Denkmeier Optical, Inc.
100 Pinehurst Road Berlin, MD 21811 Voice : (410) 208-6014 Fax: (410) 208-6505
Denk II & Standard Universal Power x Switch Packages™
This manual contains instructions for using either The Denk II or Standard Universal Power x
Switch System with Refractors, Newtonians, SCTs and other telescope designs (ex. Mak-Newts,
Maksutovs and other "sub-groups"). All Universal Power x Switch Packages include the optical
accessories that will allow your Denk Binoviewer to reach focus at several magnifications in the
majority of telescopes currently available. Instructions for using the Self Centering Diopter
Holders (SCD Holders) as well as cleaning the prisms of your binoviewer, other optical
components, and the mechanical parts of the system are also provided. Specifications and other
information that is covered can be found in the table of contents.
Depending upon which system you have purchased, please refer to the section covering "The
Denkmeier Standard Universal Power x Switch Package" or "The Denk II Universal Power x
Switch Package" before using your Denk Binoviewer System. Instructions for Standard and Denk
II Systems cover use in Refractors, SCTs (Schmidt Cassegrain Telescopes), or Newtonian
Telescopes. Other telescopes that are to be used in the same manner will be listed within the
section of each of the three major designs with which they share operational instructions.
Descriptions of some available optional accessories and their use are found in the "Accessories"
section. Visit
http://denkmeier.com
for an up-to-date listing.
Warranty and Return Policy
All Denkmeier Optical products are guaranteed to be free from mechanical and optical defects.
Our warranty extends for one year following customer receipt of all merchandise. Denkmeier
Optical, Inc. will repair or replace any product and will collimate the binoviewer within that time
period if alignment problems are suspected to have occurred, free of charge. The warranty is
transferable during the first year to a third party and shall be valid if accompanied by a copy of
the original dated invoice. All items may be returned for a full refund within 30 days of receipt of
the product. The returned items must be free from damage and in original condition. Original
shipping costs are not refundable.
Technical assistance is available. Call us at 866-340-4578 10:00 AM – 500 PM EST.
No part of this manual may be reprinted without expressed written permission from
Denkmeier Optical, Inc.
©2004 Denkmeier Optical, Inc.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Denk II and is the answer not in the manual?

Questions and answers

Summary of Contents for Denkmeier Denk II

  • Page 1 100 Pinehurst Road Berlin, MD 21811 Voice : (410) 208-6014 Fax: (410) 208-6505 Denk II & Standard Universal Power x Switch Packages™ This manual contains instructions for using either The Denk II or Standard Universal Power x Switch System with Refractors, Newtonians, SCTs and other telescope designs (ex. Mak-Newts, Maksutovs and other “sub-groups”).
  • Page 2 Denkmeier Optical, Inc. 100 Pinehurst Road Berlin, MD 21811 Voice : (410) 208-6014 Fax: (410) 208-6505 Table Of Contents Page 1: Denk II Universal Power x Switch Package Introduction & Warranty Page 2: Table Of Contents Page 3: SCD Holders Page 4-5: The Denk II Dual Arm Power x Switch™...
  • Page 3 SCD Holder, otherwise eyepieces with longer barrels may prevent the diopter from being lowered below that point during use. This step is unnecessary when using Denkmeier Brand Eyepieces because our eyepieces have been designed for a perfect fit when used with any Denkemeier Binoviewer Holder.
  • Page 4 “SCT Use”. Using The Power x Switch Arms When using the Dual Arm Power x Switch included with all Denk II Power x Switch Packages, there are three possible positions that the arms can be in: 1. Logo-Side Arm “IN” (figure 1) 2.
  • Page 5 The Power x Switch will create different magnifications depending on telescope used. Please see instructions for a particular telescope design to determine what those factors are. Universal Denk II Power x Switch Package : Newtonians Related Telescopes: Follow the Newtonian instructions when using Maksutov-Newtonians or any other reflector where a star diagonal is not used.
  • Page 6 Denkmeier Optical, Inc. 100 Pinehurst Road Berlin, MD 21811 Voice : (410) 208-6014 Fax: (410) 208-6505 Newtonian Use (continued) Step 2: Make sure that the 2” Multi-Purpose OCS Cell is threaded into the opposite end of the Newtonian Spacer Tube Assembly. (Figure 6)
  • Page 7 2” Nosepiece and will provide the necessary additional back focus if needed. Unthread the shorter tube a small amount and test focus (Figure 8). An Additional Silver Lock Ring is available from Denkmeier Optical in the unlikely case where the shorter spacer must be unthreaded to achieve focus...
  • Page 8 “OUT” position (Figure 9). Most telescope focuser knobs will need to be rotated counter-clockwise from where a single eyepiece focus position was. This is “Normal” magnification mode. With the Denkmeier Binoviewer 114.5mm light path, this is approximately 15% greater magnification as compared to the same eyepiece with no binoviewer being used.
  • Page 9 Universal Package with SCTs when using the Logo-Side reducer arm. For those using only an SCT, choose the Standard or Denk II SCT Power x Switch Package and D21 Eyepieces. The new Power x Switch Star Diagonals are also a very good choice for SCTs with single eyepiece use or binoviewer use.
  • Page 10 D21s with the Universal Power x Switch low power setting. See our Website or call for more information. Choose the Standard or Denk II SCT Power x Switch Package, not the Universal if your only telescope is an SCT.

  • Page 11: Required Parts

    After carefully securing the 2” star diagonal in your telescope focuser tube, place the Denk II with Power x Switch into the eyepiece receptacle of your star diagonal and make sure that it is also well secured by tightening the diagonal set-screw.
  • Page 12 2”/1.25” adapter in the star diagonal without the binoviewer. The Multi- Purpose OCS Cell must be in place in the diagonal filter threads. Out-travel requirements are reduced using a Denkmeier star diagonal. (See previous Figure 13B) OCS Cell Figure 15 Arms “OUT”...
  • Page 13 Denkmeier Optical, Inc. 100 Pinehurst Road Berlin, MD 21811 Voice : (410) 208-6014 Fax: (410) 208-6505 Using Short-Tube Refractors Some Refractors are being produced with special shortened tubes so that binoviewers will reach focus without employing a relay device like the Power x Switch System and Multi-Purpose OCS Cell.
  • Page 14 Denkmeier Optical Company offers cleaning and collimating services at very reasonable prices. © 2004 Denkmeier Optical, Inc. No part of this manual may be reproduced for any purpose without expressed written permission from Denkmeier Optical, Incorporated.
  • Page 15 Related telescope designs that are used similarly are listed at the beginning of those sections. Information on the differences between the Standard and Denk II Binoviewer are provided in a comparison chart included in this manual (Page 23). If your Standard Binoviewer is equipped with SCD Holders (see page 3), please read instructions on their use before using the binoviewer system.
  • Page 16 The Standard Power x Switch This is a brief introduction to the Power x Switch. See instructions included for the specific telescope type being used with the Denkmeier Power Switch System for more details. Definition The Power x Switch (the “x” is silent): A Patent Pending innovation that allows Denk Binoviewers and any single pair of eyepieces to operate at varying magnifications instantly.
  • Page 17 Denkmeier Optical, Inc. 12636 Sunset Ave J2 Ocean City, MD 21842 410-208-6014 Standard Universal Power x Switch Package: Newtonian Use Related Telescopes: Follow the Newtonian instructions when using Maksutov-Newtonians or any other reflector where a star diagonal is not used.
  • Page 18 This is “Normal” magnification mode. With the Denkmeier Binoviewer 114.5mm light path, there is approximately a 15% magnification gain as compared to the same eyepiece with no binoviewer being used.
  • Page 19 Some eyepieces with long focal lengths may show edge darkening. For the maximum field of view, the ideal eyepiece to use in the reduction mode of the Power x Switch (logo-side arm “IN”) optimized for use with the Power x Switch is the new Denkmeier D21™ eyepieces which are...
  • Page 20 In an 8” SCT, a well illuminated 1.3 degree true field of view will result. Optional Accessories: 2” Nosepiece, Denkmeier 2” SCT Power x Switch Star Diagonal, 2” Multi-Purpose OCS Cell, 2” Multiplier Cell (See “Accessories” for complete description). Standard Universal Power Switch Package : Refractors Related Telescopes These Instructions should be followed when using ;...
  • Page 21 (48mm) filter threads are present on the telescope side of almost all good quality 2” star diagonals. Our Denkmeier 97% enhanced silver, or 99.4% Reflectivity Dielectric 2” Mirror Star Diagonal is available if your diagonal does not have such threads. See http://denkmeier.com...
  • Page 22 S) on page 20. Note: The 1.25” OCS Cell is an optional accessory ($119) in Denk II Universal Power x Switch Packages since all optics included with the Denk II are in a 2” format. If the cell Code #Ref150-1.25 is being ordered for Coronado 1.25”...
  • Page 23 Denkmeier Optical, Inc. 12636 Sunset Ave J2 Ocean City, MD 21842 410-208-6014 Standard Binoviewer & Denk II Binoviewer Comparison Chart Category STD Binoviewer Denk II Weight oz.24 oz.242 20 oz. MgF2 Multi-coated Coatings Magnesium Flouride Broadband Dielectric Glass types Grade A Schott BK7...
  • Page 24 Binoviewer use for $29). Code # NEWTOCS-125 2” Star*Sweeper with Nosepiece: Threads to any Denkmeier Binoviewer and works as a binoviewer focal reducer. Typically F6.6 (Add adapter for TV or AP Binoviewer use for $29). Star*Sweeper Cell also unthreads from nosepiece for use on any adapter with female 48mm threads.
  • Page 25 Allows 1.3X, 2.5X magnifications when using a Denkmeier Binoviewer (add adapter for TV and AP Binoviewers for $29). Includes 2”Refractor OCS Cell, and 2” Part SR for Denkmeier 2” Star Diagonals, Tak, TV, and AP. For Denk 2” Diagonals and others: Specify “Low Power S” Cell. Part SR shown in silver (right) is now black anodized.
  • Page 26 12636 Sunset Ave J2 Ocean City, MD 21842 410-208-6014 New Denkmeier D21mm and D14mm Eyepieces The D21 and D14 Eyepieces have been designed and produced by Denkmeier Optical to be used specifically in Denkmeier Binoviewers with our Power x Switch™ and OCS™ systems.

  • Page 27: Specifications

    Vault. Each Vault is made of anodized aluminum and is fully CNC Machined and laser engraved. Vaults are included with all Denkmeier eyepiece pairs. The eyecup is folded down and the eyepiece is threaded onto the clear anodized base of the Vault. Then the cover may be slipped over the eyepiece and threaded to the base.
  • Page 28 Brian Schilt “Guys: The Denk II Universal Power x Switch Package with D21s will cause me to lose sleep and my job if I'm careful! Very nice view of Saturn tonight before clouds rolled in...great job!”...
  • Page 29 Following these instructions will prevent any eyeglass lens damage from occurring. Denkmeier Eyepieces are covered by a one-year warranty from time of purchase for any mechanical or optical failure during normal use. Disassembly or tampering with Denkmeier Eyepieces may make warranty null and void.
