- Page 1 W W W . S A I K O S Y S T E M S . C O M U S B T y p e C Ma l e P l u g B r e a k o u t B o a r d B R K - U S B - C P V 3 .
-
Page 2: Table Of Contents
BRK-USB-CP v3.0 User Manual 2021 Table of Contents Chapter 1: Introduction ........................... 3 What to Expect ........................3 Ordering Information ....................... 4 Chapter 2: Getting Started ......................... 5 Unpacking ..........................5 Device Diagram & Dimensions ....................6 Chapter 3: Setup and Operation ......................7 Schematics .......................... - Page 3 Hard copies may be produced for personal use. Saiko Systems Ltd. products are not tested for use in life support or life critical devices. If this product is used for such applications, the developer/integrator/user agrees to perform further testing to ensure the reliability of the product in such applications.
-
Page 4: Chapter 1: Introduction
Chapter 1: Introduction 1.1 What to Expect The BRK-USB-CP is a breakout board designed for adding a USB Type C male plug connector to any prototyping or DIY project. A standard 0.1” pitch, 13-pin header can be soldered to J2 and J3, allowing developers access to each USB connector pin individually. -
Page 5: Ordering Information
BRK-USB-CP v3.0 User Manual 2021 1.2 Ordering Information Part Number Description BRK-USB-CPv3.0 USB Type C Male Plug Breakout Board v3.0 All models can be ordered in bulk in retail packaging. Please contact us if retail packaging is required. -
Page 6: Chapter 2: Getting Started
BRK-USB-CP v3.0 User Manual 2021 Chapter 2: Getting Started 2.1 Unpacking Please ensure that all necessary Electrostatic Discharge (ESD) precautions are taken before removing the product from its packaging. These may include touching a grounded object, using a grounded wrist... -
Page 7: Device Diagram & Dimensions
BRK-USB-CP v3.0 User Manual 2021 2.2 Device Diagram & Dimensions Indicator Function USB Type C Male Plug connector 0.1” I/O connector 0.1” I/O connector... -
Page 8: Chapter 3: Setup And Operation
BRK-USB-CP v3.0 User Manual 2021 Chapter 3: Setup and Operation 3.1 Schematics USB Ty pe C Plug B1-GND A12-GND B2-TX2+ A11-RX2+ B3-TX2- A10-RX2- B4-VBUS A9-VBUS B5-VCONN A8-SBU1 B6-D+ A7-D- B7-D- A6-D+ B8-SBU2 A5-CC B9-VBUS A4-VBUS B10-RX1- A3-TX1- B11-RX1+ A2-TX1+ B12-GND A1-GND 0.1"... -
Page 9: Chapter 4: Technical Support & Warranty
Technical Support & Warranty 4.1 Technical Support If you run into any trouble with your Saiko Systems Ltd. product, or need further assistance than is provided in this User Manual or other resources, rest assured that we are here to help! The Saiko Systems Ltd. -
Page 10: Chapter 5: History
BRK-USB-CP v3.0 User Manual 2021 Chapter 5: History Date Version Action 09/07/2021 Original Released... - Page 11 W W W . S A I K O S Y S T E M S . C O M C O P Y R I G H T 2 0 2 1 A L L R I G H T S R E S E R V E D...
