Description
The emergency converter EEC61L/M/H is universal design for use with most LED lamps that works with constant power drivers.
It is an emergency battery pack that uses electronic circuitry to convert energy stored in a battery into the DC voltage and current
necessary to drive the LED load.
The unit can be installed as maintained or non-maintained unit and it allows the same LED fixture to be used for both normal and
emergency operation.
When in emergency mode, the unit will operate a 5W/10W LED load with constant power with a rated output voltage of
10-90V/20-90V/60-250V/240-430V. The emergency power can be adjusted by dial switch. The unit has a discharge
protection circuit, over load, short circuit and battery low voltage protection.
Each unit includes the battery pack, LED charge indicator, a test switch and the emergency power module, everything combined
in a single box.
General Specification
Rated supply voltage
Mains frequency
Ambient temperature
Battery discharge and LED output specifications
Battery discharge voltage
Item Code
Min-Typ-Max
EEC61L-5W
EEC61M-5W
2.5-3.2-3.6V
EEC61H-5W
EEC61L-10W
EEC61M-10W
5-6.4-7.3V
EEC61H-10W
Item Code
EEC61L
3.2V/6000mAhLiFePO4 battery
EEC61M
EEC61H
EEC61L-ST
EEC61M-ST
6.4V/6000mAhLiFePO4 battery
EEC61H-ST
Note
1.
All specifications are typical at 25°C unless otherwise stated.
2. "ST" represents the self test.
3. In an emergency state, press the test button for at least 1 second to turn off the emergency LED light (simplifying theoperation of
opening the battery cover and disconnecting the battery)
Important information for the installation
The unit use dangerous mains voltage, it should be installed by qualified electricians only according to European safety standard
or relevant nation regulations.
The emergency converter can only be used with the LED lamps and only suitable for use in indoors. Protect the electronics
converter against excessive heat.
Connect the LED lamps to the emergency converter with correct polarity according to the schematic drawing.
The maximum length of the output cable to the LED lamps should not exceed 3m according to the EMC standard.
Connect the unit to AC power only after the wiring been completed between emergency converter and LED lamps.
About such situations, no ability can be taken over for possible damage. The emergency converter is used for purposes other than
originally intended; connected in the wrong way.
Battery should be charged every three months in order to keep it's initial performance.
The emergency function test must be performed when a battery is fully charged for 24 hours.
When customers match the emergency driver with Class II lighting fixtures, the grounding mark is E. When matching it with
Class I lighting fixtures, the grounding mark is
If grounding is required for actual use, it can be customized according to actual needs.
INSTALLATION INSTRUCTION
‫ﺗﻌﻠﻴﻤﺎت اﻟﺘﺮﻛﻴﺐ‬
220-240VAC
50/60Hz
°C
°C
5
-45
Battery discharge current
Battery output power
Min-Max
1400-1750mA
1500-1800mA
Batteries
As our emergency driver is a Class II product, the default grounding mark is E.
-
- -
Output voltage
Min-Max
Min-Max
10-90Vdc
4-5W
60-250Vdc
240-430Vdc
20-90Vdc
8-10W
60-250Vdc
240-430Vdc
Emergency
Emergency
Power
Duration
5W
3h
10W
Output current
Output power
Min-Max
Min-Max
25-320mA
10-65mA
2.5-3.5W
6-16mA
75-430mA
17-144mA
7.5-8.5W
16-35mA
Charge
Charge
Current
Time
400mA±10%
24h
230-300mA
