Summary of Contents for AED Climate Box
- Page 1 Installa'on Manual MODELS: ACB-1-H, ACB-2-H...
- Page 2 ACB-1-H, ACB-2-H 1. Introduction The AED Climate Box is an innovative device specifically designed to protect and maintain AED defibrillators in optimal conditions, ensuring they are ready for use 24 hours a day. Due to the crucial role defibrillators play in saving lives, their functionality and availability under all conditions are absolutely critical.
-
Page 3: Wall Installation
MODELS: ACB-1-H, ACB-2-H 3. AED ClimateBOX body WARNING! Mechanical ventilation inlets and outlets. Do not cover! 4. Wall installation Drill holes in the wall using drilling template. WARNING! Place the transformer inside at all times Transformer wire outlet in cabinet body back... - Page 4 ACB-1-H, ACB-2-H 5. Power connecting Each AED Climate BOX cabinet is equipped with a electrical junction box that allows the connection of the power cable from the 24V transformer to the heater installed inside the cabinet. The electrical junction box is supplied separately to facilitate the installation of the wire connections.
- Page 5 8. Placing the AED in the Cabinet 1. To activate door open alarm, switch on it 1. Hang the AED device in the cabinet on a using the switch located on the side of the hanger installed in the upper part of the cabinet.
-
Page 6: Technical Data
λ0 [W / (m · K)] ≤ 0.036 Frost protection -25℃ -25℃ IP class Installation Outdoor and indoor Outdoor and indoor Overall dimensions 440x380x217 440x380x215 Space for AED / DAE 280x280x170 280x280x170 Weight 9,5kg 7,2kg Compliance EN 12944 level of corrosion ● ● EN 55035... - Page 7 AED ClimateBOX GRAS PPPH 77-230 KORZYBIE Sławieńska 12 street POLAND w w w. a e d c b . c o m...
