Summary of Contents for AtlasIED IP-DB
- Page 1 IP-DB IP VIDEO DOORBELL QUICK START GUIDE QUICK START GUIDE 1601 JACK MCKAY BLVD. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 TELEPHONE: (800) 876-3333 AtlasIED.com AtlasIED.com ENNIS, TEXAS 75119 U.S.A. ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM SUPPORT@ATLASIED.COM...
- Page 2 Despite having a full metal housing and an IP66 rating, the IP-DB retains a sleek modern aesthetic that would not be out of place in a high-end residential setting. With...
-
Page 3: Package Contents
IP-DB IP VIDEO DOORBELL QUICK START GUIDE PAC KAG E CO N T E N TS IP-DB IP Video Doorbell Quick Start Guide RFID Cards (Qty 2) Connector Mounting Template Screws and Mounting Hardware F R ON T PA NE L D E SC R IPT I O N... -
Page 4: Interface Description
IP VIDEO DOORBELL QUICK START GUIDE I N T E R FAC E D ES CR IPT IO N Open the rear case of the IP-DB allowing access to the terminal blocks. SERIAL # DESCRIPTION Ethernet interface: standard RJ45 interface, 10/100M adaptive, it is recommended to use CAT5 or higher network cable... -
Page 5: Wiring Instructions
IP-DB IP VIDEO DOORBELL QUICK START GUIDE WI R I NG I NST RU CT I O N S NO: Normally Open Contact; COM: Common Contact; NC: Normally Close Contact. External SW 1 12V IN+ Power Supply SW 2 12V IN - 12V/2A –... -
Page 6: Installation Diagram
IP-DB IP VIDEO DOORBELL QUICK START GUIDE I N STA LL AT IO N D IAG R A M Wall Mounting Installation preparation Included hardware: • M3 x 6mm screw x3 • M4 x 30mm screw x5 • M6 x 30mm screw anchors x5 •... - Page 7 Push or hammer screw anchors into the drilled holes. Remove the wall bracket from the back of the IP-DB Detach the wall bracket from the device and loosen the four screw on the rear cover using a screwdriver.
- Page 8 IP-DB IP VIDEO DOORBELL QUICK START GUIDE Install the wall bracket and wiring Align the screw holes of the wall bracket with the holes in the wall and fix them to the wall with the 4x 30mm screws. Pass all the wires through the silicone plug in the middle of the bottom case. Leave a service loop of 15~20CM length.
- Page 9 S E AR C H I N G T H E I P - DB Method 1 Open the AtlasIED Discover using a computer on the same network as the IP-DB. Method 2 After the unit has fully started up, press the Lock DSS Key for 3 seconds. The unit will announce its IP Address.
- Page 10 IP-DB IP VIDEO DOORBELL QUICK START GUIDE Step 2 Set SIP server address, port, user name, password and SIP user with assigned SIP account parameters. Select “Activate”, and then click Apply to save this setting. 1601 JACK MCKAY BLVD. 1601 JACK MCKAY BLVD.
- Page 11 IP-DB IP VIDEO DOORBELL QUICK START GUIDE Step 3 Set the Speed Dial key as shown below for a quick start. Click “Apply” to save this setting. DSS Key 4 will reflect the speed dial button on the doorbell key specified above. *5-7 can be configured for the input sensor settings under the Security Settings then input settings “SW1-SW3”.
- Page 12 IP-DB IP VIDEO DOORBELL QUICK START GUIDE Step 4 EGS (Electronic Gate System) Settings 1601 JACK MCKAY BLVD. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 TELEPHONE: (800) 876-3333 AtlasIED.com AtlasIED.com ENNIS, TEXAS 75119 U.S.A. ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM SUPPORT@ATLASIED.COM...
-
Page 13: D Oor U N Loc K I Ng S Et T I N G
IP-DB IP VIDEO DOORBELL QUICK START GUIDE D OOR U N LOC K I NG S ET T I N G RFID Card Access control settings on web page / Personnel Management / Select Add / (“Normal”card provides door opening function, “Add ”card and “Del” card provides add and delete card function, Default “Normal”... -
Page 14: Remote Password
IP-DB IP VIDEO DOORBELL QUICK START GUIDE Remote Password Set Access control settings on web page / Personnel Management / Select Add. Enter the Name, Password Type “Remote”, Password and Number, Select Apply. The owner answers the access control call and presses “ * “ (default password). -
Page 15: Local Password
IP-DB IP VIDEO DOORBELL QUICK START GUIDE Local Password Set Access control settings on web page / Personnel Management / Select Add. Enter the Name, Password Type “Local”, Password and Number, Select Apply. Owners and visitors can open the door by entering “6789” (default password). -
Page 16: Limited Warranty
INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. AtlasIED does not assume, or does it authorize any other person to assume or extend on its behalf, any other warranty, obligation, or liability. This warranty gives you specific legal rights and you may have other rights which vary from state to state.
