- Page 1 NOVUS PRO USER MANUAL USER MANUAL NOVUS PRO 071020 PROGRAMMABLE DIGITAL AMPLIFIER ITS Partner O.B.S S.L.U. Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés Barcelona (Spain) Phone: +34935839543 info@ek.plus www.ek.plus MU_NOVUS PRO ICT_EN_V01...
-
Page 2: Table Of Contents
NOVUS PRO USER MANUAL INDEX INTRODUCTION: ..........................................3 Description: ............................................3 Key features ............................................4 Packaging Contents: ......................................... 4 CONNECTIONS AND INTERFACES: ................................. 5 ASSEMBLY RECOMMENDATIONS: ................................... 5 CONFIGURACION DE LA NOVUS PRO: ................................ 6 General Equipment Use: ....................................... 6 Menu overview: .......................................... -
Page 3: Introduction
NOVUS PRO USER MANUAL INTRODUCTION: Description: EK presents its new range of NOVUS PRO programmable amplifiers, developed with the most advanced digital filtering technology. The NOVUS PRO models feature 32 ultra-selective digital filters that allow each digital multiplex to be selected, filtered, and amplified. This ensures an optimal output level for all types of installations, both individual and collective, guaranteeing exceptional output signal quality. -
Page 4: Key Features
NOVUS PRO USER MANUAL Key features • 4 inputs: 2 x UHF, 1 x FM, 1 x DAB/VHF-UHF (selectable). • 2 outputs: TER / TEST. • 32 ultra-selective digital filters. • Automatic search for digital multiplexes. • Gain > 70 dB (autoreg). •... -
Page 5: Connections And Interfaces
NOVUS PRO USER MANUAL CONNECTIONS AND INTERFACES: 1.-VHF-UHF Input 1 2.-VHF-UHF 2 Input 3.-DAB or VHF-UHF3 input, selectable 4.-FM Input 5.- OLED Display 6.-Joystick 7.- Aux DC 12V Input 8.- USB for PC connection 9.-Ter Output 10.- Ter + SAT Output 11.- Input Vac 100-240V ASSEMBLY RECOMMENDATIONS: 1.- Mount the equipment vertically in a well-ventilated area, ensuring that the maximum... -
Page 6: Configuracion De La Novus Pro
NOVUS PRO USER MANUAL CONFIGURACION DE LA NOVUS PRO: General Equipment Use: The user interface consists of an OLED screen that displays the menus in a clear and intuitive manner. Navigation is performed using a four-way joystick. The selected element or parameter flashes on the screen. To confirm values or select an option, simply press the central button on the joystick. -
Page 7: Menu Overview
NOVUS PRO USER MANUAL Menu overview: The menu is organized into four main categories and follows a hierarchical structure that continuously guides the user, making it easy to navigate and explore the available options. Settings related to filter configuration Settings relating to the output level Technical and Less Frequent Features ITS Partner O.B.S S.L.U. - Page 8 NOVUS PRO USER MANUAL While navigating through the submenus, the top bar of the screen continuously shows the hierarchical location using a navigation trail or "breadcrumb". This allows the user to always know exactly which section of the menu they are in. Breadcrumbs In the following chapters of the manual, each section of the menu will be explained in detail.
-
Page 9: Filter Menu
NOVUS PRO USER MANUAL 1.- FILTER Menu This menu groups all the functions needed to configure programmable filters 1.1.-AUTOSCAN The AUTOSCAN option allows you to configure the equipment quickly and easily with just three clicks, making it suitable for most situations. It is located within the FILTER menu and can be executed directly by selecting START. -
Page 10: Manual
NOVUS PRO USER MANUAL 1.2.-MANUAL This option allows you to manually configure all possible filter settings, such as creating, deleting, editing, etc. The existing filters are displayed grouped by input, and from this option, you can also activate the preamp power (12V or 24V) as needed. The following describes the process for each of the filter editing functions: Clear All: Removes all filters from the selected input. -
Page 11: Spectrum
NOVUS PRO USER MANUAL 1.3.-SPECTRUM This unique function of the NOVUS PRO series provides a graphical representation of the spectrum of programmed filters. The input signal for each filter is shown by a vertical bar, with the length representing the signal level. The small upper bar represents the output level of each filter and allows you to quickly verify if it is properly equalized by aligning horizontally with the other filters. -
Page 12: Dab
NOVUS PRO USER MANUAL 1.3.-DAB This option, which is disabled by default, allows input 3 to be configured as a filter for the DAB band, covering the range from 170 MHz to 240 MHz. Activate DAB 1.4.-LTE By default, inputs 2 and 3 are configured with a filter to block LTE and LTE2 signals above 700 MHz. To receive DTT channels up to 790 MHz, select the LTE option. -
Page 13: Output Menu (Dtt And Fm)
NOVUS PRO USER MANUAL 2.-OUTPUT menu (DTT and FM) In this menu, you can directly access the configuration of the output level and slope for the DTT and FM channels. 2.1-DTT Output Level Based on the number of programmed filters, the device sets the recommended maximum output level. -
Page 14: Advanced Menu
NOVUS PRO USER MANUAL 3.-ADVANCED Menu This menu contains functions that, although less frequently used or more technical, are equally important and extremely useful. 3.1-Language You can select between SPANISH, ENGLISH, FRENCH and ITALIAN Select Language 3.2-RESET The RESET erases all data and restores the factory settings for the selected geographic region: EUROPE;... -
Page 15: Status
NOVUS PRO USER MANUAL 3.3-STATUS This option provides information about the internal workings of the equipment, helping the installer verify that ventilation is proper and diagnose potential issues. The equipment displays the internal operating temperature in real-time, along with the highest internal temperature it has reached at any point. -
Page 16: Test Mode
NOVUS PRO USER MANUAL 3.4-TEST MODE The TEST mode is another exclusive feature of the NOVUS PRO series that allows for the quick detection and localization of defects in the installation wiring. While in this mode, the unit temporarily modifies the output signal and generates an equalized channel comb that spans the entire UHF band. - Page 17 NOVUS PRO USER MANUAL Example of TEST Mode usage: ITS Partner O.B.S S.L.U. Av. Cerdanyola 79-81 Local C MU_NOVUS PRO ICT_EN_V01 08172 Sant Cugat del Vallés Barcelona (Spain) Phone: +34935839543 info@ek.plus www.ek.plus...
-
Page 18: Visual Mode (Ek Patented)
NOVUS PRO USER MANUAL 3.5-VISUAL MODE (EK PATENTED) Another exclusive and patented feature by EK is the VISUAL MODE, in which the programmable control panel screen is not used, but rather the field meter's screen. This mode has been developed primarily for the NOVUS MAST range of programmable mast amplifiers, which are the only ones on the market of their kind that allow individual adjustment of filters. - Page 19 NOVUS PRO USER MANUAL Select filter: When you press the central button on the joystick, the filter with the lowest frequency will start to change its width repeatedly, flashing, making it easier to identify among all the existing filters. While the filter is flashing, any adjustments made with the joystick will be applied to that filter.
- Page 20 NOVUS PRO USER MANUAL Adjusting the output frequency (selected filter): Using the side buttons on the joystick, the installer can change the output frequency of the selected filter. To confirm the changes, you need to press the central button on the joystick. Frequency change (Selected filter) Deleting a filter (selected filter): Holding the down button on the joystick for 3 seconds will...
- Page 21 NOVUS PRO USER MANUAL Creating a new filter: Holding down the top button on the joystick for 3 seconds will bring up a new filter flashing. With the side keys you can adjust the input and output frequency. To confirm the creation of the filter, the middle button on the joystick must be pressed. 3”...
-
Page 22: Selectivity
NOVUS PRO USER MANUAL 3.5-SELECTIVITY The NOVUS PRO offers two configurations for filter selectivity. The default option is OPTIMAL, which provides higher rejection and is suitable for most situations, especially when there are adjacent channels. Alternatively, there is the SOFT option, which offers slightly lower rejection but better preservation of the channel of interest. -
Page 23: Pc Connection
NOVUS PRO USER MANUAL PC CONNECTION The EK NOVUS Upgrade Tool is a simple software application that allows you to update the firmware and save configurations. Installing the EK NOVUS Upgrade Tool In the downloads section of www.EK.plus, you can download the latest version of the software as a compressed file. -
Page 24: Configuration Cloning
NOVUS PRO USER MANUAL Configuration cloning If the programmable amplifier has existing settings, they will be displayed in the "Device Settings" section. By clicking the SAVE button, you can store them on your PC and later clone them to other programmable amplifiers: To copy one of the saved settings to another programmable amplifier, select the desired file using the LOAD button:... - Page 25 NOVUS PRO USER MANUAL Once the settings file is uploaded, press SEND to save it to the control panel ITS Partner O.B.S S.L.U. Av. Cerdanyola 79-81 Local C MU_NOVUS PRO ICT_EN_V01 08172 Sant Cugat del Vallés Barcelona (Spain) Phone: +34935839543 info@ek.plus www.ek.plus...
