- Page 1 Porodo 720P High Brightness 120ANSILlumens Mini Projector SKU: PD-P720PJR...
-
Page 2: Table Of Contents
Table of Content Safety Guideline --------------------------------------------------- Accessories -------------------------------------------------------- Schematic View of Mini Projector ------------------------------ Installation Guideline --------------------------------------------- Specifications ----------------------------------------------------- Supporting Formats ---------------------------------------------- Schematic View of Remote Controller ------------------------ Powering ON/OFF ------------------------------------------------- Default Setting ---------------------------------------------------- Focusing ------------------------------------------------------------ Operation Instructions ------------------------------------------- 1. Choosing the Input Source ----------------------------------- 2. -
Page 3: Safety Guideline
Safety Guideline Before installing and using the product, please carefully read this User Manual to guarantee correct usage and keep it securely for future reference. Ensure a stable power supply. Utilize only the standard power cord provided in the package. Install the device to the power supply and cable. Choose the power supply and cable according to the specifications required by producer. -
Page 4: Schematic View Of Mini Projector
Schematic View of Mini Projector IR Receiver Lens Speaker IR Receiver Air Outlet Camera (Available with auto focus option) 10 . Cooling Window Headphone Jack 11 . Cooling Window USB Port 12 . Power Socket HDMI Port Note: To clean the dust net gently press the dust net cover and it will pop open. Take out the dust net for cleaning. - Page 5 Power Key Bracket Holes (1/4" - length: 6 mm) [Supports hoist] Bottom Label Note: Please check the following diagram to correctly adjust the projector. Projector Screen Screen Symmetry Axis Incorrect Installation Correct Installation Incorrect Installation...
-
Page 6: Installation Guideline
Installation Guideline It is recommended to enlist a qualified installer for ceiling-mounting this projector. Adhere to the following directions to ensure proper positioning of the projector: Front projection ceiling mount Rear projection ceiling mount Rear projection table mount Front projection table mount Warning Improper installation of the projector onto a ceiling or surface may lead to irreparable damage. -
Page 7: Specifications
Settings Specifications Model PD-P720PJR Size 178×156×120 mm Working Temperature 0° to 35° C Aspect Ratio 4:3 / 16:9 Weight 1.3 kg Input Voltage 240 - 100V AC (60/50 Hz) Manual/ Remote Control Operating Mode Lamp Image System Input Port HDMI/USB... -
Page 8: Default Setting
the remote control. The indicator light will illuminate in a steady “blue” color. Step 2: Within 2 seconds, the projector begins its startup process, the image will be projected onto the screen, and the projector will enter its standard operating mode. Step 3: For projectors that are being used for the first time, initial images may appear blurry or exhibit keystone distortion. -
Page 9: Focusing
Aspect Ratio 16:9 Picture Size (inch) Projection Distance (m) 1.48 2.30 2.86 3.40 120" 100" 80" 50" 3.40 m 2.30 m 2.86 m 1.48 m Focusing Upon first use of the newly installed projector, the image may appear blurry which requires the user to adjust the focus setting. -
Page 10: Operation Instructions
Operation Instructions Choosing the Input Source Step 1: Power on the projector and open the main menu interface. Step 2: Navigate to the input source selection, choose the desired signal source, and establish the connection. Accessing Files on a USB Drive Step 1: Insert the USB drive and select "Media"... -
Page 11: Downloading App
Downloading App Step 1: Navigate to the App Store icon located at the bottom of the main interface, open it, and browse for the applications you wish to download. Step 2: Add new apps by selecting the "+" sign adjacent to the App Store icon. Connect to WiFi Step 1: From the main interface, go to "Network"... -
Page 12: Using Maxhubshare
Using MaxhubShare Step 1: On the main interface, navigate to and select the "MaxhubShare" option. Step 2: In the MaxhubShare interface, scan the QR code displayed on the right side using your mobile device to download and install the "MaxhubShare" application. -
Page 13: Using Miracast
Using Miracast (Android Users) Step 1: Open the settings menu on your Android phone/tablet. Step 2: Access the display setting. Step 3: Select the name of the "Miracast" receiver (For instance the TV name "TV-****" that is displayed on the projector's interface) Miracast steps: IOS Cast Step 1:... -
Page 14: Bluetooth Connection
IOS Cast steps: Note: The TV name indicated in the pictures is for the sake of the example and can differ from your TV name. Bluetooth Connection To connect audio devices to the projector via Bluetooth follow these steps. Step 1: On the home page of user interface select "Settings". -
Page 16: Projection Settings
Projection Settings Step 1: To enter the settings menu, select the “Settings” icon located on the left side of the main interface and press the "OK" button on the remote controller. Step 2: Within the settings menu, navigate to and select "Projection Settings" and choose the desired projection mode. -
Page 17: Square Trapezoid Correction
Square Trapezoid Correction Step 1: To perform advanced correction, select the "Corners" mode from the options. Step 2: Choose "Square trapezoid" and proceed to adjust as guided by the on -screen prompts. Use the arrow keys to adjust the screen until the guides form a perfect rectangle. -
Page 18: Customized Zoom
Customized Zoom Upon start-up, choose the appropriate zoom setting to modify the screen size according to your preferences. Projection Method Choose from four configurations: Front/Ceiling, Front/Rear, Ceiling/Rear, to suit the specific setup requirements. -
Page 19: Warranty
Products that you buy directly from our Porodo website or shop come with a 24-month warranty. When you buy Porodo products from any of our approved sellers, you only get a 12-month warranty. If you want to extend this warranty, go to our website at https://porodo.net/warranty and fill out the form with your information.
