Installation
Instructions
If you have any questions, call GE Appliances at 800.432.2737 or visit our Website at: GEAppliances.com
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
local electrical inspector's use.
IMPORTANT
codes and ordinances.
Note to Installer
instructions with the Consumer.
Note to Consumer
future reference.
• Installation must be performed by a qualified
installer.
• Proper installation is the responsibility of the installer.
Stack dryer only on washer. Do not stack washer on
dryer, washer on washer or dryer on dryer.
Do not modify this installation kit. Any modification will
void the product Warranty.
Disconnect power before
WARNING
installing. Failure to do so could
result in serious injury or death.
WARNING
• Use two or more people to install dryer.
• Keep fingers out of pinch point areas.
• Avoid tipping and rupture of utility services.
• Dryer must be securely attached to the washer.
• DO NOT place the washer on top of the dryer.
Failure to do so may result in serious injury,
death, or property damage.
INSTALLATION PREPARATION
Remove the packaging.
Flatten the product carton to use as a pad to lay
the dryer down on its back or side. Continue using
the carton to protect the finished floor in front of the
installation location.
31-3000369 Rev 1
In Canada, call 800.661.1616 or visit www.GEAppliances.ca
– Save these instructions for
– Observe all governing
– Be sure to leave these
– Keep these instructions for
- Excessive Weight
Hazard
09-23 GEA
Stack Bracket Kit
GFA24MIDV
WARNING
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Failure to do so can result in death, explosion, or fire.
WARNING
To prevent large amounts of lint and moisture from
accumulating and to maintain dryer efficiency,
this machine must be exhausted outdoors.
REQUIREMENTS FOR ALCOVE OR
CLOSET INSTALLATION
• If your dryer is approved for installation in an alcove
or closet, it will be stated on a label on the dryer
back. The installation must conform to the following
specifications:
• Minimum clearances between dryer cabinet and
adjacent walls or other surfaces are:
Sides
Top
Front
Rear
• Minimum vertical space from floor to overhead
cabinets, ceiling, etc. is 52 in.
• Closet doors must be louvered or otherwise ventilated
and must contain at least 60 square inches of open
area. If the closet contains both a washer and a dryer,
doors must contain at least 120 square inches of
open area.
NOTE: The clearances stated above are minimums.
Consideration must be given to provide adequate
clearance for installation and service.
MINIMUM CLEARANCE OTHER
THAN ALCOVE OR CLOSET
INSTALLATION
Minimum clearance to combustible surfaces and for
air opening are: 0" both sides*, 0" rear and 0" top.
The rear of the dryer should face a wall.
Consideration must be given to provide adequate
clearance for installation and service.
*
For improved performance, a 1/2" clearance is suggested on either side.
- Explosion Hazard
- Fire Hazard
Alcove
Closet
0"
1"
1"
1"
-
3"
3"
3"

Advertisement

loading
Need help?

Need help?

Do you have a question about the GFA24MIDV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GE GFA24MIDV

  • Page 1 Stack Bracket Kit Installation Instructions GFA24MIDV If you have any questions, call GE Appliances at 800.432.2737 or visit our Website at: GEAppliances.com In Canada, call 800.661.1616 or visit www.GEAppliances.ca BEFORE YOU BEGIN WARNING - Explosion Hazard Read these instructions completely and carefully.
  • Page 2: Tools You Will Need

    Installation Instructions ATTACH REAR WASHER BRACKET NOTE TO TOP REAR OF WASHER Refer to the Installation Instructions in the Owner's Manual for washer model GFW148 and dryer model Place the rear washer bracket on the washer top rear DSKS333 for electrical, water, drain and venting and align the holes in the bracket with the holes in requirements before starting the stacking installation.
  • Page 3 Installation Instructions ATTACH DRYER BRACKET TO ATTACH FRONT OF DRYER TO BOTTOM (REAR) OF DRYER FRONT WASHER BRACKET Carefully lay the dryer on its side. Use the packing Securely attach the front of the dryer to the front washer material so you don’t scratch the finish on the dryer. bracket with 4 #10 self-drilling screws (maximum torque should not exceed 22 in.
  • Page 4 Notes...
  • Page 5: Instructions D'installation

    Instructions KIT DE SUPPORT D’EMPILAGE d’installation GFA24MIDV Des questions? Appelez le 800.661.1616 ou Visitez notre site Web à l’adresse : www.electromenagersge.ca AVANT DE COMMENCER AVERTISSEMENT - Risque d’explosion Lisez attentivement ces instructions dans leur intégralité. Gardez les matières et les vapeurs inflammables IMPORTANT •...
  • Page 6: Outils Nécessaires

    Instructions d’installation FIXEZ LE SUPPORT DE LAVEUSE REMARQUE ARRIÈRE SUR LA PARTIE SUPÉRIEURE Reportez-vous aux instructions d’installation dans le ARRIÈRE DE LA LAVEUSE Manuel du propriétaire pour le modèle de laveuse GFW148 et le modèle de sécheuse DSKS333 pour Placez le support arrière de la laveuse sur la partie arrière connaître les exigences en matière d’électricité, d’eau, supérieure de la laveuse et alignez les trous du support avec de drainage et de ventilation avant de commencer...
  • Page 7 Instructions d’installation FIXEZ LE SUPPORT DE SÉCHEUSE FIXEZ L’AVANT DE LA SÉCHEUSE SUR LE BAS DE LA SÉCHEUSE AU SUPPORT AVANT DE LA LAVEUSE Posez soigneusement la sécheuse sur le côté. Utilisez le matériel d’emballage pour ne pas rayer la finition de la sécheuse. Fixez solidement l’avant de la sécheuse au support avant de la Placez le support de la sécheuse sur le bas de la sécheuse laveuse avec 4 vis autoperceuses numéro 10 (le couple...
  • Page 8 Remarques...
  • Page 9: Instrucciones De Instalación

    Instrucciones KIT DE SOPORTE DE APILAMIENTO de Instalación GFA24MIDV Si tiene alguna pregunta, llame GE Appliances a 800.432.2737 o visite nuestro sitio Web en: GEAppliances.com ANTES DE COMENZAR ADVERTENCIA - Riesgo de explosión Lea estas instrucciones por completo y con Mantenga cualquier material y vapores inflamables, tales detenimiento.
  • Page 10 Instrucciones de instalación NOTA FIJE EL SOPORTE TRASERO DE LA LAVADORA A LA PARTE SUPERIOR Consulte las instrucciones de instalación en el manual TRASERA DE LA LAVADORA del propietario de la lavadora modelo GFW148 y la secadora modelo DSKS333 para conocer los requisitos Coloque el soporte trasero de la lavadora en la parte eléctricos, de agua, drenaje y ventilación antes de superior trasera de la lavadora y alinee los orificios...
  • Page 11 Instrucciones de instalación FIJE EL SOPORTE DE LA SECADORA FIJE EL FRENTE DE LA A LA PARTE INFERIOR DE LA SECADORA SECADORA AL SOPORTE FRONTAL DE LA LAVADORA Coloque con cuidado la secadora sobre un costado. Utilice el material de embalaje para no rayar el acabado Fije de forma segura el frente de la secadora al soporte de la secadora.
  • Page 12 Notas...
