- Page 1 INSTALLATION INSTRUCTION INSTALLATION INSTRUCTION / VENTAIR / NATURAL VENTILLATION ROOF AND FACADE SKYDOME S.A.S ENTRE DEUX VILLES - 02270 SONS-ET-RONCHERE...
-
Page 2: Table Of Contents
VENTAIR is manufactured in raw aluminium or with a RAL paint finish. It can be installed on both roofs and facades This product has been designed to be as discreet as possible: AF version is flush with the roof and no more than 320mm deep. The body of the product is recessed into the roof. -
Page 3: 2° Version
500mm < A < 3000mm with the step of 125mm 500mm < B < 3000mm with a step of 100mm VENTAIR - AF 45° Roof slope: greater than 45 or frontage Dimensions: 500mm < A < 3000mm with step of 125mm 500mm <... -
Page 4: 3° Performance
See excel sizing table VENTAIR. 4° ENTRETIENT: The different versions of VENTAIR require no specific maintenance. The only maintenance required is the annual cleaning of debris and leaves that accumulate in the blades of the grid and on the anti-volatile grilles. - Page 5 Remove the self-drilling screws from underneath the appliance. Then remove the finishing bracket and slide the anti-volatile grid frames. Cleaning anti-volatile screens DE Remove the rivets under the brackets. VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
-
Page 6: 5° Installation
5° INSTALLATION : INSTALLATION DRAWING VENTAIR - AF VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /... - Page 7 INSTALLATION DRAWING VENTAIR – AF 45 VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
- Page 8 INSTALLATION DRAWING VENTAIR – DE VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
-
Page 9: 6° Roof Installation
(not provided). Attach them either along the Place the product on its support support on the heel every 30 cm, or from underneath by the roofer using brackets (not provided), as shown above VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /... - Page 10 Support with its waterproofing to be made Place the 1st part or complete grid on its Create a silicone seal along the entire by the roofer support length of the first part VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
- Page 11 Fix the 2 parts with the screws and washers Place the second part on its support along the support every 30cm or from provided underneath using brackets (not provided) as shown above VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
- Page 12 An extraction or air introduction sheath can be installed under the bottom of the device and must be securely fixed to the rail of the anti-volatile grid using self- drilling screws (not provided). View from underneath the device Rail of the grid where the sheath is to be attached Position of self-drilling screws for fastening Ventilation duct VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
- Page 13 VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
- Page 14 NOTES : SKYDOME S.A.S ENTRE DEUX VILLES - 02270 SONS-ET-RONCHERE https://www.skydome.eu Tél : 03.23.21.79.90 VENTAIR PRODUCT RANGE / NATURAL VENTILATION FOR FACADES AND ROOFS /...
