- Page 1 CA 15 Scope Meter Instruction Manual Elektro Partner ApS - Trehøjevej 2 - 7200 Grindsted - 75310906 - elektropartner.com - post@elektropartner.com...
-
Page 2: Safety Guide
◎ DO NOT disassemble the device or remove the back panel of the device. ◎ Please follow the instructions stipulated within this manual for operating this device safely. Product Specification CA 15 Specificaiton ◎ Working Voltage: 3.6V ◎ Working Current: 600mA ◎ Working Tempurature: 0 - 50 Celsius ◎... -
Page 3: Operation
● Instruction of Multimeter Operation ● Power On/Off An On/Off switch on the left-top side of the device. DCV measurement 13.8V Multimeter A set of positive/negative ports on the top of the device. Please plug the probes into the Scope corresponding ports accordingly before measuring. - Page 4 Circuit Short Test OHM Measurement Circuit Short Test Circuit Short Test Frequency(Hz) Frequency(Hz) Please press ‘EXIT’key to exit Connect positive and negative probe and then press ENTER to calibrate when entering OHM, then to measure resistance. When entering Circuit Short Test the screen will display the circuit short image. By selecting the above option the user will enter the Circuit Short Test.
-
Page 5: Frequency(Hz)
Frequency(Hz) Duty/Cycle (%) Frequency Measurement Duty/Cycle Percentage Measurement Duty/Cycle(%) Signal measuring for Sensors only, Signal measuring for Sensors only, Do not test with compoments like Active Time(mS) Do not test with compoments like Ignition primary, Injection signals, Ignition primary, Injection signals, Circuit Short Test the measured result might be Ignition Dwell... - Page 6 Active Time (mS) Ignition Dwell Activation Time Measurement Ignition Dwell Measurement Duty/Cycle(%) Duty/Cycle(%) Setting Signal measuring for Sensors only, Active Time(mS) Do not test with compoments like Active Time(mS) Ignition Type：Single Direct Ignition primary, Injection signals, Ignition System Ignition Dwell the measured result might be Ignition Dwell incorrect.
- Page 7 Amp. Temperature Measuring the magnitude of current. Duty/Cycle(%) Temperature Please set the Volt/Amp Value Active Time(mS) O2 Sensor Please connect external Temperature Conversion Setting on CA15 and Module(under developing) current clamp synchronized. Ignition Dwell CAM/CRANK/SPEED Sensor Injection System Please press ‘ENTER’ key to Start Please press ‘EXIT’key to exit Please connect AC/DC Current clamp (OPTIONAL) Temperature Module is under development.
- Page 8 O2 Sensor CAM/CRANK/SPEED Sensor Max：0.01V Min：0.01 V Temperature Temperature 0.01 O2 Sensor O2 Sensor 0.00 CAM/CRANK/SPEED Sensor CAM/CRANK/SPEED Sensor Injection System Injection System Please press ‘EXIT’key to exit Please press ‘EXIT’key to exit Enter O2 Sensor and connect positive probe (Red) with sensor and the negative probe Enter CAM/CRANK/SPEED Sensor and connect positive probe (Red) with sensor and the (Black) with chassis ground of the vehicle in order to measure O2 Sensor Voltage.
-
Page 9: Injection System
Injection System Ignition System Temperature Ignition System O2 Sensor Setup CAM/CRANK/SPEED Sensor Injection System Enter Injection System to select display mode: Injection Time (number). Enter Ignition System to select display mode: Ignition Dwell. ： 5 9.99V Min： 0.76 V Coil Power ：14.56V Injection Time Ignition Dwell 2.01... -
Page 10: Sleep Mode Setting
Enter Ignition System to select display mode: Ignition Scanwaveform. Setup Enter Setup to view and modify current settings. Setting 1.Ignition Type Single Direct Ignition Dwell Ignition System Ignition System 2.Sleep Mode 5 Minutes Ignition Scanwaveform Setup 3.DCV Refresh Time 5 Seconds 4.Frequency Refresh Time : 5 Seconds 5.Duty Refresh Time... - Page 11 DCV Refresh Time O2 Refresh Time Ignition Type Setting 5 Seconds Duty Refresh Time 5 Seconds Sleep Mode Setting 25 Seconds Active Time Refresh Time 25 Seconds DCV Refresh Time 45 Seconds O2 Refresh Time 45 Seconds Frequency Refresh Time 1 Minutes Ignition Dwell Refresh Time 1 Minutes...
-
Page 12: Software Information
Software Information About CA1 5 About CA15 ：CA-0000000 7 ： 1.25 Software Ver BootLoader Ver ：1.1 Please press ‘EXIT’key to exit page. page. - Page 13 ● Instruction of Scope Sensors & Components General Signal General Signal Sensors & Components 13.8V Multimeter Charging System Ignition System Scope O2 Sensor Freq ：-- Max ： 0.04 V Max： 0.04 V Duty ：-- Min ： 0.00 V Min ：0.00 V General Signal 15.0 O2 Sensor...
- Page 14 CRANK/SPEED Sensor Camshaft O2 Sensor Engine start, and running O2 Sensor Engine start, and running CRANK/SPEED Sensor Engine start, but can not run CRANK/SPEED Sensor Engine start, but can not run Camshaft Camshaft Injection System Injection System Select Engine start, and running Select Engine start, and running.
- Page 15 Injection System Injection Waveform (Digital) Active： -- O2 Sensor Injection Time Scanwaveform Injection Time Scanwaveform 60.0 50.0 CRANK/SPEED Sensor Injection Waveform (Digital) Injection Waveform (Digital) 40.0 30.0 Camshaft Injection Waveform (Analog) Injection Waveform (Analog) 20.0 10.0 Injection System Please select Injection Waveform mode: Injection Time Scanwaveform, Injection Waveform Active：...
-
Page 16: Throttle Position Sensor
Throttle Position Sensor Idle Air Control Max： 0.00 V Freq ： 244 Max：9.69 V Min ：0.00 V Duty ：53 Min ：0.33 V Throttle Position Sensor Throttle Position Sensor 6.00 15.0 5.00 12.5 Idle Air Control Idle Air Control 4.00 10.0 3.00 7.50 Engine Temperature Sensor Engine Temperature Sensor... -
Page 17: Inlet Air Temperature Sensor
Inlet Air Temperature Sensor Ignition Trigger Signal Max： 0.00 V Freq ：-- Max：0.01 V Min ：0.00 V Duty ：-- Min ：0.00 V Throttle Position Sensor Ignition Trigger Signal 6.00 6.00 5.00 5.00 Idle Air Control Air Flow Sensor 4.00 4.00 3.00 3.00 Engine Temperature Sensor... -
Page 18: Air Flow Sensor
Air Flow Sensor Square Waveform Mode Voltage Scan Mode Freq ： -- Max：0.00 V Min ：0.00 V Voltage Scan Mode 15.0 12.5 Ignition Trigger Signal Voltage Scan Mode Square Waveform Mode 10.0 7.50 Air Flow Sensor Square Waveform Mode 5.00 2.50 7.50 ms/Grid Freq ... -
Page 19: Charging System
Charging System Ripple Test Enter Charging System to select Battery Voltage or Ripple Test. Max：0.00 V Min ： -0.01V Battery Voltage 0.75 0.50 General Signal Battery Voltage Ripple Test 0.25 Sensors & Components Ripple Test -0.25 Charging System -0.50 0.75 ms/Grid Ignition System Max：0.03 V Min ：... - Page 20 Ignition System Ignition Primary Enter Ignition System to select Ignition Primary or Ignition Secondary Max：0.00 V Dwell Scanwaveform Min ： -0.01V Battery Voltage 0.75 Ignition Coil Primary Waveform 0.50 Ripple Test 0.25 -0.25 -0.50 0.75 ms/Grid Enter Ignition Primary to select Dwell Scanwaveform or Ignition Coil Primary Waveform. Max：0.03 V Min ：...
-
Page 21: Ignition Coil Primary
Ignition Coil Primary Additional function of waveform Max ：1.17 V Max ：363.5V Active ：0.00 mS Active ：31.25mS Dwell Scanwaveform 60.0 50.0 Ignition Coil Primary Waveform 40.0 30.0 20.0 10.0 3.00 ms/Grid 7.50 ms/Grid When measuring waveform, press ENTER for freeze-frame current waveform. Max ：59.99V Active：... - Page 22 Setup Sleep Mode Setting Enter Setup to view and modify current settings. Setting Ignition Type Setting 1.Ignition Type Single Direct Setup Waveform Trigger 5 Minutes Ignition System 2.Trigger Type Falling Edge Sleep Mode Setting 10 Minutes 3.Sleep Mode 5 Minutes 4.Voltage Measure Type Maximum Voltage Voltage Measure Type...
-
Page 23: Software Update
CA-15 Software update (3) Please select "Install this driver software anyway". Step 1: Download and Install driver (1) Please login to our member and download driver from website www.autolandscientech.com PSM3_driver_v4.inf (iSCAN-II / VeDiS-II / PSM3 USB Driver) (You must have registered to become our member to be able to access the member area) NOTE The driver is same as driver for iScan-IIwt / VeDiS-II. - Page 24 (2) Please download latest CA15 software by clicking Update (4) After installation, CA15 will reboot . www.autolandscientech.com Close software and remove USB cable. (3) Please open CA15 software and update. page. page.
- Page 25 (5) How to check if PC/NB connects to CA15 properly? If successfully installed "Autoland PSModule (COM3)" will be listed under Device Manager. Please right click " Computer" and select "Properties". Select "Device Manager" page. page.
