- Page 1 LIVERYMAN Make It Smooth, Make It Professional KARE-PRO 50 Professional Cordless Trimmer EN FR INSTRUCTIONS FOR USE...
-
Page 2: Technical Specification
INSTRUCTION MANUAL FOR KARE-PRO 50 TRIMMER To ensure you achieve the best possible results from your clipper, please read the following instructions carefully before use. TECHNICAL SPECIFICATION Charging time: 3.5hours Operation time: 2.5hours Blade width: 46 mm Dimensions: 17 (H) x 4.6 (B) x 4.1 (D) cm... -
Page 3: Keep Away From Water
SAFETY GUIDELINES AND OPERATOR RESPONSIBILITIES KEEP AWAY FROM WATER 1. Only use this appliance for its intended purpose. Use only on clean dry hair. 2. Close supervision is necessary when this appliance is by or near children. 3. Use only with accessories included in the package, or recommended by the manufacturer. 4. -
Page 4: Blade Adjustment
BATTERY 1. Do not overcharge. It takes 2.5 hours to charge your trimmer. Charging over 36 hours may shorten the life of the battery. 2. The life of the battery will be shortened if the trimmer remains uncharged for long periods. Charge every 3 months of non-use to activate the battery. -
Page 5: Maintenance
CAUTION • Except for the purpose of charging, always switch off and unplug the adapter from the wall after use. • Do not frequently use the clipper plugged without having recharged the battery, as this may reduce the life of the battery. •... -
Page 6: Comb Attachments
COMB ATTACHMENTS You may adjust the cutting length from 3-12mm by attaching the comb attachment. 1. The cutting length is marked on the of comb attachments. 2. Select a suitable size and slide the blade into the comb attachment. BLADE LIFE The service life of the blade may be shortened in the following situations: 1. -
Page 7: Operational Hints
OPERATIONAL HINTS • The Kare-Pro 50 can be used to clip with or against the direction of the coat. • For clipping longer hair use in conjunction with the combs and clip with the direction of the hair. • For a closer clip use against the hair. - Page 8 112483 Kare-Pro 50 Mains Adapter 112473 Kare-Pro 50 Charging Base 112273 Kare-Pro 50 Blade Adjustable 112283 Kare-Pro 50 Comb Set (4 piece: 3,6,9&12mm) KARE-PRO 50 TRIMMER BLADE INFORMATION Kare-Pro 50 Trimmer Width Clip mm Type of Clipping Combs KARE-PRO 50 Close to medium adjustable.
- Page 9 Professional Clipper 610 WARRANTY REGISTRATION FURZONE WARRANTY REGISTRATION erial umber...
- Page 10 Whilst every care has been taken in the compiling of information within our instructions, Agrihealth Ltd (Liveryman) accepts no responsibility for any errors or omissions in technical data or other information as stated. Model No: KP50/CL F URZ ONE...
- Page 11 LIVERYMAN Make It Smooth, Make It Professional KARE-PRO 50 Tondeuse Professionnelle avec batterie interne EN FR GUIDE D’UTILISATION...
- Page 12 2. Bouton de démarrage 7. Levier hauteur de tonte 3. Fixation peigne 8. Sur Peignes 3/6/9/12 mm 4. Témoin de chargement 9. Base de chargement 5. Fiche de chargement électrique Une bonne utilisation de la tondeuse Kare-Pro 50 vous permettra d’optimiser sa longévité...
-
Page 13: Précautions D'utilisation
2. Rester vigilent si des enfants sont à proximité de cet outil. 3. Utiliser seulement avec les accessoires inclus dans le pack ou recommandés par Liveryman 4. Éviter tout contact avec les yeux ou sur une peau abimée ou sensible. - Page 14 • Contrôler que le bouton de démarrage est sur la position off avant de brancher la tondeuse • Avant usage, contrôler que les peignes sont bien lubrifiés avec une huile pour tondeuse de préférence de marque Liveryman ENTRETIEN ET CHANGEMENT DE PEIGNES 1.
-
Page 15: Entretien
3. Faire bouger la partie oscillante du peigne pour enlever les poils coincés entre les dents du peigne. LUBRIFIER LE PEIGNE Lubrifier les deux côtés du peigne avec une huile adaptée (de préférence Liveryman Spray ) mais aussi les parties de la tondeuse qui supportent le peigne. REMPLACEMENT DES PEIGNES 1. -
Page 16: Entretien Du Moteur
NETTOYAGE DU CORPS DE LA TONDEUSE ET ACCESSOIRES 1. Éteindre la tondeuse 2. Nettoyer avec un chiffon humide 3. Laisser sécher avec de remettre en marche SUR-PEIGNES Vous pouvez choisir d’ajuster la hauteur de tonte de 3 à 12 mm en utilisant les sur peignes. 1. - Page 17 LA DURÉE DE VIE DE LA BATTERIE • La durée de vie de la batterie est d’environ 1000 cycles de recharge. Au-delà la recharge sera mois efficace et la puissance moins importante. La dure de vie de la batterie peut être réduite selon les situations suivantes : 1.
- Page 18 112483 Kare-Pro 50 Mains Adapter 112473 Kare-Pro 50 Charging Base 112273 Kare-Pro 50 Blade Adjustable 112283 Kare-Pro 50 Comb Set (4 piece: 3,6,9&12mm) KARE-PRO 50 TRIMMER BLADE INFORMATION Kare-Pro 50 Trimmer Width Clip mm Type of Clipping Combs KARE-PRO 50 Close to medium adjustable.
- Page 19 Professional Clipper 610 WARRANTY REGISTRATION FURZONE WARRANTY REGISTRATION erial umber...
- Page 20 United Kingdom www.agrihealth.ie www.agrihealth.co.uk Bien que nous ayons porté beaucoup d’attention à la réalisation de ce guide d’utilisation, Agrihealth Ltd (Liveryman) n’est pas responsable des erreurs ou omission concernant les informations techniques mentionnées. Model No: KP50/CL F URZ ONE AGRIHEALTH 9 Silverwood Industrial Area 3402 North.
- Page 21 LIVERYMAN KARE-PRO 50 INSTRUCTIONS FOR USE...
- Page 22 INSTRUCTION MANUAL FOR KARE-PRO 50 TRIMMER To ensure you achieve the best possible results from your clipper, please read the following instructions carefully before use. TECHNICAL SPECIFICATION Charging time: 3.5hours Operation time: 2.5hours Blade width: 46 mm Dimensions: 17 (H) x 4.6 (B) x 4.1 (D) cm...
- Page 24 SAFETY GUIDELINES AND OPERATOR RESPONSIBILITIES KEEP AWAY FROM WATER 1. Only use this appliance for its intended purpose. Use only on clean dry hair. 2. Close supervision is necessary when this appliance is by or near children. 3. Use only with accessories included in the package, or recommended by the manufacturer. 4.
- Page 25 IMPORTANT NOTICE BLADE 1. The blade must be lubricated before and after each use. This will maintain it in good condition and will extend its service life. 2. Non-stop usage for hours may cause overheating of blades, reducing the cutting performance and shortening their life.
- Page 26 OPERATING INSTRUCTIONS CHARGING 1. Switch off trimmer. 2. Connect the DC plug to the charging stand. 3. Place the trimmer into the charging stand. 4. Connect the adapter to the wall socket. 5. Check the charging indicator. When the indicator light of the clipper unit is red, the unit is charging. 6.
- Page 27 5. Wait for 1 minute to activate the internal parts. 6. Switch on to operate. CAUTION • Except for the purpose of charging, always switch off and unplug the adapter from the wall after use. • Do not frequently use the clipper plugged without having recharged the battery, as this may reduce the life of the battery.
- Page 28 1. Hind supporting areas: Push the oscillating part to one side; lubricate the visible friction surface on the other side. Drop a small amount of oil on both sides. 2. Front cutting teeth: Drop a small amount of oil on the blade teeth and spread evenly. Slightly move the oscillating part to permeate the oil between the blades.
- Page 29 If the cutting efficiency is reduced substantially despite proper maintenance, the blade has exceeded its service life and should be re-sharpened or replaced. MOTOR LIFE • No maintenance is required for the motor. • The service live expectancy if the motor is approximately 10000 under proper usage. The service life of the motor may be shortened in the following situations: 1.
- Page 30 OPERATIONAL HINTS • The Kare-Pro 50 can be used to clip with or against the direction of the coat. • For clipping longer hair use in conjunction with the combs and clip with the direction of the hair. • For a closer clip use against the hair.
- Page 31 9 Silverwood Industrial Area, Silverwood Road Clones Road, Monaghan Lurgan, Craigavon, Co. Armagh BT66 6LN Co. Monaghan United Kingdom Ireland www.agrihealth.co.uk www.agrihealth.ie WARRANTY REGISTRATION FURZONE WARRANTY REGISTRATION erial umber...
- Page 32 Whilst every care has been taken in the compiling of information within our instructions, Agrihealth Ltd (Liveryman) accepts no responsibility for any errors or omissions in technical data or other information as stated. Model No: KP50/CL FU R ZO NE...
