ENGO CONTROLS EDOORZB Quick Manual

DOOR
EDOORZB | ZigBee Door/Window Sensor
Quick Guide
Ver. 5.3 Works with app Powered By
Date of issue: VII 2024
Soft: v1.0.3
GET IT ON
Available on the
Producer:
Engo Controls sp. z o.o. sp. k.
43-262 Kobielice
4 Rolna St.
Poland
www.engocontrols.com
Technical Informations
Power supply CR2450
Communication ZigBee 3.0
Dimensions 72 x 42 x 16 mm
SAFETY INFORMATION
Use in accordance with national and EU regulations. Use
the device only as intended, keeping it in a dry condition.
The product is for indoor use only. Please read the entire
manual, before installation or use.
Introduction
EDOORZB is a battery-operated magnetic sensor, compatible
with the ZigBee 3.0 standard. A change in the state of the
device automatically sends a signal to a ZigBee Internet
gateway (Engo EGATEZB). It can be used to create rules for the
operation of home appliances (scenes) and where you need
information about the opening or closing of doors, windows,
garage doors, etc. Using the Engo Smart app, it is possible to
create a relationship between the window opening sensor
and the room temperature thermostat (e.g. if the window
is opened, the heating or air conditioning is turned off). The
opening is detected by the distance between the sensor and
the magnet. The product is designed for indoor use only.
The sensor must be combined with a universal ZigBee 3.0
gateway (Engo EGATEZB).
Products features
operation in ZigBee 3.0 standard
Works with ENGO Smart
(Compatible with Tuya App)
operation status indicator light
small size of the device
Product Compliance
This product complies with the following EU Directives:
2014/53/EU, 2011/65/EU
Installation:
Installation must be performed by a qualified person with
appropriate electrical qualifications, in accordance with
the standards and regulations in force in a given country
and in the EU. The manufacturer is not responsible for
non-compliance with the instructions.
WARNING:
For the entire installation, there may be additional
protection requirements, which the installer is responsible
for.
Explanation for LED indicator
LED
DEVICE
INDICATOR DESCRIPTION
STATUS
STATUS
This mode is triggered by
The Green LED The device is in long button press
flashes pairing mode (reset button hold for
8 sec.).
Device is properly
the device sends connected to the
Single flash of
information to network and app can
the Green LED
the app receive information
from sensor.
EDOORZB installation
1
Remove the battery cover.
3
Stick the sensor and magnet to the frame and sash of the door / window,
no more than 5mm from each other.
LED indicates
current status of
the device
2
Remove protective film of the sensor.
