- Page 1 ShapeCure/ShapeCure+ User Manual V1.2...
-
Page 2: Table Of Contents
Contents General Information Product Information Unpacking Installation Interface Introduction Operation Guide Maintenance Warranty... -
Page 3: General Information
General Information... - Page 4 Instructions This manual contains the technical information, safety guidelines, and detailed operation instructions for ShapeCure series post-curing machines. Please read this manual carefully before using the device. Failure to comply with the safety and operating instructions required by this manual will result in consequences for the user's responsibility.
-
Page 5: Safety Guidelines
If the power cable is found aging or damaged, replace it before using the device. Risk of UV exposure ShapeCure/ShapeCure+ was designed basing on the principle of UV light curing and there is UV light available inside the device during operation , the risk of UV exposure shall be avoided accordingly. - Page 6 Safety Guidelines Risk of scalding LED tubes will be hot after long time working, make sure to avoid direct touching. Wear protection gloves When operating the devices, please wear disposable gloves to avoid direct contact with the resin material. Wear anti-UV goggles If any operation or maintenance work is needed to proceed while the device is working, anti-UV goggles should be worn accordingly.
-
Page 7: Product Information
Product Information... -
Page 8: Technical Specification
Technical specification ShapeCure ShapeCure+ Main Parameters Diameter 7.87 inches × Height 11.81 Diameter 17.32 inches × Height 15.74 Curing volume inches inches 200 mm × 300 mm 440 mm × 400 mm Wavelength of curing 405 nm 395 nm light... -
Page 9: Unpacking
Unpacking... - Page 10 Unpacking ShapeCure ShapeCure+ ShapeCure ShapeCure+ Name Quantity Name Quantity ShapeCure ShapeCure+ Power cord Power cord Turntable Turntable Spare Led tube Spare Led tube Partition After unpacking, please check the type and quantity of the attached accessories according to the list above. In case of any...
- Page 11 Equipment ShapeCure : Name Name Top cover Turntable Operation panel Handle Enclosure Power interface Inspection window Power switch ShapeCure+ : Name Name Door Heat emission hole Operation panel Power switch Inspection window Power interface...
-
Page 12: Installation
Installation... - Page 13 Installation Platform - ShapeCure: The platform shall be more than 50cm in width, more than 40cm in length and more than 15kg in bearing capacity. - ShapeCure+: The platform shall be more than 80cm in width, 60cm in length, and more than 30kg in bearing capacity.
-
Page 14: Interface Introduction
Interface Introduction... - Page 15 Interface Introduction Main interface Main menu History task Maintenance Resin options： -Basic resins -Functional resins -Dental resins -Customized setting Resin selection Ex. Basic resins Standard resins Fast resins Detailed resins History tasks Start-up of curing start cancle Curing parameters...
- Page 16 Interface introduction Maintenance Reboot (tap to restart) Customized setting Temperature Curing time Start Cancel Curing in progress Chamber temperature Time progress Cancel Completion of curing Click to return to main interface...
-
Page 17: Operation Guide
Operation Guide... - Page 18 Operation Guide Place printed parts Put printed parts on the turntable and close the door/cover, then turn on the switch. ShapeCure ShapeCure+ Curing: Step 1: Select right resin series. Step 2: Select right resin type. Step 3: Click on the "Start" button to start curing.
- Page 19 Operation Guide Curing with customized setting Set temperature and time by clicking on "-" or "+" button, then click on "Start" button to start curing. Please seek for curing setting advice from your resin supplier in advance. Completion of curing When countdown ends, take out printed parts and wait for them to cool.
-
Page 20: Maintenance
Maintenance... - Page 21 Maintenance The placed part in the curing chamber should not obstruct the rotation of the turntable. The uniform curing of the printed part is guaranteed by the rotation of the turntable. Be caution that the turntable will be damaged if it is stuck during working. Do not work continuously for a long time It is recommended to stop the device for about 20 minutes after 1 hour curing.
-
Page 22: Warranty
Warranty... - Page 23 Warranty 1. Warranty period RAYSHAPE ShapeCure series post-curing machines are provided with 12 months of warranty and lifetime maintenance services. 2. Preconditions - The equipment failure is not caused by human reasons or force majeure. - A valid proof of purchase.
- Page 24 Contact Sales Inquiries sales.os@rayshape3d.com +86 400 0983 356 Comments and suggestions: feedback@rayshape3d.com Your feedback is greatly appreciated, and your comments and suggestions will be sent to our sales, R&D, and technical support departments to help us provide better products and services.
-
Page 25: Warranty Card
Warranty Card... - Page 26 W0500005 Suzhou Laisai Intelligence Technology Co., Ltd | + 86 400 0983 356 | www.rayshape3d.com | Room 101, Building 6, No.59 Jiangnan Avenue, Changshu City, Jiangsu Province, China...
