ORDER NO. BSD0109M622
Digital Video Cassette Recorder / Component Serial Interface Board /
Digital Video Interface Board / Cassette Adapter
AJ-D455E/MC / AJ-YA455P / AJ-YAD455P / AJ-CS455P
2001 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
Please refer to the Operating Instructions in the appendix folder.
/
(Go to Appendix List)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AJ-D455E/MC and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic AJ-D455E/MC

Summary of Contents for Panasonic AJ-D455E/MC

  • Page 1 Digital Video Cassette Recorder / Component Serial Interface Board / Digital Video Interface Board / Cassette Adapter AJ-D455E/MC / AJ-YA455P / AJ-YAD455P / AJ-CS455P 2001 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 3 SAFETY PRECAUTIONS GENERAL GUIDELINES 1. When servicing, observe the original lead dress. If a short / circuit is found, replace all parts which have been over-heated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 4: Electrostatically Sensitive (Es) Devices

    LEAKAGE CURRENT HOT CHECK (See Figure 1) 1. Plug the AC cord directly into the AC outlet. / Do not use an isolation transformer for this check. 2. Connect a 1.5k , 10W resistor, in parallel with a 0.15 F capacitor, between each exposed metallic part on the set an a good earth ground such as a water pipe, as shown in Figure1.
  • Page 5 obtain and wear a commercially available discharging wrist trap device, which should be removed for potential shock reasons prior to applying power to the unit under test. 2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
  • Page 6 3. Measure the High Voltage. The meter (electric type) reading should indicate 2.5kV, 0.15kV. If the meter indication is out of tolerance, immediate service and correction is required to prevent the possibility of premature component failure. To prevent an x-radiation possibility, it is essential to use the specified picture tube.

  • Page 8: Schematic Diagrams

    1. Service Information 2. Disassembly Procedures 3. Electrical Adjustment 4. Block Diagrams Note for printing “Page Size” is originally set to “A3” in the PDF file for the Block Diagrams. To print then in A4-Size, change print setting in Acrobat reader as follows.
  • Page 9 NOTE BE SURE TO MAKE YOUR ORDERS OF REPLACEMENT PARTS ACCORDING TO PARTS LIST. CAUTION MARK INDICATES THE PRIMARY CIRCUIT TO DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. / PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK DURING REPAIR AN SERVICE OF THE PRODUCTS.
  • Page 10 5.11. MOTHER (VEP80C14A) 5.12. MECHA IF (VEP82239A) 5.13. MECHA IF2 (VEP82240A) 5.14. POWER1 (VEP81221B) 5.15. POWER2 (VEP81222A) 5.16. AV JACK (VEP80C13A) 5.17. DV uCOM (VEP83560A) 5.18. FRONT (VEP86315A) 5.19. HP (VEP80C15A) 5.20. EJECT (VEP80C16A) 5.21. DIF JACK (VEP80C21A) 5.22. F3B:DIF (AJ-YAD455P) OPTION (VEP83559A) 6.

  • Page 11: Important Safety Notice

    6.5. CSP SUB P.C.BOARD (VEP83555A) 6.6. F5:V IN P.C.BOARD (VEP83553B) 6.7. F6:SYSCON P.C.BOARD (VEP86314B) 6.8. F7:SERVO P.C.BOARD (VEP82238B) 6.9. RF CUE P.C.BOARD (VEP85197A) 6.10. F8:RF EQ P.C.BOARD (VEP85196A) 6.11. MOTHER P.C.BOARD (VEP80C14A) 6.12. MECHA IF P.C.BOARD (VEP82239A) 6.13. MECHA IF2 P.C.BOARD (VEP82240A) 6.14.

  • Page 12: Electrical Replacement Parts List

    8. Electrical Replacement Parts List NOTE: 1. Be sure to make your orders of replacement parts according to this list. 2. Unless otherwise specified, all resistors are in OHMS, K=1,000 OHMS, all capacitors are in MICROFARADS ( F), P= 3. The P.C. Board untils marked with " "...
  • Page 13 OVERALL BLOCK DIAGRAM...
  • Page 14 F1:AUDIO BLOCK DIAGRAM IC4504, IC4507<6>...
  • Page 15 F2:VIDEO OUT BLOCK DIAGRAM IP202<3> IC568<10>...
  • Page 16 F4:D PROCESS BLOCK DIAGRAM (1/3) IC3631 <18> IC3661 <19>...
  • Page 17 F4:D PROCESS BLOCK DIAGRAM (2/3)
  • Page 18 F4:D PROCESS BLOCK DIAGRAM PB BLOCK DIAGRAM(3/3)
  • Page 19 F5:VIDEO IN BLOCK DIAGRAM IC3630<13>...
  • Page 20 F6:SYSCON BLOCK DIAGRAM (1/2)
  • Page 21 F6:SYSCON BLOCK DIAGRAM (2/2)

  • Page 22: Front Block Diagram

    FRONT BLOCK DIAGRAM IC7 <2>...
  • Page 23 F7:SERVO BLOCK DIAGRAM...
  • Page 24 RF CUE BLOCK DIAGRAM IC5101<2>...
  • Page 25 F8:RF/EQ BLOCK DIAGRAM...
  • Page 26 F3A:SDI BLOCK DIAGRAM (AJ-YA455P)
  • Page 27 F3B: DIF BLOCK DIAGRAM (AJ-YAD455P) IP401<4> DIF JACK C.B.A.
  • Page 32 F3A SDI P.C. BOARD (VEP83558A) (AJ-YA455P) COMPONENT SIDE IC3100 IC3101 IC3201 IC3203 IC3204 IC3300 IC3301 IC3400 IC3401 IC3402 IC3502 IC3507 IP3503 P3000 P3500 TG3000 TG3200 TG3400 TP3500 TP3501 TP3503 TP3504 TP3505 TP3506 TP3507 TP3508 TP3509 TP3510 TP3511 TP3512 TP3513 TP3514 TP3515 TP3516 TP3517...
  • Page 35 CSP SUB P.C. BOARD (VEP83555A) COMPONENT SIDE IC3101 IC3200 IC3201 IC3300 IC3400 IC3501 P3000 (COMPONENT SIDE) FOIL SIDE IC3100 IC3202 IC3203 IC3204 IC3500 TP3100 TP3101 TP3102 TP3103 TP3104 TP3200 TP3201 TP3202 TP3204 TP3205 TP3207 TP3208 TP3209 TP3210 TP3211 TP3213 TP3300 TP3301 TP3400 TP3401...
  • Page 42 RF CUE P.C. BOARD (VEP85197A) COMPONENT SIDE IC4001 Q5007 IC4002 Q5008 IC4005 Q5011 IC4006 Q5012 IC5001 Q5013 IC5002 Q5014 IC5003 Q5101 IC5004 Q5102 IC5005 Q5103 IC5006 Q5111 IC5007 Q5116 IC5012 Q5117 IC5101 Q5121 IC5103 Q5126 IC5104 Q5127 IC5201 Q5202 IC5202 Q5203 IC5203 Q5204...
  • Page 43 F8 RF EQ P.C. BOARD (VEP85196A) COMPONENT SIDE IC5001 Q5405 IC5002 Q5408 IC5003 Q5411 IC5004 Q5412 IC5005 Q5413 IC5007 Q5415 IC5009 QR5201 IC5010 TG5001 IC5101 TG5002 IC5103 TG5003 IC5104 TG5004 IC5105 TP5001 IC5108 TP5002 IC5110 TP5003 IC5201 TP5005 IC5202 TP5006 IC5203 TP5007 IC5401...
  • Page 46 MECHA IF P.C. BOARD (VEP82239A) COMPONENT SIDE P151 IC151 Q101 IC152 Q102 IC153 Q103 IC154 Q104 IC155 Q106 IC156 Q107 IC157 Q108 QR101 QR102 QR103 QR104 QR105 QR106 QR107 QR108 QR109 QR110 QR111 QR112 VR201 VR202 (COMPONENT SIDE) FOIL SIDE P151 VR201 VR202...
  • Page 47 MECHA IF2 P.C.BOARD (VEP82240A) (COMPONENT SIDE) (FOIL SIDE) CBA-20...
  • Page 48 POWER1 P.C. BOARD (VEP81221B) COMPONENT SIDE IC1001 IC1101 IC1102 IC1103 IC1201 IC1202 IC1203 IC1205 P1103 P1201 P1202 Q1001 Q1002 Q1003 Q1004 Q1102 Q1103 VR1102 VR1201 (COMPONENT SIDE) CBA-21...
  • Page 49 POWER1 P.C. BOARD (VEP81221B) FOIL SIDE IC1001 IC1101 IC1102 IC1103 IC1201 IC1202 IC1203 IC1204 IC1205 P1103 P1201 P1202 Q1001 Q1002 Q1003 Q1004 Q1101 Q1102 Q1103 Q1201 Q1202 Q1203 Q1204 QR1001 QR1002 QR1101 QR1102 QR1103 QR1104 QR1105 QR1201 QR1202 QR1203 QR1204 QR1205 QR1206 QR1207...
  • Page 53 DV u COM P.C. BOARD (VEP83560A) (COMPONENT SIDE) (FOIL SIDE) HP P.C. BOARD (VEP80C15A) COMPONENT SIDE FOIL SIDE IC1001 P1001 Q1001 VR1001 Q1002 VR1001 P1001 (COMPONENT SIDE) (FOIL SIDE) CBA-26...
  • Page 54 F3B DIF / DIF JACK P.C.BOARD (VEP83559A / VEP80C21A) (AJ-YAD455P) COMPONENT SIDE IC206 IC902 SW301 TP619 TP660 TP901 IC207 IC903 SW701 TP620 TP661 TP902 IC208 IP401 TG201 TP621 TP662 TP903 IC209 IP702 TG202 TP626 TP663 IC301 IP703 TG203 TP628 TP701 IC402 P101 TG204...
  • Page 55 F3B DIF / DIF JACK P.C.BOARD (VEP83559A / VEP80C21A) (AJ-YAD455P) FOIL SIDE IC201 TP303 IC202 TP304 IC203 TP305 IC204 TP401 IC210 TP402 IC211 TP403 IC302 TP404 IC802 TP405 P101 TP406 P501 TP709 QR301 TP710 QR302 TP711 SW201 TP712 TP301 TP713 (FOIL SIDE) TP302 TP715...

  • Page 56: Cassette Adapter

    Sec. 1 Service Information Sec. 2 Disassembly Procedures Sec. 3 Electrical Adjustment Digital Video Cassette Recorder Sec. 4 Block Diagrams AJ-D455E/MC Sec. 5 Schematic Diagrams Sec. 6 Circuit Board Diagrams Component Serial Interface Board Sec. 7 Exploded Views & AJ-YA455P...
  • Page 57 Any attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death. AJ-D455E/MC - 2 -...
  • Page 58 AJ-YA455P AJ-YAD455P - 3 -...

  • Page 59: General Guidelines

    SAFETY PRECAUTIONS ELECTROSTATICALLY SENSITIVE (ES) DEVICES GENERAL GUIDELINES Some semiconductor (solid state) devices can be damaged 1. When servicing, observe the original lead dress. If a easily by static electricity. Such components commonly are short circuit is found, replace all parts which have been called Electrostatically sensitive (ED) Devices.
  • Page 60 - 5 -...
  • Page 61 - 6 -...
  • Page 62 Printed in Japan FCD0109NCKK80/E362/E363...
  • Page 63 DISASSEMBLE PROCEDURES 1-1. Removal of Top Panel 1-3. Removal of Front Panel 1. Loosen s screws (A) and remove the Top Panel. 1. Unscrew the 4 screws (A) and remove the Front Panel. Screws (A) Screws (A) Notes:1. When remove the Front Panel, slightly pull the Front panel for direction in arrow (a) 1-2.
  • Page 64 3. Disconnect 2 connectors (A) at Front Loading 5. Unscrew the 4 screws (A) and (B), then remove the motor Board and the Interconnection Board. Front Loading Unit. Screws (B) Interconnection Board Front Loading Motor Part Screws (A) Connectors (A) 4.

  • Page 65: Removal Of Fan Motor

    1-6. Removal of Cylinder Unit 1. Remove the Mechanism Unit. Refer to item 1-5. 2. Unscrew a screw (A). 3. Unscrew the 2 screws (B) and remove the T1 Guide. Screws (A) Connector (B) T1Guide Screw (A) Screws (B) Notes: 1.
  • Page 66 ELECTRICAL REPLACEMENT PARTS LIST (AJ-D455E/MC) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C4220 EEVHB1C220 E.CAPACITOR VEP84374A F1 AUDIO P.C.BOARD0 1 (RTL) C4221,22 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C4223 EEVHB1C100 E.CAPACITOR VEP83557B F2 V OUT P.C.BOARD0...
  • Page 67 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D4407 MA142WK DIODE R4108-11 ERJ3RBD123 M.RESISTOR CH 1/16W 12K D4800 MA716 DIODE R4112 ERJ3RBD202 M.RESISTOR CH 1/16W D4900 MA152A DIODE R4113 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K D4901 MA157 DIODE...
  • Page 68 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R4302 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K R4521,22 ERJ3GEY0R00 M.RESISTOR CH 1/16W R4304,05 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K R4523 ERJ3GEYG102 M.RESISTOR CH 1/16W R4308 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K R4524,25 ERJ3GEY0R00...
  • Page 69 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R4922 ERJ3RBD822 M.RESISTOR CH 1/16W 8.2K C308 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R4923 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K C309,10 ECUM1C105KBM C.CAPACITOR CH 16V R4924 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K C311...
  • Page 70 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C578,79 EEVHB0J470 E.CAPACITOR 6.3V IC453 NJM2534V C580-83 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC454 XC62DN5002P C584 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U IC455 AD8055AR C585,86 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC456 XC62FP5002P C587...
  • Page 71 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR500 UN5113 TRANSISTOR-RESISTOR R426-31 ERJ6GEYG121 M.RESISTOR CH 1/10W 120 QR501 UN5213 TRANSISTOR-RESISTOR R432 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K QR700 UN5213 TRANSISTOR-RESISTOR R433 ERJ6RED750 M.RESISTOR CH 1/10W R434 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K...
  • Page 72 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R560 ERJ3GEYJ224 M.RESISTOR CH 1/16W 220K VR456 EVMEGSA00B13 V.RESISTOR R561 ERJ3GEYJ684 M.RESISTOR CH 1/16W 680K VR560 EVMEGSA00B14 V.RESISTOR R562 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K VR600 EVMEGSA00B14 V.RESISTOR R563...
  • Page 73 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3228 ECUX1H100CCV C.CAPACITOR CH 50V C4313 EEVHB0J101 E.CAPACITOR 6.3V 100U C3230 EEVHP1E3R3 E.CAPACITOR 25V 3.3U C4314,15 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3232 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C4316 ECUX1H102KBV C.CAPACITOR CH 50V 1000P C3233...
  • Page 74 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3210 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 1 FOR VEP83555A IP3101,02 C1ZBZ0001555 R3211 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 1 FOR VEP83555A R3212 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 1 FOR VEP83555A JP3000 VJR1008...
  • Page 75 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3403 ERJ3GEYG102 M.RESISTOR CH 1/16W 1 FOR VEP83555A R3404 ERJ3GEYJ223 M.RESISTOR CH 1/16W 22K 1 FOR VEP83555A R3406 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 1 FOR VEP83555A C3001 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R3407...
  • Page 76 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3321,22 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3561 ECUX1H102JCV C.CAPACITOR CH 50V 1000P C3323 ECUX1H220JCV C.CAPACITOR CH 50V C3562 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3325-30 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3563 ECUX1H681JCV C.CAPACITOR CH 50V 680P...
  • Page 77 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3827 EEVHB0J470 E.CAPACITOR 6.3V IC3632 THC4053FT C3828 EEVHB1C470 E.CAPACITOR IC3633 NJM084M 1 C0ABFB000008 C3829,30 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC3700 NJM082BM 1 C0ABEB000017 C3831 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U IC3701 C0FBAF000042...
  • Page 78 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q3310 2SD601A TRANSISTOR R3161 ERJ3GEYJ394 M.RESISTOR CH 1/16W 390K Q3311 XN4601 TRANSISTOR-RESISTOR R3162 ERJ3GEYJ334 M.RESISTOR CH 1/16W 330K Q3312 2SD601A TRANSISTOR R3163 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K Q3313 2SB709A TRANSISTOR...
  • Page 79 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3347,48 ERJ3GEYJ470 M.RESISTOR CH 1/16W R3491 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 R3349 ERJ3GEYJ393 M.RESISTOR CH 1/16W 39K R3492 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 R3350 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R3493...
  • Page 80 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3653 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R3823 ERJ3GEYJ470 M.RESISTOR CH 1/16W R3654 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K R3826 ERJ3GEYG102 M.RESISTOR CH 1/16W R3655 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K R3827 ERJ3GEYJ182...
  • Page 81 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VC3500 VCV0047 TRIMMER C701-28 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U VR3401 EVMEASA00B53 V.RESISTOR MA716 DIODE VR3402 EVMEASA00B13 V.RESISTOR D252-56 MA716 DIODE VR3403 EVMEASA00B53 V.RESISTOR D301 MA147 DIODE VR3404...
  • Page 82 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks IC661 NVHC541MTCX R408 D1H84704A008 COMBI.R-R IC663 NVHC245MTCX R501 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K IC701,02 NJM084V R502 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K IC703,04 NVHC541MTCX R503 ERJ3GEYJ105 M.RESISTOR CH 1/16W IC705...
  • Page 83 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C458,59 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C500 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C501 EEUFC1V101 E.CAPACITOR 35V 100U C502,03 ECUX1H682KBV C.CAPACITOR CH 50V 6800P VEP82238B F7 SERVO P.C.BOARD0 1 (RTL) C504...
  • Page 84 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D355,56 MA142K DIODE IC658 NJM2903M 1 C0BBBA000019 D401,02 MA142K DIODE D403-06 MA716 DIODE VVVSI3567 SOFTWARE D407 MA147 DIODE ID201 VVVSI3566 SOFTWARE D450,51 MA728 DIODE D452,53 MA736 DIODE...
  • Page 85 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ERJ6GEYG272 M.RESISTOR CH 1/10W 2.7K R178,79 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K R180,81 ERJ3GEYJ123 M.RESISTOR CH 1/16W 12K ERJ3GEYJ823 M.RESISTOR CH 1/16W 82K R182,83 ERJ3GEYJ562 M.RESISTOR CH 1/16W 5.6K...
  • Page 86 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R507 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R679,80 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K R508 ERJ3GEYJ563 M.RESISTOR CH 1/16W 56K R681-83 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R509 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K...
  • Page 87 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C5145,46 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C5602 ECUM1C224KBN C.CAPACITOR CH 16V 0.22U C5147,48 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C5603 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U C5149,50 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C5604-11...
  • Page 88 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q5108-10 2SC3930 TRANSISTOR R5149 ERJ3RBD121 M.RESISTOR CH 1/16W 120 Q5111 XN5531 TRANSISTOR-RESISTOR R5150,51 ERJ3GEYG152 M.RESISTOR CH 1/16W 1.5K Q5112-15 2SC3930 TRANSISTOR R5152 ERJ3GEYJ470 M.RESISTOR CH 1/16W Q5201 XN5531 TRANSISTOR-RESISTOR...
  • Page 89 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R5323 ERJ3GEYJ470 M.RESISTOR CH 1/16W R5462,63 ERJ3GEYG102 M.RESISTOR CH 1/16W R5324 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R5464,65 ERJ3GEYJ470 M.RESISTOR CH 1/16W R5325 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 R5466 ERJ3RBD102 M.RESISTOR CH 1/16W...
  • Page 90 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks RY5051 VSY2176 RELAY 1 K6B2CDA00045 C5119-22 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C5123 ECUX1H121JCV C.CAPACITOR CH 50V 120P TG5001-04 EYF6CU TEST POINT C5124-27 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C5131 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U TP5001-03...
  • Page 91 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q4010 2SB779-R TRANSISTOR R4045 ERJ3GEYJ124 M.RESISTOR CH 1/16W 120K Q4011 2SD874-R TRANSISTOR R4046 ERJ3GEY0R00 M.RESISTOR CH 1/16W Q5001-04 2SC3935 TRANSISTOR R4047,48 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K Q5005,06 2SC2954 TRANSISTOR...
  • Page 92 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R5210 ERJ3RBD392 M.RESISTOR CH 1/16W 3.9K L1,L2 VLP0017 COIL 2 J0JHB0000010 R5211 ERJ3RBD102 M.RESISTOR CH 1/16W R5212 ERJ3RBD392 M.RESISTOR CH 1/16W 3.9K K1KB96A00048 CONNECTOR (FEMALE) R5213 ERJ3RBD102 M.RESISTOR CH 1/16W...
  • Page 93 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VJS3406B015 CONNECTOR (FEMALE) C1006 ECA1HXL010 E.CAPACITOR P34,35 VJS2889A017 CONNECTOR (FEMALE) 2 K1MN17A00008 C1007 ECQE6473KF P.CAPACITOR 630V 0.047U VJS3406B019 CONNECTOR (FEMALE) C1008 VCK0106K221 C.CAPACITOR 220P VJP3125B002 CONNECTOR (MALE) 1 K1KA02B00111...
  • Page 94 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D1113-15 SFPL-52 DIODE R1008,09 ERG3SJ333 M.RESISTOR 3W 33K D1116 MA3068-M DIODE R1010 ERG2SJ180 M.RESISTOR D1117 MA142K DIODE R1011 ERJ6RBD241 M.RESISTOR CH 1/10W 240 D1118 FML-G26S DIODE R1012...
  • Page 95 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R1233 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R1234 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K EEAHB1C470B E.CAPACITOR R1235 ERJ3GEYG102 M.RESISTOR CH 1/16W C3,C4 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R1237-39...
  • Page 96 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ERJ6GEYG681 M.RESISTOR CH 1/10W 680 IC14 NJM78L09UA 1 C0CBAHC00002 ERJ6GEYG220 M.RESISTOR CH 1/10W ERJ6GEYG101 M.RESISTOR CH 1/10W 100 L1,L2 VLF1151A132 COIL ERJ6GEYG220 M.RESISTOR CH 1/10W ERJ6GEYJ820 M.RESISTOR CH 1/10W K1KA22C00001...
  • Page 97 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q1001,02 2SD1328 TRANSISTOR R1001 ERJ3GEYG102 M.RESISTOR CH 1/16W R1002 ERJ3GEYJ122 M.RESISTOR CH 1/16W 1.2K R1003 ERJ3GEYJ273 M.RESISTOR CH 1/16W 27K R1004 ERJ6GEYG331 M.RESISTOR CH 1/10W 330 R1005 ERJ6GEYG271 M.RESISTOR CH 1/10W 270...
  • Page 98 ELECTRICAL REPLACEMENT PARTS LIST (AJ-YA455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks IC3404 XC62FP5002P C3000,01 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC3405 NVHC541MTCX IC C3002,03 EEVHB0J470 E.CAPACITOR 6.3V IC3500,01 NVHC541MTCX IC C3004-06 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC3502 C1ZBZ0001837...
  • Page 99 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3519 ERJ3GEY0R00 M.RESISTOR CH 1/16W R3520 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R3521 ERJ3GEY0R00 M.RESISTOR CH 1/16W R3522-24 D1H810140001 COMBI.R-R R3526 ERJ3RBD361 M.RESISTOR CH 1/16W 360 R3528 ERJ3RED510 M.RESISTOR CH 1/16W...
  • Page 100 ELECTRICAL REPLACEMENT PARTS LIST (AJ-YAD455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ID705 VVVSI3622 SOFTWARE VEP83559A DIF P.C.BOARD 1 (RTL) IP401 C3FBLD000046 VEP80C21A DIF JACK P.C.BOARD 1 (RTL) IP702 C3FBLD000046 L201-03 VLF1151A132 COIL L501,02...
  • Page 101 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R723 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R724 ERJ3GEYG102 M.RESISTOR CH 1/16W R726,27 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R728 ERJ3GEYJ182 M.RESISTOR CH 1/16W 1.8K R732 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R733...

  • Page 102: Power Supply Unit

    1. POWER SUPPLY UNIT 2. SERVO 2-1. SERVO FG Offset Adjustment 1-1. Power Supply Voltage Adjustment BOARD SERVO (F7) ----- BOARD POWER UNIT ADJ. Service Menu TP6 (+3.3V) (on the extension board) TAPE ----- ADJ. VR1201 (+3.3V) INPUT ----- TAPE ----- MODE EJECT...
  • Page 103 2-2. Reel Torque Gain Adjustment 2-3. Motor Torque Offset Adjustment BOARD SERVO (F7) ----- BOARD SERVO (F7) ADJ. Service Menu S,T REEL TABLE TAPE ----- ADJ. SERVICE MENU INPUT ----- TAPE ----- MODE EJECT INPUT ----- M. EQ Monitor TV MODE EJECT SPEC.
  • Page 104 Connect the Carriage tool (see the following 2-4. Tension Sensor Voltage figure) to connector P1 which is coming from the Adjustment (1) MECH. I/F board to Carriage board of the front loading unit. BOARD SERVO (F7) Open the SERVICE MENU. (Refer to SEC1 TP201 Service Information.) ADJ.
  • Page 105 2-6. PG Shifter Adjustment BOARD SERVO (F7) TP233 (RP HSW) TP320 (SPA) ADJ. Service Menu TAPE VFM3680KM/KL INPUT ----- MODE EJECT M. EQ Oscilloscope SPEC. T1, T2 = 126.4 ± 4µs Open the SERVICE MENU. (Refer to SEC1 Service Information.) Select the A00: SERVO ADJUST and press the “SET”...
  • Page 106 3. RF/EQ (F8) The adjustment of this section should be performed after adjusting the Servo (F7) board. This adjustment mainly uses the Service Menu. The procedures for opening the menu, changing the settings and closing the menu are described below. Opening the Service Menu a) Press the “MENU”...

  • Page 107: Adjust Menu

    Press the MENU button to return to the C00: PRO 3-1. Adjustment Data Initialization ADJUST menu. Open the C-3: PB ADJUT in the Service Menu. Initialize the adjustment values for the following items 10. Select the C32: IC READ and change the setting before starting the adjustment.
  • Page 108 3-3. Envelope Level Adjustment 3-4. Phase Compensation Adjustment BOARD RF/EQ (F8) TP20, TP10, TP2 (Trigger) BOARD RF/EQ (F8) ADJ. Service Menu Audiometer (Error Rate Display) TAPE 625(PAL): VFM3680KM (L)/VFM3110EDS ADJ. Service Menu. Alignment Tape (Colour Bar) TAPE 625(PAL): VFM3680KM (L)/VFM3110EDS INPUT Colour bar Alignment Tape (Colour Bar)

  • Page 109: Mode Play

    25. Select the D31: IC READ and change the setting 3-5. Confirmation of Error Rate and from “SINGLE” to “OFF”. Press the “SET” AEQ Tap Coefficient Values button. BOARD RF/EQ (F8) Audiometer (Error Rate Display). CH 1 ADJ. Service Menu TAPE 625(PAL): VFM3680KM (L)/VFM3110EDS CH 2...
  • Page 110 12. Set the numerical value of C01: REC CURR L 3-6. REC Frequency Characteristic and C03: REC CURR R as follows. and REC Current Adjustment C01: REC CURR L! ! ! ! -120 C03: REC CURR R! ! ! ! +120 (DVCPRO 25M) 13.
  • Page 111 12. Insert the DV alignment tape (VFM3110EDS) and 3-7. REC Frequency Characteristic play it back. and REC Current Adjustment 13. Confirm that the level difference between the TRACE B (Memorized self-recording playback (DV) spectrum) and TRACE A (Alignment tape playback spectrum) at 5 MHz is in the following BOARD EQ MAIN (H2) specification.

  • Page 112: Serial Out

    4. V OUT (F2) 4-1. Connection 4-9. Component Sync DC Adjustment 4-2. Reference PLL Center Frequency Adjustment 4-3. Reference CF Detection Adjustment 4-10. Component Y Level Adjustment 4-11. Component Pb Level Adjustment 4-4. Composite Sync DC Level Adjustment 4-5. Composite Y Level Adjustment 4-12.

  • Page 113: Frequency Adjustment

    4-2. Reference PLL Center 4-3. Reference CF Detection Frequency Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) TP600 (VCO) TP561 (Trigger) Composite Signal CF OUT, TP704 (CF) ADJ. VC600 (FREQ ADJ) TP702 (CF_TP2), TP703 (CF_TP1) TAPE ----- ADJ. VR560 (SCH DET) INPUT REF VIDEO IN...
  • Page 114 4-4. Composite Sync DC Level 4-6. Composite YC Timing Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) VIDEO OUT 1 (CH B) VIDEO OUT 1 (CH B) ADJ. VR452 (ENC SYNC DC) ADJ. VR456 (ENC C DL) TAPE 625(PAL): VFM3680KM (L) TAPE 625(PAL): VFM3680KM (L)
  • Page 115 4-8. System Sub-Carrier Phase 4-9. Component Sync DC Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) REF IN (CH A), VIDEO OUT 1 (CH B) Y OUT (CH B1) ADJ. VR600 (SYS SC) ADJ. VR301 (SYNC DC) TAPE 625(PAL): VFM3680KM (L) TAPE 625(PAL): VFM3680KM (L)
  • Page 116 4-11.Component Pb Level 4-13.Component Y-Pb Timing Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) Pb OUT (CH B2) Y OUT (CH B1), Pb OUT (CH B2) ADJ. VR400 (PB LEV) ADJ. VR302 (Pb DL) TAPE 625(PAL): VFM3680KM (L) TAPE 625(PAL): VFM3680KM (L) Alignment Tape (Color Bar)
  • Page 117 5. V IN (F5) 5-1. Connection and Menu Setting 5-17. Composite Pb Signal Offset level Adjustment 5-2. PL DC Adjustment 5-18. Composite Pr signal Offset level Adjustment 5-3. Composite Color Demodulation Timing Adjustment 5-19. Composite Pb signal Level Adjustment 5-20. Composite Pr Signal Level Adjustment 5-4.
  • Page 118 5-1. Connection and Menu Setting Select Wave Form Monitor AJ-D455E Signal Generator Ch A1 Y OUT (Termination ON) Component Y Y IN Ch A2 PB OUT (Termination ON) Component PB PB IN Ch A3 PR OUT (Termination ON) Component PR PR IN Ch A (Termination ON)
  • Page 119 5-2. PLL DC Adjustment 5-4. Composite SCH Detection Adjustment BOARD V IN (F5) TP552 (PLL DC) BOARD V IN (F5) ADJ. VC500 (VCO DC) TP980 (INCF), TP932, TP933 TAPE ----- ADJ. VR402 (SCH SITE) INPUT Analog Component Signal TAPE ----- (100% Color Bar) INPUT CF Signal...

  • Page 120: Timing Adjustment

    5-5. YC IN Color Demodulation 5-6. YC IN SCH Detection Timing Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) TP400, TP401 TP980 (INCF), TP932, TP933 ADJ. VR403 (RSTH YC), Service Menu ADJ. VR404 (SCH YC) TAPE ----- TAPE ----- INPUT Analog YC Signal...

  • Page 121: Level Adjustment

    5-7. Component Y signal level 5-8. Component Y Signal Offset Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Y OUT Component Y OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal INPUT Analog Component Signal (100% Color Bar)
  • Page 122 5-9. Component Pb Signal Offset 5-10.Component Pr signal Offset level Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component PB OUT Component PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal INPUT Analog Component Signal (0% Flat Field)
  • Page 123 5-11 Component Pb signal Level 5-12.Component Pr Signal Level Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component PB OUT Component PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal INPUT Analog Component Signal (100% Color Bar) (100% Color Bar)
  • Page 124 5-13.Component Pb Signal Timing 5-14.Component Pr Signal Timing Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component Pr OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal (Bowtie) INPUT Analog Component Signal (Bowtie) βCAM Level MODE...
  • Page 125 5-15.Composite Y signal Level 5-16.Composite Y Signal Offset Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Y OUT Component Y OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Composite Signal INPUT Analog Composite Signal (100% Color Bar) (100% Colour Bar)
  • Page 126 5-17.Composite Pb Signal Offset 5-18.Composite Pr signal Offset level Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component Pr OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Composite Signal INPUT Analog Composite Signal (0% Flat Field)
  • Page 127 5-19.Composite Pb signal Level 5-20.Composite Pr Signal Level Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Composite PB OUT Composite PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Composite Signal INPUT Analog Composite Signal (100% Colour Bar) (100% Colour Bar) MODE...
  • Page 128 5-21.Composite Pb/Pr Signal Timing Adjustment BOARD V IN (F5) COMPONENT Y, Pr, Pb OUT Y OUT ADJ. Service Menu TAPE ----- Analog Composite Signal INPUT 12.5T Pulse COMPONENT (Pulse and Bar with 12.5T modulation Signal) PB or PR OUT MODE M.
  • Page 129 5-22.Composite Video Out Phase 5-23.Composite Vector Adjustment Adjustment BOARD V IN (F5) VIDEO 1 OUT BOARD V IN (F5) ADJ. Service Menu VIDEO IN THRU TAPE ----- VIDEO2 OUT INPUT Analog Composite Signal ADJ. VR550 (SYNC0) (100% Colour Bar) TAPE ----- MODE Analog Composite Signal...
  • Page 130 5-24.Y Signal Level (YC IN) 5-25.Y Signal Offset Level (YC IN) Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Y OUT Component Y OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog YC Signal INPUT Analog YC Signal (100% Colour Bar)
  • Page 131 5-26.Pb Signal Offset level (YC IN) 5-27.Pr Signal Offset level (YC IN) Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component Pr OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog YC Signal INPUT Analog YC Signal (0% Flat Field)
  • Page 132 5-28.Pb signal Level (YC IN) 5-29.Pr signal Level (YC IN) Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog YC Signal INPUT Analog YC Signal (100% Colour Bar)
  • Page 133 5-30.Pb/Pr Signal Timing (YC IN) Adjustment BOARD V IN (F5) COMPONENT Y, Pr, Pb OUT Y OUT ADJ. Service Menu TAPE ----- Analog YC Signal 12.5T Pulse INPUT COMPONENT (Pulse and Bar with 12.5T modulation PB or PR OUT Signal) MODE M.
  • Page 134 5-31.YC IN Vector Adjustment BOARD V IN (F5) VIDEO 1 OUT ADJ. Service Menu TAPE ----- INPUT Analog YC Signal (100% Colour Bar with 7.5% Set-up) MODE M. EQ Analog WFM SPEC All vector dots are in the inner box Open the SERVICE MENU.
  • Page 135 6. AUDIO (F1) and 6-2. CH1, CH2 Output Level Adjustment RF/CUE BOARD AUDIO (F1) 6-1. Setting AUDIO OUT (CH1, CH2) ADJ. VR300 (CH1 OUT LV) Set the audio impedance switches on the Audio VR301 (CH2 OUT LV) (F1) board as shown below. TAPE ----- INPUT...
  • Page 136 6-4. CUE BIAS CURRENT 6-6. CUE REC/PB Level Adjustment Adjustment BOARD AUDIO (F1) TP4005 [RF/CUE Board] BOARD RF/CUE TP4006 (GND) [RF/CUE Board] TP4005 [RF/CUE Board] AUDIO OUT (CH1) TP4006 (GND) [RF/CUE Board] ADJ. SERVICE MENU ADJ. VR4001(BIAS), FL4001(Core) VR802 (REC CURR) TAPE Blank Tape TAPE...
  • Page 137 7. TP, VR, SW Location F1 AUDIO P.C.BOARD (VEP84374A) COMPONENT SIDE F2 V OUT P.C.BOARD (VEP83557B) COMPONENT SIDE ELE-36...

  • Page 138: Component Side

    F3A SDI P.C.BOARD (VEP83558A) (AJ-YA455P) COMPONENT SIDE F4 D PROC P.C.BOARD (VEP83554B) FOIL SIDE ELE-37...
  • Page 139 F5 V IN P.C.BOARD (VEP83553B) COMPONENT SIDE F6 SYSCON P.C.BOARD (VEP86314B) COMPONENT SIDE ELE-38...
  • Page 140 F7 SERVO P.C.BOARD (VEP82238B) COMPONENT SIDE F8 RF EQ P.C.BOARD (VEP85196A) COMPONENT SIDE ELE-39...
  • Page 141 MECHA IF P.C.BOARD (VEP82239A) COMPONENT SIDE RF CUE P.C.BOARD (VEP85197A) COMPONENT SIDE ELE-40...
  • Page 142 CSP SUB P.C.BOARD (VEP83555A) FOIL SIDE ELE-41...
  • Page 143 SERVICING FIXTURES & TOOLS Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VFK1145A BACK TENSION METER VFK1149A POST DRIVER VFK71A DIAL TORQUE GAUGE VFK1191A DIAL TORQUE GAUGE VFK1152 GORQUE GAUGE ADAPTOR VFK0357 ECCENTRIC SCREWDRIVER 1 (1.5MM) VFK1154...
  • Page 144 MECHANICAL CHASSIS ASSEMBLY (1) PRT-2...
  • Page 145 MECHANICAL CHASSIS ASSEMBLY (1) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEM0686 S REEL MOTOR A ASS'Y 1 (M) VEM0687 T REEL MOTOR A ASS'Y 1 (M) VMS5923 REEL OUTER RAIL VMS5924 REEL INNER RAIL VXL2589...
  • Page 146 MECHANICAL CHASSIS ASSEMBLY (2) PRT-4...
  • Page 147 MECHANICAL CHASSIS ASSEMBLY (2) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks XVE2B6FP HEX SCREW VXA5554 A/C HEAD BASE (1) ASS'Y XVE2B12FP HEX SCREW VED0419 A/C HEAD 1 (M) VXQ0439 SCREW VXA6067 A/C HEAD BASE (2) ASS'Y VMX0967 CUT WASHER...
  • Page 148 SUB CHASSIS ASSEMBLY PRT-6...
  • Page 149 SUB CHASSIS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VXL2656 MIC DRIVE ARM (A) ASS'Y VMB3018 MIC DRIVE SPRING VXL2657 MIC DRIVE ARM (B) ASS'Y VDB1429 MIC DRIVE ARM BOSS VXL2613 REEL DRIVE ARM ASS'Y VDG1192...

  • Page 150: Cassette Compartment Assembly

    CASSETTE COMPARTMENT ASSEMBLY PRT-8...
  • Page 151 CASSETTE COMPARTMENT ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks XYN2+C4 SCREW VXA6593 CASSETTE COMPARTMENT 1 (M) XQN2+A3 SCREW VMS5865 MAIN SHAFT LMHD16064 SCREW VMA9849 TOP PLATE XWGV2Z5G WASHER VXA6572 FRONT GUIDE 1 ASS'Y VMB3075 M GUIDE SPRING VML3191...

  • Page 152: Casing Parts Assembly

    CASING PARTS ASSEMBLY PRT-10...
  • Page 153 CASING PARTS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYP7626 TOP PANEL ASS'Y VXA7031 P.C.B. PLATE L ASS'Y VMT1222 P.C.B. RUBBER CUSHION L VMX2510 SPACER VMZ2325 TOP PANEL BARRIER VGM1699 SIDE PANEL VKU0546 BOTTOM PLATE...

  • Page 154: Front Panel Assembly

    FRONT PANEL ASSEMBLY PRT-12...
  • Page 155 FRONT PANEL ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYP8126 FRONT PANEL (1) ASS'Y VGU5334 LEVER VR KNOB VGU6516 SLIDE SW KNOB (L) VGU7459 TACT SW KNOB VKF3100 FRONT WINDOW VKF2785 BLINDER PANEL VMB2923...

  • Page 156: Chassis Frame Assembly

    CHASSIS FRAME ASSEMBLY PRT-14...
  • Page 157 CHASSIS FRAME ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VMP6832 SIDE FRAME (L) VGQ4011 P.C.BOARD GUIDE RAIL A VMP6802 REAR FRAME VKA0117 PLASTIC FOOT VMP6020 BOTTOM FRAME VMP4881 SW BRACKET EST15367S POWER SWITCH VMZ0580...

  • Page 158: Rear Panel Assembly

    REAR PANEL ASSEMBLY PRT-16...
  • Page 159 REAR PANEL ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VRF0190 FAN MOTOR 1 L6FALEFH0007 VHN0063 NYLON NUT VMX0835 SPACER VJH1205 JACK PANEL VML2903 AC CORD HOOK VMP5032 OPTION PANEL VEK9369 POWER ASS'Y VSC5223 POWER CASE (LOWER)
  • Page 160 PACKING PARTS ASSEMBLY PRT-18...
  • Page 161 PACKING PARTS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VJA0774 POWER CORD (B) 1 FOR AJ-D455E VJA0775 POWER CORD (E) 1 FOR AJ-D455E VJA1147 POWER CORD 1 FOR AJ-D455MC VPN4305 ACCESSORY PAD VQT9349 OPERATING INSTRUCTIONS...
  • Page 162 PACKING PARTS ASSEMBLY (AJ-YA455P) PRT-20...
  • Page 163 PACKING PARTS ASSEMBLY (AJ-YA455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VJS3462 CONNECTOR (FEMALE) 5 K1SMBDBA0002 VPF0678 AIR CAP BAG VPF0359 POLYETHYLENE BAG VQT9173 OPERATING INSTRUCTIONS VPF0679 AIR CAP BAG VPG6296 PACKING CASE VMP5900 JACK PANEL...
  • Page 164 PACKING PARTS ASSEMBLY (AJ-YAD455P) PRT-22...
  • Page 165 PACKING PARTS ASSEMBLY (AJ-YAD455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPG6296 PACKING CASE VPF0678 AIR CAP BAG VPF0359 POLYETHYLENE BAG VQT9174 OPERATIONG INSTRUCTIONS VPF0679 AIR CAP BAG VEE0N57 CABLE VJF1344 CONNECTOR HOLDER (1) VJF1345 CONNECTOR HOLDER (2)
  • Page 166 PACKING PARTS ASSEMBLY (AJ-CS455P) PRT-24...
  • Page 167 PACKING PARTS ASSEMBLY (AJ-CS455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPG8753 PACKING CASE VPF0887 POLYETHYLENE BAG VQT9175 OPERATING INSTRUCTIONS VPK1856 M CASSETTE SOFT CASE PRT-25...

  • Page 168: Servicing Fixtures And Tools

    1. SERVICING FIXTURES & TOOLS PART NO. FIXTURE & TOOL NAME REMARKS VFK1145A Back Tension Meter VFK1149A Post Driver VFK71A Dial Torque Gauge (1.5 cN!m) 150 g VFK1191A Dial Torque Gauge (0.45 cN!m) 45 g VFK1152 Dial Torque Gauge Adapter VFK0357 Eccentric Screwdriver (1.5 mm) VFK1154...
  • Page 169 VFK1145A VFK1149A VFK71A VFK1152 Back Tension Meter Post Driver Dial Torque Gauge VFK1191A Adapter Dial Torque Gauge VFK0357 VFK1154 VFK1153 VFK1155 (REV/Silver) Mech. Neutral Plate Eccentric Screwdriver Post Height Fixture VFK1156 (PLAY/Black) (1.5 mm) VFK1208 (Neutral/Black with hole) Position Tool VFK0948A VFK1150 VFK1151...
  • Page 170 VFM3680KM or L VFM3110EDS VFM3100EDS AJ-CL12MP DV Alignment Tape DV Alignment Tape Cleaning Tape VFM3681KM or L (Color Bars) (NTSC) (LISTA) VFM3682KM or L DVCPRO Alignment Tape VFK1423 VFK1192 VFK1496 VFK1481B LISTA Software Tape Beg./End F Extender Board Extender Board Detection Cassette VFK1186 LISTA Cable...

  • Page 171: Alignment Tape

    2. Alignment Tape 2-1. VFM3680KM / L (PAL) (25 M adjustment tape) TIME VIDEO PCM AUDIO (min.) Signal Purpose Signal Purpose Signal Purpose 0:00 Color bar Video level 1KHz 100% Confirmation Cue Level Reference 10:00 Frequency Confirmation Level H Sweep Response 14:00 Video start...
  • Page 172 3. List of Recommended Measuring Instruments MODEL NO. (Example) NAME REMARK TSG1411 PAL analog composite signal generator (with CF OUT) SCH meter Tektronix 1761 (op. SC) or 1781R Waveform monitor Vector scope Oscilloscope Digital voltmeter (D.V.M.) Frequency counter Audio noise meter Audio analyzer Spectrum analyzer INF-5...

  • Page 173: Maintenance Schedule

    4. Maintenance 4-1. Maintenance Schedule Maintenance is done by periodically performing suitable maintenance servicing in order to maintain the functions always in the best condition, so that the user can use the equipment safely. Video equipment with mounted mechanisms uses wear parts, and their wear and deterioration causes troubles. Dust and dirt also can impair stable operation.
  • Page 174 4-2. Layout of the Maintenance Parts 3. Cleaning Arm Unit 9. T1 Boat Unit 13. Loading Motor (1) Arm Unit 7. Mode SW Unit 12. A/C Head 1. Cylinder Unit 20. Main Cam Gear 19. Cleaner Solenoid 15. Pinch Solenoid 21.
  • Page 175 5. Manual Tape Eject (Emergency Eject) When a tape can not be ejected by normal operation due to some trouble, the tape can be removed manually as follows. Turn off power and remove the top Case Unit. Repeat item 2 and 3 until the tape in wound up Rotate the red plastic screw by a Phillips-head completely inside of the cassette.
  • Page 176 6. Cylinder Head Cleaning Method 6-1. Cylinder Head Chips Cleaning 6-4. Pinch Roller and Capstan Shaft Method: (Daily) Cleaning Method:(Weekly) Turn off Power. Wipe the Pinch Roller and Capstan with a cloth dipped Dip cloth into De-natural Alcohol. in cleaning liquid. Press cleaning cloth gently against Cylinder Head.

  • Page 177: Normal Screen

    7. DIAG-MENU Display The DIAG-MENU is the menu for investigating the status of the VTR, and it has the warning display (WARNING) and the hour meter display (HOURS METER). 7-1. DIAG-MENU Operation Method 1. Press the “DIAG” button.“DIAG-MENU” will be displayed on the video monitor (VIDEO OUT 3) and on the counter display (front panel).

  • Page 178: Hour Meter Display

    7-2. Hour Meter Display 1. When the “ ” and “ ” button is pressed during hour meter display, the operation hours for each item can be confirmed on the counter display part (front panel). H00-0000 DIAG-MENU HOURS METER ∗ ∗ ∗ ∗ H00 OPERATION 00000H Press the...

  • Page 179: Software Version Display

    8. Software Version Display 8-1. Version Display Operation Procedure 1. Press the “EJECT” button. (If a tape is inserted, eject it.) 2. When the “PLAY” button and the “STOP” button are pressed simultaneously, the version will be displayed on the counter display part (front panel) while these buttons are being pressed. 3.
  • Page 180 9. Software Version Upgrade Method 9-1. Version Upgrade for the SERVO Microcomputer with Built-in Flash Memory The SERVO microcomputer of the F7: SERVO circuit board has a built-in flash memory. For the software version up, connect the “Flash memory version up tool (VFK1304A)” to the tool connection connector and use the “Servo version up software (VFK1503)”...
  • Page 181 Servo circuit board connector Flat cable Blue side up Flat cable Tool connector Blue side up 5. Turn on the AJ-D455E power. 6. Execute the “VSIXXX.bat” copied to the personal computer. It also can be done directly on Windows. (During execution, the file “servo.exe”...
  • Page 182 9-2. E-PROM (SYSCON, IF, AV) Version Upgrade The F6: SYSCON circuit board use an E-PROM (SYSCON, I/F, AV). For the software version up, replace an E-PROM with the new version. F6: SYSCON circuit board P-ROM (I/F) P-ROM (AV) (IC104) (IC502) P-ROM (SYSCON) (IC302) 9-3.

  • Page 183: Personal Computer

    9-3-2. CPLD Version up Method 1 (ALTERA) A. Preparation ITEM REMARK VFK1590 C PLD WRITER VFK1590P2 (VFK1590 standard) D-sub 25pin-25pin Cable Straight (Male - Female), Length : Within 1meter MAX+plus II Software Version Upgrade (Please Download from Software www.altera.com/support/devices/programing/sup-asap2.html) Version Upgrade Data TDF File or POF ( Include in “vsi xxxx”...
  • Page 184 C. Boot up the Ver. up Software and Ver. up Procedure 1. Boot up the “MAX+plus II 9.6 programmer only” Software. 2. On main window, select tab “MAX+plus II” and then “Programmer”. 3. On main window (Programmer window is displayed), select tab “Option” and then “Hardware Setup”. 4.
  • Page 185 <Reference : Creation of chain file> Use a “chain file (in jcf format)” for write-operation when a PCB includes several PLDs. If no chain file has been created, create a chain file by the following procedures. (Example of L1 PCB) A.
  • Page 186 Repeat the steps 2 and 3 to capture the “pof” file. Click the “Save JCF” button. Then, the “Save JCF” screen is displayed. Enter a file name, and click the “OK” button. Click the “OK” button on the “Multi Device JTAG Chain Setup” screen. Then, the following message is displayed : Multi-device JTAG chain mode, which is needed to use the information entered in this dialog box, is off.

  • Page 187: Progress Bar

    7. Click the “Program” button on Programmer dialog. 8. When Progress Bar reaches at point of 100, the message “Programming Complete” appears, then PLD version upgrade is completed. Click “OK” button on the Programming complete message Dialog. Progress bar * MAX+PLUS are registered trademarks of Altera Corporation. * Windows95 and Windows98 are registered trademarks of Microsoft Corporation.
  • Page 188 9-3-3. PLD Version up Method 2 (XILINX) A. Preparation ITEM REMARK VFK1590 C PLD WRITER VFK1590P4 (VFK1590 standard) 25pin-25pin Cable Straight (Male - Female), Length : Within 1meter JTAG Programmer Software Please download from the following URL Version Upgrade http://www.xilinx.com/support/download.htm 1.
  • Page 189 2. Click “OUTPUT” on the menu bar and select “Parallel” for “Cable Communication Setup” (default port is “lpt1”). 3. If connection is correct, following message appears. 4. Click “OK” button. 5. Insert the floppy disk for version up data into A drive. 6.
  • Page 190 7. Click “Open” button, then following screen appears. 8. Then click “Operations” on menu bar and select “Chain Operation”. Then following screen appears. 9. Select the device from the “Device Type” column on the Chain Operation Window. Click the “Selected Device Operation” and select “Program”. Perform this procedure to all devices.
  • Page 191 10. Click “Execute” button. 11. When the following screen with the message of “All operation were completed successfully.” appears, data writing is completed. INF-24...
  • Page 192 10. Error Rate Display and Confirmation Method The error rate is displayed on the AUDIO LEVEL METER in Service mode. (When enters in Service menu mode, the AUDIO LEVEL METER changes into the error display mode automatically.) The error rate of the head selected for the setting of “B00: RF ADJUST” in the service menu. While the DVCPRO is played back, the selection is possible when “C45 PB HEAD”...
  • Page 193 11. Internal Switch Setting Method The switches setting on each circuit board are shown below. The switches “Factory use only” must be set to the “factory setting”. FACTORY BOARD Ref. No. FEATURE SETTING − F1: AUDIO SW4100 HIGH Audio input impedance setting (600Ω/ HIGH) −...

  • Page 194: Service Menu

    13. Service Menu 13-1. Service Menu Operation Method 1. Confirm that the “REMOTE/LOCAL” switch on the front panel is set to the “LOCAL”. 2. Press the “MENU” button on the front panel to display the “SETUP-MENU”. 3. When the “SETUP-MENU” is displayed, press the “MENU” button while pressing the “EJECT” button and the “STOP”...

  • Page 195: Default Operation

    13-2. DEFAULT Operation 13-2-1. RF adjustment (B00) In the RF adjustment, it is possible to save the set values to an area different from the back up area for the present set valng. The saved setting can be loaded as the present setting. This operation is effective only after the loading is completed.
  • Page 196 13-3. Service Menu Contents A00: SERVO ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. A01 FG DC ADJ Automatic adjustment of the DC offset of the capstan, S/T-Reel FG. This shall be done is in EJECT condition. Operation: 1.
  • Page 197 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. A06 T PHOTO Voltage Indication of the detection voltage of the photo sensor for beginning and end value detection on the T-side This is used for adjustment of the sensitivity of the photosensor. 0.0V Operation 1.
  • Page 198 B00: RF ADJUST RF ADJUST has a subscreen composition, and there is a hierarchical structure for each format. RF ADJUST subscreen Item Item contents SUPER DISP. C00 PRO ADJUST Adjustment for DVCPRO (25 Mbps) D00 DV ADJUST Adjustment for DV •...
  • Page 199 C-1: REC ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. REC CURR L -128 -128 Adjustment of the RP L head recording current REC FREQ L -128 -128 Adjustment of the RP L head recording f characteristic REC CURR R -128 -128...
  • Page 200 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. Playback signal envelope level read-out value averaged for each ENV L track of each head ENV L: Lch head ENV R: Rch head Averaging is performed at 8 points in the track, and the newest track value for which averaging has been completed at the time when read-out is started will be read out.
  • Page 201 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. TH ULK Setting of the threshold value for judging the signal quality after equalization The judgment result for the signal quality is used for adaptive equalization, PLL, fault detection function, and other control.
  • Page 202 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. The initial values for six of the seven tap coefficients of the adaptive T R 3A equalization filter, excluding the fixed center tap, are set for the Rch head.
  • Page 203 C-1: REC ADJUST / C-2: RP ADJUST / C-3: PB ADJUST COMMON ITEM Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. VITERBI MODE Setting whether Viterbi decoding is to be used for detection of playback data or not •...
  • Page 204 E00: VIN ADJUST VIN ADJUST has a subscreen composition, and there is a hierarchical structure for each format. VIN ADJUST subscreen Item Item contents SUPER DISP. CMPNT ADJUST Adjustment to component input CMPST ADJUST Adjustment of composite input YC ADJUST Adjustment of S-VIDEO (Y/C) input E-1: CMPNT ADJUST Item...
  • Page 205 E-2: CMPST ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. E00 SITE Y GAIN -128 -128 Adjustment of composite Y level E01 SITE Y OFS -128 -128 Adjustment of composite Y offset level E02 SITE PB GAIN -128 -128...
  • Page 206 E-3: Y/C ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. E00 YC Y GAIN -128 -128 Adjustment of the Y level for S-VIDEO (YC) E01 YC Y OFS -128 -128 Adjustment of the Y offset for S-VIDEO (YC) E02 YC PB GAIN -128 -128...
  • Page 207 F00: VIDEO ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. F03 VIDEO MUTE NORMAL Select whether the VIDEO output is to be made gray or not MUTE 0:Normal output 1:Forced gray output F06 EE TEST MODE NORMAL EE check for the entire signal processing system...
  • Page 208 H00: OTHER ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. H01 STILL LIMIT 2 min Set the maximum value of the "SETUP-MENU 400 : STILL TIMER". 6 min Decide whether the still timer should be reset when the STANDBY- ON command is received during the STOP mode.
  • Page 209 14. Notes on Removal of PCB F3A, F3B, F8 In AJ-D455E, the H-PCBs (half-size PCBs) are inserted in the F-PCB (full-size PCB) slots. Pulling of the three PCBs, F3A (SDI option), F3B (DIF option), and F8 (RF), with only one リア...

  • Page 210: Auto Off Mode

    15. Auto OFF mode In case AUTO OFF Error is occurred, error number is flashed on counter display of front panel and error message appear on the monitor screen(superimpose on VIDEO 3 OUT). The number of below table indicates as priority display of error number and message, when some error occurred at the same time.
  • Page 211 Display Detection Reset Contents (20 characters) Operation Place Condition E-60 DRUM ROTA The cylinder motor speed is abnormally high. PG STOP SERVO POWER OFF → interval is less than 3ms for 2seconds. TOO FAST E-61 CAP ROTA TOO The capstan motor speed is abnormally low. In the STOP SERVO POWER...
  • Page 212 16. Circuit board layout drawing INF-45...
  • Page 213 17. AJ-YAD455P Service Information 17-1. Node Unique ID (UID) number Setting Procedure <Confirmation of UID number> AJ-YAD455 has “Node Unique ID” for IEEE1394 I/F. This number is displayed in the DIF STATUS MENU. Press the “DIAG” button, then open the Warning page. Press the “!”...
  • Page 214 17-2. Version Upgrade for Flash Memory The AJ-YAD455P (F3B: DIF board) has flash memory. For the software version up, connect the “Flash memory version up tool (VFK1304A)” to the tool connection connector and use the “Flash memory version up software (VFK1248E)”.
  • Page 215 Connector on the circuit board side Flat cable Blue side Flat cable Tool connector Blue side on top 17-2-2. Version Upgrade Procedure 1. Boot up the personal computer in the condition which “16-2-1. Version Upgrade Preparations” is completed. 2. Turn on the power of the AJ-D455E. Confirm that the LED1 and LED2 on the DIF board should be OFF. 3.
  • Page 216 6. When the settings on the “Setup Panel” is completed, click “Ok(O)”. The “Main Panel” will be opened as shown below. 7. Click “Start (S) ” on the “Main Panel”. (If you want to quit here, click “Exit”. If you want to return again to the “Setup Panel”, click “Setup(Z)”.) 8.
  • Page 217 17-3. PLD Version Upgrade Procedure The AJ-YAD455P uses PLDs. At the time of a version upgrade, use the special tool, connect the respective connection connectors, and use the PLD writing software. 17-3-1. PLD Chart Numbe Circuit board name Connector r of PLD No.
  • Page 218 C. Boot up the Ver. Up Software and Ver. up Procedure 1. After download the program, “Xilinx CPLD Webpack” folder is created on windows. Click the start button of windows program “Xilinx CPLD Webpack”, then Device Program is boot up and following screen appears.
  • Page 219 3. If connection is correct, following message appears. 4. Click “OK” button. 5. Insert the floppy disk for version up data into A drive. 6. Open the target file. This file called Disk file, because one file can write several CPLDs like a chain. 7.
  • Page 220 8. Then click “Operations” on menu bar and select “Chain Operation”. Then following screen appears. 9. Select the device from the “Device Type” column on the Chain Operation Window. Click the “Selected Device Operation” and select “Program”. Perform this procedure to all devices. 10.
  • Page 221 COMPONENT F1:AUDIO(CONNECTOR) 01/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (1/9) VEP84374A SCM001...
  • Page 222 COMPONENT F1:AUDIO (INPUT_12) 02/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR4K05 (2/9) VEP84374A SCM002...
  • Page 223 COMPONENT F1:AUDIO (D/A, A/D) 03/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05(3/9) VEP84374A SCM003...
  • Page 224 COMPONENT F1:AUDIO (D/AOUT_12LR) 04/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05(4/9) VEP84374A SCM004...
  • Page 225 COMPONENT F1:AUDIO (MIX/HP_OUT) 05/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (5/9) VEP84374A SCM005...
  • Page 226 COMPONENT F1:AUDIO (OUT PUT_12) 06/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (6/9) VEP84374A SCM006...
  • Page 227 COMPONENT F1:AUDIO (PIO) 07/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (7/9) VEP84374A SCM007...
  • Page 228 COMPONENT F1:AUDIO (CUE_R/P) 08/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (8/9) VEP84374A SCM008...
  • Page 229 COMPONENT F1:AUDIO (CUE_INPUT) 09/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (9/9) VEP84374A SCM009...
  • Page 230 COMPONENT F2:V OUT (CONNECTOR) 01/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (1/14) VEP83557B SCM010...
  • Page 231 COMPONENT F2:V OUT (COM_BUFF) 02/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (2/14) VEP83557B SCM011...
  • Page 232 COMPONENT F2:V OUT (DIN_BUFF) 03/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (3/14) VEP83557B SCM012...
  • Page 233 COMPONENT F2:V OUT (PROC) 04/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (4/14) VEP83557B SCM013...
  • Page 234 COMPONENT F2:V OUT (DOUT_BUFF) 05/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (5/14) VEP83557B SCM014...
  • Page 235 COMPONENT F2:V OUT (DAC) 06/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (6/14) VEP83557B SCM015...
  • Page 236 COMPONENT F2:V OUT (COMPONENT_BUFF) 07/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (7/14) VEP83557B SCM016...
  • Page 237 COMPONENT F2:V OUT (YC_MIX) 08/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (8/14) VEP83557B SCM017...
  • Page 238 COMPONENT F2:V OUT (COMPOSITE_BUFF) 09/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (9/14) VEP83557B SCM018...
  • Page 239 COMPONENT F2:V OUT (SYNC_SEP) 10/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091(10/14) VEP83557B SCM019...
  • Page 240 COMPONENT F2:V OUT (PLL) 11/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (11/14) VEP83557B SCM020...
  • Page 241 COMPONENT F2:V OUT (SYNC_GEN) 12/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (12/14) VEP83557B SCM021...
  • Page 242 COMPONENT F2:V OUT (INT) 13/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (13/14) VEP83557B SCM022...
  • Page 243 AJ-D455E AJ-D455E COMPONENT F2:V OUT (PARTS_TABLE) 14/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (14/14) VEP83557B SCM023...
  • Page 244 COMPONENT F3A:SDI (CONNECTOR) 01/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (1/6) VEP83558A SCM024...
  • Page 245 COMPONENT F3A:SDI (SYSIO) 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (2/6) VEP83558A SCM025...
  • Page 246 COMPONENT F3A:SDI (S2P) 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (3/6) VEP83558A SCM026...
  • Page 247 COMPONENT F3A:SDI (DECODER) 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (4/6) VEP83558A SCM027...
  • Page 248 COMPONENT F3A:SDI (P2S_1) 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (5/6) VEP83558A SCM028...
  • Page 249 VSI3569A COMPONENT F3A:SDI (P2S_2) 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092(6/6) VEP83558A SCM029...
  • Page 250 COMPONENT F4:D PROC (MOTHER) 01/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (1/27) VEP83554B SCM030...
  • Page 251 COMPONENT F4:D PROC (POWER) 02/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (2/27) VEP83554B SCM031...
  • Page 252 COMPONENT F4:D PROC (AVIF) 03/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (3/27) VEP83554B SCM032...
  • Page 253 VSI3555A COMPONENT F4:D PROC (ISP) 04/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (4/27) VEP83554B SCM033...
  • Page 254 COMPONENT F4:D PROC (IOBUF_V) 05/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (5/27) VEP83554B SCM034...
  • Page 255 COMPONENT F4:D PROC (IOBUF_A) 06/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (6/27) VEP83554B SCM035...
  • Page 256 PAT/J3 22K/J3 15K/J3 15K/J3 22K/J3 COMPONENT F4:D PROC (PLL_VCO) 07/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (7/27) VEP83554B SCM036...
  • Page 257 COMPONENT F4:D PROC (TBC_FIFO) 08/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (8/27) VEP83554B SCM037...
  • Page 258 COMPONENT F4:D PROC (DV_IO FPGA1) 09/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (9/27) VEP83554B SCM038...
  • Page 259 COMPONENT F4:D PROC (CSP_CON) 10/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (10/27) VEP83554B SCM039...
  • Page 260 COMPONENT F4:D PROC (DV_ PROC) 11/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (11/27) VEP83554B SCM040...
  • Page 261 COMPONENT F4:D PROC (EE_FIFO) 12/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (12/27) VEP83554B SCM041...
  • Page 262 COMPONENT F4:D PROC (REC_DV_CON) 13/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (13/27) VEP83554B SCM042...
  • Page 263 COMPONENT F4:D PROC (PB_DV_CON) 14/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (14/27) VEP83554B SCM043...
  • Page 264 COMPONENT F4:D PROC (VIDEO DATA VITC/CC) 15/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (15/27) VEP83554B SCM044...
  • Page 265 COMPONENT F4:D PROC (LVDS) 16/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (16/27) VEP83554B SCM045...
  • Page 266 COMPONENT F4:D PROC (VBLK_CON) 17/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (17/27) VEP83554B SCM046...
  • Page 267 COMPONENT F4:D PROC (REC_411_FLITER) 18/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088(18/27) VEP83554B SCM047...
  • Page 268 COMPONENT F4:D PROC (PB_411_FILTER) 19/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (19/27) VEP83554B SCM048...
  • Page 269 COMPONENT F4:D PROC (REC_DV_MPU) 20/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (20/27) VEP83554B SCM049...
  • Page 270 COMPONENT F4:D PROC (PB_DV_MPU) 21/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (21/27) VEP83554B SCM050...
  • Page 271 COMPONENT F4:D PROC (PLL) 22/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (22/27) VEP83554B SCM051...
  • Page 272 COMPONENT F4:D PROC (PCMCNT) 23/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (23/27) VEP83554B SCM052...
  • Page 273 COMPONENT F4:D PROC (SLOW) 24/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088(24/27) VEP83554B SCM053...
  • Page 274 COMPONENT F4:D PROC (ACNT) 25/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (25/27) VEP83554B SCM054...
  • Page 275 COMPONENT F4:D PROC (SRC) 26/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (26/27) VEP83554B SCM055...
  • Page 276 COMPONENT F4:D PROC (AMEM) 27/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (27/27) VEP83554B SCM056...
  • Page 277 COMPONENT CSP SUB (CONNECTOR) 01/06 NAME DRAWING NO. CIRCUIT BOARD NO. KR30089 (1/6) VEP83555A SCM057...
  • Page 278 COMPONENT CSP SUB (REC VIOLA) 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (2/6) VEP83555A SCM058...
  • Page 279 COMPONENT CSP SUB (REC LUPIN) 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (3/6) VEP83555A SCM059...
  • Page 280 COMPONENT CSP SUB (PB VIOLA) 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (4/6) VEP83555A SCM060...
  • Page 281 COMPONENT CSP SUB (PB LUPIN) 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (5/6) VEP83555A SCM061...
  • Page 282 COMPONENT CSP SUB (RF_PLL) 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (6/6) VEP83555A SCM062...
  • Page 283 COMPONENT F5:V_IN (CONNECTOR) 01/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (1/18) VEP83553B SCM063...
  • Page 284 COMPONENT F5:V_IN (POWER) 02/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (2/18) VEP83553B SCM064...
  • Page 285 COMPONENT F5:V_IN (COMP_IN) 03/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (3/18) VEP83553B SCM065...
  • Page 286 COMPONENT F5:V_IN (1st_AD) 04/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (4/18) VEP83553B SCM066...
  • Page 287 COMPONENT F5:V_IN (SDEC) 05/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (5/18) VEP83553B SCM067...
  • Page 288 COMPONENT F5:V_IN (SDEC2) 06/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (6/18) VEP83553B SCM068...
  • Page 289 COMPONENT F5:V_IN (DECBUF) 07/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (7/18) VEP83553B SCM069...
  • Page 290 COMPONENT F5:V_IN (4fsc_PLL) 08/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (8/18) VEP83553B SCM070...
  • Page 291 COMPONENT F5:V_IN (CDEM) 09/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (9/18) VEP83553B SCM071...
  • Page 292 COMPONENT F5:V_IN (SYNC_SEP) 10/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (10/18) VEP83553B SCM072...
  • Page 293 COMPONENT F5:V_IN (135M_PLL) 11/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (11/18) VEP83553B SCM073...
  • Page 294 COMPONENT F5:V_IN (M2B_SEL) 12/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (12/18) VEP83553B SCM074...
  • Page 295 COMPONENT F5:V_IN (2nd_AD_Y) 13/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (13/18) VEP83553B SCM075...
  • Page 296 COMPONENT F5:V_IN (2nd_AD_PB) 14/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (14/18) VEP83553B SCM076...
  • Page 297 COMPONENT F5:V_IN (2nd_AD_PR) 15/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (15/18) VEP83553B SCM077...
  • Page 298 COMPONENT F5:V_IN (EVR) 16/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (16/18) VEP83553B SCM078...
  • Page 299 VSI3573C COMPONENT F5:V_IN (DIG_GEN) 17/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (17/18) VEP83553B SCM079...
  • Page 300 COMPONENT F5:V_IN (OUTBUFF) 18/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (18/18) VEP83553B SCM080...
  • Page 301 COMPONENT F6:SYSCON 01/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (1/13) VEP86314B SCM081...
  • Page 302 COMPONENT F6:SYSCON (IF) 02/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (2/13) VEP86314B SCM082...
  • Page 303 COMPONENT F6:SYSCON (IF) 03/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (3/13) VEP86314B SCM083...
  • Page 304 COMPONENT F6:SYSCON (IF) 04/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (4/13) VEP86314B SCM084...
  • Page 305 COMPONENT F6:SYSCON (IF) 05/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (5/13) VEP86314B SCM085...
  • Page 306 COMPONENT F6:SYSCON (SYS) 06/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (6/13) VEP86314B SCM086...
  • Page 307 COMPONENT F6:SYSCON (SYS) 07/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (7/13) VEP86314B SCM087...
  • Page 308 COMPONENT F6:SYSCON (SYS) 08/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (8/13) VEP86314B SCM088...
  • Page 309 COMPONENT F6:SYSCON (AV) 09/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (9/13) VEP86314B SCM089...
  • Page 310 COMPONENT F6:SYSCON (AV) 10/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (10/13) VEP86314B SCM090...
  • Page 311 COMPONENT F6:SYSCON (AV) 11/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (11/13) VEP86314B SCM091...
  • Page 312 COMPONENT F6:SYSCON (AV) 12/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (12/13) VEP86314B SCM092...
  • Page 313 AJ-D455E VSI3558A VSI3562A VSI3564B COMPONENT SYSCON 13/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (13/13) VEP85314B SCM093...
  • Page 314 COMPONENT F7:SERVO (CTL) 01/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (1/14) VEP82238B SCM094...
  • Page 315 COMPONENT F7:SERVO (REEL_FG) 02/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (2/14) VEP82238B SCM095...
  • Page 316 COMPONENT F7:SERVO (CA_CY_FG) 03/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (3/14) VEP82238B SCM096...
  • Page 317 COMPONENT F7:SERVO (CPU) 04/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (4/14) VEP82238B SCM097...
  • Page 318 COMPONENT F7:SERVO (PLD) 05/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (5/14) VEP82238B SCM098...
  • Page 319 COMPONENT F7:SERVO (CPU_IF) 06/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (6/14) VEP82238B SCM099...
  • Page 320 COMPONENT F7:SERVO (POWER) 07/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (7/14) VEP82238B SCM100...
  • Page 321 IMPORTANT SAFETY NOTICE: COMPONENT F7:SERVO (SW2) 08/14 NAME COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. CIRCUIT BOARD NO. DRAWING NO. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE KR2E01 (8/14) SAME TYPE. VEP82238B SCM101...
  • Page 322 COMPONENT F7:SERVO (SW1) 09/14 NAME IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CIRCUIT BOARD NO. DRAWING NO. CHARACTERISTICS FOR SAFETY. KR2E01 (9/14) WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE VEP82238B SAME TYPE. SCM102...
  • Page 323 COMPONENT F7:SERVO (RL_DRV) 10/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01(10/14) VEP82238B SCM103...
  • Page 324 COMPONENT F7:SERVO (CA_CY_DRV) 11/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (11/14) VEP82238B SCM104...
  • Page 325 COMPONENT F7:SERVO (M_IF) 12/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (12/14) VEP82238B SCM105...
  • Page 326 COMPONENT F7:SERVO 13/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (13/14) VEP82238B SCM106...
  • Page 327 VSI3565A COMPONENT F7:SERVO (SOFT) 14/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (14/14) VEP82238B SCM107...
  • Page 328 COMPONENT RF/CUE 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (1/4) VEP85197A SCM108...
  • Page 329 COMPONENT RF/CUE 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (2/4) VEP85197A SCM109...
  • Page 330 COMPONENT RF/CUE 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (3/4) VEP85197A SCM110...
  • Page 331 COMPONENT RF/CUE 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (4/4) VEP85197A SCM111...
  • Page 332 COMPONENT F8:RF/EQ 01/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (1/7) VEP85196A SCM112...
  • Page 333 COMPONENT F8:RF/EQ 02/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (2/7) VEP85196A SCM113...
  • Page 334 COMPONENT F8:RF/EQ 03/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (3/7) VEP85196A SCM114...
  • Page 335 COMPONENT F8:RF/EQ 04/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (4/7) VEP85196A SCM115...
  • Page 336 COMPONENT F8:RF/EQ 05/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (5/7) VEP85196A SCM116...
  • Page 337 COMPONENT F8:RF/EQ 06/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (6/7) VEP85196A SCM117...
  • Page 338 COMPONENT F8:RF/EQ 07/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (7/7) VEP85196A SCM118...
  • Page 339 F1 (AUDIO) COMPONENT MOTHER 01/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (1/10) VEP80C14A SCM119...
  • Page 340 F2 (V_OUT) COMPONENT MOTHER 02/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (2/10) VEP80C14A SCM120...
  • Page 341 F3A (SDI) F3B (DIF) COMPONENT MOTHER 03/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (3/10) VEP80C14A SCM121...
  • Page 342 F4 (D_PROC) COMPONENT MOTHER 04/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (4/10) VEP80C14A SCM122...
  • Page 343 F5 (V_IN) COMPONENT MOTHER 05/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (5/10) VEP80C14A SCM123...
  • Page 344 F6 (SYSCON) COMPONENT MOTHER 06/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (6/10) VEP80C14A SCM124...
  • Page 345 F7 (SERVO) COMPONENT MOTHER 07/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (7/10) VEP80C14A SCM125...
  • Page 346 F8 (RF/EQ) HEAD_BUFF (RF/CUE) COMPONENT MOTHER 08/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (8/10) VEP80C14A SCM126...
  • Page 347 MECHA_IF POWER COMPONENT MOTHER 09/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (9/10) VEP80C14A SCM127...
  • Page 348 REAR (VA_JACK) FRONT COMPONENT MOTHER 10/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (10/10) VEP80C14A SCM128...
  • Page 349 COMPONENT MECHA_IF 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (1/4) VEP82239A SCM129...
  • Page 350 COMPONENT MECHA_IF 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (2/4) VEP82239A SCM130...
  • Page 351 COMPONENT MECHA_IF 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (3/4) VEP82239A SCM131...
  • Page 352 COMPONENT MECHA_IF 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (4/4) VEP82239A SCM132...
  • Page 353 COMPONENT MECHA_IF2 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E03 (1/1) VEP82240A SCM133...
  • Page 354 CAUTION MARK INDICATES THE PRIMARY CIRCUIT TO DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK DURING REPAIR AND SERVICE OF THE PRODUCTS. COMPONENT POWER1 01/02 NAME IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CIRCUIT BOARD NO.
  • Page 355 COMPONENT CAUTION POWER1 02/02 NAME IMPORTANT SAFETY NOTICE: MARK INDICATES THE PRIMARY CIRCUIT TO CIRCUIT BOARD NO. DRAWING NO. COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. CHARACTERISTICS FOR SAFETY. KR1F70 (2/2) PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE VEP81221B SAME TYPE.
  • Page 356 CAUTION IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL COMPONENT POWER2 01/01 MARK INDICATES THE PRIMARY CIRCUIT TO NAME CHARACTERISTICS FOR SAFETY. DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE CIRCUIT BOARD NO.
  • Page 357 COMPONENT AV_JACK (CONNECTOR) 01/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (1/5) VEP80C13A SCM137...
  • Page 358 COMPONENT AV_JACK (BNC I/O) 02/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (2/5) VEP80C13A SCM138...
  • Page 359 For OVER SEAS For OVER SEAS For JAPAN COMPONENT AV_JACK (AUDIO I/O) 03/05 NAME For OVER SEAS CIRCUIT BOARD NO. DRAWING NO. For JAPAN KR0Q23 (3/5) VEP80C13A SCM139...
  • Page 360 COMPONENT AV_JACK (AES I/O) 04/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (4/5) VEP80C13A SCM140...
  • Page 361 COMPONENT AV_JACK (AES OUT) 05/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (5/5) VEP80C13A SCM141...
  • Page 362 COMPONENT DV u COM 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR30103 (1/1) VEP83560A SCM142...
  • Page 363 COMPONENT FRONT (KEY & LED) 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR06T81 (1/3) VEP86315A SCM143...
  • Page 364 MA185 COMPONENT FRONT (VFD) 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR06T81 (2/3) VEP86315A SCM144...
  • Page 365 0.1/UFV COMPONENT FRONT (VR, CONECTOR) 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR06T81 (3/3) VEP86315A SCM145...
  • Page 366 COMPONENT HP (HEAD PHONE) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q25 (1/1) VEP80C15A SCM146...
  • Page 367 COMPONENT EJECT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q26 (1/1) VEP80C16A SCM147...
  • Page 368 COMPONENT DIF JACK (1394 JACK) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q49 (1/1) VEP80C21A SCM148...
  • Page 369 COMPONENT F3B : DIF (MOTHER) 01/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR30093 (1/9) VEP83559A SCM149...
  • Page 370 COMPONENT F3B : DIF (POWER BUFFER) 02/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 VEP83559A SCM150...
  • Page 371 COMPONENT F3B : DIF (u COM) 03/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR30093 (3/9) VEP83559A SCM151...
  • Page 372 COMPONENT F3B : DIF (uCOM MEMORY) 04/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (4/9) VEP83559A SCM152...
  • Page 373 COMPONENT F3B : DIF (PINE) 05/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR30093 (5/9) VEP83559A SCM153...
  • Page 374 COMPONENT F3B : DIF (FPGA) 06/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (6/9) VEP83559A SCM154...
  • Page 375 COMPONENT F3B : DIF (FPGA CONFIG) 07/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR30093 (7/9) VEP83559A SCM155...
  • Page 376 COMPONENT F3B : DIF (FPGA DRAM) 08/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (8/9) VEP83559A SCM156...
  • Page 377 COMPONENT F3B : DIF (CLKGEN) 09/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR30093 (9/9) VEP83559A SCM157...

  • Page 378: Table Of Contents

    SERVICE INFORMATION CONTENTS 1. SERVICING FIXTURES & TOOLS....................INF-1 2. Alignment Tape ..........................INF-4 2-1. VFM3680KM / L (PAL) (25 M adjustment tape) ............... INF-4 2-2. VFM3681KM / L (PAL) (Manufacturer (LISTA) adjustment tape) ..........INF-4 2-3. VFM3682KM / L (PAL) (Manufacturer (X-value) adjustment tape) .......... INF-4 2-4.

  • Page 379: Servicing Fixtures & Tools

    1. SERVICING FIXTURES & TOOLS PART NO. FIXTURE & TOOL NAME REMARKS VFK1145A Back Tension Meter VFK1149A Post Driver VFK71A Dial Torque Gauge (1.5 cN!m) 150 g VFK1191A Dial Torque Gauge (0.45 cN!m) 45 g VFK1152 Dial Torque Gauge Adapter VFK0357 Eccentric Screwdriver (1.5 mm) VFK1154...
  • Page 380 VFK1145A VFK1149A VFK71A VFK1152 Back Tension Meter Post Driver Dial Torque Gauge VFK1191A Adapter Dial Torque Gauge VFK0357 VFK1154 VFK1153 VFK1155 (REV/Silver) Mech. Neutral Plate Eccentric Screwdriver Post Height Fixture VFK1156 (PLAY/Black) (1.5 mm) VFK1208 (Neutral/Black with hole) Position Tool VFK0948A VFK1150 VFK1151...
  • Page 381 VFM3680KM or L VFM3110EDS VFM3100EDS AJ-CL12MP DV Alignment Tape DV Alignment Tape Cleaning Tape VFM3681KM or L (Color Bars) (NTSC) (LISTA) VFM3682KM or L DVCPRO Alignment Tape VFK1423 VFK1192 VFK1496 VFK1481B LISTA Software Tape Beg./End F Extender Board Extender Board Detection Cassette VFK1186 LISTA Cable...

  • Page 382: Alignment Tape

    2. Alignment Tape 2-1. VFM3680KM / L (PAL) (25 M adjustment tape) TIME VIDEO PCM AUDIO (min.) Signal Purpose Signal Purpose Signal Purpose 0:00 Color bar Video level 1KHz 100% Confirmation Cue Level Reference 10:00 Frequency Confirmation Level H Sweep Response 14:00 Video start...

  • Page 383: List Of Recommended Measuring Instruments

    3. List of Recommended Measuring Instruments MODEL NO. (Example) NAME REMARK TSG1411 PAL analog composite signal generator (with CF OUT) SCH meter Tektronix 1761 (op. SC) or 1781R Waveform monitor Vector scope Oscilloscope Digital voltmeter (D.V.M.) Frequency counter Audio noise meter Audio analyzer Spectrum analyzer INF-5...

  • Page 384: Maintenance

    4. Maintenance 4-1. Maintenance Schedule Maintenance is done by periodically performing suitable maintenance servicing in order to maintain the functions always in the best condition, so that the user can use the equipment safely. Video equipment with mounted mechanisms uses wear parts, and their wear and deterioration causes troubles. Dust and dirt also can impair stable operation.

  • Page 385: Layout Of The Maintenance Parts

    4-2. Layout of the Maintenance Parts 3. Cleaning Arm Unit 9. T1 Boat Unit 13. Loading Motor (1) Arm Unit 7. Mode SW Unit 12. A/C Head 1. Cylinder Unit 20. Main Cam Gear 19. Cleaner Solenoid 15. Pinch Solenoid 21.

  • Page 386: Manual Tape Eject (Emergency Eject)

    5. Manual Tape Eject (Emergency Eject) When a tape can not be ejected by normal operation due to some trouble, the tape can be removed manually as follows. Turn off power and remove the top Case Unit. Repeat item 2 and 3 until the tape in wound up Rotate the red plastic screw by a Phillips-head completely inside of the cassette.

  • Page 387: Cylinder Head Cleaning Method

    6. Cylinder Head Cleaning Method 6-1. Cylinder Head Chips Cleaning 6-4. Pinch Roller and Capstan Shaft Method: (Daily) Cleaning Method:(Weekly) Turn off Power. Wipe the Pinch Roller and Capstan with a cloth dipped Dip cloth into De-natural Alcohol. in cleaning liquid. Press cleaning cloth gently against Cylinder Head.

  • Page 388: Diag-Menu Display

    7. DIAG-MENU Display The DIAG-MENU is the menu for investigating the status of the VTR, and it has the warning display (WARNING) and the hour meter display (HOURS METER). 7-1. DIAG-MENU Operation Method 1. Press the “DIAG” button.“DIAG-MENU” will be displayed on the video monitor (VIDEO OUT 3) and on the counter display (front panel).

  • Page 389: Hour Meter Display

    7-2. Hour Meter Display 1. When the “ ” and “ ” button is pressed during hour meter display, the operation hours for each item can be confirmed on the counter display part (front panel). H00-0000 DIAG-MENU HOURS METER ∗ ∗ ∗ ∗ H00 OPERATION 00000H Press the...

  • Page 390: Software Version Display

    8. Software Version Display 8-1. Version Display Operation Procedure 1. Press the “EJECT” button. (If a tape is inserted, eject it.) 2. When the “PLAY” button and the “STOP” button are pressed simultaneously, the version will be displayed on the counter display part (front panel) while these buttons are being pressed. 3.

  • Page 391: Software Version Upgrade Method

    9. Software Version Upgrade Method 9-1. Version Upgrade for the SERVO Microcomputer with Built-in Flash Memory The SERVO microcomputer of the F7: SERVO circuit board has a built-in flash memory. For the software version up, connect the “Flash memory version up tool (VFK1304A)” to the tool connection connector and use the “Servo version up software (VFK1503)”...
  • Page 392 Servo circuit board connector Flat cable Blue side up Flat cable Tool connector Blue side up 5. Turn on the AJ-D455E power. 6. Execute the “VSIXXX.bat” copied to the personal computer. It also can be done directly on Windows. (During execution, the file “servo.exe”...

  • Page 393: E-Prom (Syscon, If, Av) Version Upgrade

    9-2. E-PROM (SYSCON, IF, AV) Version Upgrade The F6: SYSCON circuit board use an E-PROM (SYSCON, I/F, AV). For the software version up, replace an E-PROM with the new version. F6: SYSCON circuit board P-ROM (I/F) P-ROM (AV) (IC104) (IC502) P-ROM (SYSCON) (IC302) 9-3.
  • Page 394 9-3-2. CPLD Version up Method 1 (ALTERA) A. Preparation ITEM REMARK VFK1590 C PLD WRITER VFK1590P2 (VFK1590 standard) D-sub 25pin-25pin Cable Straight (Male - Female), Length : Within 1meter MAX+plus II Software Version Upgrade (Please Download from Software www.altera.com/support/devices/programing/sup-asap2.html) Version Upgrade Data TDF File or POF ( Include in “vsi xxxx”...
  • Page 395 C. Boot up the Ver. up Software and Ver. up Procedure 1. Boot up the “MAX+plus II 9.6 programmer only” Software. 2. On main window, select tab “MAX+plus II” and then “Programmer”. 3. On main window (Programmer window is displayed), select tab “Option” and then “Hardware Setup”. 4.
  • Page 396 <Reference : Creation of chain file> Use a “chain file (in jcf format)” for write-operation when a PCB includes several PLDs. If no chain file has been created, create a chain file by the following procedures. (Example of L1 PCB) A.
  • Page 397 Repeat the steps 2 and 3 to capture the “pof” file. Click the “Save JCF” button. Then, the “Save JCF” screen is displayed. Enter a file name, and click the “OK” button. Click the “OK” button on the “Multi Device JTAG Chain Setup” screen. Then, the following message is displayed : Multi-device JTAG chain mode, which is needed to use the information entered in this dialog box, is off.
  • Page 398 7. Click the “Program” button on Programmer dialog. 8. When Progress Bar reaches at point of 100, the message “Programming Complete” appears, then PLD version upgrade is completed. Click “OK” button on the Programming complete message Dialog. Progress bar * MAX+PLUS are registered trademarks of Altera Corporation. * Windows95 and Windows98 are registered trademarks of Microsoft Corporation.
  • Page 399 9-3-3. PLD Version up Method 2 (XILINX) A. Preparation ITEM REMARK VFK1590 C PLD WRITER VFK1590P4 (VFK1590 standard) 25pin-25pin Cable Straight (Male - Female), Length : Within 1meter JTAG Programmer Software Please download from the following URL Version Upgrade http://www.xilinx.com/support/download.htm 1.
  • Page 400 2. Click “OUTPUT” on the menu bar and select “Parallel” for “Cable Communication Setup” (default port is “lpt1”). 3. If connection is correct, following message appears. 4. Click “OK” button. 5. Insert the floppy disk for version up data into A drive. 6.
  • Page 401 7. Click “Open” button, then following screen appears. 8. Then click “Operations” on menu bar and select “Chain Operation”. Then following screen appears. 9. Select the device from the “Device Type” column on the Chain Operation Window. Click the “Selected Device Operation” and select “Program”. Perform this procedure to all devices.
  • Page 402 10. Click “Execute” button. 11. When the following screen with the message of “All operation were completed successfully.” appears, data writing is completed. INF-24...

  • Page 403: Error Rate Display And Confirmation Method

    10. Error Rate Display and Confirmation Method The error rate is displayed on the AUDIO LEVEL METER in Service mode. (When enters in Service menu mode, the AUDIO LEVEL METER changes into the error display mode automatically.) The error rate of the head selected for the setting of “B00: RF ADJUST” in the service menu. While the DVCPRO is played back, the selection is possible when “C45 PB HEAD”...

  • Page 404: Internal Switch Setting Method

    11. Internal Switch Setting Method The switches setting on each circuit board are shown below. The switches “Factory use only” must be set to the “factory setting”. FACTORY BOARD Ref. No. FEATURE SETTING − F1: AUDIO SW4100 HIGH Audio input impedance setting (600Ω/ HIGH) −...

  • Page 405: Service Menu

    13. Service Menu 13-1. Service Menu Operation Method 1. Confirm that the “REMOTE/LOCAL” switch on the front panel is set to the “LOCAL”. 2. Press the “MENU” button on the front panel to display the “SETUP-MENU”. 3. When the “SETUP-MENU” is displayed, press the “MENU” button while pressing the “EJECT” button and the “STOP”...

  • Page 406: Default Operation

    13-2. DEFAULT Operation 13-2-1. RF adjustment (B00) In the RF adjustment, it is possible to save the set values to an area different from the back up area for the present set valng. The saved setting can be loaded as the present setting. This operation is effective only after the loading is completed.

  • Page 407: Service Menu Contents

    13-3. Service Menu Contents A00: SERVO ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. A01 FG DC ADJ Automatic adjustment of the DC offset of the capstan, S/T-Reel FG. This shall be done is in EJECT condition. Operation: 1.
  • Page 408 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. A06 T PHOTO Voltage Indication of the detection voltage of the photo sensor for beginning and end value detection on the T-side This is used for adjustment of the sensitivity of the photosensor. 0.0V Operation 1.
  • Page 409 B00: RF ADJUST RF ADJUST has a subscreen composition, and there is a hierarchical structure for each format. RF ADJUST subscreen Item Item contents SUPER DISP. C00 PRO ADJUST Adjustment for DVCPRO (25 Mbps) D00 DV ADJUST Adjustment for DV •...
  • Page 410 C-1: REC ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. REC CURR L -128 -128 Adjustment of the RP L head recording current REC FREQ L -128 -128 Adjustment of the RP L head recording f characteristic REC CURR R -128 -128...
  • Page 411 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. Playback signal envelope level read-out value averaged for each ENV L track of each head ENV L: Lch head ENV R: Rch head Averaging is performed at 8 points in the track, and the newest track value for which averaging has been completed at the time when read-out is started will be read out.
  • Page 412 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. TH ULK Setting of the threshold value for judging the signal quality after equalization The judgment result for the signal quality is used for adaptive equalization, PLL, fault detection function, and other control.
  • Page 413 Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. The initial values for six of the seven tap coefficients of the adaptive T R 3A equalization filter, excluding the fixed center tap, are set for the Rch head.
  • Page 414 C-1: REC ADJUST / C-2: RP ADJUST / C-3: PB ADJUST COMMON ITEM Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. VITERBI MODE Setting whether Viterbi decoding is to be used for detection of playback data or not •...
  • Page 415 E00: VIN ADJUST VIN ADJUST has a subscreen composition, and there is a hierarchical structure for each format. VIN ADJUST subscreen Item Item contents SUPER DISP. CMPNT ADJUST Adjustment to component input CMPST ADJUST Adjustment of composite input YC ADJUST Adjustment of S-VIDEO (Y/C) input E-1: CMPNT ADJUST Item...
  • Page 416 E-2: CMPST ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. E00 SITE Y GAIN -128 -128 Adjustment of composite Y level E01 SITE Y OFS -128 -128 Adjustment of composite Y offset level E02 SITE PB GAIN -128 -128...
  • Page 417 E-3: Y/C ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. E00 YC Y GAIN -128 -128 Adjustment of the Y level for S-VIDEO (YC) E01 YC Y OFS -128 -128 Adjustment of the Y offset for S-VIDEO (YC) E02 YC PB GAIN -128 -128...
  • Page 418 F00: VIDEO ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. F03 VIDEO MUTE NORMAL Select whether the VIDEO output is to be made gray or not MUTE 0:Normal output 1:Forced gray output F06 EE TEST MODE NORMAL EE check for the entire signal processing system...

  • Page 419: Set-Up Menu Initialization

    H00: OTHER ADJUST Item Set value Setting contents and BACK Remarks SUPER SUPER outline function explanation DISP. DISP. H01 STILL LIMIT 2 min Set the maximum value of the "SETUP-MENU 400 : STILL TIMER". 6 min Decide whether the still timer should be reset when the STANDBY- ON command is received during the STOP mode.

  • Page 420: Notes On Removal Of Pcb F3A, F3B, F8

    14. Notes on Removal of PCB F3A, F3B, F8 In AJ-D455E, the H-PCBs (half-size PCBs) are inserted in the F-PCB (full-size PCB) slots. Pulling of the three PCBs, F3A (SDI option), F3B (DIF option), and F8 (RF), with only one リア...

  • Page 421: Auto Off Mode

    15. Auto OFF mode In case AUTO OFF Error is occurred, error number is flashed on counter display of front panel and error message appear on the monitor screen(superimpose on VIDEO 3 OUT). The number of below table indicates as priority display of error number and message, when some error occurred at the same time.
  • Page 422 Display Detection Reset Contents (20 characters) Operation Place Condition E-60 DRUM ROTA The cylinder motor speed is abnormally high. PG STOP SERVO POWER OFF → interval is less than 3ms for 2seconds. TOO FAST E-61 CAP ROTA TOO The capstan motor speed is abnormally low. In the STOP SERVO POWER...

  • Page 423: Circuit Board Layout Drawing

    16. Circuit board layout drawing INF-45...

  • Page 424: Aj-Yad455P Service Information

    17. AJ-YAD455P Service Information 17-1. Node Unique ID (UID) number Setting Procedure <Confirmation of UID number> AJ-YAD455 has “Node Unique ID” for IEEE1394 I/F. This number is displayed in the DIF STATUS MENU. Press the “DIAG” button, then open the Warning page. Press the “!”...

  • Page 425: Version Upgrade For Flash Memory

    17-2. Version Upgrade for Flash Memory The AJ-YAD455P (F3B: DIF board) has flash memory. For the software version up, connect the “Flash memory version up tool (VFK1304A)” to the tool connection connector and use the “Flash memory version up software (VFK1248E)”.
  • Page 426 Connector on the circuit board side Flat cable Blue side Flat cable Tool connector Blue side on top 17-2-2. Version Upgrade Procedure 1. Boot up the personal computer in the condition which “16-2-1. Version Upgrade Preparations” is completed. 2. Turn on the power of the AJ-D455E. Confirm that the LED1 and LED2 on the DIF board should be OFF. 3.
  • Page 427 6. When the settings on the “Setup Panel” is completed, click “Ok(O)”. The “Main Panel” will be opened as shown below. 7. Click “Start (S) ” on the “Main Panel”. (If you want to quit here, click “Exit”. If you want to return again to the “Setup Panel”, click “Setup(Z)”.) 8.

  • Page 428: Pld Version Upgrade Procedure

    17-3. PLD Version Upgrade Procedure The AJ-YAD455P uses PLDs. At the time of a version upgrade, use the special tool, connect the respective connection connectors, and use the PLD writing software. 17-3-1. PLD Chart Numbe Circuit board name Connector r of PLD No.
  • Page 429 C. Boot up the Ver. Up Software and Ver. up Procedure 1. After download the program, “Xilinx CPLD Webpack” folder is created on windows. Click the start button of windows program “Xilinx CPLD Webpack”, then Device Program is boot up and following screen appears.
  • Page 430 3. If connection is correct, following message appears. 4. Click “OK” button. 5. Insert the floppy disk for version up data into A drive. 6. Open the target file. This file called Disk file, because one file can write several CPLDs like a chain. 7.
  • Page 431 8. Then click “Operations” on menu bar and select “Chain Operation”. Then following screen appears. 9. Select the device from the “Device Type” column on the Chain Operation Window. Click the “Selected Device Operation” and select “Program”. Perform this procedure to all devices. 10.

  • Page 432: Disassembly Procedures

    DISASSEMBLY PROCEDURES CONTENTS DISASSEMBLY PROCEDURES ............DIS-1 1-1. Removal of Top Panel .............DIS-1 1-2. Removal of Bottom Panel ............DIS-1 1-3. Removal of Front Panel Unit ............DIS-1 1-4. Removal of Front Loading Unit ..........DIS-1 1-5. Removal of Mechanism Unit ............DIS-2 1-6. Removal of Cylinder Unit ............DIS-3 1-7.

  • Page 433: Removal Of Top Panel

    DISASSEMBLE PROCEDURES 1-1. Removal of Top Panel 1-3. Removal of Front Panel 1. Loosen s screws (A) and remove the Top Panel. 1. Unscrew the 4 screws (A) and remove the Front Panel. Screws (A) Screws (A) Notes:1. When remove the Front Panel, slightly pull the Front panel for direction in arrow (a) 1-2.

  • Page 434: Removal Of Mechanism Unit

    3. Disconnect 2 connectors (A) at Front Loading 5. Unscrew the 4 screws (A) and (B), then remove the motor Board and the Interconnection Board. Front Loading Unit. Screws (B) Interconnection Board Front Loading Motor Part Screws (A) Connectors (A) 4.

  • Page 435: Removal Of Cylinder Unit

    1-6. Removal of Cylinder Unit 1. Remove the Mechanism Unit. Refer to item 1-5. 2. Unscrew a screw (A). 3. Unscrew the 2 screws (B) and remove the T1 Guide. Screws (A) Connector (B) T1Guide Screw (A) Screws (B) Notes: 1.

  • Page 436: Electrical Adjustment

    ELECTRICAL ADJUSTMENT CONTENTS 1. POWER SUPPLY UNIT ..........................ELE-1 1-1. Power Supply Voltage Adjustment....................ELE-1 2. SERVO..............................ELE-1 2-1. SERVO FG Offset Adjustment ....................ELE-1 2-2. Reel Torque Gain Adjustment....................ELE-2 2-3. Motor Torque Offset Adjustment....................ELE-2 2-4. Tension Sensor Voltage Adjustment (1) ...................ELE-3 2-5. Tension Sensor Voltage Adjustment (2) ...................ELE-3 2-6.
  • Page 437 5-7. Component Y signal level Adjustment ..................ELE-20 5-8. Component Y Signal Offset level Adjustment ................ELE-20 5-9. Component Pb Signal Offset level Adjustment ................ ELE-21 5-10. Component Pr signal Offset level Adjustment................ELE-21 5-11 Component Pb signal Level Adjustment .................. ELE-22 5-12.

  • Page 438: Power Supply Unit

    1. POWER SUPPLY UNIT 2. SERVO 2-1. SERVO FG Offset Adjustment 1-1. Power Supply Voltage Adjustment BOARD SERVO (F7) ----- BOARD POWER UNIT ADJ. Service Menu TP6 (+3.3V) (on the extension board) TAPE ----- ADJ. VR1201 (+3.3V) INPUT ----- TAPE ----- MODE EJECT...

  • Page 439: Reel Torque Gain Adjustment

    2-2. Reel Torque Gain Adjustment 2-3. Motor Torque Offset Adjustment BOARD SERVO (F7) ----- BOARD SERVO (F7) ADJ. Service Menu S,T REEL TABLE TAPE ----- ADJ. SERVICE MENU INPUT ----- TAPE ----- MODE EJECT INPUT ----- M. EQ Monitor TV MODE EJECT SPEC.

  • Page 440: Tension Sensor Voltage Adjustment (1)

    Connect the Carriage tool (see the following 2-4. Tension Sensor Voltage figure) to connector P1 which is coming from the Adjustment (1) MECH. I/F board to Carriage board of the front loading unit. BOARD SERVO (F7) Open the SERVICE MENU. (Refer to SEC1 TP201 Service Information.) ADJ.

  • Page 441: Pg Shifter Adjustment

    2-6. PG Shifter Adjustment BOARD SERVO (F7) TP233 (RP HSW) TP320 (SPA) ADJ. Service Menu TAPE VFM3680KM/KL INPUT ----- MODE EJECT M. EQ Oscilloscope SPEC. T1, T2 = 126.4 ± 4µs Open the SERVICE MENU. (Refer to SEC1 Service Information.) Select the A00: SERVO ADJUST and press the “SET”...

  • Page 442: Rf/Eq (F8)

    3. RF/EQ (F8) The adjustment of this section should be performed after adjusting the Servo (F7) board. This adjustment mainly uses the Service Menu. The procedures for opening the menu, changing the settings and closing the menu are described below. Opening the Service Menu a) Press the “MENU”...

  • Page 443: Adjustment Data Initialization

    Press the MENU button to return to the C00: PRO 3-1. Adjustment Data Initialization ADJUST menu. Open the C-3: PB ADJUT in the Service Menu. Initialize the adjustment values for the following items 10. Select the C32: IC READ and change the setting before starting the adjustment.

  • Page 444: Envelope Level Adjustment

    3-3. Envelope Level Adjustment 3-4. Phase Compensation Adjustment BOARD RF/EQ (F8) TP20, TP10, TP2 (Trigger) BOARD RF/EQ (F8) ADJ. Service Menu Audiometer (Error Rate Display) TAPE 625(PAL): VFM3680KM (L)/VFM3110EDS ADJ. Service Menu. Alignment Tape (Colour Bar) TAPE 625(PAL): VFM3680KM (L)/VFM3110EDS INPUT Colour bar Alignment Tape (Colour Bar)

  • Page 445: Confirmation Of Error Rate And Aeq Tap Coefficient Values

    25. Select the D31: IC READ and change the setting 3-5. Confirmation of Error Rate and from “SINGLE” to “OFF”. Press the “SET” AEQ Tap Coefficient Values button. BOARD RF/EQ (F8) Audiometer (Error Rate Display). CH 1 ADJ. Service Menu TAPE 625(PAL): VFM3680KM (L)/VFM3110EDS CH 2...

  • Page 446: Rec Frequency Characteristic And Rec Current Adjustment

    12. Set the numerical value of C01: REC CURR L 3-6. REC Frequency Characteristic and C03: REC CURR R as follows. and REC Current Adjustment C01: REC CURR L! ! ! ! -120 C03: REC CURR R! ! ! ! +120 (DVCPRO 25M) 13.

  • Page 447: Rec Frequency Characteristic And Rec Current Adjustment (Dv)

    12. Insert the DV alignment tape (VFM3110EDS) and 3-7. REC Frequency Characteristic play it back. and REC Current Adjustment 13. Confirm that the level difference between the TRACE B (Memorized self-recording playback (DV) spectrum) and TRACE A (Alignment tape playback spectrum) at 5 MHz is in the following BOARD EQ MAIN (H2) specification.

  • Page 448: Out (F2)

    4. V OUT (F2) 4-1. Connection 4-9. Component Sync DC Adjustment 4-2. Reference PLL Center Frequency Adjustment 4-3. Reference CF Detection Adjustment 4-10. Component Y Level Adjustment 4-11. Component Pb Level Adjustment 4-4. Composite Sync DC Level Adjustment 4-5. Composite Y Level Adjustment 4-12.

  • Page 449: Reference Pll Center Frequency Adjustment

    4-2. Reference PLL Center 4-3. Reference CF Detection Frequency Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) TP600 (VCO) TP561 (Trigger) Composite Signal CF OUT, TP704 (CF) ADJ. VC600 (FREQ ADJ) TP702 (CF_TP2), TP703 (CF_TP1) TAPE ----- ADJ. VR560 (SCH DET) INPUT REF VIDEO IN...

  • Page 450: Composite Sync Dc Level Adjustment

    4-4. Composite Sync DC Level 4-6. Composite YC Timing Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) VIDEO OUT 1 (CH B) VIDEO OUT 1 (CH B) ADJ. VR452 (ENC SYNC DC) ADJ. VR456 (ENC C DL) TAPE 625(PAL): VFM3680KM (L) TAPE 625(PAL): VFM3680KM (L)

  • Page 451: System Sub-Carrier Phase Adjustment

    4-8. System Sub-Carrier Phase 4-9. Component Sync DC Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) REF IN (CH A), VIDEO OUT 1 (CH B) Y OUT (CH B1) ADJ. VR600 (SYS SC) ADJ. VR301 (SYNC DC) TAPE 625(PAL): VFM3680KM (L) TAPE 625(PAL): VFM3680KM (L)
  • Page 452 4-11.Component Pb Level 4-13.Component Y-Pb Timing Adjustment Adjustment BOARD BOARD V OUT (F2) V OUT (F2) Pb OUT (CH B2) Y OUT (CH B1), Pb OUT (CH B2) ADJ. VR400 (PB LEV) ADJ. VR302 (Pb DL) TAPE 625(PAL): VFM3680KM (L) TAPE 625(PAL): VFM3680KM (L) Alignment Tape (Color Bar)

  • Page 453: Component Pb Level Adjustment

    5. V IN (F5) 5-1. Connection and Menu Setting 5-17. Composite Pb Signal Offset level Adjustment 5-2. PL DC Adjustment 5-18. Composite Pr signal Offset level Adjustment 5-3. Composite Color Demodulation Timing Adjustment 5-19. Composite Pb signal Level Adjustment 5-20. Composite Pr Signal Level Adjustment 5-4.

  • Page 454: Connection And Menu Setting

    5-1. Connection and Menu Setting Select Wave Form Monitor AJ-D455E Signal Generator Ch A1 Y OUT (Termination ON) Component Y Y IN Ch A2 PB OUT (Termination ON) Component PB PB IN Ch A3 PR OUT (Termination ON) Component PR PR IN Ch A (Termination ON)

  • Page 455: Composite Color Demodulation Timing Adjustment

    5-2. PLL DC Adjustment 5-4. Composite SCH Detection Adjustment BOARD V IN (F5) TP552 (PLL DC) BOARD V IN (F5) ADJ. VC500 (VCO DC) TP980 (INCF), TP932, TP933 TAPE ----- ADJ. VR402 (SCH SITE) INPUT Analog Component Signal TAPE ----- (100% Color Bar) INPUT CF Signal...

  • Page 456: Yc In Color Demodulation Timing Adjustment

    5-5. YC IN Color Demodulation 5-6. YC IN SCH Detection Timing Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) TP400, TP401 TP980 (INCF), TP932, TP933 ADJ. VR403 (RSTH YC), Service Menu ADJ. VR404 (SCH YC) TAPE ----- TAPE ----- INPUT Analog YC Signal...

  • Page 457: Component Y Signal Level Adjustment

    5-7. Component Y signal level 5-8. Component Y Signal Offset Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Y OUT Component Y OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal INPUT Analog Component Signal (100% Color Bar)

  • Page 458: Component Pb Signal Offset Level Adjustment

    5-9. Component Pb Signal Offset 5-10.Component Pr signal Offset level Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component PB OUT Component PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal INPUT Analog Component Signal (0% Flat Field)

  • Page 459: Component Pb Signal Level Adjustment

    5-11 Component Pb signal Level 5-12.Component Pr Signal Level Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component PB OUT Component PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal INPUT Analog Component Signal (100% Color Bar) (100% Color Bar)

  • Page 460: Component Pb Signal Timing Adjustment

    5-13.Component Pb Signal Timing 5-14.Component Pr Signal Timing Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component Pr OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Component Signal (Bowtie) INPUT Analog Component Signal (Bowtie) βCAM Level MODE...

  • Page 461: Composite Y Signal Level Adjustment

    5-15.Composite Y signal Level 5-16.Composite Y Signal Offset Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Y OUT Component Y OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Composite Signal INPUT Analog Composite Signal (100% Color Bar) (100% Colour Bar)

  • Page 462: Composite Pb Signal Offset Level Adjustment

    5-17.Composite Pb Signal Offset 5-18.Composite Pr signal Offset level Adjustment level Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component Pr OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Composite Signal INPUT Analog Composite Signal (0% Flat Field)

  • Page 463: Composite Pb Signal Level Adjustment

    5-19.Composite Pb signal Level 5-20.Composite Pr Signal Level Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Composite PB OUT Composite PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog Composite Signal INPUT Analog Composite Signal (100% Colour Bar) (100% Colour Bar) MODE...

  • Page 464: Composite Pb/Pr Signal Timing Adjustment

    5-21.Composite Pb/Pr Signal Timing Adjustment BOARD V IN (F5) COMPONENT Y, Pr, Pb OUT Y OUT ADJ. Service Menu TAPE ----- Analog Composite Signal INPUT 12.5T Pulse COMPONENT (Pulse and Bar with 12.5T modulation Signal) PB or PR OUT MODE M.

  • Page 465: Composite Video Out Phase Adjustment

    5-22.Composite Video Out Phase 5-23.Composite Vector Adjustment Adjustment BOARD V IN (F5) VIDEO 1 OUT BOARD V IN (F5) ADJ. Service Menu VIDEO IN THRU TAPE ----- VIDEO2 OUT INPUT Analog Composite Signal ADJ. VR550 (SYNC0) (100% Colour Bar) TAPE ----- MODE Analog Composite Signal...

  • Page 466: Y Signal Level (Yc In) Adjustment

    5-24.Y Signal Level (YC IN) 5-25.Y Signal Offset Level (YC IN) Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Y OUT Component Y OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog YC Signal INPUT Analog YC Signal (100% Colour Bar)

  • Page 467: Pb Signal Offset Level (Yc In) Adjustment

    5-26.Pb Signal Offset level (YC IN) 5-27.Pr Signal Offset level (YC IN) Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component Pr OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog YC Signal INPUT Analog YC Signal (0% Flat Field)

  • Page 468: Pb Signal Level (Yc In) Adjustment

    5-28.Pb signal Level (YC IN) 5-29.Pr signal Level (YC IN) Adjustment Adjustment BOARD BOARD V IN (F5) V IN (F5) Component Pb OUT Component PR OUT ADJ. Service Menu ADJ. Service Menu TAPE ----- TAPE ----- INPUT Analog YC Signal INPUT Analog YC Signal (100% Colour Bar)

  • Page 469: Pb/Pr Signal Timing (Yc In) Adjustment

    5-30.Pb/Pr Signal Timing (YC IN) Adjustment BOARD V IN (F5) COMPONENT Y, Pr, Pb OUT Y OUT ADJ. Service Menu TAPE ----- Analog YC Signal 12.5T Pulse INPUT COMPONENT (Pulse and Bar with 12.5T modulation PB or PR OUT Signal) MODE M.

  • Page 470: Yc In Vector Adjustment

    5-31.YC IN Vector Adjustment BOARD V IN (F5) VIDEO 1 OUT ADJ. Service Menu TAPE ----- INPUT Analog YC Signal (100% Colour Bar with 7.5% Set-up) MODE M. EQ Analog WFM SPEC All vector dots are in the inner box Open the SERVICE MENU.

  • Page 471: Audio (F1) And Rf/Cue

    6. AUDIO (F1) and 6-2. CH1, CH2 Output Level Adjustment RF/CUE BOARD AUDIO (F1) 6-1. Setting AUDIO OUT (CH1, CH2) ADJ. VR300 (CH1 OUT LV) Set the audio impedance switches on the Audio VR301 (CH2 OUT LV) (F1) board as shown below. TAPE ----- INPUT...

  • Page 472: Cue Bias Current Adjustment

    6-4. CUE BIAS CURRENT 6-6. CUE REC/PB Level Adjustment Adjustment BOARD AUDIO (F1) TP4005 [RF/CUE Board] BOARD RF/CUE TP4006 (GND) [RF/CUE Board] TP4005 [RF/CUE Board] AUDIO OUT (CH1) TP4006 (GND) [RF/CUE Board] ADJ. SERVICE MENU ADJ. VR4001(BIAS), FL4001(Core) VR802 (REC CURR) TAPE Blank Tape TAPE...

  • Page 473: Tp, Vr, Sw Location

    7. TP, VR, SW Location F1 AUDIO P.C.BOARD (VEP84374A) COMPONENT SIDE F2 V OUT P.C.BOARD (VEP83557B) COMPONENT SIDE ELE-36...

  • Page 474: Component Side

    F3A SDI P.C.BOARD (VEP83558A) (AJ-YA455P) COMPONENT SIDE F4 D PROC P.C.BOARD (VEP83554B) FOIL SIDE ELE-37...
  • Page 475 F5 V IN P.C.BOARD (VEP83553B) COMPONENT SIDE F6 SYSCON P.C.BOARD (VEP86314B) COMPONENT SIDE ELE-38...
  • Page 476 F7 SERVO P.C.BOARD (VEP82238B) COMPONENT SIDE F8 RF EQ P.C.BOARD (VEP85196A) COMPONENT SIDE ELE-39...
  • Page 477 MECHA IF P.C.BOARD (VEP82239A) COMPONENT SIDE RF CUE P.C.BOARD (VEP85197A) COMPONENT SIDE ELE-40...
  • Page 478 CSP SUB P.C.BOARD (VEP83555A) FOIL SIDE ELE-41...

  • Page 479: Block Diagrams

    BLOCK DIAGRAMS CONTENTS OVERALL BLOCK DIAGRAM ................BLK-1 F1:AUDIO BLOCK DIAGRAM ................BLK-3 F2:VIDEO OUT BLOCK DIAGRAM ..............BLK-5 FRONT BLOCK DIAGRAM................... BLK-7 F4:D PROCESS BLOCK DIAGRAM..............BLK-8 F5:VIDEO IN BLOCK DIAGRAM ................BLK-13 F6:SYSCON BLOCK DIAGRAM................BLK-15 F7:SERVO BLOCK DIAGRAM ................BLK-17 RF/CUE BLOCK DIAGRAM..................

  • Page 480: Overall Block Diagram

    OVERALL BLOCK DIAGRAM (1/2) BLK-1...
  • Page 481 OVERALL BLOCK DIAGRAM (2/2) BLK-2...

  • Page 482: F1:Audio Block Diagram

    F1:AUDIO BLOCK DIAGRAM (1/2) BLK-3...
  • Page 483 F1:AUDIO BLOCK DIAGRAM (2/2) IC4504, IC4507<6> BLK-4...

  • Page 484: F2:Video Out Block Diagram

    F2:VIDEO OUT BLOCK DIAGRAM (1/2) IP202<3> IC568<10> BLK-5...
  • Page 485 F2:VIDEO OUT BLOCK DIAGRAM (2/2) BLK-6...

  • Page 486: Front Block Diagram

    FRONT BLOCK DIAGRAM IC7 <2> BLK-7...

  • Page 487: F4:D Process Block Diagram

    F4:D PROCESS BLOCK DIAGRAM (1/5) IC3631 <18> IC3661 <19> BLK-8...
  • Page 488 F4:D PROCESS BLOCK DIAGRAM (2/5) BLK-9...
  • Page 489 F4:D PROCESS BLOCK DIAGRAM (3/5) BLK-10...
  • Page 490 F4:D PROCESS BLOCK DIAGRAM (4/5) BLK-11...
  • Page 491 F4:D PROCESS BLOCK DIAGRAM (5/5) BLK-12...

  • Page 492: F5:Video In Block Diagram

    F5:VIDEO IN BLOCK DIAGRAM (1/2) BLK-13...
  • Page 493 F5:VIDEO IN BLOCK DIAGRAM (2/2) IC3630<13> BLK-14...

  • Page 494: F6:Syscon Block Diagram

    F6:SYSCON BLOCK DIAGRAM (1/2) BLK-15...
  • Page 495 F6:SYSCON BLOCK DIAGRAM (2/2) BLK-16...

  • Page 496: F7:Servo Block Diagram

    F7:SERVO BLOCK DIAGRAM (1/2) BLK-17...
  • Page 497 F7:SERVO BLOCK DIAGRAM (2/2) BLK-18...

  • Page 498: Rf/Cue Block Diagram

    RF CUE BLOCK DIAGRAM IC5101<2> BLK-19...

  • Page 499: F8:Rf/Eq Block Diagram

    F8:RF/EQ BLOCK DIAGRAM BLK-20...

  • Page 500: F3A:sdi Block Diagram(Aj-Ya455P)

    F3A:SDI BLOCK DIAGRAM (1/2) (AJ-YA455P) BLK-21...
  • Page 501 F3A:SDI BLOCK DIAGRAM (2/2) (AJ-YA455P) BLK-22...
  • Page 502 F3B: DIF BLOCK DIAGRAM (1/2) (AJ-YAD455P) DIF JACK C.B.A. BLK-23...
  • Page 503 F3B: DIF BLOCK DIAGRAM (2/2) (AJ-YAD455P) IP401<4> BLK-24...
  • Page 504 SCHAMATIC DIAGRAMS NOTE: BE SURE TO MAKE YOUR ORDERS OF REPLACEMENT PARTS ACCORDING TO PARTS LIST, SECTION 7...
  • Page 505 CONTENTS PLL (22/27) ..........SCM051 F1 : AUDIO PCMCNT (23/27) ........SCM052 AUDIO (CONNECTOR) (1/9) ....SCM001 SLOW (24/27) ........SCM053 AUDIO (INPUT_12) (2/9) .......SCM002 ACNT (25/27)......... SCM054 AUDIO (A/D, D/A) (3/9) ......SCM003 SRC (26/27) ........... SCM055 AUDIO (D/AOUT_12LR) (4/9) ....SCM004 AMEM (27/27)........
  • Page 506 SERVO (POWER) (7/14) ....... SCM100 DV uCOM SERVO (SW2) (8/14) ......SCM101 DV u COM (1/1)........SCM142 SERVO (SW1) (9/14) ......SCM102 SERVO (RL_DRV) (10/14) ....SCM103 FRONT SERVO (CA_CY_DRV) (11/14) ..... SCM104 FRONT (KEY & LED) (1/3).....SCM143 SERVO (M_IF) (12/14) ......SCM105 FRONT (VFD) (2/3) ........SCM144 SERVO (13/14) ........
  • Page 507 COMPONENT F1:AUDIO(CONNECTOR) 01/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (1/9) VEP84374A SCM001...
  • Page 508 COMPONENT F1:AUDIO (INPUT_12) 02/09 NAME DRAWING NO. CIRCUIT BOARD NO. KR4K05 (2/9) VEP84374A SCM002...
  • Page 509 COMPONENT F1:AUDIO (D/A, A/D) 03/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05(3/9) VEP84374A SCM003...
  • Page 510 COMPONENT F1:AUDIO (D/AOUT_12LR) 04/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05(4/9) VEP84374A SCM004...
  • Page 511 COMPONENT F1:AUDIO (MIX/HP_OUT) 05/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (5/9) VEP84374A SCM005...
  • Page 512 COMPONENT F1:AUDIO (OUT PUT_12) 06/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (6/9) VEP84374A SCM006...
  • Page 513 COMPONENT F1:AUDIO (PIO) 07/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (7/9) VEP84374A SCM007...
  • Page 514 COMPONENT F1:AUDIO (CUE_R/P) 08/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (8/9) VEP84374A SCM008...
  • Page 515 COMPONENT F1:AUDIO (CUE_INPUT) 09/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR4K05 (9/9) VEP84374A SCM009...
  • Page 516 COMPONENT F2:V OUT (CONNECTOR) 01/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (1/14) VEP83557B SCM010...
  • Page 517 COMPONENT F2:V OUT (COM_BUFF) 02/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (2/14) VEP83557B SCM011...
  • Page 518 COMPONENT F2:V OUT (DIN_BUFF) 03/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (3/14) VEP83557B SCM012...
  • Page 519 COMPONENT F2:V OUT (PROC) 04/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (4/14) VEP83557B SCM013...
  • Page 520 COMPONENT F2:V OUT (DOUT_BUFF) 05/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (5/14) VEP83557B SCM014...
  • Page 521 COMPONENT F2:V OUT (DAC) 06/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (6/14) VEP83557B SCM015...
  • Page 522 COMPONENT F2:V OUT (COMPONENT_BUFF) 07/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (7/14) VEP83557B SCM016...
  • Page 523 COMPONENT F2:V OUT (YC_MIX) 08/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (8/14) VEP83557B SCM017...
  • Page 524 COMPONENT F2:V OUT (COMPOSITE_BUFF) 09/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (9/14) VEP83557B SCM018...
  • Page 525 COMPONENT F2:V OUT (SYNC_SEP) 10/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091(10/14) VEP83557B SCM019...
  • Page 526 COMPONENT F2:V OUT (PLL) 11/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (11/14) VEP83557B SCM020...
  • Page 527 COMPONENT F2:V OUT (SYNC_GEN) 12/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (12/14) VEP83557B SCM021...
  • Page 528 COMPONENT F2:V OUT (INT) 13/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (13/14) VEP83557B SCM022...
  • Page 529 AJ-D455E AJ-D455E COMPONENT F2:V OUT (PARTS_TABLE) 14/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR30091 (14/14) VEP83557B SCM023...
  • Page 530 COMPONENT F3A:SDI (CONNECTOR) 01/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (1/6) VEP83558A SCM024...
  • Page 531 COMPONENT F3A:SDI (SYSIO) 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (2/6) VEP83558A SCM025...
  • Page 532 COMPONENT F3A:SDI (S2P) 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (3/6) VEP83558A SCM026...
  • Page 533 COMPONENT F3A:SDI (DECODER) 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (4/6) VEP83558A SCM027...
  • Page 534 COMPONENT F3A:SDI (P2S_1) 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092 (5/6) VEP83558A SCM028...
  • Page 535 VSI3569A COMPONENT F3A:SDI (P2S_2) 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30092(6/6) VEP83558A SCM029...
  • Page 536 COMPONENT F4:D PROC (MOTHER) 01/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (1/27) VEP83554B SCM030...
  • Page 537 COMPONENT F4:D PROC (POWER) 02/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (2/27) VEP83554B SCM031...
  • Page 538 COMPONENT F4:D PROC (AVIF) 03/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (3/27) VEP83554B SCM032...
  • Page 539 VSI3555A COMPONENT F4:D PROC (ISP) 04/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (4/27) VEP83554B SCM033...
  • Page 540 COMPONENT F4:D PROC (IOBUF_V) 05/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (5/27) VEP83554B SCM034...
  • Page 541 COMPONENT F4:D PROC (IOBUF_A) 06/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (6/27) VEP83554B SCM035...
  • Page 542 PAT/J3 22K/J3 15K/J3 15K/J3 22K/J3 COMPONENT F4:D PROC (PLL_VCO) 07/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (7/27) VEP83554B SCM036...
  • Page 543 COMPONENT F4:D PROC (TBC_FIFO) 08/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (8/27) VEP83554B SCM037...
  • Page 544 COMPONENT F4:D PROC (DV_IO FPGA1) 09/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (9/27) VEP83554B SCM038...
  • Page 545 COMPONENT F4:D PROC (CSP_CON) 10/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (10/27) VEP83554B SCM039...
  • Page 546 COMPONENT F4:D PROC (DV_ PROC) 11/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (11/27) VEP83554B SCM040...
  • Page 547 COMPONENT F4:D PROC (EE_FIFO) 12/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (12/27) VEP83554B SCM041...
  • Page 548 COMPONENT F4:D PROC (REC_DV_CON) 13/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (13/27) VEP83554B SCM042...
  • Page 549 COMPONENT F4:D PROC (PB_DV_CON) 14/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (14/27) VEP83554B SCM043...
  • Page 550 COMPONENT F4:D PROC (VIDEO DATA VITC/CC) 15/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (15/27) VEP83554B SCM044...
  • Page 551 COMPONENT F4:D PROC (LVDS) 16/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (16/27) VEP83554B SCM045...
  • Page 552 COMPONENT F4:D PROC (VBLK_CON) 17/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (17/27) VEP83554B SCM046...
  • Page 553 COMPONENT F4:D PROC (REC_411_FLITER) 18/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088(18/27) VEP83554B SCM047...
  • Page 554 COMPONENT F4:D PROC (PB_411_FILTER) 19/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (19/27) VEP83554B SCM048...
  • Page 555 COMPONENT F4:D PROC (REC_DV_MPU) 20/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (20/27) VEP83554B SCM049...
  • Page 556 COMPONENT F4:D PROC (PB_DV_MPU) 21/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (21/27) VEP83554B SCM050...
  • Page 557 COMPONENT F4:D PROC (PLL) 22/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (22/27) VEP83554B SCM051...
  • Page 558 COMPONENT F4:D PROC (PCMCNT) 23/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (23/27) VEP83554B SCM052...
  • Page 559 COMPONENT F4:D PROC (SLOW) 24/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088(24/27) VEP83554B SCM053...
  • Page 560 COMPONENT F4:D PROC (ACNT) 25/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (25/27) VEP83554B SCM054...
  • Page 561 COMPONENT F4:D PROC (SRC) 26/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (26/27) VEP83554B SCM055...
  • Page 562 COMPONENT F4:D PROC (AMEM) 27/27 NAME CIRCUIT BOARD NO. DRAWING NO. KR30088 (27/27) VEP83554B SCM056...
  • Page 563 COMPONENT CSP SUB (CONNECTOR) 01/06 NAME DRAWING NO. CIRCUIT BOARD NO. KR30089 (1/6) VEP83555A SCM057...
  • Page 564 COMPONENT CSP SUB (REC VIOLA) 02/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (2/6) VEP83555A SCM058...
  • Page 565 CSP SUB (REC LUPIN) COMPONENT 03/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (3/6) VEP83555A SCM059...
  • Page 566 COMPONENT CSP SUB (PB VIOLA) 04/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (4/6) VEP83555A SCM060...
  • Page 567 COMPONENT CSP SUB (PB LUPIN) 05/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (5/6) VEP83555A SCM061...
  • Page 568 COMPONENT CSP SUB (RF_PLL) 06/06 NAME CIRCUIT BOARD NO. DRAWING NO. KR30089 (6/6) VEP83555A SCM062...
  • Page 569 COMPONENT F5:V_IN (CONNECTOR) 01/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (1/18) VEP83553B SCM063...
  • Page 570 COMPONENT F5:V_IN (POWER) 02/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (2/18) VEP83553B SCM064...
  • Page 571 COMPONENT F5:V_IN (COMP_IN) 03/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (3/18) VEP83553B SCM065...
  • Page 572 COMPONENT F5:V_IN (1st_AD) 04/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (4/18) VEP83553B SCM066...
  • Page 573 COMPONENT F5:V_IN (SDEC) 05/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (5/18) VEP83553B SCM067...
  • Page 574 COMPONENT F5:V_IN (SDEC2) 06/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (6/18) VEP83553B SCM068...
  • Page 575 COMPONENT F5:V_IN (DECBUF) 07/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (7/18) VEP83553B SCM069...
  • Page 576 COMPONENT F5:V_IN (4fsc_PLL) 08/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (8/18) VEP83553B SCM070...
  • Page 577 COMPONENT F5:V_IN (CDEM) 09/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (9/18) VEP83553B SCM071...
  • Page 578 COMPONENT F5:V_IN (SYNC_SEP) 10/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (10/18) VEP83553B SCM072...
  • Page 579 COMPONENT F5:V_IN (135M_PLL) 11/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (11/18) VEP83553B SCM073...
  • Page 580 COMPONENT F5:V_IN (M2B_SEL) 12/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (12/18) VEP83553B SCM074...
  • Page 581 COMPONENT F5:V_IN (2nd_AD_Y) 13/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (13/18) VEP83553B SCM075...
  • Page 582 COMPONENT F5:V_IN (2nd_AD_PB) 14/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (14/18) VEP83553B SCM076...
  • Page 583 COMPONENT F5:V_IN (2nd_AD_PR) 15/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (15/18) VEP83553B SCM077...
  • Page 584 COMPONENT F5:V_IN (EVR) 16/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (16/18) VEP83553B SCM078...
  • Page 585 VSI3573C COMPONENT F5:V_IN (DIG_GEN) 17/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (17/18) VEP83553B SCM079...
  • Page 586 COMPONENT F5:V_IN (OUTBUFF) 18/18 NAME CIRCUIT BOARD NO. DRAWING NO. KR2471 (18/18) VEP83553B SCM080...
  • Page 587 COMPONENT F6:SYSCON 01/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (1/13) VEP86314B SCM081...
  • Page 588 COMPONENT F6:SYSCON (IF) 02/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (2/13) VEP86314B SCM082...
  • Page 589 COMPONENT F6:SYSCON (IF) 03/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (3/13) VEP86314B SCM083...
  • Page 590 COMPONENT F6:SYSCON (IF) 04/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (4/13) VEP86314B SCM084...
  • Page 591 COMPONENT F6:SYSCON (IF) 05/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (5/13) VEP86314B SCM085...
  • Page 592 COMPONENT F6:SYSCON (SYS) 06/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (6/13) VEP86314B SCM086...
  • Page 593 COMPONENT F6:SYSCON (SYS) 07/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (7/13) VEP86314B SCM087...
  • Page 594 COMPONENT F6:SYSCON (SYS) 08/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (8/13) VEP86314B SCM088...
  • Page 595 COMPONENT F6:SYSCON (AV) 09/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (9/13) VEP86314B SCM089...
  • Page 596 COMPONENT F6:SYSCON (AV) 10/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (10/13) VEP86314B SCM090...
  • Page 597 COMPONENT F6:SYSCON (AV) 11/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (11/13) VEP86314B SCM091...
  • Page 598 COMPONENT F6:SYSCON (AV) 12/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (12/13) VEP86314B SCM092...
  • Page 599 AJ-D455E VSI3558A VSI3562A VSI3564B COMPONENT SYSCON 13/13 NAME CIRCUIT BOARD NO. DRAWING NO. KR6T80 (13/13) VEP85314B SCM093...
  • Page 600 COMPONENT F7:SERVO (CTL) 01/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (1/14) VEP82238B SCM094...
  • Page 601 COMPONENT F7:SERVO (REEL_FG) 02/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (2/14) VEP82238B SCM095...
  • Page 602 COMPONENT F7:SERVO (CA_CY_FG) 03/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (3/14) VEP82238B SCM096...
  • Page 603 COMPONENT F7:SERVO (CPU) 04/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (4/14) VEP82238B SCM097...
  • Page 604 COMPONENT F7:SERVO (PLD) 05/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (5/14) VEP82238B SCM098...
  • Page 605 COMPONENT F7:SERVO (CPU_IF) 06/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (6/14) VEP82238B SCM099...
  • Page 606 COMPONENT F7:SERVO (POWER) 07/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (7/14) VEP82238B SCM100...
  • Page 607 IMPORTANT SAFETY NOTICE: COMPONENT F7:SERVO (SW2) 08/14 NAME COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. CIRCUIT BOARD NO. DRAWING NO. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE KR2E01 (8/14) SAME TYPE. VEP82238B SCM101...
  • Page 608 COMPONENT F7:SERVO (SW1) 09/14 NAME IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CIRCUIT BOARD NO. DRAWING NO. CHARACTERISTICS FOR SAFETY. KR2E01 (9/14) WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE VEP82238B SAME TYPE. SCM102...
  • Page 609 COMPONENT F7:SERVO (RL_DRV) 10/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01(10/14) VEP82238B SCM103...
  • Page 610 COMPONENT F7:SERVO (CA_CY_DRV) 11/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (11/14) VEP82238B SCM104...
  • Page 611 F7:SERVO (M_IF) COMPONENT 12/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (12/14) VEP82238B SCM105...
  • Page 612 COMPONENT F7:SERVO 13/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (13/14) VEP82238B SCM106...
  • Page 613 VSI3565A COMPONENT F7:SERVO (SOFT) 14/14 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E01 (14/14) VEP82238B SCM107...

  • Page 614: Rf/Cue (1/4)

    COMPONENT RF/CUE 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (1/4) VEP85197A SCM108...

  • Page 615: Rf/Cue (3/4)

    COMPONENT RF/CUE 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (2/4) VEP85197A SCM109...
  • Page 616 COMPONENT RF/CUE 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (3/4) VEP85197A SCM110...
  • Page 617 COMPONENT RF/CUE 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR5586 (4/4) VEP85197A SCM111...

  • Page 618: F8:Rf/Eq

    COMPONENT F8:RF/EQ 01/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (1/7) VEP85196A SCM112...
  • Page 619 COMPONENT F8:RF/EQ 02/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (2/7) VEP85196A SCM113...
  • Page 620 COMPONENT F8:RF/EQ 03/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (3/7) VEP85196A SCM114...
  • Page 621 COMPONENT F8:RF/EQ 04/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (4/7) VEP85196A SCM115...
  • Page 622 COMPONENT F8:RF/EQ 05/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (5/7) VEP85196A SCM116...
  • Page 623 COMPONENT F8:RF/EQ 06/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (6/7) VEP85196A SCM117...
  • Page 624 COMPONENT F8:RF/EQ 07/07 NAME CIRCUIT BOARD NO. DRAWING NO. KR5585 (7/7) VEP85196A SCM118...

  • Page 625: Mother (1/10)

    F1 (AUDIO) COMPONENT MOTHER 01/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (1/10) VEP80C14A SCM119...
  • Page 626 F2 (V_OUT) COMPONENT MOTHER 02/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (2/10) VEP80C14A SCM120...
  • Page 627 F3A (SDI) F3B (DIF) COMPONENT MOTHER 03/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (3/10) VEP80C14A SCM121...
  • Page 628 F4 (D_PROC) COMPONENT MOTHER 04/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (4/10) VEP80C14A SCM122...
  • Page 629 F5 (V_IN) COMPONENT MOTHER 05/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (5/10) VEP80C14A SCM123...
  • Page 630 F6 (SYSCON) COMPONENT MOTHER 06/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (6/10) VEP80C14A SCM124...
  • Page 631 F7 (SERVO) COMPONENT MOTHER 07/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (7/10) VEP80C14A SCM125...
  • Page 632 F8 (RF/EQ) HEAD_BUFF (RF/CUE) COMPONENT MOTHER 08/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (8/10) VEP80C14A SCM126...

  • Page 633: Mecha_If (1/4)

    MECHA_IF POWER COMPONENT MOTHER 09/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (9/10) VEP80C14A SCM127...
  • Page 634 REAR (VA_JACK) FRONT COMPONENT MOTHER 10/10 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q24 (10/10) VEP80C14A SCM128...
  • Page 635 COMPONENT MECHA_IF 01/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (1/4) VEP82239A SCM129...
  • Page 636 COMPONENT MECHA_IF 02/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (2/4) VEP82239A SCM130...
  • Page 637 COMPONENT MECHA_IF 03/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (3/4) VEP82239A SCM131...
  • Page 638 COMPONENT MECHA_IF 04/04 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E02 (4/4) VEP82239A SCM132...

  • Page 639: Mecha If2

    COMPONENT MECHA_IF2 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR2E03 (1/1) VEP82240A SCM133...

  • Page 640: Power1 (2/2)

    CAUTION MARK INDICATES THE PRIMARY CIRCUIT TO DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK DURING REPAIR AND SERVICE OF THE PRODUCTS. COMPONENT POWER1 01/02 NAME IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CIRCUIT BOARD NO.
  • Page 641 COMPONENT CAUTION POWER1 02/02 NAME IMPORTANT SAFETY NOTICE: MARK INDICATES THE PRIMARY CIRCUIT TO CIRCUIT BOARD NO. DRAWING NO. COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. CHARACTERISTICS FOR SAFETY. KR1F70 (2/2) PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE VEP81221B SAME TYPE.

  • Page 642: Power2

    CAUTION IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL COMPONENT POWER2 01/01 MARK INDICATES THE PRIMARY CIRCUIT TO NAME CHARACTERISTICS FOR SAFETY. DISTINGUISH THE PRIMARY FROM THE SECONDARY CIRCUIT. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE CIRCUIT BOARD NO.

  • Page 643: Av_Jack (Connector) (1/5)

    COMPONENT AV_JACK (CONNECTOR) 01/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (1/5) VEP80C13A SCM137...

  • Page 644: Av_Jack (Aes I/O) (4/5)

    COMPONENT AV_JACK (BNC I/O) 02/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (2/5) VEP80C13A SCM138...
  • Page 645 For OVER SEAS For OVER SEAS For JAPAN COMPONENT AV_JACK (AUDIO I/O) 03/05 NAME For OVER SEAS CIRCUIT BOARD NO. DRAWING NO. For JAPAN KR0Q23 (3/5) VEP80C13A SCM139...
  • Page 646 COMPONENT AV_JACK (AES I/O) 04/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (4/5) VEP80C13A SCM140...
  • Page 647 COMPONENT AV_JACK (AES OUT) 05/05 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q23 (5/5) VEP80C13A SCM141...

  • Page 648: Dv Ucom

    COMPONENT DV u COM 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR30103 (1/1) VEP83560A SCM142...
  • Page 649 COMPONENT FRONT (KEY & LED) 01/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR06T81 (1/3) VEP86315A SCM143...

  • Page 650: Front (Vfd) (2/3)

    MA185 COMPONENT FRONT (VFD) 02/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR06T81 (2/3) VEP86315A SCM144...

  • Page 651: Front(Vr, Conector) (3/3)

    0.1/UFV COMPONENT FRONT (VR, CONECTOR) 03/03 NAME CIRCUIT BOARD NO. DRAWING NO. KR06T81 (3/3) VEP86315A SCM145...
  • Page 652 COMPONENT HP (HEAD PHONE) 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q25 (1/1) VEP80C15A SCM146...

  • Page 653: Eject

    COMPONENT EJECT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q26 (1/1) VEP80C16A SCM147...

  • Page 654: Dif Jack

    DIF JACK (1394 JACK) COMPONENT 01/01 NAME CIRCUIT BOARD NO. DRAWING NO. KR0Q49 (1/1) VEP80C21A SCM148...
  • Page 655 F3B : DIF (MOTHER) COMPONENT 01/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (1/9) VEP83559A SCM149...
  • Page 656 F3B : DIF (POWER BUFFER) COMPONENT 02/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 VEP83559A SCM150...
  • Page 657 F3B : DIF (u COM) COMPONENT 03/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (3/9) VEP83559A SCM151...
  • Page 658 F3B : DIF (uCOM MEMORY) COMPONENT 04/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (4/9) VEP83559A SCM152...
  • Page 659 F3B : DIF (PINE) COMPONENT 05/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (5/9) VEP83559A SCM153...
  • Page 660 F3B : DIF (FPGA) COMPONENT 06/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (6/9) VEP83559A SCM154...
  • Page 661 F3B : DIF (FPGA CONFIG) COMPONENT 07/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (7/9) VEP83559A SCM155...
  • Page 662 F3B : DIF (FPGA DRAM) COMPONENT 08/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (8/9) VEP83559A SCM156...
  • Page 663 F3B : DIF (CLKGEN) COMPONENT 09/09 NAME CIRCUIT BOARD NO. DRAWING NO. KR30093 (9/9) VEP83559A SCM157...

  • Page 664: Circuit Board Diagrams

    CIRCUIT BOARD DIAGRAMS NOTE: BE SURE TO MAKE YOUR ORDERS OF REPLACEMENT PARTS ACCORDING TO PARTS LIST, SECTION 7 CONTENTS F1 AUDIO P.C. BOARD (VEP84374A) ..CBA-1 MECHA IF P.C. BOARD (VEP82239A)..CBA-19 F2 V OUT P.C. BOARD (VEP83557B) ..CBA-3 MECHA IF2 P.C. BOARD (VEP82240A)... CBA-20 F3A SDI P.C.

  • Page 669: F3A Sdi P.c. Board (Vep83558A)

    F3A SDI P.C. BOARD (VEP83558A) (AJ-YA455P) COMPONENT SIDE IC3100 IC3101 IC3201 IC3203 IC3204 IC3300 IC3301 IC3400 IC3401 IC3402 IC3502 IC3507 IP3503 P3000 P3500 TG3000 TG3200 TG3400 TP3500 TP3501 TP3503 TP3504 TP3505 TP3506 TP3507 TP3508 TP3509 TP3510 TP3511 TP3512 TP3513 TP3514 TP3515 TP3516 TP3517...

  • Page 672: Csp Sub P.c. Board (Vep83555A)

    CSP SUB P.C. BOARD (VEP83555A) COMPONENT SIDE IC3101 IC3200 IC3201 IC3300 IC3400 IC3501 P3000 (COMPONENT SIDE) FOIL SIDE IC3100 IC3202 IC3203 IC3204 IC3500 TP3100 TP3101 TP3102 TP3103 TP3104 TP3200 TP3201 TP3202 TP3204 TP3205 TP3207 TP3208 TP3209 TP3210 TP3211 TP3213 TP3300 TP3301 TP3400 TP3401...

  • Page 679: Rf Cue P.c. Board (Vep85197A)

    RF CUE P.C. BOARD (VEP85197A) COMPONENT SIDE IC4001 Q5007 IC4002 Q5008 IC4005 Q5011 IC4006 Q5012 IC5001 Q5013 IC5002 Q5014 IC5003 Q5101 IC5004 Q5102 IC5005 Q5103 IC5006 Q5111 IC5007 Q5116 IC5012 Q5117 IC5101 Q5121 IC5103 Q5126 IC5104 Q5127 IC5201 Q5202 IC5202 Q5203 IC5203 Q5204...

  • Page 680: F8 Rf Eq P.c. Board (Vep85196A)

    F8 RF EQ P.C. BOARD (VEP85196A) COMPONENT SIDE IC5001 Q5405 IC5002 Q5408 IC5003 Q5411 IC5004 Q5412 IC5005 Q5413 IC5007 Q5415 IC5009 QR5201 IC5010 TG5001 IC5101 TG5002 IC5103 TG5003 IC5104 TG5004 IC5105 TP5001 IC5108 TP5002 IC5110 TP5003 IC5201 TP5005 IC5202 TP5006 IC5203 TP5007 IC5401...

  • Page 683: Mecha If P.c. Board (Vep82239A)

    MECHA IF P.C. BOARD (VEP82239A) COMPONENT SIDE P151 IC151 Q101 IC152 Q102 IC153 Q103 IC154 Q104 IC155 Q106 IC156 Q107 IC157 Q108 QR101 QR102 QR103 QR104 QR105 QR106 QR107 QR108 QR109 QR110 QR111 QR112 VR201 VR202 (COMPONENT SIDE) FOIL SIDE P151 VR201 VR202...

  • Page 684: Mecha If2 P.c. Board (Vep82240A)

    MECHA IF2 P.C. BOARD (VEP82240A) (COMPONENT SIDE) (FOIL SIDE) CBA-20...

  • Page 685: Power1 P.c. Board (Vep81221B)

    POWER1 P.C. BOARD (VEP81221B) COMPONENT SIDE IC1001 IC1101 IC1102 IC1103 IC1201 IC1202 IC1203 IC1205 P1103 P1201 P1202 Q1001 Q1002 Q1003 Q1004 Q1102 Q1103 VR1102 VR1201 (COMPONENT SIDE) CBA-21...
  • Page 686 POWER1 P.C. BOARD (VEP81221B) FOIL SIDE IC1001 IC1101 IC1102 IC1103 IC1201 IC1202 IC1203 IC1204 IC1205 P1103 P1201 P1202 Q1001 Q1002 Q1003 Q1004 Q1101 Q1102 Q1103 Q1201 Q1202 Q1203 Q1204 QR1001 QR1002 QR1101 QR1102 QR1103 QR1104 QR1105 QR1201 QR1202 QR1203 QR1204 QR1205 QR1206 QR1207...

  • Page 690: Dv U Com P.c. Board (Vep83560A)

    DV u COM P.C. BOARD (VEP83560A) (COMPONENT SIDE) (FOIL SIDE) HP P.C. BOARD (VEP80C15A) COMPONENT SIDE FOIL SIDE IC1001 P1001 Q1001 VR1001 Q1002 VR1001 P1001 (COMPONENT SIDE) (FOIL SIDE) CBA-26...
  • Page 691 F3B DIF / DIF JACK P.C.BOARD (VEP83559A / VEP80C21A) (AJ-YAD455P) COMPONENT SIDE IC206 IC902 SW301 TP619 TP660 TP901 IC207 IC903 SW701 TP620 TP661 TP902 IC208 IP401 TG201 TP621 TP662 TP903 IC209 IP702 TG202 TP626 TP663 IC301 IP703 TG203 TP628 TP701 IC402 P101 TG204...
  • Page 692 F3B DIF / DIF JACK P.C.BOARD (VEP83559A / VEP80C21A) (AJ-YAD455P) FOIL SIDE IC201 TP303 IC202 TP304 IC203 TP305 IC204 TP401 IC210 TP402 DIF JACK IC211 TP403 IC302 TP404 IC802 TP405 P101 TP406 P501 TP709 QR301 TP710 QR302 TP711 SW201 TP712 TP301 TP713 TP302...

  • Page 693: Exploded Views

    PACKING PARTS ASSEMBLY ................PRT-18 PACKING PARTS ASSEMBLY (AJ-YA455P)............PRT-20 PACKING PARTS ASSEMBLY (AJ-YAD455P) ............ PRT-22 PACKING PARTS ASSEMBLY (AJ-CS455P) ............PRT-24 ELECTRICAL REPLACEMNT PARTS LIST (AJ-D455E/MC)....... PRT-26 ELECTRICAL REPLACEMNT PARTS LIST (AJ-YA455P) ........PRT-58 ELECTRICAL REPLACEMNT PARTS LIST (AJ-YAD455P) ........ PRT-60...

  • Page 694: Servicing Fixtures & Tools

    SERVICING FIXTURES & TOOLS Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VFK1145A BACK TENSION METER VFK1149A POST DRIVER VFK71A DIAL TORQUE GAUGE VFK1191A DIAL TORQUE GAUGE VFK1152 GORQUE GAUGE ADAPTOR VFK0357 ECCENTRIC SCREWDRIVER 1 (1.5MM) VFK1154...

  • Page 695: Mechanical Chassis Assembly (1)

    MECHANICAL CHASSIS ASSEMBLY (1) PRT-2...
  • Page 696 MECHANICAL CHASSIS ASSEMBLY (1) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEM0686 S REEL MOTOR A ASS'Y 1 (M) VEM0687 T REEL MOTOR A ASS'Y 1 (M) VMS5923 REEL OUTER RAIL VMS5924 REEL INNER RAIL VXL2589...

  • Page 697: Mechanical Chassis Assembly (2)

    MECHANICAL CHASSIS ASSEMBLY (2) PRT-4...
  • Page 698 MECHANICAL CHASSIS ASSEMBLY (2) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks XVE2B6FP HEX SCREW VXA5554 A/C HEAD BASE (1) ASS'Y XVE2B12FP HEX SCREW VED0419 A/C HEAD 1 (M) VXQ0439 SCREW VXA6067 A/C HEAD BASE (2) ASS'Y VMX0967 CUT WASHER...

  • Page 699: Sub Chassis Assembly

    SUB CHASSIS ASSEMBLY PRT-6...
  • Page 700 SUB CHASSIS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VXL2656 MIC DRIVE ARM (A) ASS'Y VMB3018 MIC DRIVE SPRING VXL2657 MIC DRIVE ARM (B) ASS'Y VDB1429 MIC DRIVE ARM BOSS VXL2613 REEL DRIVE ARM ASS'Y VDG1192...

  • Page 701: Cassette Compartment Assembly

    CASSETTE COMPARTMENT ASSEMBLY PRT-8...
  • Page 702 CASSETTE COMPARTMENT ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks XYN2+C4 SCREW VXA6593 CASSETTE COMPARTMENT 1 (M) XQN2+A3 SCREW VMS5865 MAIN SHAFT LMHD16064 SCREW VMA9849 TOP PLATE XWGV2Z5G WASHER VXA6572 FRONT GUIDE 1 ASS'Y VMB3075 M GUIDE SPRING VML3191...

  • Page 703: Casing Parts Assembly

    CASING PARTS ASSEMBLY PRT-10...
  • Page 704 CASING PARTS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYP7626 TOP PANEL ASS'Y VXA7031 P.C.B. PLATE L ASS'Y VMT1222 P.C.B. RUBBER CUSHION L VMX2510 SPACER VMZ2325 TOP PANEL BARRIER VGM1699 SIDE PANEL VKU0546 BOTTOM PLATE...

  • Page 705: Front Panel Assembly

    FRONT PANEL ASSEMBLY PRT-12...
  • Page 706 FRONT PANEL ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VYP8126 FRONT PANEL (1) ASS'Y VGU5334 LEVER VR KNOB VGU6516 SLIDE SW KNOB (L) VGU7459 TACT SW KNOB VKF3100 FRONT WINDOW VKF2785 BLINDER PANEL VMB2923...

  • Page 707: Chassis Frame Assembly

    CHASSIS FRAME ASSEMBLY PRT-14...
  • Page 708 CHASSIS FRAME ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VMP6832 SIDE FRAME (L) VGQ4011 P.C.BOARD GUIDE RAIL A VMP6802 REAR FRAME VKA0117 PLASTIC FOOT VMP6020 BOTTOM FRAME VMP4881 SW BRACKET EST15367S POWER SWITCH VMZ0580...

  • Page 709: Rear Panel Assembly

    REAR PANEL ASSEMBLY PRT-16...
  • Page 710 REAR PANEL ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VRF0190 FAN MOTOR 1 L6FALEFH0007 VHN0063 NYLON NUT VMX0835 SPACER VJH1205 JACK PANEL VML2903 AC CORD HOOK VMP5032 OPTION PANEL VEK9369 POWER ASS'Y VSC5223 POWER CASE (LOWER)

  • Page 711: Packing Parts Assembly

    PACKING PARTS ASSEMBLY PRT-18...

  • Page 712: Packing Parts Assembly (Aj-Ya455P)

    PACKING PARTS ASSEMBLY Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VJA0774 POWER CORD (B) 1 FOR AJ-D455E VJA0775 POWER CORD (E) 1 FOR AJ-D455E VJA1147 POWER CORD 1 FOR AJ-D455MC VPN4305 ACCESSORY PAD VQT9349 OPERATING INSTRUCTIONS...

  • Page 713: Packing Parts Assembly (Aj-Yad455P)

    PACKING PARTS ASSEMBLY (AJ-YA455P) PRT-20...

  • Page 714: Packing Parts Assembly (Aj-Cs455P)

    PACKING PARTS ASSEMBLY (AJ-YA455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VJS3462 CONNECTOR (FEMALE) 5 K1SMBDBA0002 VPF0678 AIR CAP BAG VPF0359 POLYETHYLENE BAG VQT9173 OPERATING INSTRUCTIONS VPF0679 AIR CAP BAG VPG6296 PACKING CASE VMP5900 JACK PANEL...
  • Page 715 PACKING PARTS ASSEMBLY (AJ-YAD455P) PRT-22...
  • Page 716 PACKING PARTS ASSEMBLY (AJ-YAD455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPG6296 PACKING CASE VPF0678 AIR CAP BAG VPF0359 POLYETHYLENE BAG VQT9174 OPERATIONG INSTRUCTIONS VPF0679 AIR CAP BAG VEE0N57 CABLE VJF1344 CONNECTOR HOLDER (1) VJF1345 CONNECTOR HOLDER (2)
  • Page 717 PACKING PARTS ASSEMBLY (AJ-CS455P) PRT-24...
  • Page 718 PACKING PARTS ASSEMBLY (AJ-CS455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPG8753 PACKING CASE VPF0887 POLYETHYLENE BAG VQT9175 OPERATING INSTRUCTIONS VPK1856 M CASSETTE SOFT CASE PRT-25...
  • Page 719 ELECTRICAL REPLACEMENT PARTS LIST (AJ-D455E/MC) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C4220 EEVHB1C220 E.CAPACITOR VEP84374A F1 AUDIO P.C.BOARD0 1 (RTL) C4221,22 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C4223 EEVHB1C100 E.CAPACITOR VEP83557B F2 V OUT P.C.BOARD0...
  • Page 720 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D4407 MA142WK DIODE R4108-11 ERJ3RBD123 M.RESISTOR CH 1/16W 12K D4800 MA716 DIODE R4112 ERJ3RBD202 M.RESISTOR CH 1/16W D4900 MA152A DIODE R4113 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K D4901 MA157 DIODE...
  • Page 721 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R4302 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K R4521,22 ERJ3GEY0R00 M.RESISTOR CH 1/16W R4304,05 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K R4523 ERJ3GEYG102 M.RESISTOR CH 1/16W R4308 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K R4524,25 ERJ3GEY0R00...
  • Page 722 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R4922 ERJ3RBD822 M.RESISTOR CH 1/16W 8.2K C308 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R4923 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K C309,10 ECUM1C105KBM C.CAPACITOR CH 16V R4924 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K C311...
  • Page 723 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C578,79 EEVHB0J470 E.CAPACITOR 6.3V IC453 NJM2534V C580-83 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC454 XC62DN5002P C584 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U IC455 AD8055AR C585,86 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC456 XC62FP5002P C587...
  • Page 724 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks QR500 UN5113 TRANSISTOR-RESISTOR R426-31 ERJ6GEYG121 M.RESISTOR CH 1/10W 120 QR501 UN5213 TRANSISTOR-RESISTOR R432 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K QR700 UN5213 TRANSISTOR-RESISTOR R433 ERJ6RED750 M.RESISTOR CH 1/10W R434 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K...
  • Page 725 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R560 ERJ3GEYJ224 M.RESISTOR CH 1/16W 220K VR456 EVMEGSA00B13 V.RESISTOR R561 ERJ3GEYJ684 M.RESISTOR CH 1/16W 680K VR560 EVMEGSA00B14 V.RESISTOR R562 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K VR600 EVMEGSA00B14 V.RESISTOR R563...
  • Page 726 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3228 ECUX1H100CCV C.CAPACITOR CH 50V C4313 EEVHB0J101 E.CAPACITOR 6.3V 100U C3230 EEVHP1E3R3 E.CAPACITOR 25V 3.3U C4314,15 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3232 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C4316 ECUX1H102KBV C.CAPACITOR CH 50V 1000P C3233...
  • Page 727 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3210 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 1 FOR VEP83555A IP3101,02 C1ZBZ0001555 R3211 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 1 FOR VEP83555A R3212 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 1 FOR VEP83555A JP3000 VJR1008...
  • Page 728 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3403 ERJ3GEYG102 M.RESISTOR CH 1/16W 1 FOR VEP83555A R3404 ERJ3GEYJ223 M.RESISTOR CH 1/16W 22K 1 FOR VEP83555A R3406 ERJ3GEYJ221 M.RESISTOR CH 1/16W 220 1 FOR VEP83555A C3001 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R3407...
  • Page 729 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3321,22 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3561 ECUX1H102JCV C.CAPACITOR CH 50V 1000P C3323 ECUX1H220JCV C.CAPACITOR CH 50V C3562 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3325-30 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C3563 ECUX1H681JCV C.CAPACITOR CH 50V 680P...
  • Page 730 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C3827 EEVHB0J470 E.CAPACITOR 6.3V IC3632 THC4053FT C3828 EEVHB1C470 E.CAPACITOR IC3633 NJM084M 1 C0ABFB000008 C3829,30 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC3700 NJM082BM 1 C0ABEB000017 C3831 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U IC3701 C0FBAF000042...
  • Page 731 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q3310 2SD601A TRANSISTOR R3161 ERJ3GEYJ394 M.RESISTOR CH 1/16W 390K Q3311 XN4601 TRANSISTOR-RESISTOR R3162 ERJ3GEYJ334 M.RESISTOR CH 1/16W 330K Q3312 2SD601A TRANSISTOR R3163 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K Q3313 2SB709A TRANSISTOR...
  • Page 732 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3347,48 ERJ3GEYJ470 M.RESISTOR CH 1/16W R3491 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 R3349 ERJ3GEYJ393 M.RESISTOR CH 1/16W 39K R3492 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 R3350 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R3493...
  • Page 733 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3653 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R3823 ERJ3GEYJ470 M.RESISTOR CH 1/16W R3654 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K R3826 ERJ3GEYG102 M.RESISTOR CH 1/16W R3655 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K R3827 ERJ3GEYJ182...
  • Page 734 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VC3500 VCV0047 TRIMMER C701-28 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U VR3401 EVMEASA00B53 V.RESISTOR MA716 DIODE VR3402 EVMEASA00B13 V.RESISTOR D252-56 MA716 DIODE VR3403 EVMEASA00B53 V.RESISTOR D301 MA147 DIODE VR3404...
  • Page 735 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks IC661 NVHC541MTCX R408 D1H84704A008 COMBI.R-R IC663 NVHC245MTCX R501 ERJ3GEYJ222 M.RESISTOR CH 1/16W 2.2K IC701,02 NJM084V R502 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K IC703,04 NVHC541MTCX R503 ERJ3GEYJ105 M.RESISTOR CH 1/16W IC705...
  • Page 736 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C458,59 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C500 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C501 EEUFC1V101 E.CAPACITOR 35V 100U C502,03 ECUX1H682KBV C.CAPACITOR CH 50V 6800P VEP82238B F7 SERVO P.C.BOARD0 1 (RTL) C504...
  • Page 737 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D355,56 MA142K DIODE IC658 NJM2903M 1 C0BBBA000019 D401,02 MA142K DIODE D403-06 MA716 DIODE VVVSI3567 SOFTWARE D407 MA147 DIODE ID201 VVVSI3566 SOFTWARE D450,51 MA728 DIODE D452,53 MA736 DIODE...
  • Page 738 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ERJ6GEYG272 M.RESISTOR CH 1/10W 2.7K R178,79 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K R180,81 ERJ3GEYJ123 M.RESISTOR CH 1/16W 12K ERJ3GEYJ823 M.RESISTOR CH 1/16W 82K R182,83 ERJ3GEYJ562 M.RESISTOR CH 1/16W 5.6K...
  • Page 739 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R507 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R679,80 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K R508 ERJ3GEYJ563 M.RESISTOR CH 1/16W 56K R681-83 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R509 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K...
  • Page 740 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks C5145,46 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C5602 ECUM1C224KBN C.CAPACITOR CH 16V 0.22U C5147,48 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C5603 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U C5149,50 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C5604-11...
  • Page 741 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q5108-10 2SC3930 TRANSISTOR R5149 ERJ3RBD121 M.RESISTOR CH 1/16W 120 Q5111 XN5531 TRANSISTOR-RESISTOR R5150,51 ERJ3GEYG152 M.RESISTOR CH 1/16W 1.5K Q5112-15 2SC3930 TRANSISTOR R5152 ERJ3GEYJ470 M.RESISTOR CH 1/16W Q5201 XN5531 TRANSISTOR-RESISTOR...
  • Page 742 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R5323 ERJ3GEYJ470 M.RESISTOR CH 1/16W R5462,63 ERJ3GEYG102 M.RESISTOR CH 1/16W R5324 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R5464,65 ERJ3GEYJ470 M.RESISTOR CH 1/16W R5325 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 R5466 ERJ3RBD102 M.RESISTOR CH 1/16W...
  • Page 743 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks RY5051 VSY2176 RELAY 1 K6B2CDA00045 C5119-22 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U C5123 ECUX1H121JCV C.CAPACITOR CH 50V 120P TG5001-04 EYF6CU TEST POINT C5124-27 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U C5131 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U TP5001-03...
  • Page 744 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q4010 2SB779-R TRANSISTOR R4045 ERJ3GEYJ124 M.RESISTOR CH 1/16W 120K Q4011 2SD874-R TRANSISTOR R4046 ERJ3GEY0R00 M.RESISTOR CH 1/16W Q5001-04 2SC3935 TRANSISTOR R4047,48 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K Q5005,06 2SC2954 TRANSISTOR...
  • Page 745 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R5210 ERJ3RBD392 M.RESISTOR CH 1/16W 3.9K L1,L2 VLP0017 COIL 2 J0JHB0000010 R5211 ERJ3RBD102 M.RESISTOR CH 1/16W R5212 ERJ3RBD392 M.RESISTOR CH 1/16W 3.9K K1KB96A00048 CONNECTOR (FEMALE) R5213 ERJ3RBD102 M.RESISTOR CH 1/16W...
  • Page 746 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VJS3406B015 CONNECTOR (FEMALE) C1006 ECA1HXL010 E.CAPACITOR P34,35 VJS2889A017 CONNECTOR (FEMALE) 2 K1MN17A00008 C1007 ECQE6473KF P.CAPACITOR 630V 0.047U VJS3406B019 CONNECTOR (FEMALE) C1008 VCK0106K221 C.CAPACITOR 220P VJP3125B002 CONNECTOR (MALE) 1 K1KA02B00111...
  • Page 747 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks D1113-15 SFPL-52 DIODE R1008,09 ERG3SJ333 M.RESISTOR 3W 33K D1116 MA3068-M DIODE R1010 ERG2SJ180 M.RESISTOR D1117 MA142K DIODE R1011 ERJ6RBD241 M.RESISTOR CH 1/10W 240 D1118 FML-G26S DIODE R1012...
  • Page 748 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R1233 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R1234 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K EEAHB1C470B E.CAPACITOR R1235 ERJ3GEYG102 M.RESISTOR CH 1/16W C3,C4 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U R1237-39...
  • Page 749 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ERJ6GEYG681 M.RESISTOR CH 1/10W 680 IC14 NJM78L09UA 1 C0CBAHC00002 ERJ6GEYG220 M.RESISTOR CH 1/10W ERJ6GEYG101 M.RESISTOR CH 1/10W 100 L1,L2 VLF1151A132 COIL ERJ6GEYG220 M.RESISTOR CH 1/10W ERJ6GEYJ820 M.RESISTOR CH 1/10W K1KA22C00001...
  • Page 750 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks Q1001,02 2SD1328 TRANSISTOR R1001 ERJ3GEYG102 M.RESISTOR CH 1/16W R1002 ERJ3GEYJ122 M.RESISTOR CH 1/16W 1.2K R1003 ERJ3GEYJ273 M.RESISTOR CH 1/16W 27K R1004 ERJ6GEYG331 M.RESISTOR CH 1/10W 330 R1005 ERJ6GEYG271 M.RESISTOR CH 1/10W 270...
  • Page 751 ELECTRICAL REPLACEMENT PARTS LIST (AJ-YA455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks IC3404 XC62FP5002P C3000,01 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC3405 NVHC541MTCX IC C3002,03 EEVHB0J470 E.CAPACITOR 6.3V IC3500,01 NVHC541MTCX IC C3004-06 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U IC3502 C1ZBZ0001837...
  • Page 752 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R3519 ERJ3GEY0R00 M.RESISTOR CH 1/16W R3520 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K R3521 ERJ3GEY0R00 M.RESISTOR CH 1/16W R3522-24 D1H810140001 COMBI.R-R R3526 ERJ3RBD361 M.RESISTOR CH 1/16W 360 R3528 ERJ3RED510 M.RESISTOR CH 1/16W...
  • Page 753 ELECTRICAL REPLACEMENT PARTS LIST (AJ-YAD455P) Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ID705 VVVSI3622 SOFTWARE VEP83559A DIF P.C.BOARD 1 (RTL) IP401 C3FBLD000046 VEP80C21A DIF JACK P.C.BOARD 1 (RTL) IP702 C3FBLD000046 L201-03 VLF1151A132 COIL L501,02...
  • Page 754 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R723 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R724 ERJ3GEYG102 M.RESISTOR CH 1/16W R726,27 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R728 ERJ3GEYJ182 M.RESISTOR CH 1/16W 1.8K R732 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K R733...

This manual is also suitable for:

Aj-ya455pAj-yad455pAj-cs455p

Table of Contents
