- Page 1 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471...
-
Page 2: Table Of Contents
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 “KIDDY CARS RACING” TABLE OF CONTENTS 1. GAME PLAY INSTRUCTIONS 2. DIMENSIONS & TECHNICAL PARAMETERS 3. PARTS OF THE MACHINE 4. INTEGRAL STRUCTURE OF THE GAME 5. -
Page 3: Game Play Instructions
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 1. GAME PLAY INSTRUCTIONS ENTER THE CORRECT NUMBER OF CREDITS. THE GAME WILL START AUTOMATICALLY WHEN THE PROPER NUMBER OF CREDITS HAS BEEN ENTERED. -
Page 4: Dimensions & Technical Parameters
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 2. DIMENSIONS & TECHNICAL PARAMETERS W43.3” x L82.7” x H46.5” 1. GAME DIMENSIONS: 2. POWER REQ.: 110V/AC ± 5%, 60 Hz-or-220V/AC ± 5%, 50 Hz 3. -
Page 5: Parts Of The Machine
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 3. PARTS OF THE MACHINE REFER TO THE CHART BELOW FOR THE MACHINE PARTS LOCATIONS AND THE CONTENTS OF THE SPARE PARTS KIT SUPPLIED WITH THE GAME. -
Page 6: Integral Structure Of The Game
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 4. INTEGRAL STRUCTURE OF THE GAME VGA MONITOR SPEAKERS (2) JUMP BUTTON STEERING WHEEL MAIN PC & I/O ACCESS MONITOR ACCESS LID SETTINGS (LOCKING) THROUGH THIS DOOR. -
Page 7: Installation Of The Game
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 5. INSTALLATION OF THE GAME THE MACHINE MAY ONLY BE USED IN A SAFE, INDOOR ENVIRONMENT. USE OF THE GAME OUTDOORS IS PROHIBITED. THE RECOMMENDED AREA REQUIRED FOR SAFE OPERATION;... - Page 8 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 GAME DURING OPERATION. BE SURE THE AREA IS FREE OF OBSTRUCTION. ALWAYS TURN THE POWER OFF BEFORE MOVING THE GAME AND ALWAYS DISCONNECT THE POWER CABLE FROM THE POWER SOURCE AND FROM THE GAME PRIOR TO MOVING.
-
Page 9: Notice For Safe Operation
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 6. NOTICE FOR SAFE OPERATION CHECK WHETHER THE POWER PLUG AND POWER CORD ARE IN GOOD CONDITION BEFORE SWITCHING THE POWER ON. MAKE SURE THAT THE VOLTAGE IS SUITABLE FOR THE MACHINE. -
Page 10: Power Supply
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 7. POWER SUPPLY POWER SUPPLY INPUT ; MAIN POWER SWITCH FUSE HOLDER TUBE AND COVER AC CORD INLET THERE IS A FUSE LOCATED IN THE FUSE HOLDER TUBE WHICH IS;... -
Page 11: Game Adjustments & Test
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 8. GAME ADJUSTMENTS & TEST MONITOR ADJUSTMENT PANEL: MENU DOWN POWER GNR AUTO PICTURE 1 THIS PANEL SHOWS THE PUSHBUTTONS USED IN MAKING ADJUSTMENTS TO THE LCD MONITOR. “ITEM SELECT” & “SETUP SW”... - Page 12 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 THE CONTROL PANEL AT ANY TIME TO EXIT THE ADJUSTMENT MENU AND RETURN TO NORMAL ATTRACT. PASSWORD SCREEN PROMPT; PICTURE 3 BYPASS THE PASSWORD PROMPT, - PRESS “START” 5 TIMES TO CONFIRM THE CODE AS SHOWN ABOVE AND ADVANCE THE SCREEN TO PICTURE 4;...
- Page 13 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 PARAMETERS IN EACH SETTING. PRESS “START” TO ADVANCE TO THE NEXT SETTING DOWN IN THE MENU. AT ANY TIME, PRESS THE “JUMP” BUTTON TO ESCAPE THE MENU AND RETURN TO NORMAL.
-
Page 14: Service And Maintenance
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 9. SERVICE & MAINTENANCE TO REMOVE THE CAR BODY FOR SERVICING THE MOTION BASE, MOTOR OR LINKAGE, ACCESS THE FOUR 10MM ALLEN BOLTS LOCATED AT THE FOUR CORNERS OF THE CAR’S BODY FRAME FROM UNDERNEATH THE FRONT AND... -
Page 15: Hardware Components
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 10. HARDWARE COMPONENTS THE GAME HARDWARE IS LOCATED IN THE REAR TRUNK AREA MAIN PC BASE STEERING SENSOR LAMP BOARD CONTROL BOARD AUDIO AMPLIFIER... -
Page 16: Wiring Diagrams
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 11. WIRING DIAGRAM... - Page 17 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471...
- Page 18 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471...
-
Page 19: Parts List
LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 12. PARTS LIST KIDDY CARS RACING PARTS LIST and QUANTITY REQUIRED Part Number Location Image Qty Unit Special and ID Main Game Hard Drive... - Page 20 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 Tail Lamp LED PCB Trunk KCR-009 KCR Relay Trunk KCR-010 Single Phase Resistor, Base Frame Motion Drive Motor KCR-011 LCD Flat Panel Original Inside Monitor 15"...
- Page 21 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 "START" Pushbutton Removed on *Deleted* (Optional) US version KCR-017 Menu & Adjustment Inside Cin Mech 2 required on Pushbuttons Door US Version KCR-018 Low Level...
- Page 22 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 Motion Linkage Joint Base Frame Bearing KCR-028 A600 Motion Motor Drive Belt KCR-029 Motion Direction Base Frame Type：6200 Bearing "A" KCR-030 Monitor Bezel and...
- Page 23 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 Front Corner Front Lamp Cover KCR-038 20W Audio Speaker Inside KCR-039 Speaker Grill Cover Inside KCR-040 Steering Wheel Inside KCR-041 AC Line cord Rear...
- Page 24 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 Cam Lock Two; AH57, Door & Trunk KCR-048 One; AH578 Label Label Label Label Label Label Label Accelerator Decal Label Graphic KCR-056...
- Page 25 LOLO INCORPORATED WWW.LOLO-INC.COM 420 CROSSEN AVE.,ELK GROVE, IL 60007 USA TECH SUPPORT PH: 847-427-0639 FX: 847-427-9471 Control Panel Graphic Graphic KCR-057 Side Decal Graphic Graphic KCR-058 License Plate Graphic Graphic KCR-059 THIS MANUAL AND ITS CONTENTS ARE SUBJECT TO CHANGE...
