Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024
QE-CURRENT-485 | QE-CURRENT-485-H
Visit the product page
for news, updates and downloads
....................................................................................................................
PRODUCT MANUAL
3
3
4
Status LEDs
4
4
4
5
5
5
6
6
7
7
8
9
9
9
QE-CURRENT-485
....................................................................................................................................................................................
....................................................................................................................................................................
.........................................................................................................................................................................
...................................................................................................................................................
..........................................................................................................................................................
...........................................................................................................................
.......................................................................................................................................................................
..........................................................................................................................
..............................................................................................................................................................................
GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024
PAGE
1 of 17
QE-CURRENT-485-H
9
9
9
10
10
10
...........................................
10
10
11
11
.................................................................
12
................................................
13
..............................................................
14
Advertisement
Table of Contents
Summary of Contents for QEED QE-CURRENT-485
-
Page 1: Table Of Contents
Order codes Register map ......................................................................Connection and installation ............................RS485 bus termination ............................Status LEDs ..................................... Product features ..................................Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 2: Product Manual
This document is subject to periodic revision and updating. guaranteed (e.g. visible damage). Disconnect all connections in QEED reserves the right to make changes to the product and/ this case. The unit should be returned to the manufacturer or to or its technical documentation at any time in the interests of an authorised service centre for repair. -
Page 3: Product Overview
PRODUCT OVERVIEW The QE-CURRENT-485 is a current transducer (and analyzer in the -H version) capable of interfacing with various isolated current transducers, with both current and voltage outputs, also suitable for reading 2- or 3-wire PT100 or NTC temperature probes, as well as non-characterized probes by entering the STEINHART-HART curve in the Q-WIZARD configuration software. -
Page 4: Inputs
In addition, the digital output can also be associated with an alarm on the input measurement reported at the output; depending on the configuration software setting, the output contact can be set as NC or NO. Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 5: Technical Specifications
Resistance RTD/NTC ✓ ✓ ✓ ✓ picco ✓ ✓ Harmonic analysis up to the 63rd harmony ✓ ✓ Internal microcontroller temperature Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 6: Measurement Accuracy
1 start bit, 8-bit data, NO/ODD/EVEN parity (default NO parity) Response delay 1÷1000ms Connection Via removable terminal, T-BUS or microUSB Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 7: General Data
EN61000-6-3; EN61000-4-2; EN61000-4-3; EN61000-4-4; EN61000-4-5; EN61000-4-6; EN61010-1 Installation DIN rail mounting Order codes Converter QE-CURRENT-485 Converter and analyzer QE-CURRENT-485-H T-BUS QA-TBUS-22 Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 8: Connection And Installation
The number of modules supported by the bus depends on the power supply used (please check the power consumption of the modules) Figure 1: DIN-rail installation with T-BUS Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 9: Rs485 Bus Termination
By adjusting register [40008], it is possible to set a fault signal to be displayed via the Fail LED on the front of the device. Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 10: Digital Input Alarm
In addition to the configuration of various parameters, inputs and outputs, the Q-WIZARD also allows real-time monitoring of device variables. Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 11: Third-Party Modbus Master
Exception code 1 byte 01, 02, 03, 04 (see note) 03: Illegal data value 2 bytes 04: Slave device failure Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 12: Function 06 Hexadecimal (Write Single Holding Register)
Exception code 1 byte 01, 02, 03, 04 (see note) 03: Illegal data value 2 bytes 04: Slave device failure Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 13: Function 10 Hexadecimal (Write Multiple Registers)
Exception code 1 byte 01, 02, 03, 04 (see note) 03: Illegal data value 2 bytes 04: Slave device failure Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... -
Page 14: Register Map
3 → Output Under-range 4 → Output Over-range 5 → RTD Out of the range 6 → RTD Third Wire error Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024... - Page 15 3rd Harmonic Float [32b-LSW] 40167 I 4 Rms 4th Harmonic Float [32b-LSW] 40169 I 5 Rms 5th Harmonic Float [32b-LSW] 40171 Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024...
- Page 16 40291 Rtd Resistance RTD Resistance [Ω] Float [32b-LSW] 40293 Rtd 3rd Wire Resistance Third wire Resistance [Ω] Float [32b-LSW] 40295 Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024...
- Page 17 UInt [32b-MSW] = Unsigned Integer (32 bit - MSW First Register) Int [64b-LSW] = Signed Long Long (64 bit - LSW First Register) Product Manual QE-CURRENT-485 | QE-CURRENT-485-H - Rev. A.0 issued 25.11.2024 GL 1.3 - QE-Current-485 - v1.3.4.2 - ENG - 19.12.2024...
