  • Page 1 IPSAN Series Network Storage System Quick Guide V2.07...

  • Page 2: Table Of Contents

    Contents 1 Introduction · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1 2 Hardware Installation ·...
  • Page 3 5 Appendix Disk Installation and Removal for the 60 Slots Products · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 34 Installing a Disk ·...

  • Page 4: Introduction

    1 Introduction IPSAN Series storage hosts include nine types of products: single controller with 12 disk slots, single control with 16 disk slots, single control with 24 disk slots, single control with 36 disk slots, single control with 48 disk slots, single control with 60 disk slots, dual control with 24 disk slots, dual control with 48 disk slots, and dual control with 60 disk slots.

  • Page 5: Hardware Installation

    NOTE!  This manual takes the single control with 24 disk slots for example. For more details, see the Online Help which is released with the software. Method to check the Online Help: click Help button on the GUI.  The following illustrations are only for your reference.

  • Page 6: Installation Steps

    2.3 Installation Steps [Installing the guide rail on the cabinet](Optional) [Installing the chassis on the guide rail] Place the guide rail between the front and rear Slowly push the main cabinet along the guide rail until mounting holes of the cabinet, align the screw holes the suspension loop is onto the front mounting hole, and use screws to secure the suspension loop to the with holes on the cabinet, and tighten the thumb...
  • Page 7 CAUTION!  When installing a device, ensure that the device and the mark line on the square hole strip on the cabinet are properly aligned in 1U. Otherwise, you are not allowed to install the rack-mounting ear screws. Figure 2-1 Correct installation ...

  • Page 8: Connect Cables And Perform Verification

    WARNING!  If the rack-mounting ear screws are forcibly installed without the aligning procedure, a gap exists between the device and the tray and the device is hanging over the square hole strip. Consequently, the device is unstable, thereby affecting stability of the hard disks. If the hard disks are running for a long time in such situation, many problems, such as a high read-and-write error rate and a high damage rate, will arise.
  • Page 9 (3) Switch on the storage controller. Single controller: To the ESD wrist strap To the serial port To the power Power-on button To the USB port To DEU To the monitoring server To the grounding To the management cable workstation To the storage To the power controller/upper level DEU...
  • Page 10 To the management workstation To the ESD wrist strap To the power To DEU To the monitoring To the grounding server To the serial port cable Power-on button To the USB port To the power To the storage controller/upper level DEU To the lower level DEU Serial port 2 Check...
  • Page 11 SAS port LED Digital display Power LED Service port LED Heartbeat LED Alarm LED Management port LED Power LED Heartbeat LED SAS port LED Alarm LED Double controller: Power LED Digital display Management Service port LED Heartbeat LED port LED Alarm LED SAS port LED...

  • Page 12: Software Configuration

    Basic Concept Description Console Indicates the Graphical User Port (GUI) used in configuration and management. Server Indicates IPSAN series in the console. Management Indicates the PC where the console is installed. workstation VMS(Video Management Server) RAID Group Indicates a logical entity consists of multiple physical hard disks.

  • Page 13: Configuration Workflow

    Logical resource Indicates a logical entity that is created on a RAID LUN for direct access from a client. A client can access a logical resource after it is created on basis of a RAID LUN and assigned to a target. Initiator Indicates an entity that initiates an Internet Small Computer System Port (iSCSI) request.
  • Page 14 (2) In the Java Control Panel dialog box, select Security and click Edit Site list. (3) Click Add. If no VMS is installed, enter http://IP; If VMS is installed, enter http://IP:8083; If the IP address is IPV6, enter http://[IPV6].
  • Page 15 (4) Click OK. 2. Open your browser, enter the device’s IP in the address bar to download the storage console. (1) If no VMS is installed, enter http://IPin the address bar. (2) If VMS is installed, enter http://IP:8083 in the address bar. You will be directed to the VMS platform if you enter http://IP.
  • Page 16 If be reminded that the Java version is out of date, click Run again to download the console. 4. Enter the default username and password (admin/123456) to log in to the console.

  • Page 17: Set The Ip Address Of The Service Port

    Figure 3-1 Login via Management Network Port Management workstation (IP address belonging to the 192.168.0.X/24 network segment) Management network port 3.4 Set the IP address of the service port 1. Choose Server Maintenance > Configure Network. 2. Change the IP address of the service port.

  • Page 18: Create A Raid Group

    NOTE!  The default IP addresses of the service ports are empty.  If expansion boards are inserted, the corresponding default IP addresses are empty too. Figure 3-2 Change the IP address 3. Click OK. 3.5 Create a RAID group 1.
  • Page 19 11 (RAID5) + 12 (RAID5) + 1 (hot standby) 7 (RAID5) + 8 (RAID5) +1 (hot standby) Figure 3-3 Create a RAID Group 4. (Optional) Click Next.Confirm the information of the RAID LUN.

  • Page 20: Create A Raid Lun

    Figure 3-4 The information of the RAID LUN 5. Click Finish. 3.6 Create a RAID LUN If no RAID LUN has been created when you start to create a RAID Group, follow these steps to create one. 1. Choose RAID LUN Resources > Local RAID LUNs > Create. 2.

  • Page 21: Create Logical Resources

    Figure 3-5 Create a RAID LUN 3. Click OK. 3.7 Create logical resources 1. Choose Logical Resources > SAN Resources > Create. 2. Set the SAN resource name and size, and select its RAID LUN.

  • Page 22: Create A Target And Add An Initiator

    Figure 3-6 Create the SAN Resource 3. Click OK. 3.8 Create a target and add an initiator 1. Choose Target Manager > ISCSI Target > Create. 2. Deselect Auto Allocated, and customize the name. Select the IP address of the target, then click Next.
  • Page 23 Figure 3-7 Create a target 3. Click Add to add an initiator. Figure 3-8 Add an initiator 4. Set the name of the initiator, then click OK.
  • Page 24 Figure 3-9 Set the name of the initiator 5. Confirm the result, then click Finish. Figure 3-10 Confirm...

  • Page 25: Assign San Resources

    3.9 Assign SAN resources 1. Choose Target Manager > ISCSI Target > target123 > SAN Resources > Assign. Figure 3-11 Assign 2. Select resources to be assigned to a target. Click OK. Figure 3-12 Assign a resource 3.10 Configure the initiator (with Windows client as an example) 1.
  • Page 26 Figure 3-13 Change the Initiator Name NOTE!  The New initiator name configured on the windows client must be the same as that configured on the storage. 2. Select Targets, enter the IP address, then click Quick Connect….
  • Page 27 Figure 3-14 Quick Connect to the Target 3. Click Done.
  • Page 28 Figure 3-15 Finish Quick Connect 4. You can see that the target is connected.

  • Page 29: View Disks Assigned (With Windows Xp As An Example)

    Figure 3-16 Check the Status 3.11 View disks assigned (with Windows XP as an example) 1. Right-click My Computer. 2. Choose Computer Management. 3. Check the added disk space.

  • Page 30: Optional) Video Management Server Configuration Description

    Figure 3-17 Check the added disk space 4 (Optional) Video Management Server Configuration Description 4.1 Product Introduction The Video Management Serve is a smart integrated surveillance platform with video input, storage, transfer and device management functions designed specifically for digital surveillance applications. The Unicorn has adopted audio/video compression and decompression, embedded system, storage, network, and smart technologies and it is suitable for security surveillance scenarios such as residential areas, buildings, campus, hotels, and shopping...

  • Page 31: Basic Concepts

    NOTE!  SCU (Storage Control Unit)  This manual takes the single control with 24 disk slots for example. For more details, see the Online Help which is released with the software. Method to check the Online Help: click Help button on the GUI. ...

  • Page 32: Set The Ip Address

    NOTE!  Compatible browser versions: Edge 79 or higher, Chrome 60 or higher, Firefox 60 or higher.  The website http://IP:8083/ is used to download professional storage management CS client. The website http://IP:80 is a simple web management client. 4.5 Set the IP address 1.

  • Page 33: Create And Format Raids

    4.6 Create and Format RAIDs 1. Choose System > Disk > RAID Manage > Physical Disk. Check whether the number of disks under "DEU" is consistent with the actual number. 2. Click Manual Create to Create RAIDs. Recommend number of disks: 11 (RAID5) + 1 (hot standby) + 11 (RAID5) + 1 (hot standby) 11 (RAID5) + 12 (RAID5) + 1 (hot standby) 7 (RAID5) + 8 (RAID5) +1 (hot standby)

  • Page 34: Primary/Replica Switch

    Figure 4-3 Format RAID 4. Check formatting results. Figure 4-4 Ensure The Status Is Normal 4.7 Primary/Replica Switch 1. Choose System > Primary/Replica Switch. 2. If this server as Replica mode, enter Primary IP address, Click Save. 3. If this server as Primary mode, switch Primary, Click Save.

  • Page 35: Add Ipc And Recording Schedule (Primary)

    Figure 4-5 Primary/Replica Switch 4. Click OK to restart. Figure 4-6 Confirm Restart 4.8 Add IPC and Recording Schedule (Primary) Make sure RAID has been added and formatted successfully before you start configuring a recording schedule. The following steps take ONVIF as an example. You may add the IPC with other protocols.

  • Page 36: Recording Status And Playback (Primary)

    2. Choose Basic > Recording Schedule, click +Add, select ipc11_V_1, click OK. Figure 4-8 Add Recording Schedule 4.9 Recording Status and Playback (Primary) 1. Choose Statistics > Server > Recording. Figure 4-9 Check Recording Status 2. Choose Video Service > Playback > Center, select ipc11_V_1, click Search.
  • Page 37 Figure 4-10 Playback 5 Appendix Disk Installation and Removal for the 60 Slots Products For the 60 slots products, the installation and removal of the disk are slightly different from other slots. Here is a separate introduction. Do not touch the Printed Circuit Board (PCB) of the disk. Verify that the handle and screws on both sides of the disk case are secure.
  • Page 38 NOTE!  The disk subrack cannot be completely unplugged. You only need to extract it to the appropriate position to install the disk.  No. 0-3 slot of each disk subrack must be full before using other slots to install the disk.
  • Page 39 4. After putting the disk into the slot one by one, press the handle to install the disk in place (following the blue arrow radian in the figure below). 5. After all the disks are installed, push the disk subrack back into place to let the handle bar fit the panel.

  • Page 40: Removing A Disk

    Removing a Disk The steps to remove the disk are as follows: 1. Turn the screw of the disk subrack (counter clockwise, please refer to the blue mark below). After the screws are loose, pull out the disk insert frame (like pulling a drawer) with both hands at the same time.
  • Page 41 3. Pull the pull ring with your finger, pull out the disk (along the blue arc direction shown in the figure below), and take out the disk by holding the middle position on both sides of the disk. 4. Disk subrack reset. Make sure that the disk insert frame is pushed back in place, the handle bar is connected with the panel, turn the screws on the panel (clockwise, as shown in the figure below), and lock the screws.
  • Page 43 No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). The product described in this manual may contain proprietary software owned by Uniview and its possible licensors.
  • Page 44 incidental, consequential, pecuniary, coverage, exemplary, subsidiary losses, however caused and on any theory of liability, whether in contract, strict liability or tort (including negligence or otherwise) in any way out of the use of the product, even if Uniview has been advised of the possibility of such damages (other than as may be required by applicable law in cases involving personal injury, incidental or subsidiary damage).
  • Page 45 CAUTION!SHOCK HAZARD! Power Requirements  Installation and use of the device must be in strict accordance with your local electrical safety regulations.  Use the battery properly. Improper use of the battery may cause risks of fire and explosion. Replace only with an identical battery.
  • Page 46 LVD/EMC Directive This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner. Battery Directive-2013/56/EC Battery in the product complies with the European Battery Directive 2013/56/EC.
