G-Force GH201-22W Operation Manual

22 inch wheel trimmer mower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION MANUAL
GARDEN
PRODUCTS
22 INCH
WHEEL
TRIMMERM O W E R
GH201-22W
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GH201-22W and is the answer not in the manual?

Questions and answers

Related Manuals for G-Force GH201-22W

Summary of Contents for G-Force GH201-22W

  • Page 1 OPERATION MANUAL GARDEN PRODUCTS 22 INCH WHEEL TRIMMERM O W E R GH201-22W...
  • Page 2 years years engine chassis WARNING! Read this manual carefully before using your lawn mower and keep it in a safe place for future reference.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS DESCRIPTION OF PRODUCT PARTS TECHNICAL SPECIFICATIONS INTENDED USE SAFETY INFORMATION ASSEMBLY PREPARING THE ENGINE ADJUSTMENT OPERATION MAINTENANCE AND STORAGE TROUBLESHOOTING WARRANTY...

  • Page 4: Description Of Product Parts

    DESCRIPTION OF PRODUCT PARTS As shown below Control level Engine Trimmer line Spindle Trimmer shield Recoil starter...
  • Page 5 DESCRIPTION OF PRODUCT PARTS Check the delivery parts 1 x Wheel trimmer B. 2 x Wheels C. 1 x Axle D. 1 x Handle 1 x Pack of bolts and nuts 1 x Pack of trimmer line G. 1 x Pack of tools H.

  • Page 6: Technical Specifications

    TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Wheel trimmer Model GH201-22W Trimmer line diameter 4.0 mm Trimmer line length 0.47 m Cutting Width 560 mm Cutting Height 50 mm- 105 mm Engine Model Honda GCV200H-S4BB Engine type OHV, 4-stoke Engine displacement 201 cc Engine oil capacity 0.4 L...

  • Page 7: Safety Information

    DESCRIPTION OF PRODUCT PARTS SAFETY INFORMATION WARNING! To reduce the risk of injury, user must read and understand the instruction manual before using the mower WARNING! Beware of thrown objects Keep bystanders away WARNING! Keep hands and feet away from the blades Unplug the spark plug before maintenance Risk of fire Never refuel while the engine is running...

  • Page 8: General Safety Warnings

    GENERAL SAFETY WARNINGS GENERAL SAFETY WARNINGS Training Read the instructions carefully. Be familiar with the controls and the proper use of the mower; Never allow children or people unfamiliar with these instructions to use the mower. Local regulations can restrict the age of the operator; Never mow while people, especially children or pets are nearby;...
  • Page 9 GENERAL SAFETY WARNINGS 12. Do not change the engine governor settings or over speed the engine; 13. Disengage all trimming lines before starting the engine; 14. Start the engine carefully according to instructions and with feet well away from the cutting line; 15.

  • Page 10: Assembly

    ASSEMBLY ASSEMBLY Assembling the wheels washer bushing axle wheel Assembling the handle hook quadrate bolt knobe hexagon bolt...

  • Page 11: Preparing The Engine

    PREPARING THE ENGINE Starter rope 1. Disconnect the spark plug lead from the spark plug. 2. Pull the starter rope out from the engine. 3. Put the start rope into the hook PREPARING THE ENGINE Checking engine oil level and filling the engine oil WARNING! Fill up the wheel trimmer's engine with 0.4 Litre 4-Stroke engine oil before starting the engine for the first time.

  • Page 12: Adjustment

    ADJUSTMENT WARNING! Do not mix fuel (petrol) with engine oil. WARNING! Do not overfill the fuel tank. WARNING! Fuel (petrol) is highly inflammable. Handle the fuel (petrol) with extreme precaution. Keep the fuel (petrol) out of reach of children. WARNING! Do not smoke when handling the fuel (petrol). WARNING! Do not smoke or allow flame/sparks in the area where the engine is refueled or where the fuel (petrol) is stored.

  • Page 13: Operation

    OPERATION OPERATION Starting and stopping the engine WARNING! The trimming line will rotate as soon as the engine is started. WARNING! The wheel trimmer is for outdoor use only. Do not start the engine in an enclosed or poorly ventilated area. Exhaust gas contains toxic gases.

  • Page 14: Cleaning, Maintenance And Storage

    MAINTENANCE AND STORAGE Using your wheel trimmer 1. This wheel trimmer is designed with the spindle offset to the left side, allowing the operator to trim along a fence, landscaping, or a house to his or her right side without having to make any adjustments to the wheel trimmer.

  • Page 15: Maintenance

    MAINTENANCE AND STORAGE 3. Remove the spark plug and wipe it dry with a cloth. 4. Wait for 5 minutes and then reinstall the spark plug. Note: install the spark plug carefully by hand to avoid cross threading. After the spark plug is seated, tighten the spark plug with a 1/8 or 1/4 turn.
  • Page 16 MAINTENANCE AND STORAGE Adjusting the spark plug gap 1. Remove the spark plug from the wheel trimmer. 2. Clean the spark plug with a wire brush. 3. Use a feeler gauge and set the gap of the spark plug to 0.7-0.8 mm. 4.

  • Page 17: Troubleshooting

    TROUBLESHOOTING 2. Clean the wheel trimmer before storage. 3. Use a light oil or silicone to coat the wheel trimmer, especially cables and all moving parts. 4. Store the wheel trimmer in a dry and clean area, out of reach of children.

  • Page 18: Warranty

    WARRANTY WARRANTY This product is covered by a 3 year parts and labour warranty for engine (2 years for chassis) against manufacturing defects. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
