Installation Instructions:

RDIDC-9181-PF-48

www.raycap.com

Table of Contents

Need help?

Do you have a question about the RDIDC-9181-PF-48 and is the answer not in the manual?

Questions and answers

Summary of Contents for Raycap RDIDC-9181-PF-48

Page 1 RDIDC-9181-PF-48 INSTALL INSTRUCTIONS Installation Instructions: RDIDC-9181-PF-48 www.raycap.com...
Page 3: Table Of Contents
Tools Mounting the Bracket Opening Cover Ground Cable Installation Removing Touch Guards Installing DC Trunk and Jumper Cables Installing Fiber Trunk and Jumper Cables Closing and Securing Cover ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 1 of 14...
Page 4: Copyright
The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Raycap shall have no liability for any damage of any kind resulting from the use of this document.
Page 5: Introduction
Protection systems installed in front of the PDU (DC power plant) and the RRH must be able to withstand direct lightning currents in order to protect the sensitive equipment. Raycap’s RRH solutions featuring Strikesorb SPD technology ®...
Page 6: Mounting The Bracket
Option 1: Using Pre-installed existing hardware, Option 2: Band Strap Option 3: Unit ships as shown. Hybrid Trunk (6AWG pre-installed) Spare 8AWG (M Ground inserts found in Gland Kit ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 4 of 14...
Page 7: Opening Cover
RDIDC-9181-PF-48 INSTALL INSTRUCTIONS Opening Cover A- Open cover by loosening the 2 side latches. tray by pulling on the 2 push pins. ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 5 of 14...
Page 8 RDIDC-9181-PF-48 INSTALL INSTRUCTIONS See callouts for connection -48V Circuit RETURN Callout Touch Guard Grounds Main Ground Straps for Securing Fiber Fiber Connections Fiber Connections Label Fiber Management ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 6 of 14...
Page 9: Ground Cable Installation
Ground cable installation complete. Removing Touch Guards There is 1 touch guard covering the DC connection lugs. Simply loosen the covers from the snap-on stand offs. Set touch guard aside. ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 7 of 14...
Page 10: Installing Dc Trunk And Jumper Cables
Panduit P/N # LCD10-10A-L LCD10-10A-L #8 Power Jumper 2 Lugs (8AWG) 1 Lug (8AWG) 1 Lug (8AWG)Single Hole Burndy P/N # YA8-CL-2TC-10 YA8CTC10 Panduit P/N # LCD8-10A-L LCA8-10-L ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 8 of 14...
Page 12: Installing Fiber Trunk And Jumper Cables
Insert strain relief plate in slotted grooves and pull cables through so strain relief plate rests on base. Connect cables starting from row closest to back plate. Numbering Label to assist for proper connections. ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 10 of 14...
Page 14: Closing And Securing Cover
RDIDC-9181-PF-48 INSTALL INSTRUCTIONS Closing and Securing Cover tray and secure the 2 push pins. B- Close cover by securing 2 side latches. 12.2 Installation complete. ©Raycap • All rights reserved (320-1547) Rev.F www.raycap.com Page 12 of 14...
