Summary of Contents for VOLTA S-WEB
- Page 1 GATEWAY VOLTA S-WEB USER AND INSTALLER'S MANUAL MODEL: SERVICE CONTACT:...
-
Page 3: Table Of Contents
General information ................................4 1.1. Safety considerations ................................4 1.2. Recycling ....................................5 Description ..................................... 5 2.1. VOLTA S-WEB GATEWAY device ............................5 2.2. VOLTA S-WEB web interface ..............................5 Installation ..................................... 6 Connection modes .................................. 8 4.1. DIRECT-ETHERNET mode ............................... 8 4.2. -
Page 4: General Information
This may also be used to warn of unsafe practices. The VOLTA S-WEB GATEWAY has been designed to monitor and remotely access the different VOLTA HEAT PUMPS products via a web interface. The manufacturer is not responsible for any material damage and/or personal injury resulting from improper use or incorrect installation of the equipment. -
Page 5: Recycling
The VOLTA S-WEB GATEWAY has been designed to establish different connection paths between your VOLTA HEAT PUMPS device and any type of device that has a web browser, such as a mobile phone, a tablet, a PC, etc. Through the VOLTA S-WEB GATEWAY you can access your VOLTA HEAT PUMPS device directly (Direct Access), through your local area network (Local Access) or through the Internet (Remote Access). -
Page 6: Installation
Figure 3.1. Installation of the VOLTA S-WEB GATEWAY to the VOLTA HEAT PUMPS device. Connect the antenna to the SMA connector of the VOLTA S-WEB GATEWAY and place it outside of the VOLTA HEAT PUMPS device in a vertical position. - Page 7 Table 3.1. BMS2 communications bus addresses for the different VOLTA HEAT PUMPS device. Check that the VOLTA S-WEB GATEWAY communicates correctly with the VOLTA HEAT PUMPS device. The device has a LED that indicates different connection statuses. PULSE FREQUENCY...
-
Page 8: Connection Modes
(DIRECT-ETHERNET), or through your local network (LAN-ETHERNET). 4.1. DIRECT-ETHERNET mode This lets you access the VOLTA HEAT PUMPS device from your PC through a direct connection by Ethernet cable to the VOLTA S-WEB GATEWAY. To make this type of connection, follow the steps below: Connect your PC directly to the VOLTA S-WEB GATEWAY via an Ethernet cable. -
Page 9: Ap-Wifi Original / Custom Ap-Wifi Mode
This lets you access the VOLTA HEAT PUMPS device from your device (mobile phone, tablet, PC, etc.) through a direct connection to the wireless access point generated by the VOLTA S-WEB GATEWAY, without the need to have your own local area network or an internet connection. -
Page 10: Lan-Ethernet Mode
4.3. LAN-ETHERNET mode This lets you access the VOLTA HEAT PUMPS device from your device (mobile phone, tablet, PC, etc.) by means of a connection through your local area network, using an Ethernet cable connection between your router and the VOLTA S-WEB GATEWAY. To make this type of connection, follow the steps below: Connect the VOLTA S-WEB GATEWAY to your router using an Ethernet cable. -
Page 11: Lan-Wifi Mode
4.4. LAN-WiFi mode This lets you access the VOLTA HEAT PUMPS device from your device (mobile phone, tablet, PC, etc.) by means of a connection through your local area network, using a wireless connection (WiFi) between your router and the GATEWAY VOLTA S-WEB. To make... -
Page 12: Connection Mode Settings
User and installer's manual ▪ If the connection test is unsuccessful, this may be due to the wireless signal generated by the router being too weak. Try to position the VOLTA S-WEB GATEWAY antenna in a more favourable location. NOTE ▪... -
Page 13: Smart.voltaheatpumps.com Web Portal
You can register your device through the smart.voltaheatpumps.com web portal and access the different functionalities it offers. To do this, the GATEWAY VOLTA S-WEB device must be installed in a configuration that allows you to connect via the internet. This portal will give you centralised access to all your VOLTA HEAT PUMPS equipment and will allow you to access the information contained in their operational logs which are stored in the cloud. -
Page 14: Authorised Distributors And Technical Service
6.1. Authorised distributors and technical service VOLTA HEAT PUMPS has an extensive network of authorised companies that distribute and perform the technical service on its products. This network will provide our customers with all the information and technical support they need, anywhere and under... - Page 16 Rúa das Pontes 25, 36350 Nigrán (Pontevedra) Spain contact@voltaheatpumps.com +34 986 262 184 Gateway VOLTA S-Web Gen2 USER AND INSTALLATION manual Version 03.0X/2024 The manufacturer reserves the right to make any necessary changes to the contents of this manual without prior notice.
