Base Heater Control KIT
Installation manual
AVR-M200QHAX
• Thank you for purchasing this Samsung Product
• Before operating this unit, please read this Installation manual carefully and retain it for future reference.
DB68-13072A-00_IM_ACC DVM 575V용 BASE HEATER Controller_AA_EN_.indd 1
2024-08-26 오전 11:42:57
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Samsung AVR-M200QHAX
- Page 1 Base Heater Control KIT Installation manual AVR-M200QHAX • Thank you for purchasing this Samsung Product • Before operating this unit, please read this Installation manual carefully and retain it for future reference. DB68-13072A-00_IM_ACC DVM 575V용 BASE HEATER Controller_AA_EN_.indd 1 2024-08-26 오전 11:42:57...
-
Page 2: Table Of Contents
Contents Safety Information Installation Control box parts diagram Accessories Installing the control box [DVM S2 575V Series] Connecting the power terminals Wiring diagram Configure outdoor unit option settings Cautions for base heater and control box Appendix Check items by error code 2 English DB68-13072A-00_IM_ACC DVM 575V용... -
Page 3: Safety Information
Safety Information Safety Information Be sure to use copper wire as the power cable and use only WARNING the regulated parts for wiring. Be sure to check whether wiring has been properly made. • Cancer and Reproductive Harm - www.P65Warnings. ca.gov. -
Page 4: Parts And Dimensions
Parts and Dimensions Parts and Dimensions Control box parts diagram Accessories Product Body (1) Installation Guide (1) Relay Fuse Trans power Sub PCB assembly Bracket Holder (1) M4 x L12 Screw (5) Unit: inch (mm) 8.24 (209.3) English DB68-13072A-00_IM_ACC DVM 575V용 BASE HEATER Controller_AA_EN_.indd 4 2024-08-26 오전... -
Page 5: Control Box Installation
Control Box Installation Installing the control box [DVM S2 575V • Installation in a DVM S2 X-Large model Series] Fasten the bracket to the control box's body using the supplied screws. The bracket should be installed on the left of the control box. Fasten the control box to the outdoor unit with supplied screws (3EA) for assembly. - Page 6 Control Box Installation Connect the transmission and power wires between the DVM S2 Large base heater control box and the outdoor unit control box. Secure the wires with the factory installed wire holders. Transmission Line Power Line DVM S2 Small Transmission wires (Main PBA CN807) Transmission Line...
-
Page 7: Connecting The Power Terminals
DVM S2 X-Large • Failure to tighten these connections properly may result in a loose connection causing potential overheating and subsequent damage. Transmission Line Power Line Transmission wires (Main PBA CN807) Power supply wires Base heater power wires Cable Tie Slim Wire Thick Wire Wire Stripping Position... -
Page 8: Wiring Diagram
Control Box Installation Wiring diagram • AVR-M200QHAX (For 575V) - DVM S2 Small / Large BASE HEATER CONTROL KIT MAIN CONTROL BOX • AVR-M200QHAX (For 575V) - DVM S2 X-Large BASE HEATER CONTROL KIT MAIN CONTROL BOX English DB68-13072A-00_IM_ACC DVM 575V용 BASE HEATER Controller_AA_EN_.indd 8... -
Page 9: Configure Outdoor Unit Option Settings
Configure outdoor unit option settings In the option setup menu, when you shortly press the K1 switch, the values for Segment 1 and Segment 2 change. You can select the desired option. When installing Base heater and control box, be sure to enable (e.g. -
Page 10: Cautions For Base Heater And Control Box
• To obtain the updated outdoor unit firmware, please reach out to your local Samsung HVAC service or distribution center. ※ While the ODU is in "Base Heater testing mode" or while the base heater is on under normal operation, never touch the heater or parts near the base plate to prevent serious burns. -
Page 11: Appendix
Check items by error code Symptom During the Heat mode or the heater test run, the temperature on the heater does not increase. 1) Connection error 2) Outside temperature sensor error Cause 3) Heater power connection error 4) Relay operation error The connector is properly Check operation after connecting the connected between the heater... - Page 12 Check items by error code Symptom The heater operates normally at the outside temperature of 41 ℉ (5 °C) or higher? 1) Test run Cause 2) Outside temperature sensor error 3) Relay operation error Commissioning is in progress? It operates normally. Check operation after removing foreign The outside temperature materials, or connecting or replacing the...
