For the best performance and safety purposes, please read this manual carefully before use. Please keep this manual for further reference. CHARGE FIRST! Please fully charge your new T-1000 Power Station before first use. Highly recommend to charge T-1000 when battery indicate less than 20%.
USB-A Output Folding Handle 1000W Rated AC Output Air Intake Vent with Cooling Fan Anti-collision Strip Note: No user-serviceable parts inside. Recommended to fully charge the T-1000 before use. T-1000 Accessory List MC4-7909 AC 100-240V wall 12V Car User Manual...
Button Feature A: T-1000 Power ON/OFF Button B: SOS mode & LED light Button POWER PV INPUT DC INPUT 12~26V 12~26V LIGHT C: DC Output Power ON/OFF Button AC PURE SINE WAVE AC OUTPUT QC 3.0 D: USB Output Power ON/OFF Button QC 3.0...
Cooling Fan ● T-1000 utilizes an internal cooling fan to ensure the product is operating within the appropriate temperature range. T-1000,when it experiences a higher output load, will automatically turn on the fan during discharge or recharging, the fan may operate intermittently to keep internal temperature within operating range.
General Specifications General Specs Rated Capacity 999Wh Weight (Net Weight) ≈8.1kg Weight (Including Accessories) ≈9.1kg Product Size 294 x 202 x 202mm Input Recharging Input Voltage 12-26V Recharging Input Power 155W (Max) AC/DC Adapter AC 100-240V, DC24V, 6.25A Solar Charge Input 12V-26V DC 8A MAX Car Charger DC12V, 120W MAX...
How to Charge From Solar Charger 150W about 6-9 hours Depending on solar conditions From Car Charger 12V POWER PV INPUT DC INPUT 12~26V 12~26V about 9-11 hours when car LIGHT AC PURE SINE WAVE running AC OUTPUT QC 3.0 QC 3.0 TOTAL 12V 10A QC 3.0...
Page 7
AC Adapter Charging Please use the AC adapter that we provided to charge this unit, and it will take about 6-7 hours to fully charge the power station. AC Outlet POWER PV INPUT DC INPUT 12~26V 12~26V LIGHT AC PURE SINE WAVE AC OUTPUT AC Adapter QC 3.0...
Page 8
T-1000. PASS-THROUGH CHARGING. The advanced battery management system of the T-1000 allows it to charge a connected device via DC output & USB output while charging the T-1000 and it can also charge AC. OVERLOAD CONDITION.If an overload condition occurs on the OUTPUT port, T-1000 will automatically turn off AC Output power.
Transportation: T-1000 power station meets all legal requirements for transporting dangerous goods. The capacity of the lithium battery pack exceeds 100Wh. Based on international standards, if T-1000 power station is transported by airplane, it must be transported following IATA standard packaging.
Page 10
Product Recharging: ● When you first plug in a power source, a solar panel or a wall charger, the T-1000 may take one minute to detect and adjust its charge circuitry before it starts drawing power from the source. ●...
Note: To avoid the risk of electric shock, do not use metal objects to clean the ports Trouble Shooting T-1000 does not discharge: (1) Checking whether the connecting wire has been inserted in the right place; (2) Checking whether the total output power exceeds the rated output power;...
Page 12
may result in a risk of fire, electric shock, or injury to persons. e) To reduce the risk of damage to the electric plug and cord, pull the plug rather than the cord when disconnecting the power pack. f) Do not use a battery pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury.
See www.epa.gov for additional information. Warranty All GRECELL products come with a full 2-year limited warranty from the date of purchase (accessories excluded). It will be out of guarantee if damaged due to incorrect use or force majeure.
Page 14
日本語 各部の名前 POWER PV INPUT DC INPUT 12~26V 12~26V PO W LIGHT AC PURE SINE WAVE LIG HT PV IN PU T 12 ~ 26 DC IN PU T 12 ~ 26 AC OUTPUT US B QC 3.0 AC PU RE SIN E W AV QC 3.0...
Page 15
各ボタンの名前 A: T-1000 電源ボタンON/OFF B: SOSモード& LEDライ トボタン POWER PV INPUT DC INPUT 12~26V 12~26V LIGHT C: DC出力電源ボタンON/OFF AC PURE SINE WAVE AC OUTPUT QC 3.0 D: USB 出力電源ボタンON/OFF QC 3.0 TOTAL 12V 10A QC 3.0 E : AC出力電源ボタンON/OFF PD 60W ボタンA: T-1000 電源ボタンON/OFF ● 総電源スイ ッチ。 ボタンAを押して、 電源をオンにするか、 使用していないと きに出力が切れます...
Page 17
製品仕様 仕様 999Wh 定格出力 重量 ≈8.1kg 商品のパック重量 (アクセサリーを含む) ≈9.1kg 294 x 202 x 202mm 製品サイズ 入力 入力電圧 12-26V 入力仕様 155W (Max) AC/DCアダプター AC 100-240V, DC24V, 6.25A ソーラー充電入力 12V-26V DC 8A MAX 車載充電器 DC12V, 120W MAX 出力 100-120V/60HZ AC出力電圧 1000W 定格出力電力 Pure Sine Wave 出力波形 : 正弦波 1100±80W 過負荷保護電源 12V 10A シガーソケッ ト出力 総合 10A DC 55*2.5 出力 x 2 12V 5A (単一) ワイヤレス充電器...
Page 18
充電方法 ソーラーパネル充電150W 約6-9h 電時間は日照の強度によって 異なります。 POWER 車載充電12V PV INPUT DC INPUT 12~26V 12~26V LIGHT 車を起動するとき、 約9-11h AC PURE SINE WAVE AC OUTPUT QC 3.0 QC 3.0 TOTAL 12V 10A QC 3.0 PD 60W ACアダプタ110v 約7-8h ソーラーパネル充電 動作電圧がDC12〜26Vを超える場合は、 ソーラーパネルで充電しないでく ださい。 ソーラーパネルをできるだけ直射日光に当ててください。 最大60W/80W/100W/120W/150W/200Wのソーラーパネル...
Page 19
ACアダプター 弊社が提供するACアダプターを使用して製品を充電してくださいポータブル 電源を完全に充電するには、 約7〜8時間かかります。 AC コンセント POWER PV INPUT DC INPUT 12~26V 12~26V LIGHT AC PURE SINE WAVE AC OUTPUT AC アダプター QC 3.0 QC 3.0 TOTAL 12V 10A QC 3.0 PD 60W 12Vの車載向けアクセサリーソケットによる充電 弊社が提供する車載充電器で充電してください、 完全に充電するには、 約9〜11時間かかります シガーソケッ ト カーチャージャー POWER PV INPUT DC INPUT 12~26V 12~26V...
Need help?
Do you have a question about the T-1000 and is the answer not in the manual?
Questions and answers
My T1000 is no longer charging .... I get the following reading when I attempt to try : "A06" . Does that message mean something ?
Why does the unit shut off automatically when a device is plugged into it
que tipos de aterias tiene la Greecell T 1000
que bateria usa mi Greecell T 1000
que tipo de bateria usa Mi estacion Greecell T1000
que tipo de bateria usa la Grecell T 1000
