UK Full Manual
General Information
Read the instructions before commencing installation. The user is to retain the instructions for future reference.
•
Espire Alarms have been designed and developed for fixed residential installation and use.
•
After installation the Alarm is to be tested weekly: Press and hold the Test/ Hush button for at least 10 seconds to ensure the Alarm sounds and all
interconnected Alarms activate.
Product Description
•
ES1SL Optical Smoke Alarm Powered by a Sealed 10 Year Lithium Battery
•
ES1HL Heat Alarm Powered by a Sealed 10 Year Lithium Battery
•
ES1MUL Optical Smoke and Heat Multi-Sensor Alarm Powered by a Sealed 10 Year
Lithium Battery
The Alarm head must be fitted onto the supplied Lock-In Base.
The RF-Link (ES1RF2) module is supplied with the Alarm or available separately.
The Alarm battery is sealed and non-replaceable.
Recommended
Alarm Location
Alarm locations are to follow
guidance provided in British
Standard; BS 5839-6:2019.
A Fire Risk Assessment is used to
determine the Grade and Category
of system required;
LD1
S
M
M
Bedro
Bedroom
Bathroom
S
M
Living Room
Multi Story Dwelling Example
Multi Storey Dwelling Example
Diagram Key
S
OPTIMUM
LD1
PROTECTION
Appropriate where occupants
are likely to be vulnerable (e.g
the elderly.) In addition to LD3
recommendations, Alarms are
installed in all circulation areas
and all rooms or areas in which
fire might start. Excludes toilets,
bathrooms or shower rooms.
S
M
Loft
S
M
Shower
Hallway
S
M
S
M
Bedroom
Stairs
S
M
H
Kitchen
ES1SL Optical Smoke Alarm
Alarm Powered by a Sealed 10 Year Lithium
Battery with Optional RF-Link Module
BASIC
LD2
PROTECTION
In addition to the recommendations
for an LD3 system, additional
Alarms are installed in certain
rooms determined by the risk
assessment. For example; a heat
Alarm is installed in each kitchen, or
a smoke Alarm installed in the living
room. Excludes toilets, bathrooms
or shower rooms.
LD2
H
Garage
H
ES1HL Heat Alarm
ES1SL, ES1HL, ES1MUL
Red Alarm LED
LD3
Alarms installed in all hallways,
stairways and circulation areas that
form part of the escape routes.
All Alarms are to be interconnected.
S
M
Loft
S
M
Bedroom
Shower
Hallway
S
M
Bathroom
Bedroom
Stairs
S
M
S
M
Living Room
Kitchen
Multi Story Dwelling Example
Multi Storey Dwelling Example
M
ES1MUL Multi-Sensor Alarm
Amber
Fault LED
Test/Hush
Button
Sounder
MINIMUM
PROTECTION
H
Garage
