Cruise M roamer. It will snap into place. Version 1 Last modified September 18, 2024 Page...
-
Page 16: Installation Of Camera
Installation of Camera This section covers how to install the supported Canon M50 and R100 cameras to the Cruise M roamer. 1. Mount camera to the roamer Insert supplied bolt and washer into camera tripod mount. Turn a few times to secure. Slide camera with bolt and washer into groove of... -
Page 17: Plug In Camera Cable
2. Plug in camera cable Plug the USB-C cable into the camera. *Micro USB for Canon M50 3. Insert memory card Open camera battery tray and insert memory card. Version 1 Last modified September 18, 2024 Page... -
Page 18: Insert Camera Battery
4. Insert camera battery Insert camera battery. It will click into place. 5. Close & lock battery tray Close battery tray and lock closed. Version 1 Last modified September 18, 2024 Page... -
Page 19: Powering The Unit
Powering the Unit Recommended Battery Pack Imuto 27000mAh Power Bank USB Battery Pack is the recommended battery pack for use with the Mobibooth Cruise M. With this unit it is possible to run as long as 8 hours between charges. Version 1... -
Page 20: Bluetooth App Connectivity
Bluetooth App Connectivity As an owner of a Mobibooth photo kiosk, you have access to 10% off on any new Snappic subscription. To take advantage of Mobibooth exclusive savings go to https://mobibooth.co/getsnappic. In this section, we will demonstrate how to connect the Mobibooth RGBW Bluetooth®... -
Page 21: Select Your Event
Select the event to use by tapping it in the events list. 4. Select accessories Tap Select Accessories on the screen. This will bring up a list of all available Bluetooth devices. Your Mobibooth will start with MOBIBLE_. 5. Select your Mobibooth controller Version 1 Last modified September 18, 2024 Page... -
Page 22: Device Type Selection (Not Required)
In the pop-up locate the Mobibooth Ring Light section. Pair with your Mobibooth tap the device listed there. 6. Device type selection (not required) It is no longer required that you specify a device type as the firmware in the hardware knows this. -
Page 23: Connecting The Camera To Snappic
If you do not already have an account with Snappic you will need to create one at www.mobibooth.co/getsnappic and save doing so as a Mobibooth customer. 1. Open Snappic app Open the Snappic by tapping the app icon on the iPad’s screen. -
Page 24: Log Into Your Account
2. Log into your account Log into the app using your Snappic credentials. If you have not created an account, you can do so at https://events.getsnappic.com. Once you have logged into the app it will remember your account credentials and automatically log you in upon launch. 3. - Page 25 Select the camera and iPad camera to use from the list presented in the dialog box. Note: Canon M50 was used in demonstration. If using another camera Snappic will show that camera. Version 1 Last modified September 18, 2024 Page...
-
Page 26: Start Event
6. Start event Tap the start event button to begin using the app. For detailed software instructions refer to Snappic’s documentation at https://help.getsnappic.com. Version 1 Last modified September 18, 2024 Page... -
Page 27: Troubleshooting
Trouble Shooting If you have connectivity issues try the following steps. 1. Power down the camera. 2. Unplug the USB cable from the camera. 3. Close the Snappic app on the iPad completely. 4. Reseat the USB-C cable to the iPad in the head. 5.
