TECHNICAL & SERVICE DETAILS
A B B E R F I E L D
I N D U S T R I E S
P T Y L T D
ABBERFIELD INDUSTRIES PTY LTD
32 Cross Street, Brookvale, Sydney, NSW 2100 Australia
Tel: (02) 9939 2844 Fax: (02) 9938 3462
International Tel: +61-2 9939 2844 Fax: +61-2 9938 3462
Email: contact@abberfield.com.au
Internet: www.abberfield.com.au
A B N 6 1 0 0 0 1 1 2 5 6 9
series
PACKET
DISPENSERS
Brochure # 098-3
Advertisement
Table of Contents
Summary of Contents for ABBERFIELD PVM50 Series
- Page 1 PACKET PVM52 DISPENSERS TECHNICAL & SERVICE DETAILS ABBERFIELD INDUSTRIES PTY LTD 32 Cross Street, Brookvale, Sydney, NSW 2100 Australia Tel: (02) 9939 2844 Fax: (02) 9938 3462 International Tel: +61-2 9939 2844 Fax: +61-2 9938 3462 Email: contact@abberfield.com.au Internet: www.abberfield.com.au...
-
Page 2: Table Of Contents
ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 2 Brochure# 098-3 CONTENTS Section Page PVM50 & PVM52 SERIES DESCRIPTION INSTALLATION BATTERY PACK TESTING BATTERIES CHANGING BATTERIES BATTERY MODULE REMOVAL MAINS OPERATION MOTOR DRIVE MODULE SOLD OUT SYSTEM CHANGING SPIRAL BACKING PLATE... - Page 3 ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 3 Brochure# 098-3 PVM50 SERIES PVM52 SERIES 32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: (02) 99392844 Fax: (02) 99383462 Email: contact@abberfield.com.au...
-
Page 4: Pvm50 & Pvm52 Series Description
7. Lay the back plate on its back. reassembled upon the wall. In like manner 32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: (02) 99392844 Fax: (02) 99383462 Email: contact@abberfield.com.au... -
Page 5: Battery Pack
2. Remove the old batteries. 3. Smear petroleum jelly (vaseline) on the contacts on the new battery and onto the matting surfaces of the battery cradle. 32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: (02) 99392844 Fax: (02) 99383462 Email: contact@abberfield.com.au... -
Page 6: Battery Module Removal
ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 6 Brochure# 098-3 MAINS OPERATION 4. Fit two new batteries which can be inserted in any orientation, provided the contacts face forward. Although the machine is intended for battery operation it has the ability to be converted to 5. -
Page 7: Sold Out System
ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 7 Brochure# 098-3 vertical, sloping towards the front of the When reassembling it will be necessary to machine. This equates to 10 past the hour on slightly rotate each spiral whilst refitting the a clock face. -
Page 8: Maintenance
The reflective surface to the left of the cabi- net should be kept clean. Perhaps using win- dow cleaning spray for a smear free finnish. 32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: (02) 99392844 Fax: (02) 99383462 Email: contact@abberfield.com.au... -
Page 9: Coin Validator
ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 9 Brochure# 098-3 COIN VALIDATOR Two tables of coin acceptance / rejection criteria are included in the equipment design (wide and narrow). Selection is by a dip switch on the side of... -
Page 10: Clearing Note Validator
ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 10 Brochure# 098-3 CLEARING NOTE VALIDATOR DATA RETRIEVAL To clear jammed notes or foreign matter from the A data retrieval mode allows the unit to display the note validator first remove the validator from the number of operations at each price since the last machine. -
Page 11: Error Mode
ABBERFIELD INDUSTRIES- PVM50 & PVM52 packet dispensers TECHNICAL DETAILS page 11 Brochure# 098-3 SERVICE ERROR MODE MAINTENANCE Setting the 7th dip switch up to the ON position DISASSEMBLY allows the display to show error messages for There are three active parts to the coin validator, each coin deposited.
