Pioneer PCH-D600 Service Manual

Manual
©) PIONEER
The Art of Entertainment
Order nr.
PRT-039
GSM Products
PCH-D600 sancportarie
PCM-D300 Mobile
Accessories: (only available as finished product)
CONTENTS
Paragraph
Paragraph
Paragraph
Paragraph
Paragraph
Paragraph
Paragraph
Paragraph
PCH-D600C
PCA-400
PCA-410
PCA-411
PCA-412
SLN2600A
SLN2604A
SLN3043A
SAF4630A
SNN4067A
SPN4046A
CCPN4013A
SAF4300A
SLN7340A
IEEE EIN
Handportable with standard car kit PCA-410
Transportable kit for PCM-D300
Standard car kit for PCH-D600
Battery 700 mAh (PCH-D600)
Battery 1500 mAh (PCH-D600)
Rapid Charger (PCH-D600)
Travel Charger (PCH-D600)
Battery Saver (PCH-D600)
Antenna (PCH-D600)
Battery 2300 mAh (PCM-D300)
Rapid Charger (PCM-D300)
AC Power Supply (PCM-D300)
Antenna (PCM-D300)
Carrying Strap (PCM-D300)
Operating Instructions
GSM Technical Description
Installation of a GSM Mobile
Post Installation Checks
Trouble shooting the GSM Phone
Servicing the GSM Phone
Level 1 and 2 Parts List
Appendix A Glossary of definitions and abbreviations
PIONEER ELECTRONIC CORPORATION 4-1,Meguro 1-Chome,Meguro-Ku,Tokyo 153,Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760,Long Beach,California 90801 U.S.A.,TEL. (800)421-1404
March 1993
