Summary of Contents for Enttec 70096
- Page 1 I/O Extender 70096 User Manual Enhance smart light show control with increased digital inputs, additional relays, and analog inputs for exceptional performance...
-
Page 2: Table Of Contents
I/O Extender (70096) Visit the ENTTEC website for the latest version. Contents Safety ................................................3 Electrical Safety............................................. 3 System Planning and Specification .................................... 3 Protection from Injury During Installation ................................4 Installation Safety Guidelines ....................................... 4 I/O Extender Connectivity ........................................5 Wiring Diagrams ............................................ -
Page 3: Safety
ENTTEC device. If you are in any doubt about system safety, or you plan to install ENTTEC device in a configuration that is not covered within this guide, contact ENTTEC or your ENTTEC supplier for assistance. -
Page 4: Protection From Injury During Installation
All network cabling should be terminated with an RJ45 connector in accordance with the T-568B standard. Always use suitable personal protective equipment when installing ENTTEC products. Once installation is completed, check that all hardware and components are securely in place and ... -
Page 5: I/O Extender Connectivity
I/O Extender (70096) Visit the ENTTEC website for the latest version. I/O Extender Connectivity LED Indicator Reset/Identify Button Wiring Diagram Display the device Reset the device to its default User-friendly diagram guide for status. settings, or press once to allow fast wiring. -
Page 6: Functional Features
◼ The maximum resistance of a cable that can be used to connect to a Digital Input to the I/O Extender’s GND is 20 Ohms. ◼ ENTTEC recommends a total maximum wire length of 100m. (50m total distance from the I/O Extender in a loop). -
Page 7: Connection To Analog Input
Extender’s web interface. Remember to note the changed Static IP after modification in the web interface. Note: When configuring multiple devices on a Static network, ENTTEC recommends connecting one device at a time to the network and configuring a unique IP to avoid IP conflicts. -
Page 8: How To Connect I/O Extender To S-Play Sp1-1
I/O Extender (70096) Visit the ENTTEC website for the latest version. How to Connect I/O Extender to S-PLAY SP1-1 Before linking the I/O Extender, ensure that the S-PLAY SP1-1 controller is upgraded to the latest firmware (Version 3 or above). This S-PLAY SP1-1 will serve as the central hub for managing and controlling the I/O Extender functions. -
Page 9: Web Interface
Unidentified IP address: If you are not aware of the I/O Extender’s IP address (either DHCP or Static) the following discovery methods can be used on a local network to discover devices: ENTTEC EMU software for Windows and MacOS (support Mac OSX 10.13 or later), which will Discover ... -
Page 10: Home
I/O Extender (70096) Visit the ENTTEC website for the latest version. Home The Home page, the default landing page, provides an overview of all Input/Output activities on the I/O Extender. Users can add notes to the I/Os and remotely test the relays directly from this page. -
Page 11: Settings
I/O Extender (70096) Visit the ENTTEC website for the latest version. Settings The I/O Extender's network settings and S-PLAY SP1-1 connection can be configured in the Settings tab. Use the Save button in the top right corner to apply changes. Unsaved changes will be discarded. -
Page 12: Reset To Factory Defaults
I/O Extender (70096) Visit the ENTTEC website for the latest version. displayed. The site will become accessible again once the update has finished installing. Reset to Factory Defaults The I/O Extender can be reset by either the web interface or the reset button on the device. It resumes the device’s settings back to factory default. -
Page 13: Servicing, Inspection & Maintenance
◼ Do not spray on the device or accessories. The device is an IP20 product. To clean an ENTTEC device, use low-pressure compressed air to remove dust, dirt and loose particles. If deemed necessary, wipe the device with a damp microfiber cloth. -
Page 14: Package Contents
◼ Surface/Din mounting bracket (79162) x 2pcs + screws x 4pcs ◼ Din Clip (51526) x 2pcs + screws x 4pcs Ordering Information For further support and to browse ENTTEC’s range of products visit the ENTTEC website. Item Part No.
