Oliveri Verona VA306500CR Installation Manual

CARE & MAINTENANCE
Clean with a soft cloth and warm soapy water as necessary - rinse and dry after cleaning. Under no circumstances should abrasive or acid
based cleaning products be used. If the mixer tap requires servicing, please contact your plumber (preferably the one who installed it). If the
problem represents a danger, or damage to property may occur, immediately shut off the water supply. Most problems occur due
to contaminated supply lines or water pressure exceeding 500 kPa. Unscrew and clean the spout aerator periodically - especially if you notice a
drop in water pressure. Braided flexible hoses must be inspected every 12 months for warning signs of failure including bulging,rust spots,
wear, moisture, snapped threads, kinking,water staining, general corrosion or discolouration. Mixer tails showing any signs of the above
mentioned warning signs must be replaced immediately.
WARRANTY
We provide the following warranty for products purchased in Australia or New Zealand from authorised Oliveri resellers for use in domestic
residential (indoor) or commercial (indoor) installations (Products). Commercial installations include all non-residential installations including
hotels, motels, gyms, clubs, factories, schools, hospitals, restaurants and aged care facilities. This warranty is in addition to our responsibility to
customers under all other statutory and regulatory requirements. The applicable warranty period set out below (Warranty Period) starts at the
original date of purchase.
COMPONENT
PRODUCT
Cartridge
Body
Kitchen Tapware
Finish (chrome)VA306500CR
Verona
Finish (PVD) VA306502BN
VA306505GM
Finish (other) VA306516MB
VA306503CG VA306507WH
WARRANTY STATEMENT
(a) Our Products come with guarantees that cannot be excluded
under the Australian and New Zealand consumer law. You are
entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
(b) If during the applicable Warranty Period, a Product has a
material defect which arose in the course of manufacture then,
subject to the warranty conditions below being met, you may submit
a warranty claim to us by email or calling our Customer Care Centre:
Australia
Ph: 08 8348 6444 (select Service & Warranty option)
Email: warranty@oliveri.com.au
New Zealand
Ph: 0800 440 606 (select Service & Warranty option)
Email: warranty@oliveri.co.nz
If a warranty service call finds that the product does not have a
genuine manufacturing fault, our Warranty Service Agent reserves
the right to pass on any call-out fee to the householder. If we
require you to return the Product, you must pay the expenses for
such return.
WARRANTY CONDITIONS
We will (at our cost) either repair or replace (at our option) the
Product at an equivalent value of the product purchased if it is
discovered that the Product contains a material defect which arose
during manufacture. We will pay the expense for shipment of the
repaired or replaced Product to you. The warranty set out in the
Warranty Statement above (other than sections 1(a)) is subject to
the following conditions, and accordingly will not apply if:
(a) The Product was not new as at the date of purchase or proof of
purchase details (such as invoice, receipt or transaction record) are
not provided.
Oliveri Solutions Pty Ltd ABN 12 007 551 886 For more information or any questions about this warranty, contact us or visit our website.
Australia
51 Naweena Rd, Regency Park SA 5010
P: 08 8 348 6444
E: sales@oliveri.com.au
oliveri.com.au
DOMESTIC USE COMMERCIAL USE
15 years replacement parts, 7 years replacement parts,
1 year labour 1 year labour
7 years replacement parts, 1 years replacement parts,
1 year labour & labour
7 years replacement parts,
1 year replacement parts
1 year labour
& labour
5 years replacement parts,
1 year replacement parts
1 year labour
& labour
1 year replacement parts
5 years replacement parts,
& labour
1 year labour
(b) There is a failure to follow installation instructions, evidence
cannot be provided that the Product was installed by a licensed
plumber or the Product is used other than in accordance with
product specifications. This includes operating conditions specified
for temperature and pressure.
(c) Repair work is performed on the relevant Product by a person
other than us, our authorised service agents or any plumber who
has not received authorisation from us prior to proceeding with
the work.
(d) Applicable statutes or regulations relating to public health are
not observed and the Product must not have been damaged by
misuse, accident or neglect.
(e) Standards or regulations governing sewerage, plumbing, water
supply and gas applicable to the location of the particular
plumbing installation are not observed. This includes (without
limitation) the Australian Standards (AS/NZ 3500.1 Plumbing and
Drainage Part 1: Water services) which specify that the main water
supply pressure to any new home, extension or renovation must
be limited to 500kPa. The recommended continuous operating
pressure for tapware is between 150-500kPa.
(f) Harsh detergents or abrasive cleaners are used on any finishes
of the Product.
(g) The damage is edge chipping, surface damage caused by wear
and tear, cracking or discolouration due to the Product being
subjected to high heat or damage caused by improper use.
(h) The Product must not contain excessive debris (in-line filters
must be installed).
(i) The Product has discolouration, natural pitting, corrosion or
rusting from 'hard' water and/or other environmental factors.
(j) Adequate access to products, fittings and fixtures to undertake
extended warranty repairs is required. We will not be responsible
for any consequential damage or costs where adequate access to
product fittings and fixtures is not accessible.
(k) Hairline cracking appears around cut-outs during or after
installation of the Product.
(l) The Product has been moved from original installations.
New Zealand
PO Box 4641 Christchurch 8140
P: 0800 440 606
E: sales@oliveri.co.nz
oliveri.co.nz
Verona
Goose Neck Mixer
VA306500CR VA306516MB VA306502BN
VA306505GM VA306503CG VA306507WH
IMPORTANT
This mixer tap must be installed in accordance with these instructions.
Thoroughly inspect product, and if damaged, do not install but return to the place of purchase.
This Oliveri tap is manufactured to standard AS/NZS 3718. This product complies with the Australian
Lead Free requirements of the National Construction Code Volume 3.
Please leave these instructions with the end user.
THIS MIXER TAP MUST BE INSTALLED BY A LICENSED PLUMBER IN
ACCORDANCE WITH LOCAL REGULATIONS
CAUTION
Be sure to use proper tools and always wear personal safety devices for your protection during installation.
PRE-INSTALLATION INSTRUCTIONS
• Before performing any work involving mains water supply lines, ensure the water supply is shut off.
• Stop valves must be used when installing your Oliveri mixer to allow isolation (not supplied with mixer).
Failure to do so will void warranty.
• This mixer tap is pre-assembled and tested. Do not disassemble, as this will void the warranty.
• During installation of aerators containing flow regulators, the aerator must be tightened with an aerator key
to prevent removal by hand.
• Do not remove the cartridge from the tap body as it has been pressure tested and tightened to a specific
torque. Product warranty does not apply where the ceramic cartridge has malfunctioned due to the
presence in the water supply of copper tube pieces, sand, dirt or stones; thread tape; ther objects not
normally present in potable water supplies. Ensure lines are flushed prior to installation.
• If water pressure exceeds 500 kPa, a pressure reducing device must be installed to reduce the water
pressure below 500 kPa. Note that water pressure overnight can reach 150% of the daytime pressure.
• Mixer tails have been pre-assembled. Please ensure prior to installation tails to ensure they are firmly
PRESSURES & TEMPERATURES
• Maximum Hydrostatic Pressure: 500kPa. NOTE: AS/NZS 3500.1 Subclause 3.3.4 (Maximum pressure within
buildings) states "The maximum static pressure at any outlet, other than a fire service outlet, within a
building shall not exceed 500 kPa. NOTE: Pressures above 500 kPa can cause damage from water hammer,
reduced life of appliances, taps and fittings, and cause excessive noise in the system."
• Minimum Hydrostatic Pressure: 150 kPa. NOTE: This product may not be suitable for use with low pressure or
gravity feed water supplies or with some continuous flow / instantaneous hot water systems.
• The maximum operating temperature for the mixer tap is 65°C.
• The recommended maximum delivery temperature is 50°C.
Issue Date 26/08/2024 Revision Number: V1.0
