Atherton is a world leader in sterilization equipment and infection control products for the hospital, medical and scientific industries. With the experience of more than 130 years of innovation and technological design, our complete range of products for the healthcare industry are built to the highest quality standards and made for ease of use.
Page 4
This manual contains important information on the proper use and maintenance of the Atherton Gen 5 Sterilizer range. All operators and Departmental Heads are urged to carefully read this manual and become familiar with the warnings, cautions and instructions contained within it.
Contents Warranty Cover Terms & Abbreviations Product Information Model Details Gen5 Series Gorilla Gen5 Series Tiger Gen5 Series Mongoose Layout HMI Screen and printer Operating System Symbols Basic Functions 4.2.1 HMI Home Screen 4.2.2 Door Operation 4.2.3 Running a Test Cycle 4.2.4 Running a Sterilizing Cycle...
Atherton office, are borne by the buyer. All field service will be carried out during normal working hours. If warranty service is requested outside normal working hours such work will be charged at the ruling overtime rates.
Model Details: Steam Supply: Commission Date: Commissioned By: Gen5 Series Gorilla Powerful but flexible. The Gorilla is the largest model in the Gen 5 range and has all the power and flexibility to meet the everyday challenges of modern CSSD departments and other applications that require a high-level throughput.
The replacement of paper and ribbon is detailed in the maintenance section. Operating System Symbols The following is a list of the symbols used in the Atherton Steam Steriliser Control System. Button / Image Icon Description Home – directs the user to the Home screen Login –...
Page 10
Main Settings – Access to the Main Settings Menu Admin – Grants access to the Administrator Menu Return – Returns to the previous screen Admin Settings – Accesses the settings menu User Setup – Access to the User Setup Menu Go –...
Page 11
Sleep – Selects to put the sterilizer into idle state manually Clock – Selects the clock menu to set the system time Re-Print – Reprints the last cycle Generator Blowdown – Requests a Generator Blowdown (Generator Models Only) PR-MN-CU-028 Rev 2...
Basic Functions 4.2.1 HMI Home Screen Test Cycles – Allows Access to the Test Cycle Select Menu. Standard Cycles – Allows Access to the Standard Pre-Vacuum Cycle Select Menu Repeat Last Cycle – Allows the User to quickly select the last cycle details and run that cycle profile again. Door Menu –...
4.2.2 Door Operation Horizontal Door Screen Vertical Door Screens 4.2.2.1 Door Opening Select Door Menu from Home Screen PR-MN-CU-028 Rev 2...
Page 14
Select Open If Door requires opening and has been pressurised, the following alert will appear. Wait for the Gasket to retract before Door Operation to commence. If the Door opened correclty, a Door Open alert will appear. To return to door Menu, select the Door Icon. To Return to Home screen, select the Cancel button.
Page 15
See Section 6 – System dentify Error and Error Code and Select Accept button – Alarms Check Door is clear of any obstructions Select the RESET DOOR Button Select Open or Close button If problem persists, contact Atherton Service Department PR-MN-CU-028 Rev 2...
4.2.3 Running a Test Cycle 4.2.3.1 Starting a Test Cycle Ensure all doors are closed Select Test Cycles Menu Press on the Test Cycle in the list of options. Select the GO Button PR-MN-CU-028 Rev 2...
Page 17
Enter Valid User Start Code and Confirm Press on the Passcode numerical field, enter your user start code and press enter on the keypad. Press the Go button to confirm code to start cycle. Test Cycle Screen will appear, and cycle will commence. PR-MN-CU-028 Rev 2...
Page 18
4.2.3.2 Test Cycle Screen Layout Basic Cycle Operating Screen Time – Current Date and Time. Progress Bar – Shows Progress through the Pre-Sterilize, Sterilize and Post Sterilize Phases. Pressure Gauges – Shows Pressure in Chamber and Jacket in kPa. Cycle Name – Details the Name of Current Cycle. Remaining Time –...
Page 19
Detailed Cycle Operating Screen Time – Current Date and Time Progress Bar – Shows Progress through the Pre-Sterilize, Sterilize and Post Sterilize Phases Pressure/Temperature Displays – Shows Pressure in Chamber and Jacket in kPa, Shows Temperature in Chamber and Jacket in °C Cycle Name –...
4.2.4 Running a Sterilizing Cycle Ensure all doors are closed Select Cycles Menu Press on the Cycle in the list of options. Select the GO Button Enter Valid User Start Code and Confirm Press on the Passcode numerical field, enter your user start code and press enter on the keypad.
Page 21
Basic Cycle Operating Screen Time – Current Date and Time. Progress Bar – Shows Progress through the Pre-Sterilize, Sterilize and Post Sterilize Phases. Pressure Gauges – Shows Pressure in Chamber and Jacket in kPa. Cycle Name – Details the Name of Current Cycle. Remaining Time –...
Time – Current Date and Time Progress Bar – Shows Progress through the Pre-Sterilize, Sterilize and Post Sterilize Phases Pressure/Temperature Displays – Shows Pressure in Chamber and Jacket in kPa, Shows Temperature in Chamber and Jacket in °C Cycle Name – Details the Name of Current Cycle. Cycle Details –...
4.2.6 Energy Saving Mode Sterilizers with internal steam generators, energy saving mode is selected after 20 minutes. This lowers the heating energy in the steam generator. This mode is display with the green leaves on the home screen. PR-MN-CU-028 Rev 2...
Admin/Supervisor Functions 4.3.1 Login On any screen where you see the login button you can gain administrator access. Press the Login button to access the login window. Select the alpha-numeric field to enter passcode. Enter passcode and press Enter Note: Code will be provided separately to User Manual. Important Note: When you are logged in, the Login button will appear in the unlocked state.
4.3.2 Basic Settings – Setting the Clock Important Note: Clock Mode can only be accessed by Administrator User Level. Select Settings Menu Select the Clock Menu. Show Clock Popup and How in Set Date/Time. Note: Ensure your changes have been accepted by checking that the HMI date matches your changes. 4.3.3 Creating a User ** Important Note: You must be logged in to Administrator User Level to Select the Admin Menu.
Page 26
Select an Empty user slot by pressing any text that says empty. Enter the Name and 4-digit passcode you wish to set for the user. Enter a Job title for your own reference. Note: The name set in the User Setup is the name that will appear on all cycle documentation.
Page 27
If you try and Save a password that is ‘0’ then you will receive and Invalid Password Alert. PR-MN-CU-028 Rev 2...
4.3.4 Automatic Test Cycles Select Settings Menu Select the Administrator Menu. Select Settings Menu Select the Warm-Up Timer Setup Menu Select the cycles you wish to run according to the day of the week you wish them to operate. Set the time (24hr time) for each individual day that you wish the first cycle to start. To set dates which the Auto Cycles will run, select the Date Exceptions Menu.
Page 29
Enter the dates you wish the Auto Cycles to NOT be run even if they are set in the menu. (ie Public Holidays) Select the return button when dates are set in the list. PR-MN-CU-028 Rev 2...
Cycle Types Test Cycle Types Test cycles are non-sterilizing cycles and can be found in the Test Cycles Menu. Cycle Icon Description Warm-Up – This warms the chamber, so it is ready for use. WARM-UP CYCLE Temperature Pressure Complete Pre-Heat Warm-Up Steam Exhaust...
Page 31
Leak Rate – This cycle is to detect any leaks in the chamber and pipework LEAK RATE CYCLE Temperature °C Pressure kPa -100 Leak Rate Vacuum Stabilize Complete Intake Hold Vacuum – Chamber Drain valve is opened, and a vacuum is drawn on the chamber to remove air and create a vacuum for the Leak Test, target vacuum level is -85 kPa.
Page 32
Bowie Dick Test – This cycle operates the same as a sterilizing cycle but with a 3.5minute hold time which must be run with a test indicator in the chamber during the cycle. This indicator confirms that the Sterilizer is reaching temperature and no air is present.
Page 33
Air Detector Function Test – This cycle tests the ability for the Air Detector Probe to detect Air in the Chamber during a cycle. AIR DETECTOR FUNCTION TEST CYCLE Temperature °C Pressure kPa Sterilize Steam Leak Rate -100 Stabilize Pre-Vacuum Charge Exhaust Drying...
Page 34
Exhaust – Opens the drain and begins vacuum to exhaust the steam and condensate present in the chamber. This stage will continue until the pressure falls below the vacuum level setpoint. Drying – The Chamber Drain valve is open and a vacuum is drawn in the chamber. This stage will run for the time set for the cycle.
Page 35
Air Detector Performance Test – This cycle tests the ability for the Air Detector Probe to detect Air in the Chamber during a cycle. AIR DETECTOR PERFORMANCE TEST CYCLE Temperature °C Pressure kPa Sterilize Complete Steam Leak Rate -100 Pre-Vacuum Stabilize Charge Exhaust...
Page 36
the Air is successfully detected, a “Sterilize Residual Air Fault” will appear. The cycle will abort but this is a successful test and will appear this way once you reach the complete stage. Exhaust – Opens the drain and begins vacuum to exhaust the steam and condensate present in the chamber. This stage will continue until the pressure falls below the vacuum level setpoint.
5.2 Standard Cycles Standard Cycles are sterilizing cycles and can be found in the Standard Cycles Menu. Cycle Icon Description Pre-Vacuum – This cycle operates by removing air from the chamber using the vacuum pump and then pressurizing the chamber wit steam at 134.0°C for no less than 4 minutes.
Complete – The cycle has completed. It is at this point that the user must confirm the completed cycle. System Alarms Any detected fault in the Atherton Sterilizer Operating System will provide an alert on the HMI and the printout (if in cycle). All critical and non-critical alarms will appear in this manner.
6.1.2 Printout Alarm: – The name of the detected fault Alarm Code – 4-digit Alphanumeric reference code for the detected fault. Time/Temp/Press – Time, Chamber Temperature and Pressure readings when the fault was detected Alarm Actions List 6.2.1 Alarm Codes Error Code Alarm Description Alarm Details...
GN01 Generator Low Water Steam Generator has detected a low water level GN05 Generator Heating Fault Steam Generator has taken too long to reach required pressure Door 1 Operation DR11 Door 1 has taken too long to open/close Timeout DR21 Door 2 Operation Door 2 has taken too long to open/close Timeout...
Page 41
Air Isolating Switch • Recommended Check Air Supply is present and turned on. Actions • If Air Supply is not present, contact Engineering or Atherton Service Department. Error Code Alarm Description Alarm Details SU03 Low Water Supply Water flow is below the minimum required value •...
Page 42
Actions • Check Drain Valve is operating correctly • Check there is no leak in the chamber (Run A Leak Rate Cycle) • To check Vacuum Settings, Contact Atherton Service Department. Error Code Alarm Description Alarm Details PE02 Pressure Pulse...
Page 43
Check the Steam to Chamber Valve • Check the Door/s are closed, and interlock switch has closed. • Check Drain Valve is closing. • Call Atherton Service Department. Error Code Alarm Description Alarm Details ST02 Steam Charge Warning The Steam Charge Stage is getting close to achieving a timeout fault and has not yet reached the Sterilizing set temperature.
Page 44
Check the Steam to Chamber Valve • Check the Door/s are closed, and interlock switch has closed. • Check Drain Valve is closing. • Call Atherton Service Department. Error Code Alarm Description Alarm Details ST03 Low Sterilizing The Chamber temperature has fallen below the minimum...
Page 45
Error Code Alarm Description Alarm Details ST04 Over Temperature The Chamber temperature has exceeded the maximum sterilizing temperature during Sterilize stage • Possible Causes Steam to Chamber valve has failed to close. • Faulty Temperature Probe • Recommended Check Steam to Chamber Valve operation Actions •...
Page 46
See Engineering/Maintenance Check Power to Sterilizer. Actions • Check E-Stop Button/s have not been pressed • Check the PLC controller has power – Contact Atherton Service Department Error Code Alarm Description Alarm Details GN01 Generator Low Water Steam Generator has detected a low water level •...
Page 47
Error Code Alarm Description Alarm Details DR21 Door 2 Operation Door 2 has taken too long to open or close Timeout Possible Causes • Door 2 drive system is not operating fast enough • Door 2 panel in not closed correctly. •...
Page 48
Gasket Pressure Maximum Setpoint is too low. Recommended • Check Air supply to gasket regulator. Actions • To check and/or alter Gasket Pressure Setpoints – call Atherton Error Code Alarm Description Alarm Details ST05 Sterilize – Residual Air The Air Detector and Drain Probes have a differential of >2°C...
Page 49
Air Detector probe may not be set to correct height above chamber. • Air Detector probe may be faulty. • Drain Probe may be faulty. • Call Atherton to inspect Air Detector and/or Drain probes. Recommended Actions Error Code Alarm Description Alarm Details...
Page 50
Failure of Air Supply sensor. • Recommended Contact Engineering to determine what supplied pressure is. Actions • Call Atherton to inspect the Supply Air Alarm Setpoints. Error Code Alarm Description Alarm Details SU13 High Water Supply Water Supply pressure is above the maximum required value Detected •...
Useful Guidelines Preparing the load Always use freshly laundered 140 thread count muslin (or material that can be shown to be equivalent to 140 thread count muslin) Limit the size and density of each pack. This ensures complete steam permeation and provides a liberal safety margin.
Ensure your hands and fingers are not near the top of the chamber when closing the door. Failure to do so may result in injury. Unloading the Sterilizer Care must be taken to avoid contact between bare skin and sterilizer chamber, door, carriage, basket and load. Appropriate protective clothing should be worn.
Confirm power to the control system has been isolated. Allow the sterilizer and loading equipment to cool Thank you for choosing Atherton equipment. The safety, performance and reliability of your equipment cannot be assured unless regular maintenance is performed, preferably by accredited Technicians.
Protective Formula allows you to clean almost any surface without the need of harsh chemicals Contact your local Atherton Office for details. Ultra - Blue Glove Scrubs and loosens any residue and build up. To use immerse the glove in cold water and wring out the excess water.
Spare Parts Part No. Description Image Door gasket to suit Gorilla 022704 660mm Wide x 900mm High chamber Door gasket to suit Tiger 022471 660mm Wide x 660mm High chamber Door gasket to suit Mongoose 024598 535mm Wide x 535mm High chamber Paper roll 57mm for thermal printer 139255 All models...
Page 56
RTD 190 x 6mm PT100 ½” BSP 135948 All models RTD 80 x 6 S/S PT100 ½” BSP 138593 All models Sensor Pressure Steam Gen 5 140487 Sensor Pressure Air Gen 5 140488 PR-MN-CU-028 Rev 2...
