Operating Manual
Type 1570 planer bridge guard TXF / TXR
Two-part bridge guard for use on surface planing and jointing machines
E-mail:
Type 1570 Two-part bridge guard
TXF 500 | TXF 650 | TXF 850
TXR 650 | TXR 850
HOKUBEMA Maschinenbau GmbH
Graf-Stauffenberg-Kaserne, Binger Str. 28 | Halle 120
DE 72488 Sigmaringen | Phone +49 07571 755-0
info@hokubema-panhans.de
| Web:
https://hokubema-panhans.de
Advertisement
Table of Contents
Summary of Contents for HOKUBEMA SITEC TXF 500
- Page 1 Two-part bridge guard for use on surface planing and jointing machines Type 1570 Two-part bridge guard TXF 500 | TXF 650 | TXF 850 TXR 650 | TXR 850 HOKUBEMA Maschinenbau GmbH Graf-Stauffenberg-Kaserne, Binger Str. 28 | Halle 120 DE 72488 Sigmaringen | Phone +49 07571 755-0 E-mail: info@hokubema-panhans.de...
-
Page 2: Table Of Contents
Table of Contents Product description ............................4 Components and operating elements ......................4 Dimensions ..............................5 Check delivery conditions ..........................6 Safety ................................6 Attachment to the machine ........................... 7 Adjustment of the bridge guard on the machine ................... 9 Safe operation .............................. - Page 3 9.1.2 Changing the knives from the front......................14 9.1.3 After changing the knives ..........................14 Maintenance and care ..........................14 Scrapping and disposal ..........................14 List of Figures Figure 1: Planer bridge guard type 1570 TXF ......................4 Figure 2: Dimensions ............................... 5 Figure 3: Fitting the guide arm ..........................
-
Page 4: Product Description
1 Product description The type 1570 TXF and TXR protective devices are bridge guards for covering the cutter block in front of the planer fence on surface planers & jointers and combined planer/thicknesser machines. The bridge guard can be used universally on planers from a wide range of manufacturers. The prerequisite is that the bridge guard can be securely fastened to the machine stand. -
Page 5: Dimensions
3 Dimensions Figure 2: Dimensions Type Art. no. 500 mm 40 mm 400 mm 260 mm* 3406 650 mm 40 mm 400 mm 260 mm* 3407 850 mm 80 mm 400 mm 260 mm* 3408 650 mm 40 mm 450 mm 300 mm 3415 850 mm... -
Page 6: Check Delivery Conditions
4 Check delivery conditions • The scope of delivery of the bridge guard includes the mounting plate for attaching it to the machine. • The fixing screws are not included in the scope of delivery. Check the package for completeness and possible transport damage. In case of transport damage, please keep the packaging and inform the shipping company and the manufacturer immediately! Also check whether the scope of delivery corresponds to your order. -
Page 7: Attachment To The Machine
6 Attachment to the machine Only the procedure described in this chapter may be used to attach this protective device to the planer. Before the bridge guard can be attached to the machine, the machine manufacturer must expressly authorise the attachment of this protective device to the intended machine. -
Page 8: Figure 4: Remove The Clamping Screw
Attaching the bridge guard After the guide arm has been attached to the machine body, the bridge guard can be mounted. Please also watch our YouTube video on this process: https://youtube.com/shorts/V6p521QtyLg?feature=share. 1. Remove the clamping screw (B) on the guide completely (see ... -
Page 9: Adjustment Of The Bridge Guard On The Machine
7 Adjustment of the bridge guard on the machine After installation, the bridge guard must be adjusted in accordance with the safety requirements: Adjusting the distance to the workpiece In the initial position and over the entire adjustment range, the longitudinal edge of the bridge guard may be a maximum of 2 mm above the upper workpiece surface on the infeed table side and a maximum of 3 mm above the upper workpiece surface on the removal side. -
Page 10: Safe Operation
8 Safe operation Surface planing and jointing of workpieces up to 75 mm thick 8.1.1 Preparation for surface planing up to 75 mm thickness With the left hand, the guard remaining on the outfeed table is set horizontally up to the planer fence and then raised according to the thickness of the workpiece. -
Page 11: Preparation For Jointing Up To 75 Mm Thickness
8.1.3 Preparation for jointing up to 75 mm thickness The workpiece is placed against the planer fence and pushed up to the front edge of the infeed table lip with the right hand. With the left hand, the guard is pushed up to the workpiece. The bridge guard should rest on the removal table. -
Page 12: Surface Planing Of Workpieces With A Small Cross-Section
Surface planing and jointing of small cross-section workpieces 8.3.1 Surface planing of workpieces with a small cross-section As with workpieces up to 75 mm thick, the workpiece is fed forward with hands resting flat on it. 8.3.2 Jointing of workpieces with a small cross-section The workpiece is pressed against the planer fence and the table with both hands, e.g. -
Page 13: Jointing Of Workpieces With A Small Cross-Section
8.4.2 Jointing of workpieces with a small cross-section The workpiece is pressed against the fence with the left hand, e.g. with a closed fist, and pushed forward with a push stick (see Figure 15). Figure 15: Jointing of short workpieces 8.4.3 Bevelling or chamfering on the planer fence Place the workpiece against the inclined fence with your right hand. -
Page 14: Handling During Knife Change
Handling during knife change Disconnect the machine from the power supply during maintenance and repair work and se- cure it against unauthorised restarting! The knife change must generally be carried out in accordance with the operating instructions of your machine. Pay particular attention to the maximum cutting edge protrusion of the knives and the permissible tightening torque for the screws used to secure the planing knives.
