- Page 1 P I X I T I L E I N S E R T A S S E M B L Y T A P A S 3 7 1 8 : 2 0 2 1 W M - 0 2 2 8 5 2 S P E C I F I C A T I O N S...
- Page 2 I NSTALLATION GUIDE Note: This product must be installed by a licensed plumber. This is a general installation guide - there are many factors involved that can alter the installation method. AU/NZ: For installations within Australia and New Zealand, this product must be installed in compliance with AS/NZS 3500.
- Page 3 Set Back Range for tile thickness Note: Thicker tiles have decreased range Tile Standard Extended Thickness Spindle Spindle 5mm TILE 52-62 69-80 6mm TILE 52-62 70-81 7mm TILE 52-62 71-82 8mm TILE 52-62 72-82 9mm TILE 53-62 73-82 10mm TILE 54-62 74-82 11mm TILE...
