DIGITAL VOICE
RECORDER
MODEL:ICR-300
MODE
FILE/REP
INSTRUCTION MANUAL
LOCATION OF INDICATORS
F
A
B
C
E
D
A. Year/Message
B. Recording quality
C. Month/Date
D. Elapsing of message
E. File folder
F. Battery indicator
ERASE
12
A
B
C
D
Play logo
Record logo
Hold logo
SD card logo
Voice activate
Repeat 1/repeat all
Repeat A-B
2
LOCATION OF INDICATORS
1
MODE
3
FILE/REP
ERASE
Built-in Microphone
1
MODE/Power on
UP/Down(↑/↓)key
Play/Stop
Right/left(←/→)key
5
File/Repeat
Ext. Microphone Jack
Recording indicator
8
LCD display
USB Jack
3
OPERATION
BATTERY INSTALLATION
1
Push to open battery cover..
RY
3
e
Close the battery cover
:
NOTE
Replace batteries don't affect messages or files stored on unit.
But the time and date may need reset if the unit out off power more than 1
minute.
BATTERY PRECAUTIONS
Please follow below advices while handle batteries:
1.Use only the size and type of batteries specified.
2.Be sure correctly install batteries as logos carved on battery compartment.
Batteries reversed may lead the unit defect.
3.Do not mix different types of batteries together(e.g. Alkaline and Carbon-zinc),Or
old battery with fresh.
4.If the device is not to be used for a long period of time, remove the batteries to
prevent damage or injury from possible battery leakage.
5.Do not try to recharge batteries not intended to be recharged; they can overheat
and rupture.(Follow battery manufacturer's directions.)
6.Never try to remove the batteries while recording.
Record/Stop key
11
2
Pause/Delete key
3
Speaker
13
4
Volume
14
Hold key
15
6
SD card socket
16
7
9
10
2
Insert 2pcs of"AAA"size
batteries with correct polarity.
BATTERY INDICATORS:
The batteries are fresh.
The batteries are weak or dead to
replace.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MPMan ICR 300
Summary of Contents for MPMan ICR 300
-
Page 1: Instruction Manual
LOCATION OF INDICATORS DIGITAL VOICE RECORDER MODEL:ICR-300 MODE FILE/REP ERASE MODE FILE/REP ERASE Built-in Microphone Record/Stop key MODE/Power on Pause/Delete key UP/Down(↑/↓)key Speaker Play/Stop Volume Right/left(←/→)key Hold key File/Repeat SD card socket Ext. Microphone Jack Recording indicator INSTRUCTION MANUAL LCD display USB Jack LOCATION OF INDICATORS OPERATION... - Page 2 In set mode, press down Key(↓) In set mode, press down key(↓) till MIC setting. Then press till VOX appeared on LCD. Set (←)or(→)key to LOW or HI. Press VOX on or off with (←)or(→)key. PLAY key to confirm then press Press PLAY key to confirm the MODE key to back.
-
Page 3: Delete All
OPERATION(CONTINUED) OPERATION (CONTINUED) REPEATEDLY PLAYBACK MESSAGES EARPHONE JACK For private listening, connect an earphone to EAR jack. The unit can repeat 1 or all messages, or a section from A to B. VOICE ACTIVATED (VOX) RECORDING The speaker will automatically disconnected when an earphone plug rted into EAR jack. - Page 4 Memory is Full. When memory (inside unit or SD card.)is full, ‘FULL’ appeared on Play voice recorder files on PC LCD. Delete or move some massage to other devises such as PC, and you can record again. As the voice recorder files are special format(LP, SP, MP, HP), so you may not play this files well on your PC.
- Page 5 SPECIFICATIONS Max. 99 (sigal file) Message number Max.396 (4 files total) IMPORTANTSAFETY INSTRUCTIONS Read this manual before use and keep it for future reference Recording Time(128MB memory) PRECAUTIONS 50hours 16hours 8hour 5hours30min To maintain optimum performance: Do not use unit in places which are extremely hot, cold, dusty or Memory (SD or FLASH) SD:64MB~1GB;FLASH:128MB High humidity place.
- Page 6 2-1, At ICR Mode, press MODE key and hold more than 3 sec., the display shows SET Mode. (The display will be back to “Date mode” after 60sec. without any action.) 2-2, Use (↑) or (↓) key to select one mode to be set. 2-3, After select mode, use (←) or (→) key to change setting.
