Shini SIFRA-200 Manual

Shini SIFRA-200 Manual

Intelligent flow regulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SIFRA
Intelligent Flow Regulator
Date: Jul. 2023
Version: Ver. A (English)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIFRA-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Shini SIFRA-200

Summary of Contents for Shini SIFRA-200

  • Page 1 SIFRA Intelligent Flow Regulator Date: Jul. 2023 Version: Ver. A (English)

  • Page 2: Table Of Contents

    Contents General Description ..................4 1.1 Coding Principle ..................5 1.2 Feature ....................5 1.3 Options ....................5 1.4 Accessory ....................5 1.5 Technical Specifications ................. 7 1.6 Safety Regulations .................. 8 1.6.1 Safety Signs and Labels ............... 8 1.7 Exemption Clause ................... 9 Structural Features and Working Principle ..........
  • Page 3 6.3.6 Half-yearly Checking ..............23 6.3.7 Yearly Checking ................. 23 Table Index Table 1-1：Specifications ..................7 Table 1-2：Installation Dimension Table ............. 7 Table 4-1：Centralized Flow Monitoring Screen Description ......15 Table 4-2：Flow Trend Chart Screen Description ..........16 Table 4-3：Press Buttons on the Alarm Record Screen ........17 Table 4-4：Comm.

  • Page 4: General Description

    1. General Description Read this manual carefully before operation to prevent damage of the machine or personal injuries. SIFR(A) series intelligent flow regulator is designed to work with water heater, water chiller or cooling tower that can connect with multiple mould interfaces. Its functions of temperature, flowrate monitoring and control can adapt to different working conditions.

  • Page 5: Coding Principle

    Coding Principle Notes: * SIFR(A)-400, the number of manifold loop is 4, and the loop is 4-in 4-out. SIFR(A)-800, the number of manifold loop is 8, and the loop is 8-in 8-out. Feature 1) Digital flow and temperature monitoring system can monitor the flowrate, temperature and pressure of each pipe in real time, which can display instant mould loop blockage to avoid the rejects.
  • Page 6 Chapter 6, which contains service instructions intended for service engineers. Other chapters contain instructions for the daily operator. Any modifications of the machine must be approved by SHINI in order to avoid personal injury and damage to machine. We shall not be liable for any damage caused by unauthorized change of the machine.

  • Page 7: Technical Specifications

    Working temperature 0~120℃ Measuring range 1-18 L/min Working pressure 0~100℃, max 16bar 100~120℃, max 8bar To mould/return mould 3/8”PT Main pipe in/out 3/4”PT Power 1Φ 230V,50/60Hz Table 1-2：Installation Dimension Table Model SIFRA-200 SIFRA-400 SIFRA-600 SIFRA-800 SIFRA-1000 SIFRA-1200 Dimensions 1116 A（mm） 7(25)

  • Page 8: Safety Regulations

    Safety Regulations Strictly abide by the following safety regulations to prevent damage of the machine or personal injuries. 1.6.1 Safety Signs and Labels Danger! The unit is designed to endure high temp, and high pressure. For safe operation, do not remove the covers or switches. Attention! The unit should be operated by qualified personnel only.

  • Page 9: Exemption Clause

    The following statements clarify the responsibilities and regulations born by any buyer or user who purchases products and accessories from Shini (including employees and agents). Shini is exempted from liability for any costs, fees, claims and losses caused by reasons below: 1) Any careless or man-made installations, operation and maintenances upon machines without referring to the Manual prior to machine using.

  • Page 10: Structural Features And Working Principle

    2. Structural Features and Working Principle Working Principle Picture 2-1：Working Principle The circulating water enters the flow regulator through the water inlet; The circulating water enters the mould through the regulating valve 1; After circulating water enters the mould, it will enter the flow monitor through the regulator’s auto regulating valve, and measure the water flow and temperature data.

  • Page 11: Installation And Debugging

    3. Installation and Debugging Attention 1) The maximum flow rate of the water inlet shall not be greater than the maximum throughput of the regulator (the maximum flow rate of each loop is 18L/min). 2) This regulator can only be used for water purification, not for other liquids or gases.

  • Page 12: Power Connection

    Picture 3-2：Main Pipeline Inlet / Outlet Connection Diagram Power Connection 1) Make sure the voltage and frequency of the power source comply with those indicated on the manufacturer nameplate that attached to the machine. 2) Power cable and earth connection should conform to your local regulations.

  • Page 13: Operation

    4. Operation Operation Procedure for HMI 1) Do not use keen-edged object instead of hands to operate the touch screen, and prevent violent collision of it. 2) In a dry environment, static electricity may accumulate on the touch screen. Use a metal wire to discharge it before operating. 3) Use alcohol or eleoptene to wipe off the pollutants on the screen.

  • Page 14: Specification

    Picture 4-3：System Flow Chart Specification 4.4.1 System Initialization Screen After connecting through the power, the touch screen displays the "Initialization" screen and then it enters the "Language Selection" screen, as shown in the figure below: Picture 4-4：Language Selection Screen 4.4.2 Centralized Flow Monitoring Screen Select the Chinese or English by touching the <CHIN>or<ENG>...
  • Page 15 Picture 4-5： Centralized Flow Monitoring Screen Table 4-1：Centralized Flow Monitoring Screen Description Function Icon Name Description Type Pipeline switch operate Pipeline start /stop button Flow setting operate Enter the set flow value Total flow display Total flow of all pipelines display Water inlet display...
  • Page 16 Setting button operate Click to enter the system setting screen Alarm operate, Information Click to enter the alarm setting screen display button 4.4.2.1 Flow trend chart screen Press the <HOME> button in the "Centralized Flow Monitoring" screen to return to the "Language Selection"...
  • Page 17 4.4.2.1 Temperature trend chart screen Press the < Temp. Chart > button in the "Centralized Flow Monitoring" screen to enter the "Temp. Trend "screen. Picture 4-7：Temp. Trend Chart Screen 4.4.2.2 Alarm record screen Press the < Alarm Information > button in the "Centralized Flow Monitoring" screen to enter the "Alarm Information Display"...
  • Page 18 volume Operate It means mute button 4.4.2.3 Alarm recipe setting screen Press the <Recipe> button in the "Centralized Flow Monitoring" screen to enter the "Alarm Recipe Setting" screen (Temp. unit:℃, Flow unit: L /min.). Picture 4-9：Alarm Recipe Parameter Setting Screen Alarm parameter recipe setting: 1) Define a recipe name 2) Set the alarm parameters;...
  • Page 19 Picture 4-10：System Setting Screen 4.4.2.4.1 Parameter setting screen Press the < Parameter Setting> button in the "System Setting" screen, input the password and enter the "Parameter Setting" screen. In this screen, customers can set high and low alarm values for flow or temperature as needed, as well as deviation values (temp.).
  • Page 20 Picture 4-12：Comm. Parameter Setting Screen Table 4-4：Comm. Address Comm. protocol MODBUS-RTU Comm. unit No. Comm. speed 19200 Check bit None Stop bit Note: Please refer to the Appendixes for the controller’s comm. address. 20(25)

  • Page 21: Trouble-Shooting

    Trouble-shooting Table 5-1：Trouble-shooting Symptom Possible causes Solution 1. Replace the power switch. After powering on, the touch 1.Main power switch broken 2. Check the power circuit and panel has no display. 2.Power circuit fault replace the fuse 1. Check the sensor circuit and 1.Sensor fault sensor.

  • Page 22: Maintenance And Repair

    Maintenance and Repair 1) When inspecting the machine, it is necessary to cut off the power supply, discharge the pressure and water first, and ensure the inspection and maintenance space before operation. 2) In order to prolong the service life of the system and safety accidents, it must carry out regular inspection.

  • Page 23: Weekly Checking

    Check the switch of the machine. Check all the electrical wires. 6.3.4 Weekly Checking Check loose electrical connections. Check the flow sensor Check whether the pipe connector is loose 6.3.5 Monthly Checking Check the sensitivity of the flow sensor Clean the flow sensor 6.3.6 Half-yearly Checking Check whether the pipe connector is loose Check whether the indicator is working properly.
  • Page 24 Appendix Table 6-1：Comm. Address D-Map（40000+i) Name Range Type The 1 circuit flow 1-18L/min read only 0-120 ℃ The 2 circuit temp. read only The 2 circuit flow 1-18L/min read only 0-120 ℃ The 2 circuit temp. read only The 3 circuit flow 1-18L/min read only...
  • Page 25 The 5 circuit flow setting 1-18L/min read /write The 6 circuit flow setting 1-18L/min read /write The 7 circuit flow setting 1-18L/min read /write The 8 circuit flow setting 1-18L/min read /write The 9 circuit flow setting 1-18L/min read /write The 10 circuit flow setting 1-18L/min...

This manual is also suitable for:

Sifra-400Sifra-600Sifra-800Sifra-1000Sifra-1200
