ASTRO APX™ N50/N30 Digital Portable Radios
Flexible Antenna Quick Start Guide
Note: Use only Motorola Solutions-approved batteries, wired
surveillance, and wireless audio accessories when using this
antenna. Using approved wired surveillance and wireless audio
accessories is important because the use of non-Motorola
Solutions approved accessories may result in exposure levels,
which exceed the occupational/controlled environment RF
exposure limits.

Packing List
The package contains the following items:
Flexible
1
Antenna
Figure 1. Items in the package

What You Need
1 Radio with battery pack.
2 Duct/surgical tape and/or straps.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or
registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All
other trademarks are the property of their respective owners.
© 2012 and 2024 by Motorola Solutions, Inc. All Rights Reserved.
*MN010545A01*
MN010545A01-AA
Printed in

Your radio is designed to operate while concealed under your outer
garments. Refer to Figure 2 for the recommended positions to place
your radio.
Note:

Prerequisite: Turn off the radio.
To attach the antenna to the radio, insert the antenna in the receptacle
and turn clockwise.
2 Spacer
Note:
To remove the antenna, turn off the radio and turn the antenna
counterclockwise.
1
Positioning the Radio and Devices on Your Body
Figure 2. Recommended Positions for Radio and Devices
When using the flexible antenna, securely tape or strap only the
battery side of the radio to your body.
Installing the Flexible Antenna
Figure 3. Antenna Installation
To avoid damage to the antenna and radio, the maximum
allowable tightening torque is 15 lb-f.
