AvonSynth AVS-S&R-1 User Manual

The
User Guide
Thank you for purchasing from AvonSynth
Congratulations on your purchase of a brand new AvonSynth
AVS-S&R-1 Stereo Send and Return Eurorack Module. We trust that
it will both serve and inspire you as you create beautiful music
with it for years to come.
In order to get the most out of your module, please ensure that you
read this User Guide in its entirety so that you fully understand all of
its functionality, and that you follow all necessary safety directions during use.
Included in the Box
1 x Send & Return Module
Installation
Step 1: Power your system off. Place the module in your Eurorack-
compatible rack in any convenient position. Affix the module to your
rails using the mounting screws and nylon washers. Neglecting
to use these washers may result in unnecessary marking of the unit.
Step 2: Triple check the polarity of the power connector before
connecting the power cord to your power supply. Ensure that the -12v
line marked on the back of the module connects to the same end of
the flat-cable that also connects to the -12v line on your power supply.
While AvonSynth modules use shrouded connectors that make this
process safer and more reliable, some systems do not conform to this
polarity standard, so careful checking is always necessary. Connecting
the module with incorrect polarity can result in irreversable damage
done to the module which cannot be covered by warranty.
Step 3: Power up your system and start patching!
www.AvonSynth.com
1 x 10 pin to 16 pin
flat-cable power cord
AVS-S&R-1
Stereo Send
and Return Module
4 x M3 Mounting Screws 4 x Nylon Washers
Page 1 of 3
