Summary of Contents for HY-CLOR HYCINV10
- Page 1 INVERTER VARIABLE SPEED POOL PUMP INSTALLATION & OPERATION MANUAL Suits: HYCINV10 (SMP7502E) 1 HP & HYCINV15 (SMP1102E) 1.5HP Version 1.3...
-
Page 2: Table Of Contents
Contents 1.0 INTRODUCTION 1.1 CARTON CONTENTS 2.0 SAFETY INFORMATION + WARNINGS 2.1 INSTALLATION AND HAZARDOUS SUCTION: 2.2 ELECTRICAL SAFETY: 2.3 OPERATIONAL GUIDELINES: 3.0 TECHNICAL SPECIFICATIONS 3.1 PUMP SIZE CHART 4.0 INSTALLATION 4.1 PUMP LOCATION 4.2 PLUMBING CONNECTION 4.3 ELECTRICAL CONNECTION 5.0 START UP &... -
Page 3: Introduction
1.0 INTRODUCTION Congratulations on your choice of the Hy-Clor Inverter Pool pump. It is rated at 6 stars and designed specifically for your pool or spa. When used correctly, this Belgian-designed pump will save you money on energy costs while maintaining whisper-quiet operation and keeping your pool sparkling clean all year round. -
Page 4: Carton Contents
1.1 CARTON CONTENTS Item Description 1,2,3 Union Set 40 + 50mm 2 Sets Motor Drain Set 2 Sets 7,8,9 Lid Kit 1 Set Pump Basket N/A Manual PRODUCT HELPLINE AU: 1800 625 123 help@hyclor.com.au NZ: (09) 973 2477 www.hyclor.com.au... -
Page 5: Safety Information + Warnings
2.0 SAFETY INFORMATION + WARNINGS 2.1 INSTALLATION AND HAZARDOUS SUCTION: WARNING: Hazardous Suction. Pump suction is hazardous and can trap hair and body parts, resulting in severe injury or death. Do not block filtration suction lines with any part of your body. If someone becomes trapped, immediately turn the pump off. -
Page 6: Technical Specifications
Min/Max. Recommend Max Pool Suggested MODEL Rate Power power head (m) Pool Size Size filter size (LPM) HYCINV10 1.9m (LOW) 24 - 25 inch 750W 45,000lt 65,000lt 1050-3450 (SMP7502E) 13.5m (FULL) Sand Filter HYCINV15 2.1m (LOW) 25 – 28 inch... - Page 7 HYCINV10 (SMP7502E) Performance Curve Full Speed Power usage 750W High Speed Power usage 440W Medi Speed Power usage 150W 417.5 LPM Low Speed at 2.4 (m) 340.3 LPM at 1.8 (m) Power usage 58W 224.5 LPM 140.00 LPM at 1.2 (m) at 0.91 (m)
-
Page 8: Pump Size Chart
3.1 PUMP SIZE CHART Pump (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) HYCINV10 190.1 179.5 129.5 227.9 151.4 196.1 1700 336.2 (SMP7502E) HYCINV15 190.1 179.5 129.5 244.5 151.4 196.1 1700 336.2 (SMP1102E) SIDE VIEW BOTTOM VIEW... -
Page 9: Installation
4.0 INSTALLATION The pump is designed and to be maintained as the of the Australian standard for swimming pools and water quality (AS3633). 4.1 PUMP LOCATION The pump should be placed as close to the water as practical in accordance with any relevant regulations or recommendations. -
Page 10: Plumbing Connection
4.2 PLUMBING CONNECTION The piping should be as direct and free from turns or bends as, possible as elbows and other fittings can greatly increase friction losses. If the pump is located below water level, isolation valves must be installed on both sides of the pump to prevent the back flow of pool water during any routine or required servicing. -
Page 11: Start Up & Operation
5.0 START UP & OPERATION 5.1 GENERAL START UP GUIDE CAUTION: Never run the pump without water. Running the pump “dry” for any length of time can cause severe damage to both the pump and the motor and will void the warranty. Make sure all piping is clear of debris and has been properly pressure tested especially in the case of a new construction. -
Page 12: Ongoing Operation
5.2 ONGOING OPERATION The HYCLOR INVERTER PUMP comes with Factory Preset speeds, MODE APPLICATION BEST SUITED FOR (1hp) (1.5hp) 1050 1050 Maximum energy saving MEDI 1650 1400 Slightly boosted speed for filtration + chlorination. Gentle spa jet action and filtrations at times of heavier pool use. (Suction HIGH 2500 2450... -
Page 13: Programming The Pump
6.0 PROGRAMMING THE PUMP 6.1 DISPLAY SCREEN EXPLAINED 6.1.1 MANUAL MODE: Time Current RPM of motor The percentage you are saving compated to Full Speed. Current SET Current Watts used RPM of motor Current setting Current speed setting 6.1.2 AUTO MODE: Time Current RPM of motor... -
Page 14: Priming Mode
It will remember the user set speed “Mode” and turn on when power is restored. The HY-CLOR inverter pump will automatically start at “FULL” speed for 3 minutes to ensure the pump is primed completely before changing over to the user’s set speed mode. -
Page 15: Auto Mode
6.3 AUTO MODE This mode is suited for users that do not have an external timer and want the pump to be self-sufficient. Note: Auto Mode will not function until “Current Time” and “Timers” & “Speeds Parameters” are programmed. Follow the instructions below to program Current Time and the Times &... -
Page 16: Regular Service And Maintenance
IV. Noisy Pump. As with all mechanical devices, if more noise than usual is heard coming from the pump, notify HY-CLOR. A noise can indicate a fault and the longer this is left unattended the risk of increased damage can occur resulting in an expensive repair or replacement. -
Page 17: Error Codes + Troubleshooting
(see 9.0). motor will not turn 2. Bearing damage / fro- 2. Contact HY-CLOR or take pump to zen the motor shaft. repair technician. 1. The pump will try to restart in 6 seconds automatically if it is not The output amperage is damaged. -
Page 18: General Pump Troubleshooting
8.2 GENERAL PUMP TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Make sure see-through lid and O-rings are clean and are properly positioned. Hand tighten the see through lid. Tighten all unions and fittings on suction side of pump. A: Suction air leak Be sure water in pool is high enough to flow through to the skimmer (make sure skimmer flap is open and not stuck closed) Remove pool cleaner. -
Page 19: How To Check The Impeller
This is a daunting task. If you are unsure how to do this, please read through the entire process before attempting to open the pump. HY-CLOR recommend you take the pump to a local pool shop or pump repair establishment to conduct checks on the impeller as electrical components will be exposed when undertaking this task. - Page 20 Step 6: A metal plate is held in place. Inspect it for Step 7: The diffuser will either stay attached over the wear/ warping. Behind this plate is another thicker impeller requiring removal or will come part with the O-Ring. shell of the body.
-
Page 21: Pump Spare Parts + Breakdown
10.0 PUMP SPARE PARTS + BREAKDOWN Number: Part Name 4 + 5 + 8 SCREEN MODULE KIT (SMP7502E) SPINV-CM-KIT01 4 + 5 + 8 SCREEN MODULE KIT (SMP1102E) SPINV-CM-KIT02 6 + 7 DISPLAY TRANSPARENT COVER SPINV-TC-KIT 10 + 14 + 18 + 24 + 40 INTERNAL ORING KIT SPINV-INOR-KIT 13 + (35-11) -
Page 22: Warranty Terms And Conditions
All mechanical swimming pool products supplied to consumers by HY-CLOR are to be installed or used in the Modifications to any electrical product provided by HY- manner they are manufactured for only.
