Summary of Contents for TRACTION Harrier SW218
- Page 1 Harrier SW218 User Guide Revision 1 www.tractionsound.com...
-
Page 2: Manufacturer's Declarations
Manufacturer’s Declarations 1.1 Declaration of Conformity This declaration applies to: • Traction Sound - Harrier SW218 Manufactured by Scicoustic LLC. This includes production versions of these passive loudspeakers. They must correspond with the original technical version and not subject to modification. - Page 3 2.0 User Guide 2.1 Product Description The Harrier SW218 is a dual 18” subwoofer designed specifically for use with the rest of the Harrier product line, enabling the system response to extend to 30Hz, with unparalleled clarity and effortlessness. The state of the art 18” drivers have excellent power handling and sensitivity properties, as well as a low power compression figure at full power meaning headroom is always maintained.
- Page 4 4 Ohms, and when two are wired in parallel the nominal impedance drops to 2 Ohms. This is the lower allowable limit for Traction Engine amplifiers, which have been designed to be able to provide sustained power at this impedance. Below this almost all amplifiers become unstable, and the required current delivery becomes too much for cables, power supplies and connectors to handle.
- Page 5 3.0 Connections 3.1 Connection on Harrier 218. The cabinets have a pair of Neutrik ® NL4 SpeakOn ™ connectors. The wiring for both connectors is in parallel. Pins 1+/- are connected to the two drivers which are wired in parallel. Pins 2+/- are not connected to anything inside the box other than to act as a pass- through.
-
Page 6: Safety Instructions
Secure against accidental movement. Place stands and tripods on a firm surface and test that they are stable. 4.7 Maintenance Maintenance can be dangerous. It must only be done by people authorised by Traction Sound. 4.8 Warranty conditions If any of these safety instructions are not followed then the product warranty will be void. -
Page 7: Product Specification
5.0 Product Specification 5.1 Harrier 218 T y p e Du a l 18 ” R e f le x S u b w o o f e r F re q u e n c y R e s p o n s e ( 1) 3 5 H z –... - Page 8 6.0 Technical Drawings 6.1 Harrier 218 www.tractionsound.com...
-
Page 9: Contact Details
8.0 Contact Details Web – www.tractionsound.com Email - info@tractionsound.com TRACTION UK Studio 6, The Granary, Fairclough Hall Farm, Halls Green, Hitchin, Herts, SG4 7DP United Kingdom Scicoustic LLC 8475 Murphy Drive Middleton WI 53562, USA +1 608 665 2280 www.tractionsound.com...
