PuraShield
PuraShield
ADVANCED SANITISERS
OWNER'S MANUAL
Should the installer or owner be unfamiliar with the correct installation
and/or operation of this type of equipment, please contact the distributor
or manufacturer for the correct advice before proceeding with the
installation or operation of this product.
UV
®
UV + O3
®
PENTAIRPOOL.COM.AU
Advertisement
Table of Contents
Related Manuals for Pentair PuraShield UV
Summary of Contents for Pentair PuraShield UV
- Page 1 PuraShield ® PuraShield UV + O3 ® ADVANCED SANITISERS OWNER’S MANUAL Should the installer or owner be unfamiliar with the correct installation and/or operation of this type of equipment, please contact the distributor or manufacturer for the correct advice before proceeding with the installation or operation of this product.
- Page 2 IMPORTANT Please attach your sales invoice/docket here as proof of purchase should warranty service be required. Please do not return warranty form to Pentair Australia - Retain for your records. PURCHASED FROM: PURCHASE DATE: SERIAL NO: MODEL NO:...
-
Page 3: Table Of Contents
TABLE OF CONTENTS CONTENTS 1. SAFETY WARNINGS .............................2 2. INTRODUCTION ............................3 Secondary Sanitisers .........................3 Ultraviolet Disinfection ........................3 Ozone Disinfection ..........................4 Main Advantages ..........................4 3. TECHNICAL SPECIFICATIONS ........................5 Performance Data ..........................5 Dimensions ............................5 4. INSTALLATION .............................6 Plumbing Installation .........................6 Equipment Layout..........................6 Installation Options ..........................9 Flow Switch Installation ........................9 Flow Switch Orientation ........................ -
Page 4: Safety Warnings
Special safety warning must be taken into consideration for the model PuraShield UV-C Ozone system: The UV Lamp generates ozone that emits a strong odour, even in very small quantities, and can be harmful for eyes, nose and skin. -
Page 5: Introduction
Ozone and UV-C are two of the most efficient disinfection processes in water treatment. PuraShield UV uses UV exposure only and PuraShield UV + O3 (Ozone) mixes these two concepts in one unique appliance which will help keep your swimming pool water fresh, crystal clear and disinfected, reducing the use of chlorine to a minimum. -
Page 6: Ozone Disinfection
2. INTRODUCTION Ozone Disinfection PuraShield UV & Ozone systems contain a high intensity Ultraviolet lamp different from the other UV models. This special lamp emits two separate wavelengths within the UV spectrum: 254nm and 185nm. While the 254nm wave deactivates the DNA of bacteria, viruses and other pathogens, the 185 nm wave is responsible for converting the oxygen contained in the quartz sleeve area into ozone. -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS Performance Data PuraShield UV + O3 PuraShield UV PuraShield UV PSUV-87-03 PSUV-75 PSUV-130 Main Feature UV + Ozone 220-240V, 220-240V, 220-240V, Power supply NT-UV40 50 / 60Hz 50 / 60Hz 50 / 60Hz Input power 130W Maximum working pressure... -
Page 8: Installation
Chlorinator. I.e. the UV sanitiser must be installed upstream of the chlorinator. PuraShield UV products are not recommended to be used in seawater or seawater-like environments with high salt content as the stainless steel body will be corroded and leak in long term operation. - Page 9 UV System The water circulation flows from the swimming pool skimmer to the pump to the filter. Position the PuraShield UV disinfection unit after the filter and before chlorinator. pH or ORP probes (if present) should be mounted after the filter and before the UV sanitiser.
- Page 10 UV System With Ozone The water circulation flows from the swimming pool skimmer to the pump to the filter. Position the PuraShield UV + Ozone disinfection unit after the filter and before chlorinator. pH probes (if present) should be mounted after the filter and before the UV sanitiser.
-
Page 11: 5.3 Installation Options
4. INSTALLATION 5.3 INSTALLATION OPTIONS The dark blue transparent end cap and union set is inter changeable for all models, it can be place on either side. Installation Options It is necessary to place and tighter the O-ring properly to prevent water leakage when doing relocation. There are two sets of 1.5”... -
Page 12: Flow Switch Orientation
Bypass Guide If the system flowrate exceeds the maximum flowrate for the desired UV exposure, then the PuraShield UV or PuraShield UV + Ozone needs to be installed on a bypass line. If the flowrate through the UV vessel exceeds the maximum flowrate, then the UV dosage will be insufficient and ineffective, so it is important to use the bypass where required. - Page 13 4. INSTALLATION Bypass arrangements for PuraShield UV + Ozone. Figure 12. Bypass arrangements for PuraShield UV + Ozone. Figure 13. Bypass arrangements for PuraShield UV + Ozone. Figure 14. PuraShield UV Sanitiser Owner’ s Manual ®...
-
Page 14: Venturi Installation Guide
Venturi Installation Guide Follow the instructions procedure below for installing the Nano-Tech UV Ozone System: Follow the procedure below for installing the PuraShield UV + Ozone System: 1. Fit the manometer (A) onto the Venturi circuit using Teflon tape. Hand-tighten the manometer. -
Page 15: Start Up & Adjustments
START UP & ADJUSTMENTS Preparation Before starting up the PuraShield system, perform the following actions: Backwash and rinse the sand filter or in the case of cartridge filter, clean the cartridge(s) and make sure it/they are completely clean. 2. Empty the leaf basket of the skimmer and the filtration pump. 3. -
Page 16: Operation
2. Schedule timer 7.1 DIGITALTIMER* 3. Clock As the PuraShield UV is equipped with a flow switch, it is not necessary to use the digital timer. The UV lamp will automatically activate when the water flow starts *Available for the following models: and deactivate when the water flow stops. -
Page 17: Clock Setting
6. OPERATION Manual Adjustment: 1. Press the button ‘MENU’ and select the option ‘Hr’ by pressing ‘MENU’ again. 2. The flashing number shown on the screen will indicate the hours left for replacing the lamp. 3. Press the button ‘MENU’ to modify the hours. 3.1 Use the buttons to increase or decrease the counter value in steps of 500 hours from the initial value up to the maximum value of 9500 and the minimum of 500. -
Page 18: Maintenance
flow switch installed in the chamber will automatically switch the device off if no water is flowing through it. 8. MAINTENANCE MAINTENANCE To ensure the correct operation and a long life of this UV-C system, regularly check the chemical parameters and maintain them within the recommended range: To ensure the correct operation and a long life of this UV-C system, regularly check the chemical parameters and maintain them within the recommended range:... -
Page 19: Stainless Steel Housing Maintenance
7. MAINTENANCE Stainless Steel Housing Maintenance The stainless steel interior can be cleaned with a soft brush. First of all, the UV-C and quartz lamps have to be removed following the below steps: 1. Un-thread the adaptor male - male 2 ½”– 2”. Remove the sight glass from the opposite side of the adaptor. There are two more threaded adaptors inside the connections. - Page 20 7. MAINTENANCE 7.3.2 Controller PCB The power cord Live connect to L and Neutral to N of the PCB upper terminals. The power output of the PCB has the same Live and Neutral colour wire to the UV-C lamp ballast. Don’t un-wire the lower 2 position terminal white colour wire.
-
Page 21: Lamp Socket
Loss of any grounding will trigger the RCD or GFCI and stop the power when power on. It is use to protect from personnel electric socket. 11.5 LAMP SOCKET 7. MAINTENANCE It is a T5 type lamp socket and be careful to plug the lamp in right orientation to prevent the lamp’s connect pins broken. -
Page 22: Troubleshooting
TROUBLESHOOTING Symptom Possible Solution Disconnect the power cord from the electrical outlet, disassemble the lamp and verify if the lamp connector is fixed firmly in place. Verify if the electric cable is connected into an electrified circuit. Test the electrical circuit. UV-C system failure, possible lamp disconnection Make sure you have not connected the device into any power source other... -
Page 23: Spare Parts
SPARE PARTS Key No. Part No. Description Key No. Part No. Description Adaptor end cap kit 800846 SIGHT GLASS KIT 800840 (includes 1,2,4 and 23) 800847 O-RING UV BODY 76x6MM 800841 O-ring lamp connector 800848 Stainless steel body 800842 UV Lamp 130W 800849 PIPE CLAMPS 800854... - Page 24 PuraShield UV Sanitiser Owner’ s Manual ®...
- Page 25 PROPER DISPOSAL OF THIS PRODUCT This symbol on the product, or in its packaging, indicates that this product may not be treated as household waste. Instead, it should be taken to the appropriate waste collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by the inappropriate waste handling of this product.
- Page 26 1-21 Monash Drive | Dandenong South, VIC 3175 | Australia | 1300 137 344 | pentairpool.com.au Information contained here-in remains the property of Pentair under Australian copyright law. Content may not be reproduced or transmitted without our prior written permission.
