Electrified Locks, Relays and Timers
CM-PT-Series
Power Transfer Cables
INSTALLATION INSTRUCTIONS
THIS PACKAGE INCLUDES:
1 x Power Transfer Cable
2 x End Caps
1. GENERAL DESCRIPTION
Designed for robust performance, Camden's power transfer cables are ideal for connecting power to door accessories like crash bars,
electric locks, and other security devices. Their flexible yet durable construction makes them suitable for a wide range of commercial,
industrial, and institutional applications where reliable power transmission is critical. Our power transfer cables are crafted with precision
engineering, ensuring they not only meet but exceed industry expectations for performance and durability.
2. SPECIFICATIONS
Model Number
Options
CM-PT14
CM-PT14DUR
CM-PT38
CM-PT38DUR
CM-PTS14
CM-PTSS-7, -12, -18
7", 12", 18"
CM-PTSS38-7, -12, -18 7", 12", 18"
3. INSTALATION
Preparation:
1. Identify Model: Determine the specific model of the Camden
power transfer cable you are installing (CM-PT14/CM-PT14DUR/
CM-PT38/CM-PT38DUR, PTS14, or PTSS-Series).
Initial Setup:
2. Remove Endcap Cover: For models with an endcap cover,
unscrew the #6 x 1/2" self-tapping Phillips pan head screw to
remove it.
3. Position Endcaps: Place the endcaps at the intended
mounting points on the door frame and the door, ensuring they
align with the path of the power transfer cable.
Drilling and Mounting:
4. Drill Cable Passage Hole (if not pre-drilled): Drill an
11/16" (17.5mm) diameter hole through the door frame and the
door to allow the power transfer cable to pass through.
4 x Mounting Screws
4 x Anchor Plugs (CM-PTS14 only)
Length
Inside
Diameter
18"
1/4"
#10 x 7/8" ST - Screws
18"
1/4"
#10 x 7/8" ST - Screws
18"
3/8"
#10 x 7/8" ST - Screws
18"
3/8"
#10 x 7/8" ST - Screws
12"
1/4"
1/4"
3/8"
Screw Size
#6 x 1" ST - Screws
#6 x 3/4" ST - Screws
#6 x 3/4" ST - Screws
5. Align and Mark Mounting Locations: Using the endcaps
or the previously drilled hole as a guide, mark the mounting
locations on both the door frame and the door.
6. Drill Mounting Holes: Drill pilot holes at the marked
locations using a #21 drill bit (5/32", 4.04mm) for the CM-PT
models, and a 3/32" (about 2.4mm) drill bit for the PTS14 and
PTSS-Series models.
Installation:
7. Insert Anchor Plugs (if necessary): For surfaces requiring
additional support, insert anchor plugs into the pilot holes.
8. Attach Endcaps: Secure the endcaps using the appropriate
self-tapping Phillips screws:
•
For CM-PT models, use the provided #10 x 7/8" screws.
•
For PTS14 and PTSS-Series, use the #6 x 1" screws for
PTS14 and #6 x 3/4" screws for PTSS-Series.
1 x Installation Instructions Manual
Material
Stainless Steel, US26 finish
Stainless Steel, duranodic (dark
bronze) finish
Stainless Steel, US26 finish
Stainless Steel, duranodic (dark
bronze) finish
Stainless Steel, US26 finish
Stainless Steel, US26 finish
Stainless Steel, US26 finish
Endcap Type
Aluminum
Aluminum
Aluminum
Aluminum
Grey Zamac
Stainless Steel
Stainless Steel
Page 1 of 2
