Summary of Contents for dentalfarm MT-Wet
- Page 1 MODEL TRIMMER MT-Wet INSTRUCTION AND MAINTENANCE MANUAL...
-
Page 2: General Precautions
1. DESCRIPTION MT-Wet is a machine used to carry out model-trimming operations in the dental field. It has been expressly designed to work at low-average speed (1.400 rpm) in order to assure a good smoothing effect of the surface whilst reducing the possibility for the abrasive disc to gum. -
Page 3: Installation Instructions
4. INSTALLATION INSTRUCTIONS Installation of this machine is quite easy, but must be carried out paying utmost attention in order to avoid any mistake which may originate WARNING problems during operation, inconveniences or even damages. 1. Place the machine, having considerable weight and size, on a suitable support table beside a sink (preferably on the left side since the drain pipe is fitted rightwards) 2. -
Page 4: Maintenance
6. MAINTENANCE Before carrying out any maintenance operation inside the machine or any technical modification affecting connections, unplug the electric ATTENTION: cable from the socket and close the water inlet faucet; the machine will be completely cut out from the electric wiring and water system. If you still have any doubts, difficulties or if any possibility of mistake still exist, kindly contact our Technical Service to avoid any risks or damages. - Page 5 8. EXPLODED DRAWING AND SPARE-PART LIST MT-Wet (A5103) CODE DESCRIPTION 5103005 MOTOR COMPARTMENT CONDENSER 18 F NES044 2P 2800RPM – 1100W MOTOR NES043N NVT062 5x5x25 FLAP 5103001 SUPPORTING FRAME MT-WET DISCHARGE PIPE 30x36 NEV060 NVT181 GRADUATED KNOB F. M6 5103009 DISC BACKING PAD ABRASIVE DISC with hole 25.4mm –...
-
Page 6: Technical Specifications
Directive 2002/96/EEC. DENTALFARM s.r.l. Via Susa, 9/a - 10138 TORINO - ITALY TECHNICAL-COMMERCIAL SERVICE (+39) 011/4346588 ...
