Summary of Contents for FASTRON. Fast one Ultra thin AHF/SVG
- Page 1 Ultra Slim 电能治理 恒心致远 Ultra thin AHF/SVG User manual...
-
Page 2: Safety Instructions
Safety instructions This manual involves the installation and use of SVG device. Please make sure to read this manual before installation. ·It is strictly prohibited to place combustible materials near AHF/SVG device, otherwise there is a risk of fire; ·It is strictly prohibited to install AHF/SVG device in environments containing explosive gases, other-wise there is a risk of explosion;... - Page 3 1. Overview The ultra-thin power quality comprehensive governance module AHF/SVG uses the most advanced digital signal processor as the controller, IGBT semiconductor as the switching device, and advanced three-level topology to achieve the best compensation effect. This product is small in size, lightweight, and easy to install. This module can be expanded in parallel or equipped with intelligent capacitors for comprehensive dynamic compensation.
- Page 4 Power Load Grid AHF/SVG Load Side Souce Side System CT position can be selected on the gid side or on the load side Figure 2-2 Wiring Diagram...
- Page 5 Table 2-3 Wiring Terminal Signal Description Category Terminal position Terminal signal Signal description A-phase A-phase input terminal B-phase B-phase input terminal Power input C-phase C-phase input terminal N-line Three phase four wire neutral input terminal Grounding Grounding wire Connect S2 end of C-phase CT Connect S1 end of C-phase CT Connect S2 end of B-phase CT Connect S1 end of B-phase CT...
- Page 6 Operation: 1、 The LCD data is divided into two parts, one is real-time data, and the other is setting data. You can switch between setting data and real-time data by simultaneously pressing the “Up” and “Down” keys. Real-time data is only for viewing, while the setting data can be viewed and modified. 2、...
- Page 7 1.B-phase 2.I(A) B-phase system PF 1.C-phase2.I(A) C-phase system PF 1.A-phase 2.I(A) A-phase IGBT temperature 1.B-phase 2.I(A) B-phase IGBT temperature 1.C-phase2.I(A) C-phase IGBT temperature Three phase compensation Accumulated for each group capacitor qty Split phase compensation Accumulated for each group capacitor qty 0：Standby，4：Run，10：...
- Page 8 Unbalanced current I(A) compensation capacity Modbus communication address 1. ALL Compensation 1.Full compensation mode 2. TIS 2.Compensation by harmonic order 1. LOD External CT 1.Load side position 2. POS 2.Grid side 1. SIG Internal CT 1.Single module position 2. COP 2.Multi module/mixed cabinet External CT ratio Internal CT ratio...
-
Page 9: Daily Maintenance
4.3 Manual/Auto Start After AHF/SVG is powered on, set the button start mode. Press the on/off button to start the module. If it is started by other modes, it is also necessary to press the power on button, otherwise it cannot be powered on. -
Page 10: Product Specifications
6.Product specifications Name Description Input line voltage 380V ±20% Power grid structure 3P4W Capacity 5-30kvar/44A Frequency 50±5Hz Response time <5ms System parameter PF correction -1 ～ 1 Parallel operation Up to 8 modules can be connected in parallel Module power consumption ≤...
