INSTALLATION INSTRUCTIONS
FCB 1200-DC outdoor / indoor
free cooling system
Item no. 890001 / 8 90010
Based on years of experience, we further developed the free
cooling system and set new standards in performance, noise,
quality and environmental friendliness with the free cooling
of mobile radio and fiber optic infrastructure.
air-based
cooling systems
FCB
Low-cost
Eco
The new
original
Strong
Safe
24/7
MADE IN GERMANY
Custom
Advertisement
Chapters
Table of Contents
Related Manuals for deutherm FCB 1200-DC
Summary of Contents for deutherm FCB 1200-DC
- Page 1 INSTALLATION INSTRUCTIONS FCB 1200-DC outdoor / indoor free cooling system Item no. 890001 / 8 90010 Based on years of experience, we further developed the free The new cooling system and set new standards in performance, noise, original quality and environmental friendliness with the free cooling of mobile radio and fiber optic infrastructure.
-
Page 2: Table Of Contents
FC 4000 controllers deutherm cooling GmbH . . . . . . . . . . . . . . . . . . -
Page 3: Manual Description
WARNING: this controller contains a but- are of great importance and must be observed at all ton cell battery (CR-2032) on the circuit times . deutherm cooling GmbH accepts no liability for board. Do not swallow as it can cause Symbols used operational failures or personal injury resulting from choking and burns. -
Page 4: Disposal Of The Packaging
Recycling Conformity Disposal of the packaging Disposal of the old appliance The packaging is used for handling and protects the This appliance is designed for a long service life . At the appliance from damage during transportation . The end of its service life, please recycle the appliance in packaging materials are selected according to en- accordance with national regulations and with strict vironmental and disposal aspects and are generally... -
Page 5: General Functional Principle
Technical data General functional principle The FC 4000 controller controls the FCB 1200-DC outdoor or indoor free cooling units by analyzing the indoor and outdoor temperature . Optimally controls the indoor temperature and optimizes energy consumption to reduce energy costs . -
Page 6: Transportation And Unpacking
Spirit level and tape measure Scope of delivery Silicone press PRODUCT OUTDOOR INDOOR FCB 1200-DC-G4-OD FCB 1200-DC-G4-ID FC 4000 controller Recommendation for fastening material 8-pin control cable and power supply incl. plug for the FC 4000 controller Power connection, 2-pin plug Select the appropriate fastening material for the mounting surface . -
Page 7: Dimensions Of The Fcb 1200-Dc Outdoor
Structure of the FCB 1200-DC outdoor Dimensions of the FCB 1200-DC outdoor Rear view Side view Front view Front side FIG. 4: STRUCTURE OF THE FCB 1200-DC OUTDOOR Top view POSITION DESCRIPTION Front cover FIG. 3: DIMENSIONS OF THE FCB 1200-DC OUTDOOR... -
Page 8: Mounting The Fcb 1200-Dc Outdoor
. Core hole drilling Rectangular cut-out Pull out approx. 40 mm FIG. 5: PREPARING THE FCB 1200-DC OUTDOOR FOR INSTALLATION * Ground clearance: approx. 300 mm STEP DESCRIPTION Remove the four screws on the front cover and remove it . -
Page 9: Fig . 7: Mounting The Fcb 1200-Dc Outdoor
PROCEDURE Attach the mounting bracket, according to the specified dimensions, Hook the basic housing of the FCB 1200-DC outdoor with the roof into with at least four screws in the center above the opening . Ensure that the mounting bracket . -
Page 10: Connecting The Fcb 1200-Dc Outdoor
Connect the system to the 48 VDC power supply using the 2-pin plug . Top view Top view Top view Top view FC 4000 controller 48 VDC Grounding FIG. 10: DIMENSIONS OF THE FCB 1200-DC INDOOR FIG. 9: CONNECTING THE FCB 1200-DC OUTDOOR TO THE POWER SUPPLY air-based cooling systems 18 | 19... -
Page 11: Structure Of The Fcb 1200-Dc Indoor
Preparing the FCB 1200-DC indoor for installation NOTE: The front cover and filter must be removed for installation. Pull out approx. 40 mm FIG. 11: STRUCTURE OF THE FCB 1200-DC INDOOR FIG. 12: PREPARING THE FCB 1200-DC INDOOR FOR INSTALLATION POSITION DESCRIPTION STEP DESCRIPTION Front cover Remove the four screws on the front cover and remove it . -
Page 12: Mounting The Fcb 1200-Dc Indoor
NOTE: screws, serrated lock included. washers and dowels are not included. FIG. 13: MOUNTING THE FCB 1200-DC INDOOR - OPENING AND MOUNTING BRACKET FIG. 14: MOUNTING THE FCB 1200-DC INDOOR - FASTENING THE BASIC HOUSING air-based cooling systems 22 | 23... -
Page 13: Mounting The Airmaze Large
9 × NOTE: screws, serrated lock washers and dowels are not included. FIG. 15: MOUNTING THE FCB 1200-DC INDOOR - FASTENING THE AIR INLET HOOD FIG. 16: MOUNTING THE AIRMAZE LARGE - MOUNTING BRACKET/OUTDOOR TEMPERATURE SENSOR air-based cooling systems 24 | 25... -
Page 14: Fc 4000 Controllers
Grounding Seal the outer edges of the AirMaze with silicone . FIG. 18: CONNECTING THE FCB 1200-DC INDOOR TO THE POWER SUPPLY NOTE: the instructions for installing the FC 4000 controller can be found from page 28 onwards. NOTE: we recommend check- ing the silicone seal regularly for leaks. -
Page 15: Structure Of The Fc 4000 Controller
Fastening with four screws Attach the front cover (B) with the display to the basic housing (A) . Connect the FCB 1200-DC and its accesso- ries to the appropriate plugs and terminals . Attach the cables to the cable fasteners/ strain reliefs (C) provided for this purpose . -
Page 16: Overview Of Connection Details
Overview of connection details Rating max. values The FC 4000 controller operates FCB1 FCB2 with 48 VDC, max. 1 A, max. 100 W and controls up to: CONNECTION POWER ELECTRICITY VOLTAGE CONDUCTOR Outdoor temp . 1 Not used 2 × free cooling systems/cooling fans 10 Outdoor temp . -
Page 17: Essential Connections
Essential connections Optional connections Connection to the FCB 1200-DC “FCB1” and “FCB2” / power supply Connecting the hotspot sensor “Hotspot” First connect the FC 4000 controller The hotspot sensor is an additional to the FCB 1200-DC using the 8-pin measuring point for particularly connection cable . -
Page 18: Connection Of External Air Condition 1 And 2
Alarm Alarm In - Ethernet • Pin 6 = 24 VDC close (cable 2 *) 24 VDC * for deutherm-motorized dampers • Pin 1 = -24 VDC • Pin 2 = +24 VDC 24 VDC open 24 VDC close Potential-free Potential-free FIG. -
Page 19: Connection Of Up To Four External Alarms
Connection of up to four external alarms Connection of digital inputs Assignment as NC (normally closed): Assignment as NO (normally open): The connected equipment can be controlled externally using the digital inputs . The factory default settings can be changed in the parameterization file if required . •... -
Page 20: Initial Start-Up
Digital input 3 “Digital in 3” Installation check Connect digital input 3 with two wires: STEP PROCEDURE Hotspot Heater Alarm Alarm Digital Room Damper Alarm Alarm In - Ethernet • Wire 1 to pin 1 • Wire 2 to pin 4 Start the self-test (automatic or manual) to ensure that the system has been set up and connected correctly . -
Page 21: Service
Air direction Air direction Pull out approx. 40 mm Pull out approx. 40 mm FIG. 34: FILTER CHANGE FCB 1200-DC OUTDOOR FIG. 35: FILTER CHANGE FCB 1200-DC INDOOR STEP DESCRIPTION STEP DESCRIPTION Remove the four screws on the front cover and remove it . -
Page 22: Accessories And Spare Parts
Temperature sensor 421612 Opening: 349 × 349 mm Cable length: 8 m AirMaze Cube 220130 for the FCB 1200-DC-G4-OD RAL 7035 Dimensions: 580 × 580 × 490 mm All internal dimensions, unless otherwise indicated . AirMaze large 220110 Spare parts... -
Page 23: List Of Figures
FCB 1200-DC indoor . . . . . . . . . . . . . . . . . . 19... - Page 24 Notes air-based cooling systems 46 | 47...
-
Page 25: Support
Tel .: +49 (0) 8234 . 9 66 3 966 Mail: support@deutherm .eu deutherm FCB 1200-DC outdoor/indoor Installation instructions (Vers. 5 / O ct. 2024) Current versions of the instruction manual as PDF in German and English, can be found at www .deutherm .eu/en/downloads .html...
